  1. A DevOps State of Mind: Continuous Security with Kubernetes Chris

    Van Tuin Red Hat Chief Technologist, NA West / Silicon Valley linkedin: Chris Van Tuin
 email: cvantuin@redhat.com
 twitter: @chrisvantuin
  2. “Only the paranoid survive” - Andy Grove, 1996

  3. BUSINESSES MUST KEEP PACE The Disrupters are Disrupting the Incumbents

    Static &
 Planned Dynamic &
 Policy Driven Execution Innovation Old New Execution Innovation
  4. THE DISRUPTERS = Empowered organization Speed Up
 Innovation Time

    Change Move Fast, Break Things Culture of experimentation A 20% vs. 25% Shorten the Feedback Loop Real-time data-driven intelligence & personalization AI /
 ML Data, Data, Data B
  5. THE WORLD IS AUTOMATING Those who succeed in automation will

    win
  6. I.T. MUST EVOLVE
 FROM A COST CENTER TO INNOVATION

    CENTER Development Model Application Architecture Deployment & Application Infrastructur Storage Waterfall Agile Monolithic N-tier Bare Metal Virtual Servers Data Center Hosted Scale Up Scale Out DevOps MicroServices Containers Hybrid Cloud Storage as a Service
  7. Applications & devices outside of IT control Cloud computing Software-defined

    infrastructure Dissolving security perimeter Menacing threat landscape TRADITIONAL NETWORK-BASED DEFENSES ARE NO LONGER ENOUGH SECURING THE ENTERPRISE IS HARDER THAN EVER The way we develop, deploy and manage IT is changing dramatically led by DevOps, Cloud Native Applications, and Hybrid Cloud
  8. DEVSECOPS Continuous Security Improvement Process Optimization Security Automation Dev QA

    Prod Reduce Risks, Lower Costs, Speed Delivery, Speed Reaction
  9. DEVSECOPS + + Security DEV QA OPS Culture Process Technology

    Linux + Containers IaaS Orchestration CI/CD Source Control Management Collaboration Build and Artifact Management Testing Frameworks Cloud Native Applications Hybrid Cloud Open Source
  10. docker.io Registry Private Registry FROM fedora:1.0 CMD echo “Hello” Build

    file Physical, Virtual, Cloud Container Image Container Instance Build Run Ship CONTAINERS ENABLE DEVSECOPS
  11. Scheduling Monitoring Persistence Discovery Lifecycle & health Scaling Aggregation Security

    CONTAINERS AT SCALE BARE METAL VIRTUAL PRIVATE CLOUD PUBLIC CLOUD
  12. BARE METAL VIRTUAL PRIVATE CLOUD PUBLIC CLOUD Automated Software Factory


    Speed, Resiliency, Scalability, Security

  13. AUTOMATION

  14. Web Database role=web role=db role=web replicas=1,
 role=db replicas=2,


    role=web ORCHESTRATION Deployment, Declarative Pods Nodes Services Controller Manager & Data Store (etcd)
  15. Web Database replicas=1,
 role=db replicas=2,
 role=web HEALTH CHECK

    Pods Nodes Services role=web role=db role=web Controller Manager & Data Store (etcd)
  16. Pods Nodes Services Web Database replicas=1,
 role=db replicas=3


    role=web AUTO-SCALE 50% CPU role=web role=db role=web role=web Controller Manager & Data Store (etcd)
  17. Network isolation API & Platform access Federated clusters Storage {}

    CI/CD Monitoring & Logging Builds Images SECURING YOUR CONTAINER ENVIRONMENT Container host Registry
  18. CONTAINER IMAGES

  19. LAPTOP Container Application OS dependencies Guest VM LINUX BARE METAL

    Container Application OS dependencies LINUX VIRTUALIZATION Container Application OS dependencies Virtual Machine LINUX PRIVATE CLOUD Container Application OS dependencies Virtual Machine LINUX PUBLIC CLOUD Container Application OS dependencies Virtual Machine LINUX CONTAINERS - Build Once, Deploy Anywhere Reducing Risk and Improving Security with Improved Consistency
  20. CONTAINER IMAGE JAR CONTAINER IMAGE Application Application Language runtimes OS

    dependencies 1.2/latest 1.1
  21. Config Data Kubernetes configmaps secrets Container image Traditional
 data

    services, Kubernetes
 persistent volumes TREAT CONTAINERS AS IMMUTABLE To keep containerized apps portable Application Language runtimes OS dependencies
  22. KUBERNETES CONFIGMAP Decouple configuration from container image Application Language runtimes

