PhoneGap Deep Dive

PhoneGap is an open-source framework (Apache Cordova) that allows you to create cross-platform mobile apps using the web technologies you know and love: HTML, CSS, and JavaScript. Learn how PhoneGap works and how it will enable you to start building mobile apps with web standards. This talk will take a closer look at some of the available APIs and how further extend PhoneGap through the use of it's plugin system.

Transcript

1. @ChrisGriffith


   View Slide

2. These  opinions  and  thoughts  are  my  own,  and
   may  or  may  not  reflect  the  opinions  of  the
   company  that  I  work  for.
   Disclaimer


   View Slide

3. View Slide

4. ApplicaAon  container  that  allows  you  to  build
   naAvely  installed  apps  using  HTML,  CSS  &  JavaScript

   What  is  PhoneGap?


   View Slide

5. Ge/ng  Started
   cordova.apache.org


   View Slide

6. •  Accelerometer  -­‐  when  the  device  moves
   •  Camera  -­‐  pictures  of  your  cat
   •  Capture  -­‐  audio,  video,  sAlls  of  your  cat
   •  Compass  -­‐  for  when  you're  lost
   •  Connec•  Contacts  -­‐  find  and  create  new  friends
   Features


   View Slide

7. •  Device  -­‐  device  and  OS  version  metadata
   •  Events  -­‐  various  app/hardware  related
   events
   •  File  -­‐  naAve  file  system  access  (+  upload)
   •  Geoloca•  GlobalizaformaRng

   Features


   View Slide

8. •  Media  -­‐  related  to  audio  playback
   (supports  record  as  well)
   •  No<ficanoAficaAons
   •  Splashscreen  -­‐  for  your  splash  screen
   needs
   •  Storage  -­‐  Mini  database
   Features


   View Slide

9.
   Secret  Sauce


   View Slide

10.


    PhoneGap Example


    <br/> <br/>// Wait for PhoneGap to load <br/> document.addEventListener("deviceready",<br/>onDeviceReady, false); <br/> <br/> <br/>

    View Slide

11. Device
    The  device  object  describes  the  device's
    hardware  and  soTware.


    View Slide

12. // PhoneGap is ready
    function onDeviceReady() {
    var element =
    document.getElementById('deviceProperties');

    element.innerHTML = 'Device Name: ' +
    device.name + '
    ' +
    'Device Cordova: ' + device.cordova + '
    ' +
    'Device Platform: ' + device.platform + '
    ' +
    'Device UUID: ' + device.uuid + '
    ' +
    'Device Model: ' + device.model + '
    ' +
    'Device Version: ' + device.version + '
    ';
    }




    Loading device
    properties...



    View Slide

13. ConnecThe  connecAon  object  gives  access  to  the  device's  cellular
    and  wifi  connecAon  informaAon.

    ConnecAon.UNKNOWN
    ConnecAon.ETHERNET
    ConnecAon.WIFI
    ConnecAon.CELL_2G
    ConnecAon.CELL_3G
    ConnecAon.CELL_4G
    ConnecAon.CELL
    ConnecAon.NONE


    View Slide

14. function checkConnection() {
    var networkState = navigator.connection.type;

    var states = {};
    states[Connection.UNKNOWN] = 'Unknown connection';
    states[Connection.ETHERNET] = 'Ethernet connection';
    states[Connection.WIFI] = 'WiFi connection';
    states[Connection.CELL_2G] = 'Cell 2G connection';
    states[Connection.CELL_3G] = 'Cell 3G connection';
    states[Connection.CELL_4G] = 'Cell 4G connection';
    states[Connection.CELL] = 'Cell generic connection';
    states[Connection.NONE] = 'No network connection';

    alert('Connection type: ' + states[networkState]);
    }




    View Slide

15. GeoLocaAon


    View Slide

16. GeolocaAon
    The  geolocaAon  object  provides  access  to  the
    device's  GPS  sensor.

    GeolocaAon  provides  locaAon  informaAon  for  the
    device,  such  as  laAtude  and  longitude.  Common
    sources  of  locaAon  informaAon  include  Global
    PosiAoning  System  (GPS)  and  locaAon  inferred  from
    network  signals  such  as  IP  address,  RFID,  WiFi  and
    Bluetooth  MAC  addresses,  and  GSM/CDMA  cell  IDs.
    No  guarantee  is  given  that  the  API  returns  the
    device's  actual  locaAon.


