Inside Active Storage: a code review of Rails' new framework

Presented at RailsConf, April 2018
http://railsconf.com/program/sessions#session-562

Rails 5.2 ships with a new library to support file uploads: Active Storage.

In this talk, we will analyze its internal code, learning how it integrates with Active Record and Action Pack to supply amazing features out of the box, from image previews to cloud storage.

We will review its class architecture and delve into the implementation of several Active Storage methods, such as has_one_attached and upload. On the way, we will better understand some Ruby patterns frequently used within Rails: meta-programming, macros, auto-loading, initializers, class attributes.

---

Links from this presentation:

* https://www.clutter.com
* http://guides.rubyonrails.org/active_storage_overview.html
* https://github.com/rails/rails/tree/master/activestorage
* https://evilmartians.com/chronicles/rails-5-2-active-storage-and-beyond

Claudio B.

April 12, 2018
Tweet

More Decks by Claudio B.

Other Decks in Programming

Transcript

  1. Inside Active Storage:
    a code review of Rails'
    new framework
    speakerdeck.com/claudiob

    View Slide

  2. I work for a storage company
    clutter.com

    View Slide

  3. I will talk about Active Storage
    guides.rubyonrails.org/active_storage_overview.html

    View Slide

  4. Inside Active Storage
    - How to use in a Rails app (5 min)
    - The main classes of the library (10 min)
    - How the library works (10 min)

    View Slide

  5. Inside Active Storage
    - How to use in a Rails app (5 min)
    - The main classes of the library (10 min)
    - How the library works (10 min)

    View Slide

  6. How to use Active Storage
    Let's add an image uploader to a Rails 5.2 scaffold app

    View Slide

  7. How to use Active Storage
    Start with a Rails scaffold app
    rails new catalog
    cd catalog
    bin/rails generate scaffold cat name:string
    bin/rails db:create db:migrate
    bin/rails server

    View Slide

  8. How to use Active Storage
    Start with a Rails scaffold app

    View Slide

  9. How to use Active Storage
    Step 1: add a file field called “picture”

    <%= form.label :picture %>
    <%= form.file_field :picture %>

    View Slide

  10. How to use Active Storage
    Step 2: add “picture” to the whitelisted params
    class CatsController < ApplicationController
    def index
    […]
    def cat_params
    params.require(:cat).permit(:name, :picture)
    end
    end

    View Slide

  11. How to use Active Storage
    Step 3: add “has_one_attached” to the model
    class Cat < ApplicationRecord
    […]
    has_one_attached :picture
    […]
    end

    View Slide

  12. How to use Active Storage
    Bonus step: display the picture
    <%= image_tag @cat.picture %>

    View Slide

  13. How to use Active Storage
    More features: variants, previewers, analyzers
    @cat.picture.variant(monochrome: true, flip: "90")
    has_one_attached :document
    @cat.document.preview(resize: "100x100")
    has_many_attached :videos
    @cat.videos.map(&:metadata) # size, angle, duration

    View Slide

  14. Inside Active Storage
    - How to use in a Rails app (5 min)
    - The main classes of the library (10 min)
    - How the library works (10 min)

    View Slide

  15. The main classes of Active Storage
    github.com/rails/rails/tree/master/activestorage

    View Slide

  16. The main classes of Active Storage
    bundle open activestorage

    View Slide

  17. The main classes of Active Storage
    1. ActiveStorage::Service
    2. ActiveStorage::Blob
    3. ActiveStorage::Attachment

    View Slide

  18. The main classes of Active Storage
    1. ActiveStorage::Service
    2. ActiveStorage::Blob
    3. ActiveStorage::Attachment

    View Slide

  19. ActiveStorage::Service
    Moves bytes from memory to disk
    Disk Storage (5.8ms) Uploaded file to key: nty3U4Bzagqj3ekd (checksum: LPzlVe+CBQ==)
    #{Rails.root}/storage/
    nt/y3/nty3U4Bzagqj3ekd
    ActionDispatch::
    Http::UploadedFile