    OS dependencies Environment Variable or Volume/File CONTAINER INSTANCE key:value from directories, files, or values KUBERNETES
 CONFIGMAP APPLICATION CONFIG FILE Application Configuration File e.g. XML etcd Pod Source Code Repository EnvVar require pod restart Files refresh in time
  23. •Authenticating authorship •Non-repudiation •Ensuring image integrity CONTAINER IMAGE SIGNING Validate

    what images and version are running
  24. CONTAINER BUILDS

  25. A CONVERGED SOFTWARE
 SUPPLY CHAIN

  26. CUSTOM SUPPLY CHAIN

  27. • Treat build file as a Blueprint • Version control

    build file • Don’t login to build/configure • Be explicit with versions, not latest • Always list registry pulling FROM • Specify USER, default is root • Each Run creates a new layer BUILD FILE BEST PRACTICES FROM registry.redhat.com/rhel7 RUN groupadd -g 999 appuser && \ useradd -r -u 999 -g appuser appuser USER appuser CMD echo “Hello” Build file
  28. CONTAINER REGISTRY SECURITY

  29. 64% of official images in Docker Hub
 contain high

    priority security vulnerabilities examples: ShellShock (bash) Heartbleed (OpenSSL) Poodle (OpenSSL) Source: Over 30% of Official Images in Docker Hub Contain High Priority Security Vulnerabilities, Jayanth Gummaraju, Tarun Desikan, and Yoshio Turner, BanyanOps, May 2015 (http://www.banyanops.com/pdf/BanyanOps-AnalyzingDockerHub-WhitePaper.pdf) WHAT’S INSIDE THE CONTAINER MATTERS
  30. PRIVATE REGISTRY

  31. CONTAINER HOST SECURITY

  32. Kernel Hardware (Intel, AMD) or Virtual Machine Containers Containers Containers

    Unit File Docker Image Container CLI SYSTEMD Cgroups Namespaces SELinux Drivers CONTAINERS ARE LINUX seccomp Read Only mounts
  33. CGROUPS - RESOURCE ISOLATION

  34. NAMESPACES - PROCESS ISOLATION

  35. SELINUX - MANDATORY ACCESS CONTROLS Password Files Web Server Attacker

    Discretionary Access Controls
 (file permissions) Mandatory Access Controls
 (selinux) Internal Network Firewall Rules Password Files Firewall Rules Internal Network Web Server selinux policy
  36. SECCOMP AND LINUX CAPABILITIES
 FILTERING SYSTEM CALLS and DROPPING PRIVILEGES

  37. READ ONLY MOUNTS

  38. Chris Van Tuin Chief Technologist, NA West / Silicon Valley

    cvantuin@redhat.co Best Practices • Don’t run as root • If you must,
 limit Linux Capabilities • Limit SSH Access • Use namespaces • Define resource quotas • Enable logging • Apply Security Errata • Apply Security Context and seccomp filters • Run production
 unprivileged containers
 as read-only http://blog.kubernetes.io/2016/08/security-best-practices-kubernetes-deployment.html Kernel Hardware (Intel, AMD) or Virtual Machine Containers Containers Containers Unit File Docker Image Container CLI SYSTEMD Cgroups Namespaces SELinux Drivers seccomp Read Only mounts Capabilities CONTAINER HOST SECURITY
  39. CONTINUOUS INTEGRATION WITH CONTAINERS

  40. CI/CD PIPELINE Continuous Integration Continuous Build Continuous Deployment Developer ->

    Source -> Git Git -> RPMS -> Images-> Registry Images from
 Registry -> Clusters
  41. WHAT’S INSIDE MATTERS…

