1. Few steps to make your app smarter with TensorFlow Lite Volodia Chornenkyi Android Software Engineer @TechMagic @GoodCo
2. What is TFLite? Framework for running machine learning models on mobile and embedded devices.
3. What is TFLite? Framework for running machine learning models on mobile and embedded devices.
4. Lite Two brothers
5. • Lightweight • Limited set of op • Custom op support • Optimized work with models • Hardware acceleration • No Swift support Lite • Training support • Java&Swift APIs are not up to date • Android NDK • Bazel • Higher accuracy
6. TensorFlow Mobile?
7. TensorFlow Mobile? https://www.tensorflow.org/lite/tfmobile/
8. MLKit vs Tensor Flow https://developers.google.com/ml-kit/
9. How it works inside Architecture of a CNN. — Source: https://www.mathworks.com/videos/introduction-to-deep-learning-wh at-are-convolutional-neural-networks--1489512765771.html
10. https://society6.com/product/get-shit-done--get-shit-done_print
11. Step 1. Model cp tf_files/optimized_graph.lite ios/tflite/data/graph.lite cp tf_files/retrained_labels.txt ios/tflite/data/labels.txt cp tf_files/optimized_graph.lite android/tflite/app/src/main/ass ets/graph.lite cp tf_files/retrained_labels.txt android/tflite/app/src/main/ass ets/labels.txt iOS Android https://www.tensorflow.org/lite/
12. Step 2.1. Setup platform :ios, '8.0' inhibit_all_warnings! target 'tflite_photos_example' pod 'TensorFlowLite' repositories { maven { url 'https://google.bintray.com/tensorflo w' } } dependencies { implementation 'org.tensorflow:tensorflow-lite:+' } iOS Android https://www.tensorflow.org/lite/
13. Step 2.2. Setup android { aaptOptions { noCompress "tflite" noCompress "lite" } } Android https://www.tensorflow.org/lite/
14. NSString* graph_path = [[NSBundle mainBundle] pathForResource:name ofType:extension]; std::unique_ptr<tflite::FlatBufferModel> model = tflite::FlatBufferModel::BuildFromFile([graph_path UTF8String]); iOS Android Step 3. Model AssetFileDescriptor fileDescriptor = activity.getAssets().openFd(MODEL_PATH); FileInputStream inputStream = new FileInputStream(fileDescriptor.getFileDescriptor()); FileChannel fileChannel = inputStream.getChannel(); long startOffset = fileDescriptor.getStartOffset(); long declaredLength = fileDescriptor.getDeclaredLength(); MappedByteBuffer model = fileChannel.map(FileChannel.MapMode.READ_ONLY, startOffset, declaredLength); Android https://www.tensorflow.org/lite/
15. std::vector<std::string> labels; NSString* labels_path = [[NSBundle mainBundle] pathForResource:name ofType:extension]; std::ifstream t; t.open([labels_path UTF8String]); std::string line; while (t) { std::getline(t, line); if (line.length()){ labels->push_back(line); } } t.close(); Android Step 4. Labels on iOS https://www.tensorflow.org/lite/
16. Android Step 4. Labels on Android List<String> labelList = new ArrayList<String>(); BufferedReader reader = new BufferedReader(new InputStreamReader(activity.getAssets().open(LABEL_PATH))); String line; while ((line = reader.readLine()) != null) { labelList.add(line); } reader.close(); https://www.tensorflow.org/lite/
17. Step 5. Interpreter std::unique_ptr<tflite::Interpreter> interpreter; tflite::InterpreterBuilder(*model, opResolver)(&interpreter); Interpreter tflite = new Interpreter(model); iOS Android https://www.tensorflow.org/lite/
18. float* out = interpreter->typed_input_tensor<float>(0); uint8_t* in = image.data.data(); for (int y = 0; y < wanted_input_height; ++y) { const int in_y = (y * image.height) / wanted_input_height; uint8_t* in_row = in + (in_y * image.width * image.channels); float* out_row = out + (y * wanted_input_width * wanted_input_channels); for (int x = 0; x < wanted_input_width; ++x) { const int in_x = (x * image.width) / wanted_input_width; uint8_t* in_pixel = in_row + (in_x * image.channels); float* out_pixel = out_row + (x * wanted_input_channels); for (int c = 0; c < wanted_input_channels; ++c) { out_pixel[c] = (in_pixel[c] - input_mean) / input_std; } } } Android Step 6. Convert image on iOS https://www.tensorflow.org/lite/
19. // ByteBuffer imgData bitmap.getPixels(intValues, 0, bitmap.getWidth(), 0, 0, bitmap.getWidth(), bitmap.getHeight()); int pixel = 0; for (int i = 0; i < DIM_IMG_SIZE_X; ++i) { for (int j = 0; j < DIM_IMG_SIZE_Y; ++j) { final int val = intValues[pixel++]; imgData.putFloat((((val >> 16) & 0xFF)-IMAGE_MEAN)/IMAGE_STD); imgData.putFloat((((val >> 8) & 0xFF)-IMAGE_MEAN)/IMAGE_STD); imgData.putFloat((((val) & 0xFF)-IMAGE_MEAN)/IMAGE_STD); } } Android Step 6. Convert image on Android https://www.tensorflow.org/lite/
20. Step 7. Run model interpreter->Invoke() float* output = interpreter-> typed_output_tensor<float>(0) tflite.run(imgData, labelProbArray) iOS Android https://www.tensorflow.org/lite/
21. Output. Threshold. Results number Step 8. Grand finale
22. Special slide for QA • unittest.TestCase • Model visualization • Believe
23. Use TF Lite if • Weight is important • Limited set of op is fine • Speed over accuracy • Hardware acceleration as a bonus
26. Links General: https://www.tensorflow.org/lite/ https://codelabs.developers.google.com/codelabs/tensorflow-for-poets Android: https://codelabs.developers.google.com/codelabs/tensorflow-for-poets-2-tflite iOS: https://codelabs.developers.google.com/codelabs/tensorflow-for-poets-2-ios QA: https://www.linkedin.com/pulse/tensorflow-dont-forget-unit-test-david-o-neill-1/ https://www.tensorflow.org/api_guides/python/test
