Multi-table Full Text Search in Postgres

Transcript

1. Multi-table Full Text Search Postgres with
2. @calebthompson calebthompson.io
5. I'm going to talk to you about
6. A real-life feature.
7. Full Text Search
8. Multi-table Full Text Search Postgres with
9. Views
10. Performance
11. Materialized Views
12. Gems
13. Other Options
14. Let's search for Articles
15. Article.where("body LIKE %?%", query)
16. Exact substrings
17. but that's not very useful
18. Article.where("body ILIKE %?%", query)
19. Search on title
20. Article.where( "body ILIKE %?% OR title ILIKE %?%", query, query)
21. Search by Author's name
22. Scopes def self.search(query) joins(:user) .where(<<-SQL, query, query, query) articles.body ILIKE %?% OR articles.title ILIKE %?% OR users.name ILIKE %?% SQL end
23. Query object class Search def self.for(query) [ Article.where("title ILIKE %?%", query), Article.where("body ILIKE %?%", query), Article.joins(:user) .where("users.name ILIKE %?%", query), ].flatten.uniq end end
24. Poor results
25. Full Text Search Enter
26. natural language searching
27. remove stop words and, the, also, they, would
28. eliminate casing “Factory” and “factory” should return the same results
29. synonyms hunger and hungrily
30. stemming “try” and “trying”, “tries”, and “tried” will be recorded in the index under the single concept word "tri."
31. SELECT DISTINCT(id) FROM ( SELECT id AS id, title || ' ' || body AS the_text FROM articles UNION SELECT articles.id AS id, authors.name AS the_text FROM authors JOIN articles ON authors.id = articles.author_id ) AS this_doesnt_matter WHERE to_tsvector(the_text) @@ to_tsquery('?');
32. SELECT DISTINCT(id) FROM ( SELECT id AS id, title || ' ' || body AS the_text FROM articles UNION SELECT articles.id AS id, authors.name AS the_text FROM authors JOIN articles ON authors.id = articles.author_id
33. id AS id, title || ' ' || body AS the_text FROM articles UNION SELECT articles.id AS id, authors.name AS the_text FROM authors JOIN articles ON authors.id = articles.author_id
34. SELECT DISTINCT(id) FROM ( SELECT id AS id, title || ' ' || body A FROM articles UNION SELECT articles.id AS id, authors.name AS the_te
35. title || ' ' || body A FROM articles UNION SELECT articles.id AS id, authors.name AS the_te FROM authors JOIN articles ON authors.id = articles ) AS this_doesnt_matter WHERE
36. SELECT DISTINCT(id) FROM ( SELECT id AS id, title || ' ' || body AS t FROM articles UNION SELECT
37. That's a lot of SQL.
38. We could throw that into our query object class Search def self.for(query) <<-SQL SQL end end
39. Scopes def self.search(query) where(<<-SQL, query) SQL end
40. Postgres has our answer
41. Views
42. Partial queries
43. Stored in the Database
44. Can be SELECTed from
45. Return set of columns
46. Multi- source
47. Complete the query
48. CREATE VIEW users_with_recent_activity AS SELECT DISTINCT ON (users.id) users.*, activities.created_at AS active_at FROM users JOIN activities ON activities.user_id = users.id WHERE activities.created_at >= CURRENT_DATE - interval '7 days';
49. CREATE VIEW users_with_recent_activity AS SELECT DISTINCT ON (users.id) users.*, activities.created_at AS active_at FROM users JOIN activities ON activities.user_id = users.id WHERE activities.created_at >= CURRENT_DATE - interval '7 days';
50. CREATE VIEW users_with_recent_activity SELECT DISTINCT ON (users.id) users.*, activities.created_at AS active FROM users JOIN activities ON activities.user_id = users.id WHERE activities.created_at >= CURRENT_DATE - interval '7 days
51. CREATE VIEW users_with_recent AS SELECT DISTINCT ON (users.id) users.*, activities.created_at active_at FROM users JOIN activities ON activities.user_id = u
52. VIEW users_with_recent_activity AS DISTINCT ON (users.id) users.*, activities.created_at AS active_at users activities activities.user_id = users.id activities.created_at >= CURRENT_DATE - interval '7 days';
53. CREATE VIEW users_with_recent_activity AS SELECT DISTINCT ON (users.id) users.*, activities.created_at AS active_at FROM users JOIN activities ON activities.user_id = users.id WHERE activities.created_at >= CURRENT_DATE - interval '7 days';
54. Querying a view looks just like querying a table SELECT * FROM users_with_recent_activity WHERE id IN (1,2,3…) ORDER BY active_at DESC
55. ActiveRecord can use a view as its backend
56. So we can create a fairly vanilla model
57. class UserWithRecentActivity \ < ActiveRecord::Base def self.table_name "users_with_recent_activity" end def readonly? true end end
58. ass UserWithRecentActivity \ < ActiveRecord::Base ef self.table_name "users_with_recent_activity" nd
59. class UserWithRecentActivity \ < ActiveRecord::Base def self.table_name "users_with_recent_activity" end def readonly? true end end
