Domain-Driven Transformation

Transcript

1. Starring
   Directed By
   Special
   Appearance
   Presented by
   Photo: Hackercatxxy/Wikipedia


   View Slide

2. View Slide

3. THE NAME OF THIS SPEAKER IS HENNING SCHWENTNER
   LIVE 45 MIN TALK


   View Slide

4. !"#
   Kolleg:in gesucht
   (Deutschlandweit)


   View Slide

5. View Slide

6. @hschwentner


   View Slide

7. @hschwentner
   Alphorn
   Auto Leasing Inc.


   View Slide

8. @hschwentner


   View Slide

9. @hschwentner


   View Slide

10. Monolease A


    View Slide

11. salesperson
    [person]
    Monolease
    [software system]
    Central car leasing tool
    customer
    [external person]
    risk manager
    [person]
    closes leasing
    contracts with
    creates and
    calculates contracts in
    assesses risk of
    contracts in
    Alphorn Auto Leasing Inc.
    [enterprise]
    Context


    View Slide

12. @hschwentner
    Alphorn’s boss:
    “Modernize it!”


    View Slide

13. @hschwentner
    Diagnosis:
    From Which Diseases Does
    Our Patient suffer?


    View Slide

14. @hschwentner
    Different diseases require
    different treatment


    View Slide

15. @hschwentner
    big ball
    of mud
    anemic
    domain model
    bad
    team
    organization
    Typical Diseases of
    Legacy Systems


    View Slide

16. @hschwentner
    big ball
    of mud
    anemic
    domain model
    bad
    team
    organization
    Cures
    strategic
    transformation
    tactical
    transformation socio-technical
    transformation


    View Slide

17. @hschwentner
    Domain-Driven
    Refactorings
    • Strategic
    • Socio-Technical
    • Tactical (Against Model Anemia)
    • Tactical (Against Big Ball of Mud)
    Catalog:
    https://hschwentner.io/domain-driven-refactorings


    View Slide

18. @hschwentner
    Strategic


    View Slide

19. @hschwentner
    Strategic Transformation
    1. Step: Domain re-discovery
    2. Step: Modeling the to-be
    3. Step: Aligning as-is with to-be
    4. Step: Do the move
    RISK
    MANAGE-
    MENT
    SALES


    View Slide

20. @hschwentner
    Controlling Complexity
    as Key to
    Modernization


    View Slide

21. “The most
    fundamental problem
    in software
    development is
    complexity. ”
    Bjarne Stroustrup


    View Slide

22. Controlling
    complexity is
    the essence of
    computer
    programming
    Brian
    Kernighan


    View Slide

23. “There is only one
    basic way of dealing
    with complexity:
    divide and conquer.”
    Bjarne Stroustrup


    View Slide

24. View Slide

25. View Slide

26. @hschwentner
    Too big
    to be understood
    as a whole


    View Slide

27. Photo: Henning Schwentner


    View Slide

28. View Slide

29. @hschwentner
    How to Modernize
    IT Infratructure?


    View Slide

30. @hschwentner
    Replace or
    Transform


    View Slide

31. old old old old
    new
    new new new
    “just flip
    the lever”
    1 2 3 4 5
    a.k.a.
    big bang
    replacement


    View Slide

32. old old old
    new
    new new new
    2 3 4 5
    old
    1


    View Slide

33. Strangler
    Fig
    Application
    Photo: Henning Schwentner


    View Slide

34. Strangler Fig Application


    View Slide

35. Lesson:
    is better than
    Strangler Fig
    Application
    Big Bang
    Replacement


    View Slide

36. =>
    bounded
    contexts
    monolith
    buy
    to
    carve out
    build
    new


    View Slide

37. @hschwentner
    Step 1:
    Domain Re-Discovery


    View Slide

38. @hschwentner
    To split the monolith
    we first have to
    put it aside


    View Slide

39. @hschwentner
    Mindset Switch


    View Slide

40. thinking
    about
    business
    =>
    thinking
    about
    technology
    to