    View Slide

17. Accuracy   PosiGPS   10m   2-­‐10  minutes  (only
    indoors)
    5-­‐6  hours  on  most
    phones
    WIFI   50m  (improves  with
    density)
    Almost  instant
    (server  connect  and
    lookup)
    No  addiAonal  effect
    Cell  Tower
    triangulaAon
    100-­‐1400m  (based  on
    density)
    Almost  instant
    (server  connect  and
    lookup)
    Negligible
    Single  Cell  Tower   500-­‐2500m  (based  on
    density)
    Almost  instant
    (server  connect  and
    lookup)
    Negligible
    IP   Country:  99%
    City:  46%  US,  53%
    InternaAonal
    Zip:  0%
    Almost  instant
    (server  connect  and
    lookup)
    Negligible


    View Slide

18. View Slide

19. geolocaAon.getCurrentPosiAon
    Returns  the  device's  current  posiAon  as  a
    PosiAon  object.

    navigator.geolocation.getCurrentPosition(geo
    locationSuccess, [geolocationError],
    [geolocationOptions]);


    View Slide

20. // onSuccess Callback
    // This method accepts a `Position` object, which contains
    // the current GPS coordinates

    var onSuccess = function(position) {
    alert('Latitude: ' + position.coords.latitude + '\n' +
    'Longitude: ' + position.coords.longitude + '\n' +
    'Altitude: ' + position.coords.altitude + '\n' +
    'Accuracy: ' + position.coords.accuracy + '\n' +
    'Altitude Accuracy: ' + position.coords.altitudeAccuracy + '\n' +
    'Heading: ' + position.coords.heading + '\n' +
    'Speed: ' + position.coords.speed + '\n' +
    'Timestamp: ' + position.timestamp + '\n');
    };

    // onError Callback receives a PositionError object

    function onError(error) {
    alert('code: ' + error.code + '\n' +
    'message: ' + error.message + '\n');
    }

    navigator.geolocation.getCurrentPosition(onSuccess, onError);


    View Slide

21. Compass
    Obtains  the  direcAon  that  the  device  is  poinAng.


    View Slide

22. function onDeviceReady() {
    navigator.compass.getCurrentHeading(onSuccess,
    onError);
    }

    // onSuccess: Get the current heading
    function onSuccess(heading) {
    alert('Heading: ' + heading.magneticHeading);
    }

    // onError: Failed to get the heading
    function onError(compassError) {
    alert('Compass Error: ' + compassError.code);
    }


    View Slide

23. Accelerometer


    View Slide

24. View Slide

25. View Slide

26. Accelerometer
    Captures  device  moAon  in  the  x,  y,  and  z  direcAon.

    Methods

    accelerometer.getCurrentAcceleraAon
    accelerometer.watchAcceleraAon
    accelerometer.clearWatch

    Arguments

    accelerometerSuccess
    accelerometerError
    accelerometerOpAons


    View Slide

27. function onSuccess(acceleration) {
    alert('Acceleration X: ' + acceleration.x +
    '\n' +
    'Acceleration Y: ' + acceleration.y +
    '\n' +
    'Acceleration Z: ' + acceleration.z +
    '\n' +
    'Timestamp: ' +
    acceleration.timestamp + '\n');
    };

    function onError() {
    alert('onError!');
    };

    navigator.accelerometer.getCurrentAcceleration(onS
    uccess, onError);


    View Slide

28. Events
    •  deviceready
    •  pause
    •  resume
    •  online
    •  offline
    •  backbunon
    •  banerycriAcal
    •  banerylow
    •  banerystatus
    •  menubunon
    •  searchbunon
    •  startcallbunon
    •  endcallbunon
    •  volumedownbunon
    •  volumeupbunon


    View Slide

29. document.addEventListener("offline",
    onOffline, false);

    function onOffline() {
    // Handle the offline event
    }

    document.addEventListener("online",
    onOnline, false);

    function onOnline() {
    // Handle the online event
    }


    View Slide

30. File
    This  object  contains  anributes  of  a  single  file.



    View Slide

31. Storage
    Embedded  SQLite  database

    or

    localStorage


    View Slide

32. localStorage
    Provides  access  to  a  W3C  Storage  interface
    (hnp://dev.w3.org/html5/webstorage/#the-­‐
    localstorage-­‐anribute)