60. def self.table_name "users_with_recent_acti end def readonly? true end end
61. Will it work with full text search?
62. ⚲Textacular
64. Takes care of the Full Text Search portions of queries
65. Search over every text field on a record
66. Variant search options like basic_search, fuzzy search, and advanced search
67. Game.basic_search('Sonic')
68. Game.basic_search( title: 'Mario', system: 'Nintendo' )
69. So let's go back and look at the search we wrote
70. SELECT id AS article_id, title || ' ' || body AS the_text FROM articles UNION SELECT articles.id AS article_id, authors.name AS the_text FROM authors JOIN articles ON authors.id = articles.author_id;
71. Now our search result is really simple in the Rails side
72. class Search < ActiveRecord::Base include Textacular belongs_to :article end
73. class Search < ActiveRecord::Base include Textacular belongs_to :article end
74. Search.basic_search("Sandi").map(&:article)
75. Search.basic_search("Sandi").map(&:article)
76. class SearchResult include Enumerable def initialize(query) @results = Search.basic_search(query) end def each @results.each end end
77. CREATE Migration
78. class CreateUsersWithRecentActivity < ActiveRecord::Migration def up ActiveRecord::Base.connection.execute( "--The CREATE VIEW sql from before" ) end def down ActiveRecord::Base.connection.execute( 'DROP VIEW users_with_recent_activity' ) end end
79. How resistant to change is it?
80. Let's find out - time for some feature creep!
81. Articles whose comments match the query
82. Searching on • Article (title, body) • Author (name) • Comments (body)
83. SELECT id AS article_id, title || ' ' || body AS the_text FROM articles UNION SELECT articles.id AS article_id, authors.name AS the_text FROM authors JOIN articles ON authors.id = articles.author_id UNION SELECT article_id, body AS the_text FROM comments
84. authors.name AS the_tex FROM authors JOIN articles ON authors.id = article UNION SELECT article_id, body AS the_text FROM comments
85. UPDATE Migration
86. class CreateUsersWithRecentActivity < ActiveRecord::Migration def up ActiveRecord::Base.connection.execute( "CREATE OR REPLACE VIEW searches AS --The sql from the new view" ) end def down ActiveRecord::Base.connection.execute( "CREATE OR REPLACE VIEW searches AS --The sql from the old view" ) end end
87. UPDATE Migration
88. class CreateUsersWithRecentActivity < ActiveRecord::Migration def up ActiveRecord::Base.connection.execute( "DROP VIEW searches; CREATE VIEW searches AS --The sql from the new view" ) end def down ActiveRecord::Base.connection.execute( "DROP VIEW searches; CREATE VIEW searches AS --The sql from the old view" ) end end
89. Can't be dumped to db/schema.rb
90. config.database_format = :structure db/structure.sql
91. Scenic
93. [show how scenic gets migrations from view.sql definitions]
94. [show that it has versions]
95. Model generator $ rails generate scenic:model search create app/models/search.rb create db/views/searches_v01.sql create db/migrate/..._create_searches.rb
96. $ cat app/views/searches_v01.sql SELECT id AS article_id, title || ' ' || body AS the_text FROM articles UNION SELECT articles.id AS article_id, authors.name AS the_text FROM authors JOIN articles ON authors.id = articles.author_id
97. View generator $ rails generate scenic:view search create db/views/searches_v02.sql create db/migrate/..._update_searches_to_version_2.rb
98. $ cat app/views/searches_v02.sql SELECT id AS article_id, title || ' ' || body AS the_text FROM articles UNION SELECT articles.id AS article_id, authors.name AS the_text FROM authors JOIN articles ON authors.id = articles.author_id
99. $ cat app/views/searches_v02.sql SELECT id AS article_id, title || ' ' || body AS the_text FROM articles UNION SELECT articles.id AS article_id, authors.name AS the_text FROM authors JOIN articles ON authors.id = articles.author_id UNION SELECT article_id, body AS the_text FROM comments