    View Slide

41. Collaborative Modeling


    View Slide

42. Collaborative Modeling


    View Slide

43. customer
    tells wish for
    1
    salesperson
    signs
    to
    gives
    for
    contract
    3
    risk manager
    contract
    passes on
    to
    4
    contract
    votes
    checks
    calculates
    5
    6
    7
    calculates
    to
    8
    2
    car
    credit
    rating
    installment
    car
    resale
    value
    contract


    View Slide

44. https://hschwentner.io
    Read on in:


    View Slide

45. @hschwentner
    Step 2:
    Determining the
    To-Be Architecture


    View Slide

46. @hschwentner
    Drawing Boundaries


    View Slide

47. @hschwentner
    Scope:
    coarse-grained
    to-be (optimized)
    pure


    View Slide

48. Which activities
    belong together
    (from an actor’s
    perspective)?


    View Slide

49. customer
    tells wish for
    1
    salesperson
    signs
    to
    gives
    for
    contract
    3
    risk manager
    contract
    passes on
    to
    4
    contract
    votes
    checks
    calculates
    5
    6
    7
    calculates
    to
    8
    2
    car
    credit
    rating
    installment
    car
    resale
    value
    contract
    sales
    risk assessment


    View Slide

50. Sales
    Risk
    assessment


    View Slide

51. @hschwentner
    Step 3:
    Aligning As-Is with To-Be


    View Slide

52. salesperson
    [person]
    Monolease
    [software system]
    Central car leasing tool
    customer
    [external person]
    risk manager
    [person]
    closes leasing
    contracts with
    creates and
    calculates contracts in
    assesses risk of
    contracts in
    Alphorn Auto Leasing Inc.
    [enterprise]
    Context
    again


    View Slide

53. salesperson
    [person]
    backend
    [container: EJB 2]
    risk manager
    [person]
    creates and
    calculates contracts in
    assesses risk of
    contracts in
    Monolease
    [software system]
    frontend
    [container: servlets, JSPs]
    database
    [container: IBM DB2]
    Containers


    View Slide

54. Calculator
    [component]
    frontend
    [container]
    LeasingServlet
    [component: servlet]
    CONTRACTS
    [database table]
    PartnerServlet
    [component: servlet]
    ContractService
    [component]
    PartnerService
    [component]
    backend
    [container]
    database
    [container]
    Contract
    [component]
    Partner
    [component]
    PARTNERS
    [database table]
    Components


    View Slide

55. big ball
    of mud
    =>
    no vertical
    structuring


    View Slide

56. Calculator
    [component]
    frontend
    [container]
    LeasingServlet
    [component: servlet]
    CONTRACTS
    [database table]
    PartnerServlet
    [component: servlet]
    ContractService
    [component]
    PartnerService
    [component]
    backend
    [container]
    database
    [container]
    Contract
    [component]
    Partner
    [component]
    PARTNERS
    [database table]
    Components


    View Slide

57. Calculator
    [component]
    ContractService
    [component]
    PartnerService
    [component]
    backend
    [container]
    Contract
    [component]
    Partner
    [component]
    Component Backend


    View Slide

58. Calculator
    [component]
    ContractService
    [component]
    PartnerService
    [component]
    Contract
    [component]
    Partner
    [component]
    Component Bounded
    Contexts
    Sales
    Risk Assessment


    View Slide

59. Calculator
    [component]
    ContractService
    [component]
    PartnerService
    [component]
    Contract
    [component] Partner
    [component]
    Sales
    Risk Assessment
    Contract
    [component]
    Partner
    [component]
    Duplication?