    View Slide

33. function onDeviceReady() {
    var element = document.getElementById('localData');

    window.localStorage.setItem("key", "value");
    var keyname = window.localStorage.key(i);
    // keyname is now equal to "key"
    var value = window.localStorage.getItem("key");
    // value is now equal to "value"
    window.localStorage.removeItem("key");
    window.localStorage.setItem("key2", "value2");

    element.innerHTML = "Value:"+value;

    window.localStorage.clear();
    // localStorage is now empty
    }


    View Slide

34. Embedded  SQLite  database
    var  dbShell  =
    window.openDatabase(database_name,
    database_version,  database_displayname,
    database_size);


    View Slide

35. function populateDB(tx) {
    tx.executeSql('DROP TABLE IF EXISTS DEMO');
    tx.executeSql('CREATE TABLE IF NOT EXISTS DEMO
    (id unique, data)');
    tx.executeSql('INSERT INTO DEMO (id, data)
    VALUES (1, "First row")');
    tx.executeSql('INSERT INTO DEMO (id, data)
    VALUES (2, "Second row")');
    }

    function errorCB(err) {
    alert("Error processing SQL: "+err);
    }

    function successCB() {
    alert("success!");
    }

    var db = window.openDatabase("Database", "1.0",
    "PhoneGap Demo", 200000);
    db.transaction(populateDB, errorCB, successCB);


    View Slide

36. Camera
    The  camera  object  provides  access  to  the
    device's  default  camera  applicaAon.


    View Slide

37. camera.getPicture
    Takes  a  photo  using  the  camera  or  retrieves  a
    photo  from  the  device's  album.  The  image  is
    passed  to  the  success  callback  as  a  base64
    encoded  String  or  as  the  URI  of  an  image  file.


    View Slide

38. cameraOpAons
    { quality : 75,
    destinationType :
    Camera.DestinationType.DATA_URL,
    sourceType :
    Camera.PictureSourceType.CAMERA,
    allowEdit : true,
    encodingType: Camera.EncodingType.JPEG,
    targetWidth: 100,
    targetHeight: 100,
    popoverOptions: CameraPopoverOptions,
    saveToPhotoAlbum: false };


    View Slide

39. Capture
    Provides  access  to  the  audio,  image,  and  video
    capture  capabiliAes  of  the  device.

    Methods
    capture.captureAudio:  Launch  the  device  audio
    recording  applicaAon  for  recording  audio  clip(s).
    capture.captureImage:  Launch  the  device  camera
    applicaAon  for  taking  image(s).
    capture.captureVideo:  Launch  the  device  video
    recorder  applicaAon  for  recording  video(s).



    View Slide

40. capture.captureAudio
    Start  the  audio  recorder  applicaAon  and  return
    informaAon  about  captured  audio  clip  file(s)


    View Slide

41. // capture callback
    var captureSuccess = function(mediaFiles) {
    var i, path, len;
    for (i = 0, len = mediaFiles.length; i < len; i
    += 1) {
    path = mediaFiles[i].fullPath;
    // do something interesting with the file
    }
    };

    // capture error callback
    var captureError = function(error) {
    navigator.notification.alert('Error code: ' +
    error.code, null, 'Capture Error');
    };

    // start audio capture
    navigator.device.capture.captureAudio(captureSuccess
    , captureError, {limit:2});


    View Slide

42. capture.captureImage
    // capture callback
    var captureSuccess = function(mediaFiles) {
    var i, path, len;
    for (i = 0, len = mediaFiles.length; i < len; i += 1) {
    path = mediaFiles[i].fullPath;
    // do something interesting with the file
    }
    };

    // capture error callback
    var captureError = function(error) {
    navigator.notification.alert('Error code: ' + error.code, null,
    'Capture Error');
    };

    // start image capture
    navigator.device.capture.captureImage(captureSuccess, captureError,
    {limit:2});


    View Slide

43. capture.captureVideo
    Start  the  video  recorder  applicaAon  and  return
    informaAon  about  captured  video  clip  file(s).


