How Do Computers Even Work?

miamirb july 21, 2014

Transcript

1. How do Computers Even Work? Miami Ruby Brigade July 21, 2014
2. Bryce Kerley bkerley@brycekerley.net Twitter: @bonzoesc
4. How Do Computers Even Work? • What is Abstraction? • Boolean Logic & Arithmetic • Control Units and Registers • RAM, caches, the memory hierarchy • Machine language, what bytecode is • Assemblers, compilers, interpreters
5. David Wheeler “All problems in computer science can be solved by another level of indirection, except of course for the problem of too many indirections.”
6. This stuff is cool, but you don’t need to think about it every day. Unless you do.
8. How Do Computers Even Work? • What is Abstraction? • Boolean Logic & Arithmetic • Control Units and Registers • RAM, caches, the memory hierarchy • Machine language, what bytecode is • Assemblers, compilers, interpreters
9. Boolean Logic Algebra • 0 & 1, false & true, off & on • AND, OR, XOR, NOT • NAND, NOR
10. AND 0 1 0 0 0 1 0 1
11. OR 0 1 0 0 1 1 1 1
12. XOR 0 1 0 0 1 1 1 0
13. NAND 0 1 0 1 1 1 1 0
14. Boolean Logic • Send power to the ECU if the ignition is in “ON” OR “START” • Turn on the stairway lights if the bottom switch XOR the top switch are up • Trigger the hydraulic press if the left hand button AND the right hand button are pressed.
15. Half Adder Output 1 if the left input is 1 XOR the right input is 1 Carry 1 if the left input is 1 AND the right input is 1
16. Half Adder Inputs Outputs A B C S 0 0 0 0 1 0 0 1 0 1 0 1 1 1 1 0
17. Full Adder
18. Ripple Carry Adder
19. Carry Lookahead Adder
20. 64-bit Adder
21. Big Parts Are Made Of Small Parts
22. How Do Computers Even Work? • What is Abstraction? • Boolean Logic & Arithmetic • Logic Units and Registers • RAM, caches, the memory hierarchy • Machine language, what bytecode is • Assemblers, compilers, interpreters
23. Arithmetic & Logic Units • Boolean logic units: AND, OR, XOR, etc. • Integer Arithmetic: addition, multiplication, division • Floating-point Arithmetic: addition, multiplication, division
24. Full Adder
25. Full Adder • Inputs: • Operand (1-bit) • Operand (1-bit) • Carry Operand (1-bit) • Outputs: • Result (1-bit) • Carry Result (1- bit)
26. Arithmetic Logic Unit • Inputs: • Operand (n-bit) • Operand (n-bit) • Operator Picker
 • Outputs: • Result (n-bit)
27. Multiplexer Changes channels
28. Building an ALU • Get adders, multipliers, boolean units • Use a multiplexer to pick different operations
29. Building a Calculator • Buttons to enter operands • Buttons to pick an operation • Button to show results • Memory • Decimal-to-binary circuit
30. SR Latch A bit of memory
31. Memory is just a bunch of single-bit storage
32. Arithmetic Logic Unit • Inputs: • Operand (n-bit) • Operand (n-bit) • Operator Picker
 • Outputs: • Result (n-bit)
33. Operand (8-bit) Operand (8-bit) Operator Picker (8-bit) Destination (8-bit) Operation Operand Operand Destination 8 bits 8 bits 8 bits 8 bits Logic multiplexer Input A Input B Output Multiplexer
34. MIPS Instruction Format Copyright 2009 by Elsevier, Inc., All rights reserved. From Patterson and Hennessy, Computer Organization and Design, 4th ed.
35. It would be cool if we could chain up operations and store results somewhere
36. How Do Computers Even Work? • What is Abstraction? • Boolean Logic & Arithmetic • Logic Units and Registers • RAM, caches, the memory hierarchy • Machine language, what bytecode is • Assemblers, compilers, interpreters
37. Registers • Wired in right next to the logic units • Short wires mean fast • Short wires mean you can’t have very many • This computer has sixteen 64-bit registers
38. Random Access Memory • Ask for an address, get a value • Ask to put a value in to an address • Long wires mean slow and cheap • This computer has 8GB, or 1,073,741,824 registers worth
39. Memory Hierarchy • Register: keeping a number in your head while you do math on paper • RAM: keeping a number in a file cabinet in the other room while you do math on paper
40. Cache • Faster than memory, bigger than registers • Multiple levels, L1, L2, … • Lower levels faster but smaller • Cache invalidation
41. Memory Hierarchy • Register: keeping a number in your head • L1 Cache: jotting a number down on paper • L2 Cache: putting that paper in a pile • L3 Cache: putting that pile in a folder • RAM: a file cabinet in the other room
42. Virtual Memory Automatically moving file cabinets from the other room to a storage facility on the Moon (disk is slow, and huge)
43. How Do Computers Even Work? • What is Abstraction? • Boolean Logic & Arithmetic • Logic Units and Registers • RAM, caches, the memory hierarchy • Machine language, what bytecode is • Assemblers, compilers, interpreters
44. MIPS Instruction Format Copyright 2009 by Elsevier, Inc., All rights reserved. From Patterson and Hennessy, Computer Organization and Design, 4th ed.