    View Slide

60. ContractService
    [component]
    Contract
    [component]
    Component Backend
    Sales
    Risk
    assessment


    View Slide

61. ContractService
    signContract()
    voteContract()
    Code
    Contract
    getContractNumber()
    setSignatureDate()
    setCreditRa7ng()
    setVo7ngResult()
    Sales Risk Assessment


    View Slide

62. ContractService
    signContract()
    voteContract()
    Code
    Contract
    getContractNumber()
    setSignatureDate()
    setCreditRating()
    setVotingResult()
    Sales Risk Assessment
    ContractService
    signContract()
    voteContract()
    Contract
    getContractNumber()
    setSignatureDate()
    setCreditRating()
    setVotingResult()


    View Slide

63. ContractService
    signContract()
    Code
    Contract
    getContractNumber()
    setSignatureDate()
    Sales Risk Assessment
    ContractService
    voteContract()
    Contract
    getContractNumber()
    setCreditRa7ng()
    setVo7ngResult()


    View Slide

64. ContractService
    signContract()
    Code
    Contract
    getContractNumber()
    setSignatureDate()
    Sales Risk Assessment
    ContractService
    voteContract()
    Contract
    getContractNumber()
    setCreditRating()
    setVotingResult()


    View Slide

65. @hschwentner
    1.2 Extract
    Specialized
    “Contract
    Service”
    1.1 Extract
    Specialized
    “Contract”
    1 Extract
    Context
    “Sales”
    Transformation Backlog
    2 Extract
    Context
    “Risk
    assessment”
    2.1 Extract
    Specialized
    “Contract
    Service”
    2.1 Extract
    Specialized
    “Contract”


    View Slide

66. @hschwentner
    Insertion:
    Domain-Driven
    Refactorings


    View Slide

67. @hschwentner
    Domain-Driven
    Refactorings
    • Strategic
    • Socio-Technical
    • Tactical (Against Model Anemia)
    • Tactical (Against Big Ball of Mud)


    View Slide

68. @hschwentner
    Strategic DDRs
    • Extract Bounded Context
    • Implement Bounded Context from Scratch


    View Slide

69. @hschwentner
    Tactical DDRs
    (to Support Strategic)
    • Extract Specialized Entity
    • Extract Specialized Anemic Entity
    • Extract Specialized Service
    • Extract Specialized Data Model


    View Slide

70. @hschwentner
    Extract Bounded Context
    Mechanics
    • Analyze the domain to find out which bounded contexts should be there.
    • Identify a carve-out candidate context
    • Create an empty package/namespace/module for the to-be carved out context besides the big ball of
    mud.
    • Apply the Tactical (to Support Strategic) refactorings that are right for your situation.


    View Slide

71. @hschwentner
    Extract Specialized
    Anemic Entity
    Mechanics
    • Create empty new class in carved-out context
    • Add instance field of type new class to the old class
    • Copy to-be-moved fields from old to new class => Move Field
    • Copy first to-be-moved method to new class => Move Method
    • Replace method body in old class with a forward to method in new class
    • Step by step replace calls to the method in the old class with calls to the method in the new class
    • Delete the implementation in the old class
    • Delete now unused fields in old class
    • Repeat with other to-be-moved methods
    • Remove instance field of type new class in the old class


    View Slide

72. Read on at:
    https://hschwentner.io/domain-driven-refactorings


    View Slide

73. @hschwentner
    Step 4:
    Do the Move


    View Slide

74. @hschwentner
    Transformation Backlog
    Planning Transformation
    Tactical
    Refactoring 1.2
    Strategic
    Refactoring 1
    User Story A
    Product Backlog
    User Story E
    User Story B
    User Story C
    User Story D
    Tactical
    Refactoring 1.3
    Tactical
    Refactoring 1.4
    Tactical
    Refactoring 2.1
    Strategic
    Refactoring 2
    Sprint Backlog


    View Slide

75. @hschwentner
    Transformation Backlog
    Planning Transformation
    Tactical
    Refactoring 1.2
    Strategic
    Refactoring 1
    User Story A
    Product Backlog
    User Story E
    User Story B
    User Story C
    User Story D
    Tactical
    Refactoring 1.3
    Tactical
    Refactoring 1.4
    Tactical
    Refactoring 2.1
    Strategic
    Refactoring 2
    Sprint Backlog


    View Slide

76. @hschwentner
    Transformation Backlog
    Planning Transformation
    Strategic
    Refactoring 1
    Product Backlog
    User Story E
    User Story C
    User Story D
    Tactical
    Refactoring 1.4
    Tactical
    Refactoring 2.1
    Strategic
    Refactoring 2
    Sprint Backlog


