  1. Writing file system
    in CPython
    Dmitry Alimov
    2018

    View full-size slide

  2. File System
    Application
    Virtual File System (VFS)
    Device Driver
    Device (HDD, SSD, CD-ROM, NIC, etc)
    User Space
    Kernel Space Syscall Interface
    Block Layer
    Page Cache
    Direct I/O
    Hardware
    ext2, ext3,
    ext4, btrfs
    NFS,
    smbfs
    FUSE
    procfs,
    tmpfs

    View full-size slide

  3. FUSE (File System In Userspace)
    Available for Linux, FreeBSD, OpenBSD, NetBSD (as puffs), OpenSolaris, Minix 3,
    Android and macOS [2]
    In Linux kernel since version 2.6.14
    Windows compatibility is provided by libraries and ports [3, 4, 5]

    View full-size slide

  4. FUSE
    Diagram showing how FUSE works [2]

    View full-size slide

  5. Example uses
    GlusterFS: Clustered Distributed Filesystem
    GmailFS: Filesystem which stores data as mail in Gmail
    SSHFS: Provides access to a remote filesystem through SSH
    WikipediaFS: View and edit Wikipedia articles as if they were real files
    πfs: A file system that stores all files in the digits of Pi

    View full-size slide

  6. struct fuse_operations {
    int (*getattr) (const char *path, struct stat *stbuf);
    ...
    int (*readdir) (const char *path, void *buf,
    fuse_fill_dir_t filler, off_t offset,
    struct fuse_file_info *fi);
    ...
    int (*read) (const char *path, char *buf, size_t size,
    off_t offset, struct fuse_file_info *fi);
    ...
    };
    libfuse API

    View full-size slide

  7. Python interface to FUSE
    fusepy module [7] — simple interface to FUSE and MacFUSE:
    def getattr(self, path, fh=None):
    if path != '/':
    raise FuseOSError(errno.ENOENT)
    return {'st_mode': (S_IFDIR | 0o755), 'st_nlink': 2}
    def readdir(self, path, fh=None):
    return ['.', '..']
    def read(self, path, size, offset, fh=None):
    return self.data[path][offset:offset + size]

    View full-size slide

  8. PEPFS
    Read-only file system with PEPs as the files [8]
    Uses github repository with PEPs to get the current PEPs [9]
    Implemented in Python and uses the fusepy module
    Lazy PEP files' read (download specific PEP on demand)

    View full-size slide

  9. PEPFS mount
    $ ./pepfs.py /tmp/pepfs/
    $ mount
    ...
    PEPFS on /tmp/pepfs type fuse
    (rw,nosuid,nodev,relatime,user_id=1000,group_id=1000)
    ...

    View full-size slide

  10. PEPFS example
    $ ls -la /tmp/pepfs/
    total 4
    drwxr-xr-x 2 root root 6943251 Jul 25 00:07 .
    drwxrwxrwt 35 root root 4096 Jul 25 00:07 ..
    -rw-r--r-- 1 root root 29582 Jul 25 00:07 pep-0001.txt
    -rw-r--r-- 1 root root 8214 Jul 25 00:07 pep-0002.txt
    -rw-r--r-- 1 root root 2229 Jul 25 00:07 pep-0003.txt
    ...
    -rw-r--r-- 1 root root 81947 Jul 25 00:07 pep-3333.txt

    View full-size slide

  11. Page Cache
    To enable Page Cache, you need to set the flag keep_cache, in open() method:
    def open(self, path, flags):
    flags.keep_cache = 1
    return 0
    And also set raw_fi to True in FUSE(PEPFS(), ..., raw_fi=True)
    NB: Invalidation of cache and updating of data occurs only if the file size changes

    View full-size slide

  12. Questions
    https://t.me/spbpython
    https://t.me/piterpy_meetup

    View full-size slide

  13. References:
    1. https://en.wikibooks.org/wiki/The_Linux_Kernel/Storage
    2. https://en.wikipedia.org/wiki/Filesystem_in_Userspace
    3. https://en.wikipedia.org/wiki/Dokan_Library
    4. https://github.com/crossmeta/cxfuse
    5. http://www.secfs.net/winfsp/
    6. https://github.com/libfuse/libfuse
    7. https://github.com/fusepy/fusepy
    8. https://github.com/delimitry/pepfs
    9. https://github.com/python/peps/

    View full-size slide