    View Slide

  20. What is ActiveStorage::Service
    An abstract class serving as an interface for implementations
    class ActiveStorage::Service
    def upload(key, io, checksum: nil)
    raise NotImplementedError
    end
    def download(key)
    raise NotImplementedError
    end
    end

    View Slide

  21. Inside ActiveStorage::Service (disk)
    Moves bytes from memory to local disk and back
    class ActiveStorage::Service::DiskService < Service
    def upload(key, io, checksum: nil)
    IO.copy_stream(io, make_path_for(key))
    end
    def download(key)
    File.binread path_for(key)
    end
    end

    View Slide

  22. Inside ActiveStorage::Service (S3)
    Moves bytes from memory to AWS S3 and back
    class ActiveStorage::Service::S3Service < Service
    def upload(key, io, checksum: nil)
    object_for(key).put(upload_options.merge(body: io))
    end
    def download(key)
    object_for(key).get.body.read
    end
    end

    View Slide

  23. The main classes of Active Storage
    1. ActiveStorage::Service
    2. ActiveStorage::Blob
    3. ActiveStorage::Attachment

    View Slide

  24. ActiveStorage::Blob
    Stores a reference to the uploaded file
    ActiveStorage::Blob Create (5.8ms) INSERT INTO active_storage_blobs (key, filename, …
    key: "nty3U4Bzagqj3ekd"
    filename: "fluffy.jpg"
    content_type: "image/jpeg"
    byte_size: 1565751
    ActionDispatch::
    Http::UploadedFile

    View Slide

  25. What is ActiveStorage::Blob
    A record in the database with information about one file
    create_table "active_storage_blobs", do |t|
    t.string "key", null: false
    t.string "filename", null: false
    t.string "content_type"
    t.text "metadata"
    t.bigint "byte_size", null: false
    t.string "checksum", null: false
    t.index ["key"], unique: true
    end

    View Slide

  26. What is ActiveStorage::Blob
    Migrations are provided to generate the required tables

    View Slide

  27. Inside ActiveStorage::Blob
    Extracts file metadata and invokes the service upload
    class ActiveStorage::Blob < ActiveRecord::Base
    def upload(io)
    self.checksum = compute_checksum_in_chunks(io)
    self.content_type = extract_content_type(io)
    self.byte_size = io.size
    service.upload(key, io, checksum: checksum)
    end
    end

    View Slide

  28. The main classes of Active Storage
    1. ActiveStorage::Service
    2. ActiveStorage::Blob
    3. ActiveStorage::Attachment

    View Slide

  29. ActiveStorage::Attachment
    Associates a blob with a record
    ActiveStorage::Blob Create (5.8ms) INSERT INTO active_storage_attachments (name, …
    name: "picture"
    record_type: "Cat"
    record_id: 4
    blob_id: 2
    ActionDispatch::
    Http::UploadedFile

    View Slide

  30. What is ActiveStorage::Attachment
    A record in the database associating a blob to its owner
    create_table "active_storage_attachments" do |t|
    t.string "name", null: false
    t.string "record_type", null: false
    t.integer "record_id", null: false
    t.integer "blob_id", null: false
    t.index ["blob_id"]
    t.index ["record_type", "record_id", "name", "blob_id"],
    unique: true
    end

    View Slide

  31. Inside ActiveStorage::Attachment
    A record in the database associating a blob to its owner
    class ActiveStorage::Attachment < ActiveRecord::Base
    self.table_name = "active_storage_attachments"
    belongs_to :record, polymorphic: true, touch: true
    belongs_to :blob, class_name: "ActiveStorage::Blob"
    end

    View Slide

  32. The main classes of Active Storage
    1. ActiveStorage::Service
    2. ActiveStorage::Blob
    3. ActiveStorage::Attachment