    View Slide

77. @hschwentner
    Transformation Backlog
    Planning Transformation
    Strategic
    Refactoring 1
    Product Backlog
    User Story E
    User Story C
    User Story D
    Tactical
    Refactoring 1.4
    Tactical
    Refactoring 2.1
    Strategic
    Refactoring 2
    Sprint Backlog
    User Story F
    User Story G


    View Slide

78. @hschwentner
    Transformation Backlog
    Planning Transformation
    Product Backlog
    User Story E
    Tactical
    Refactoring 2.1
    Strategic
    Refactoring 2
    Sprint Backlog
    User Story F
    User Story G


    View Slide

79. @hschwentner
    Transformation Backlog
    Planning Transformation
    Product Backlog
    User Story E
    Tactical
    Refactoring 2.1
    Strategic
    Refactoring 2
    Sprint Backlog
    User Story G
    User Story H User Story F
    User Story I


    View Slide

80. ContractService
    signContract()
    voteContract()
    Code
    Contract
    getContractNumber()
    setSignatureDate()
    setCreditRating()
    setVotingResult()
    Risk Assessment
    ContractService
    Contract
    Monolease
    voteContract()
    getContractNumber()
    setCreditRating()
    setVotingResult()


    View Slide

81. ContractService
    signContract()
    Code
    Contract
    getContractNumber()
    setSignatureDate()
    Risk Assessment
    ContractService
    Contract
    Monolease
    voteContract()
    getContractNumber()
    setCreditRating()
    setVotingResult()


    View Slide

82. @hschwentner
    Tactical


    View Slide

83. Code
    Risk Assessment
    ContractService
    voteContract()
    Contract
    getContractNumber()
    setCreditRating()
    setVotingResult()
    anemic


    View Slide

84. View Slide

85. @hschwentner
    Outlook


    View Slide

86. @hschwentner
    What Else?
    Socio-technical transformation
    Technical transformation
    Tactical transformation
    Anti-Anemia refactorings


    View Slide

87. @hschwentner
    Domain Categories
    Pipeline Domain Blackboard Domain Dialog Domain
    • Logistics
    • Insurances and banks
    • administration
    • healthcare
    • event management
    • control center
    • Software development
    • Communication software
    • Negotiations in various
    domains
    or Domain Patterns?


    View Slide

88. @hschwentner
    Conclusion


    View Slide

89. View Slide

90. https://hschwentner.io
    Read on in:
    https://hschwentner.io/domain-driven-refactorings


    View Slide

91. Lesson:
    is possible
    Monolith transformation
    (and hard)
    =>


    View Slide

92. @hschwentner
    Mistake: Going on the journey alone
    Better:


    View Slide

93. Photo: Henning Schwentner


    View Slide

94. !
    ❤


    View Slide

95. @hschwentner


    View Slide

96. Bibliography
    Foote, Brian and Joseph Yoder. “Big Ball of Mud.” PLoP ’97, Monticello, IL,
    September 1997.
    Fowler, Martin. “Strangler Fig Application.” Bliki, June 29, 2004.
    Hofer, Stefan and Henning Schwentner. Domain Storytelling: a Collaborative,
    Visual, and Agile Way to Develop Domain-Driven Software. Boston: Addison-
    Wesley, 2022.
    Lilienthal, Carola and Henning Schwentner. Domain-Driven Transformation.
    Heidelberg: dpunkt, 2023.
    Kernighan, Brian W. Software Tools in Pascal. Addison-Wesley, 1981.


    View Slide

97. View Slide

98. Henning Schwentner
    ⌂ https://hschwentner.io
    @hschwentner
    hs@wps.de


    View Slide

99. (Software) Seam:
    A place where you can alter
    behavior in your program without
    editing in that place
    Every Seam has an
    enabling point, a place
    where you can make the
    decision to use one
    behavior or the other


    View Slide

100. View Slide

101. Typical Seam:
     An interface that can have
     different implementations


     View Slide