    View Slide

44. Media
    The  Media  object  provides  the  ability  to  record
    and  play  back  audio  files  on  a  device.

    var media = new Media(src,
    mediaSuccess, [mediaError],
    [mediaStatus]);


    View Slide

45. // Audio player
    //
    var my_media = new Media(src, onSuccess, onError);

    // Update media position every second
    var mediaTimer = setInterval(function() {
    // get media position
    my_media.getCurrentPosition(
    // success callback
    function(position) {
    if (position > -1) {
    console.log((position) + " sec");
    }
    },
    // error callback
    function(e) {
    console.log("Error getting pos=" + e);
    }
    );
    }, 1000);


    View Slide

46. notification.alert
    notification.confirm
    notification.prompt
    notification.beep
    notification.vibrate
    NoAficaAons


    View Slide

47. navigator.notification.alert(message,
    alertCallback, [title], [buttonName])

    message: Dialog message (String)
    alertCallback: Callback to invoke when
    alert dialog is dismissed. (Function)
    title: Dialog title (String) (Optional,
    Default: "Alert")
    buttonName: Button name (String)
    (Optional, Default: "OK")
    Alert


    View Slide

48. View Slide

49. // Android / BlackBerry WebWorks (OS 5.0
    and higher) / iPhone / Tizen
    //
    function alertDismissed() {
    // do something
    }

    navigator.notification.alert(
    'You are the winner!', // message
    alertDismissed, // callback
    'Game Over', // title
    'Done' // buttonName
    );


    View Slide

50. navigator.notification.confirm(message,
    confirmCallback, [title], [buttonLabels])

    message: Dialog message (String)
    confirmCallback: - Callback to invoke with index of
    button pressed (1, 2 or 3) or when the dialog is
    dismissed without a button press (0), (Function)
    title: Dialog title (String) (Optional, Default:
    "Confirm")
    buttonLabels: Comma separated string with button
    labels (String) (Optional, Default: "OK,Cancel")
    Confirm


    View Slide

51. View Slide

52. // process the confirmation dialog result
    function onConfirm(buttonIndex) {
    alert('You selected button ' + buttonIndex);
    }

    // Show a custom confirmation dialog
    //
    function showConfirm() {
    navigator.notification.confirm(
    'You are the winner!', // message
    onConfirm, // callback to
    invoke with index of button pressed
    'Game Over', // title
    'Restart,Exit' // buttonLabels
    );
    }


    View Slide

53. navigator.notification.prompt(message,
    promptCallback, [title], [buttonLabels])

    message: Dialog message (String)
    promptCallback: - Callback to invoke when a
    button is pressed (Function)
    title: Dialog title (String) (Optional, Default:
    "Prompt")
    buttonLabels: Array of strings for the button
    labels (Array) (Optional, Default:
    ["OK","Cancel"])
    Prompt


    View Slide

54. View Slide

55. // process the promp dialog results
    function onPrompt(results) {
    alert("You selected button number " +
    results.buttonIndex + " and entered " +
    results.input1);
    }

    // Show a custom prompt dialog
    //
    function showPrompt() {
    navigator.notification.prompt(
    'Please enter your name', // message
    onPrompt, // callback to
    invoke
    'Registration', // title
    ['Ok','Exit'] // buttonLabels
    );
    }


    View Slide

56. navigator.notification.beep(times);
    Beep


    View Slide

57. Android  Quirks

    Android  plays  the  default  "NoAficaAon  ringtone"  specified  under  the
    "SeRngs/Sound  &  Display"  panel.

    iPhone  Quirks

    Ignores  the  beep  count  argument.
    There  is  no  naAve  beep  API  for  iPhone.
    Cordova  implements  beep  by  playing  an  audio  file  via  the  media  API.
    The  user  must  provide  a  file  with  the  desired  beep  tone.
    This  file  must  be  less  than  30  seconds  long,  located  in  the  www/  root,
    and  must  be  named  beep.wav.


    View Slide

58. navigator.notification.vibrate(mseconds)


    Vibrate


    View Slide

59. Push  NoAficaAons


    View Slide

60. Push  NoAficaAons  Flow


    View Slide

61. The  InAppBrowser  is  a  web-­‐browser  that  is  shown  in  your  app  when
    you  use  the  window.open  call.

    ref.addEventListener(eventname, callback);

    loadstart - event fired when the InAppBrowser
    starts to load a URL
    loadstop - event fired when the InAppBrowser
    finished loading a URL
    loaderror - event fired when the InAppBrowser
    encounters an error loading a URL
    exit - event fired when the InAppBrowser window
    is closed
    InAppBrowser


    View Slide

62. hHp://docs.phonegap.com/en/2.9.0/index.html
    Further  resources
    PhoneGap  API  Explorer  App  (iOS  &  Android)


    View Slide

63. Now  go  build  something!


    View Slide

64. Thanks!
    chris.griffith@gmail.com
    @chrisgriffith
    hnp://chrisgriffith.wordpress.com/


    View Slide