    View Slide

  33. Inside Active Storage
    - How to use in a Rails app (5 min)
    - The main classes of the library (10 min)
    - How the library works (10 min)

    View Slide

  34. How Active Storage works
    How does a single method add this whole behavior?
    class Cat < ApplicationRecord
    […]
    has_one_attached :picture
    […]
    end

    View Slide

  35. How Active Storage works
    When loading Active Record, extend it with new methods
    class ActiveStorage::Engine < Rails::Engine
    initializer "active_storage.attached" do
    ActiveSupport.on_load(:active_record) do
    extend ActiveStorage::Attached::Macros
    end
    end
    end

    View Slide

  36. How Active Storage works
    Meta-programming: define methods with a given name
    module ActiveStorage::Attached::Macros
    def has_one_attached(name)
    class_eval <<-CODE, __FILE__, __LINE__ + 1
    def #{name}=(attachable)
    #{name}.attach(attachable)
    end
    [… 5 more methods…]

    View Slide

  37. How Active Storage works
    Meta-programming: define methods with a given name
    module ActiveStorage::Attached::Macros
    def has_one_attached(:picture)
    class_eval <<-CODE, __FILE__, __LINE__ + 1
    def picture=(attachable)
    picture.attach(attachable)
    end
    [… 5 more methods…]

    View Slide

  38. How Active Storage works
    When a picture is attached to a cat…
    class Cat < ApplicationRecord
    has_one_attached :picture
    def picture=(attachable)
    picture.attach(attachable)
    end
    end

    View Slide

  39. How Active Storage works
    …a picture is instantiated…
    class Cat < ApplicationRecord
    has_one_attached :picture
    def picture
    ActiveStorage::Attached::One.new(
    "picture", self, dependent: :purge_later)
    end
    end

    View Slide

  40. How Active Storage works
    …and a blob and an attachment are added to the database.
    class ActiveStorage::Attached::One < Attached
    def attach(attachable)
    blob = create_blob_from(attachable)
    write_attachment build_attachment(blob: blob)
    […]
    end
    end

    View Slide

  41. How Active Storage works
    When a cat is destroyed…
    class Cat < ApplicationRecord
    has_one_attached :picture
    if dependent == :purge_later # true by default
    after_destroy_commit { picture.purge_later }
    end
    end

    View Slide

  42. How Active Storage works
    …the picture purges the attachment…
    class ActiveStorage::Attached::One < Attached
    def purge_later
    attachment.purge_later if attached?
    end
    end

    View Slide

  43. How Active Storage works
    …the attachment purges the blob…
    class ActiveStorage::Attachment < ActiveRecord::Base
    def purge_later
    blob.purge_later
    destroy
    end
    end

    View Slide

  44. How Active Storage works
    …the blob enqueues a purge job…
    class ActiveStorage::Blob < Attached
    def purge_later
    ActiveStorage::PurgeJob.perform_later(self)
    end
    end

    View Slide

  45. How Active Storage works
    …the job purges the blob…
    class ActiveStorage::PurgeJob < ActiveJob::Base
    def perform(blob)
    blob.purge
    end
    end

    View Slide

  46. How Active Storage works
    …the job purges the blob…
    class ActiveStorage::Blob < Attached
    def purge
    delete
    destroy
    end
    end

    View Slide

  47. How Active Storage works
    …the blob asks the service to delete the file…
    class ActiveStorage::Blob < Attached
    def delete
    service.delete(key)
    end
    end

    View Slide

  48. How Active Storage works
    …the service deletes the file.
    class ActiveStorage::DiskService
    def delete(key)
    File.delete path_for(key)
    end
    end

    View Slide

  49. More to explore about Active Storage
    - JavaScript module
    - ActiveSupport::Notification
    - Direct and resolve routes

    View Slide

  50. Inside Active Storage:
    a code review of Rails'
    new framework
    speakerdeck.com/claudiob

    View Slide