  42. Security CONTINUOUS INTEGRATION WITH SECURITY SCAN

  43. Java Build Environment Language runtimes OS dependencies Build Image Java

    Code Application Language runtimes OS dependencies Container Image Image Registry Source Repository Image Registry REPRODUCIBLE BUILDS Source to Image with Build Images Source v3.1 v1.0.1 v3.1
  44. DEPLOYMENT STRATEGIES

  45. CONTINUOUS DELIVERY WITH CONTAINERS

  46. CONTINUOUS DELIVERY DEPLOYMENT STRATEGIES DEPLOYMENT STRATEGIES • Recreate • Rolling

    updates • Blue / Green deployment • Canary with A/B testing • Database migrations
  47. Recreate

  48. Version 1 Version 1 Version 1 Version 1.2 ` Tests

    / CI RECREATE WITH DOWNTIME
  49. Version 1 Version 1 Version 1 Version 1.2 ` Tests

    / CI RECREATE WITH DOWNTIME
  50. Version 1.2 Version 1.2 Version 1.2 RECREATE WITH DOWNTIME Use

    Case • Non-mission critical services Pros • Simple, clean • No Schema incompatibilities • No API versioning Cons • Downtime
  51. Rolling Updates

  52. Version 1 Version 1 Version 1 Version 1.2 ` Tests

    / CI ROLLING UPDATES with ZERO DOWNTIME Rollingupdate
 maxUnavailable=0 maxSurge=1
  53. Deploy new version and wait until it’s ready… Health Check:

    readiness probe e.g. tcp, http, script Version 1 Version 1 Version
 1.2 Version 1 Rollingupdate
 maxUnavailable=0 maxSurge=1
  54. Each container/pod is updated one by one Version 1.2 50%

    Version 1 V1 V1.2
  55. Each container/pod is updated one by one Version 1.2 Version

    1.2 Version 1.2 100% Use Case • Horizontally scaled • Backward compatible API/data • Microservices Pros • Zero downtime • Reduced risk, gradual rollout w/health checks • Ready for rollback Cons • Require backward compatible APIs/data • Resource overhead
  56. Blue / Green Deployment

  57. BLUE Version 1 Ingress e.g haproxy BLUE / GREEN DEPLOYMENT

    Using Ingress 100%
  58. BLUE GREEN Version 1 Version 2 Ingress e.g haproxy BLUE

    / GREEN DEPLOYMENT Using Ingress 100% Health Check: readiness probe e.g. tcp, http, script
  59. BLUE GREEN Version 1 Version 2 Ingress e.g haproxy BLUE

    / GREEN DEPLOYMENT Using Ingress 100%
  60. BLUE / GREEN DEPLOYMENT Rollback BLUE GREEN Version 1 Version

    2 Ingress Use Case • Self-contained micro services (data) Pros • Low risk, never change production • No downtime • Production like testing • Rollback Cons • Resource overhead • Data synchronization
  61. RAPID INNOVATION & EXPERIMENTATION WITH A/B TESTING

  62. ”only about 1/3 of ideas improve the metrics
 they

    were designed to improve.”
 Ronny Kohavi, Microsoft (Amazon) MICROSERVICES RAPID INNNOVATION & EXPERIMENTATION
  63. A/B TESTING USING CANARY DEPLOYMENTS

  64. 25% Conversion Rate ?! Conversion Rate 100% Version B Version

    A Ingress CANARY DEPLOYMENTS Tests / CI
  65. 25% Conversion Rate 30% Conversion Rate 75% 25% Version B

    Version A Ingress CANARY DEPLOYMENTS
  66. 25% Conversion Rate 30% Conversion Rate 100% Version B Version

    A Ingress CANARY DEPLOYMENTS
  67. 25% Conversion Rate 20% Conversion Rate 100% Version B Version

    A Rollback Ingress CANARY DEPLOYMENTS
  68. DATABASE MIGRATIONS

  69. Application v3 Development Application V2 Test Application v1 Production DB

    v1 DB v2 DB v3 CI/CD PIPELINE Version control database updates, ex: flyway V3__add_table_scooter.sql V2__add_table_truck.sql V1__add_table_car.sql
  70. DATABASE MIGRATIONS Version control database updates with Containers CONTAINER IMAGE

