1. Raspberry Pi
   Ben Nuttall
   Raspberry Pi Foundation
   UK Charity 1129409


   View Slide

2. Raspberry Pi
   ●
   Credit card sized computer
   ●
   €32
   ●
   Made in the UK
   ●
   6 million sold


   View Slide

3. Raspberry Pi Community


   View Slide

4. Raspberry Jam


   View Slide

5. Raspberry Pi Setup


   View Slide

6. What do I need?
   ●
   USB mouse
   ●
   USB keyboard
   ●
   USB power supply
   ●
   Monitor or TV
   ●
   HDMI cable
   ●
   Micro SD card


   View Slide

7. Optional extras
   ●
   Case
   ●
   Ethernet cable
   ●
   USB WiFi dongle
   ●
   Camera module
   ●
   USB Bluetooth dongle
   ●
   Speakers or headphones


   View Slide

8. The SD Card
   ●
   This is your hard drive
   – Operating system
   – Files + programs


   View Slide

9. Getting started
   ●
   Insert SD card
   ●
   Connect mouse & keyboard
   ●
   Connect HDMI cable
   ●
   Connect power supply


   View Slide

10. Scratch
    ●
    Drag & drop block interface
    to programming
    ●
    Logic
    ●
    Computational thinking
    ●
    Easy to make games
    ●
    Impossible to create a
    program that fails to run!
    ●
    Recommended for young
    children


    View Slide

11. Sonic Pi


    View Slide

12. Python
    ●
    Powerful extensible
    programming language
    ●
    Easy to read and write
    ●
    Make software, games, GUIs,
    websites, robots and more
    ●
    Ideal for physical computing
    ●
    Extensive library of additional
    modules for Raspberry Pi
    hardware
    ●
    Recommended for education


    View Slide

13. Minecraft: Pi Edition
    ●
    Free version of Minecraft on
    Raspberry Pi
    ●
    Python programming
    interface
    ●
    Learn Python by building
    things and making games in
    Minecraft
    ●
    Creative computing


    View Slide

14. Mathematica
    ●
    Expensive proprietary
    software – free on Raspberry
    Pi
    ●
    Powerful scientific
    programming


    View Slide

15. Physical computing
    ●
    Flashy lights
    ●
    Motors & robots
    ●
    Photo & video
    ●
    Sensors
    ●
    Internet of Things
    ●
    Engaging and empowering


    View Slide

16. GPIO Pins – General Purpose Input/Output
    rasp.io


    View Slide

17. Python library - RPi.GPIO
    ●
    Included in Raspbian
    ●
    Features:
    – Configure pins as input/output
    – Read inputs (high/low)
    – Set outputs (high/low)
    – Wait for edge (wait for input to go high/low)
    – Pin event detection (callback on input pin change)


    View Slide

18. Flash an LED
    ●
    “Hello world” program of
    physical computing


    View Slide

19. 3V3 = always on


    View Slide

20. GPIO = user controllable


    View Slide

21. Flash LED with Python
    from RPi import GPIO
    from time import sleep
    GPIO.setmode(GPIO.BCM)
    led = 2
    GPIO.setup(led, GPIO.OUT)
    while True:
    GPIO.output(led, True)
    sleep(1)
    GPIO.output(led, False)
    sleep(1)


    View Slide

22. Traffic Lights
    green.on()
    yellow.off()
    red.off()
    sleep(10)


    View Slide

23. Traffic Lights
    green.off()
    yellow.on()
    sleep(1)


    View Slide

24. Traffic Lights
    yellow.off()
    red.on()
    sleep(10)


    View Slide

25. Traffic Lights
    yellow.on()
    sleep(1)


    View Slide

26. Traffic Lights
    green.on()
    yellow.off()
    red.off()


    View Slide

27. Pi in the Sky


    View Slide

28. The sky is the limit...


    View Slide

29. ...or is it?


    View Slide

30. Astro Pi


    View Slide

31. Sense HAT
    ●
    8x8 RGB LED matrix
    ●
    Mini joystick
    ●
    Gyroscope
    ●
    Accelerometer
    ●
    Magnetometer
    ●
    Temperature sensor
    ●
    Barometric pressure sensor
    ●
    Humidity sensor


    View Slide

32. Raspberry Pi
    Ben Nuttall
    Raspberry Pi Foundation
    UK Charity 1129409