45. Bytecode Bytes that are Code
46. > otool -t /bin/ls /bin/ls: (__TEXT,__text) section 00000001000010f8 55 48 89 e5 48 83 c7 68 48 83 c6 68 5d e9 50 35 0000000100001108 00 00 55 48 89 e5 48 8d 46 68 48 8d 77 68 48 89 0000000100001118 c7 5d e9 3b 35 00 00 55 48 89 e5 48 8b 4f 60 4c 0000000100001128 8b 41 30 48 8b 56 60 b8 01 00 00 00 4c 39 42 30 0000000100001138 7f 1a 7d 07 b8 ff ff ff ff eb 11 48 8b 49 38 48 0000000100001148 39 4a 38 7f 07 b8 ff ff ff ff 7d 02 5d c3 48 83 0000000100001158 c7 68 48 83 c6 68 5d e9 f6 34 00 00 55 48 89 e5 0000000100001168 48 89 f9 48 8b 51 60 4c 8b 42 30 48 8b 7e 60 b8 0000000100001178 ff ff ff ff 4c 39 47 30 7f 1a 7d 07 b8 01 00 00 0000000100001188 00 eb 11 48 8b 52 38 48 39 57 38 7f 07 b8 01 00 0000000100001198 00 00 7d 02 5d c3 48 83 c6 68 48 83 c1 68 48 89 00000001000011a8 f7 48 89 ce 5d e9 a8 34 00 00 55 48 89 e5 48 8b 00000001000011b8 4f 60 4c 8b 41 20 48 8b 56 60 b8 01 00 00 00 4c 00000001000011c8 39 42 20 7f 1a 7d 07 b8 ff ff ff ff eb 11 48 8b
47. "Altair 8800 at the Computer History Museum, cropped" by Todd Dailey - File:Altair 8800 at the Computer History Museum.jpg (cropped; curves; contrast). Licensed under Creative Commons Attribution-Share Alike 2.0 via Wikimedia Commons - http:/ /commons.wikimedia.org/wiki/ File:Altair_8800_at_the_Computer_History_Museum,_cropped.jpg#media viewer/File:Altair_8800_at_the_Computer_History_Museum,_cropped.jpg
50. > otool -tV /bin/ls /bin/ls: (__TEXT,__text) section 00000001000010f8 pushq %rbp 00000001000010f9 movq %rsp, %rbp 00000001000010fc addq $0x68, %rdi 0000000100001100 addq $0x68, %rsi 0000000100001104 popq %rbp 0000000100001105 jmpq 0x10000465a 000000010000110a pushq %rbp 000000010000110b movq %rsp, %rbp 000000010000110e leaq 0x68(%rsi), %rax 0000000100001112 leaq 0x68(%rdi), %rsi 0000000100001116 movq %rax, %rdi 0000000100001119 popq %rbp 000000010000111a jmpq 0x10000465a 000000010000111f pushq %rbp 0000000100001120 movq %rsp, %rbp
51. How Do Computers Even Work? • What is Abstraction? • Boolean Logic & Arithmetic • Logic Units and Registers • RAM, caches, the memory hierarchy • Machine language, what bytecode is • Assemblers, compilers, interpreters
52. > otool -t /bin/ls /bin/ls: (__TEXT,__text) section 00000001000010f8 55 48 89 e5 48 83 c7 68 48 83 c6 68 5d e9 50 35 0000000100001108 00 00 55 48 89 e5 48 8d 46 68 48 8d 77 68 48 89 0000000100001118 c7 5d e9 3b 35 00 00 55 48 89 e5 48 8b 4f 60 4c 0000000100001128 8b 41 30 48 8b 56 60 b8 01 00 00 00 4c 39 42 30 0000000100001138 7f 1a 7d 07 b8 ff ff ff ff eb 11 48 8b 49 38 48 0000000100001148 39 4a 38 7f 07 b8 ff ff ff ff 7d 02 5d c3 48 83 0000000100001158 c7 68 48 83 c6 68 5d e9 f6 34 00 00 55 48 89 e5 0000000100001168 48 89 f9 48 8b 51 60 4c 8b 42 30 48 8b 7e 60 b8 0000000100001178 ff ff ff ff 4c 39 47 30 7f 1a 7d 07 b8 01 00 00 0000000100001188 00 eb 11 48 8b 52 38 48 39 57 38 7f 07 b8 01 00 0000000100001198 00 00 7d 02 5d c3 48 83 c6 68 48 83 c1 68 48 89 00000001000011a8 f7 48 89 ce 5d e9 a8 34 00 00 55 48 89 e5 48 8b 00000001000011b8 4f 60 4c 8b 41 20 48 8b 56 60 b8 01 00 00 00 4c 00000001000011c8 39 42 20 7f 1a 7d 07 b8 ff ff ff ff eb 11 48 8b