    CONTAINER BUILD FILE SQL MIGRATION SCRIPT Source Code Repository V2__add_table.sql Source Code Repository V2__add_table.sql /var/flyway/data Flyway flyway-mydb:v2.0.0 Registry + Dockerfile
  71. Nodes Pods Services postgresql-0 Persistent Volume A B D C

    PostgreSQL StatefulSet replicas=1 role=postgresq pvcl DATABASE MIGRATION StatefulSet deployment with headless Service v1
  72. Nodes Pods Services postgresql-0 Persistent Volume A B D C

    PostgreSQL StatefulSet replicas=1 role=postgresql Pvc DATABASE MIGRATIONS Create a Job for Flyway Flyway Job Secrets = Database Connection Info v1 flyway-mydb:v2.0.0 Image Registry Flyway
  73. role=postgressql type=primary Nodes Pods Services postgresql-0 Persistent Volume A B

    D C PostgreSQL StatefulSet replicas=1 role=postgresql pvc DATABASE MIGRATIONS Apply schema changes to database Flyway Job Secrets = Database Connection Info V2 flyway-mydb:v2.0.0 Flyway
  74. role=postgresql type=primary Nodes Pods Services postgresql-0 Persistent Volume A B

    D C PostgreSQL StatefulSet replicas=1 role=postgresql Pvc DATABASE MIGRATIONS Version control for database with Kubernetes V2
  75. Network isolation API & Platform access Federated clusters Storage {}

    CI/CD Monitoring & Logging Images Builds Container host Registry SECURING YOUR CONTAINER ENVIRONMENT
  76. NETWORK SECURITY

  77. Network Namespace
 provides resource isolation NETWORK ISOLATION Multi-Environment Multi-Tenant

  78. NETWORK POLICY example:
 all pods in namespace ‘project-a’ allow

    traffic
 from any other pods in the same namespace.”
  79. Kubernetes
 Logical Network Model NETWORK SECURITY • Kubernetes uses

    a flat SDN model • All pods get IP from same CIDR • And live on same logical network • Assumes all nodes communicate
 Traditional
 Physical Network Model • Each layer represents a Zone with
 increased trust - DMZ > App > DB,
 interzone flow generally one direction • Intrazone traffic generally unrestricted
  80. NETWORK SECURITY MODELS Co-Existence Approaches One Cluster Multiple Zones Kubernete

    Cluster Physical Compute
 isolation based on
 Network Zones Kubernete Cluster One Cluster Per Zone Kubernete Cluster B Kubernete Cluster A Kubernetes Cluster B C D https://blog.openshift.com/openshift-and-network-security-zones-coexistence-approaches/
  81. MONITORING & LOGGING

  82. CONTINUOUS FEEDBACK LOOP

  83. KUBERNETES MONITORING CONSIDERATIONS Kubernetes* Container* Host Cluster services, services, pods,


 deployments metrics Container native metrics Traditional resource metrics - cpu, memory, network, storage prometheus + grafana kubernetes-state-metrics probes Stack Metrics Tool node-exporter kubelet:cAdvisor Application Distributed applications - traditional app metrics - service discovery - distributed tracing prometheus + grafana jaeger tracing istio
  84. Aggregate platform and application log access via Kibana + Elasticsearch

    LOGGING
  85. STORAGE SECURITY

  86. Local Storage Quota Security Context Constraints STORAGE SECURITY Sometimes we

    can also have storage isolation requirements:
 pods in a network zone must use different storage endpoints
 than pods in other network zones. We can create one storage class per storage endpoint and
 then control which storage class(es) a project can use
  87. API & PLATFORM ACCESS

  88. Authentication via OAuth tokens and SSL certificate Authorization via Policy

    Engine checks User/Group Defined Roles API & PLATFORM ACCESS
  89. FEDERATION

  90. Amazon East OpenStack FEDERATED CLUSTERS Roles & access management (in-dev)

  91. WHAT’S NEXT

  92. Traffic Control Service Resiliency Chaos Testing Observ- ability Security

  93. OPERATORS

  94. Deployment Frequency Lead Time Deployment
 Failure Rate Mean Time to

    Recover 99.999 Service Availability DEVSECOPS METRICS Compliance Score
  95. THANK YOU linkedin: Chris Van Tuin email: cvantuin@redhat.com twitter: @chrisvantuin