100. Performance
101. This query is pretty slow
102. it has to search across three tables to get us all of the results we need
103. Full Text Search ~400 ms ILIKE ~40 ms Full Text Search vs ILIKE
104. Views can't be indexed
105. Underlying tables can
106. Add indices
107. There are several types of indices
108. btree
109. GIN & GIST
110. GIN index lookups are about three times faster than GiST
111. GIN indexes take about three times longer to build than GiST
112. GIN indexes are moderately slower to update than GiST indexes
113. GIN indexes are two-to-three times larger than GiST indexes
114. Use GIN • You don't have hundreds of thousands of rows • You're not concerned about longer writes blocking the db • You're adding the index late in the game • You don't care about disk space • You want fast lookups (read-heavy)
115. Use GiST • Very large tables • You have performance concerns • For some reason disk space is important • Your table is write-heavy
116. add_index :articles, :body, using: :gin add_index :articles, :title, using: :gin add_index :authors, :name, using: :gin add_index :comments, :body, using: :gin
117. Materialized Views
118. Pre-populate the results of the view
119. Query against result set
120. Full Text Search ~400 ms ILIKE ~40 ms Materialized ~ 5.394 ms
121. REFRESH MATERIALIZED VIEW searches
122. after_commit :refresh def refresh class.connection.execute( "REFRESH MATERIALIZED VIEW #{table_name}" ) end
123. What about pre-built solutions?
124. ElasticSearch via Tire or elasticsearch-rails or Chewy require 'elasticsearch/model' class Article < ActiveRecord::Base include Elasticsearch::Model include Elasticsearch::Model::Callbacks end
125. Solr via Sunspot class Post < ActiveRecord::Base searchable do text :title, :body text :comments do comments.map { |comment| comment.body } end boolean :featured integer :blog_id integer :author_id integer :category_ids, :multiple => true double :average_rating time :published_at time :expired_at string :sort_title do title.downcase.gsub(/^(an?|the)/, '') end end end
126. text :title, :body text :comments do comments.map {|comment| comment.body} end
127. boolean :featured integer :blog_id integer :author_id integer :category_ids, :multiple => true double :average_rating time :published_at time :expired_at
128. string :sort_title do title.downcase.gsub(/^(an?|the)/, '') end
129. sphinx with ThinkingSphinx ThinkingSphinx::Index.define :article, :with => :active_record do indexes subject, :sortable => true indexes content indexes author.name, :as => :author, :sortable => true has author_id, created_at, updated_at end
130. These services excel at faceted search
131. These services excel at faceted search More difficult with full text search
132. Run on your development machine.
133. Run on your production machine.
134. Needs to be faked in tests
135. Some of these have lots of cruft in models.
136. Remove a data concern from your database
137. Arcane syntax
138. :(
139. By combining
140. materialized views
141. full text search
142. Rails magic ✨
143. we have a pretty cool search feature
144. that doesn't require any new dependencies
145. :)
146. Thank you
147. Bibliography • http://shisaa.jp/postset/postgresql-full-text-search-part-1.html • http://blog.lostpropertyhq.com/postgres-full-text-search-is-good- enough/ • http://www.postgresql.org/docs/9.3/static/textsearch.html • http://linuxgazette.net/164/sephton.html • http://www.postgresql.org/docs/current/static/sql-createview.html • http://www.postgresql.org/docs/current/static/indexes-examine.html • http://www.postgresql.org/docs/current/static/textsearch-indexes.html • http://en.wikipedia.org/wiki/Gin_and_tonic
150. http://calebthompson.io/talks/search.html
151. Come say hi That’s why I do this