53. > otool -tV /bin/ls /bin/ls: (__TEXT,__text) section 00000001000010f8 pushq %rbp 00000001000010f9 movq %rsp, %rbp 00000001000010fc addq $0x68, %rdi 0000000100001100 addq $0x68, %rsi 0000000100001104 popq %rbp 0000000100001105 jmpq 0x10000465a 000000010000110a pushq %rbp 000000010000110b movq %rsp, %rbp 000000010000110e leaq 0x68(%rsi), %rax 0000000100001112 leaq 0x68(%rdi), %rsi 0000000100001116 movq %rax, %rdi 0000000100001119 popq %rbp 000000010000111a jmpq 0x10000465a 000000010000111f pushq %rbp 0000000100001120 movq %rsp, %rbp
54. • Tapping instructions into memory from switches • Writing bytecode to tape or disk, and loading it • Writing machine code, and assembling it • Programming in higher-level languages
55. (0) INPUT INVENTORY FILE-A PRICE FILE-B ; OUTPUT PRICED-INV FILE-C UNPRICED-INV FILE-D ; HSP D . (1) COMPARE PRODUCT-NO (A) WITH PRODUCT-NO (B) ; IF GREATER GO TO OPERATION 10 ; IF EQUAL GO TO OPERATION 5 ; OTHERWISE GO TO OPERATION 2 . (2) TRANSFER A TO D . (3) WRITE-ITEM D . (4) JUMP TO OPERATION 8 . (5) TRANSFER A TO C . (6) MOVE UNIT-PRICE (B) TO UNIT-PRICE (C) . (7) WRITE-ITEM C . (8) READ-ITEM A ; IF END OF DATA GO TO OPERATION 14 . (9) JUMP TO OPERATION 1 . (10) READ ITEM B ; IF END OF DATA GO TO OPERATION 12 . (11) JUMP TO OPERATION 1 . (12) SET OPERATION 9 TO GO TO OPERATION 2 . (13) JUMP TO OPERATION 2 . (14) TEST PRODUCT-NO (B) AGAINST ZZZZZZZZZZZZ ; IF EQUAL GO TO OPERATION 16 ; OTHERWISE GO TO OPERATION 15 . (15) REWIND B . (16) CLOSE-OUT FILES C ; D . (17) STOP . (END)
56. static void __init setup_command_line(char *command_line) { saved_command_line = memblock_virt_alloc(strlen(boot_command_line) + 1, 0); initcall_command_line = memblock_virt_alloc(strlen(boot_command_line) + 1, 0); static_command_line = memblock_virt_alloc(strlen(command_line) + 1, 0); strcpy (saved_command_line, boot_command_line); strcpy (static_command_line, command_line); }
57. (defun ruby-electric--block-beg-keyword-at-point-p () "Test if there is a block beginning keyword at point." (and (looking-at ruby-block-beg-symbol-re) (if (string= (match-string 1) "do") (looking-back "\\s-") (not (looking-back “\\."))) ))
58. Language A Language B Compiler
59. • Compilers: translate code between languages • Assemblers: translate assembly language into bytecode • Interpreters: run code piece by piece
60. Why Compile • Source might be valuable • Parsing can be expensive • Optimizing is hard for humans
61. Why Interpret • Source might not be valuable • Speed might not be a big deal • Optimizing might be data-dependent
62. How Do Computers Even Work? • What is Abstraction? • Boolean Logic & Arithmetic • Logic Units and Registers • RAM, caches, the memory hierarchy • Machine language, what bytecode is • Assemblers, compilers, interpreters
63. Computers are cool
64. Hide Complexity
65. Some More Reading • Take a computer architecture class • “Inside the Machine” by Jon Stokes • “Computer Organization and Design” by Patterson & Hennessy • Wikipedia • http:/ /j.mp/howdocomputers
66. Thanks
