  1. Dynamic Multipoint
    VPN (DMVPN)
    Dmitry Figol
    CCIE R&S #53592
    dmfigol.me
    June 2017

    View Slide

  2. About me
    @dmfigol
    dmfigol
    dmfigol.me
    dmfigol
    dmfigol
    2

    View Slide

  3. Out of Scope
    3
    • DMVPN design
    • 2547oDMVPN – MPLS over DMVPN
    • DMVPN + IPsec Public Key Infrastructure (PKI)
    • IWAN

    View Slide

  4. Overview
    4
    • DMVPN is Hub-and-Spoke Overlay VPN with or without encryption
    which runs over any IP network (for example, Internet)
    • Used for scaling IPsec VPNs
    • Instead of a separate tunnel per each router pair, there is one tunnel
    interface on each router
    • All VPN members are in the same subnet
    • For adding a new device to VPN, most of configuration can be copied
    from another device
    • Uses Multipoint GRE (mGRE), Next Hop Resolution Protocol (NHRP) and
    IPsec

    View Slide

  5. Features
    5
    • DMVPN cloud has two types of addresses: overlay (logical) and
    underlay (NBMA).
    • Dynamic spoke discovery
    • Multicast replication on the hub
    • Dynamic spoke-to-spoke tunnels
    • NAT-Traversal (NAT-T) support
    • Front Door VRF support
    • IPv6 over IPv4 underlay support

    View Slide

  6. mGRE
    6
    • Multipoint GRE (mGRE) is the key building block of DMVPN
    • Removes the necessity of specifying tunnel destination
    • Relies on Next Hop Resolution Protocol (NHRP) with static or dynamic
    mappings
    • Tunnel key is required (must match on both sides) to identify the
    tunnel interface if several tunnels with the same tunnel source are
    used

    View Slide

  7. mGRE configuration example
    7
    interface Tunnel0
    ip address 10.0.0.1 255.255.255.0 ! Overlay IP
    tunnel source e0/0.150
    tunnel mode gre multipoint
    tunnel key 5
    !

    View Slide

  8. Next Hop Resolution Protocol (NHRP)
    8
    • NHRP does all DMVPN magic
    • Encapsulated into GRE, Protocol number 0x2001
    • Client-server protocol (the hub is Next Hop Server NHS, spokes are
    Next Hop Clients NHC)
    • NHS maintains NHRP database with NHRP mappings (logical IP to
    NBMA)
    • NHC sends NHRP Registration Request to all NHS
    • NHS checks for uniqueness of the claimed logical IP and replies with
    NHRP Registration Reply

    View Slide

  9. NHRP (cont.)
    9
    • NHRP network-id is mandatory, locally significant number, used to
    distinguish different NHRP clouds
    • NHRP cleartext authentication may be used to prevent configuration
    mistakes
    • NHRP hold-time controls how long NHRP mapping is valid, NHC sends
    Registration Request every one third of this value. Default hold-time is
    7200 seconds
    • NHC should have a static mapping for NHS and multicast (if needed)
    • Static mapping can be done not only for hub, but also for other spokes,
    that’s why it is needed to specify NHS additionally
    • NHS needs to know where to replicate multicast traffic (if needed)

    View Slide

  10. NHRP flags
    10
    • Authoritative – mapping was obtained from NHS
    • Implicit – mapping was learned from NHRP resolution or reply
    • Negative – requested NBMA mapping could not be obtained. Used to
    prevent triggering more NHRP resolution requests while the one is
    being resolved
    • Unique – NHRP mapping cannot be overwritten with the same logical
    IP but different NBMA address
    • Registered – created from receiving NHRP registration request

    View Slide

  11. NHRP flags (cont.)
    11
    • Used – mapping is valid
    • Router – mappings are for remote router itself to access the network
    with this flag
    • Local – list of peers where Resolution Request was sent
    • Nat – remote node supports NHRP NAT extension for dynamic spoke-
    to-spoke behind a NAT router

    View Slide

  12. NHRP configuration example
    12
    interface Tunnel 0
    ! on NHC, first IP is logical, the second is NBMA
    ip nhrp map 10.0.0.5 209.165.200.241
    ! on NHC specify NHS
    ip nhrp nhs 10.0.0.5
    ! on NHC specify where to send multicast
    ip nhrp map multicast 209.165.200.241
    ! on NHS specify where to replicate multicast
    ip nhrp map multicast dynamic
    ip nhrp network-id 50
    ip nhrp holdtime 600
    ip nhrp authentication cisco
    !

    View Slide

  13. IPsec
    13
    • Encrypts all control plane DMVPN traffic (NHRP) and data plane
    • NHRP triggers IPsec before installing new mappings
    • IPsec notifies NHRP when encryption is ready
    • NHRP installs mappings, and sends registration if needed.
    • GRE over IPsec is used
    • Transport mode should be used in most cases
    • Remember to add PSK key for spokes if spoke-to-spoke tunnels are
    going to be built
    • If there are several mGRE interfaces with the same source, the same
    profile must be used with the keyword shared

    View Slide

  14. IPsec configuration example
    14
    crypto isakmp policy 10
    encr aes
    hash sha512
    authentication pre-share
    group 14
    crypto isakmp key cisco address 0.0.0.0 0.0.0.0
    crypto ipsec transform-set TR-SET esp-aes esp-sha-hmac
    mode transport
    crypto ipsec profile DMVPN
    set transform-set TR-SET
    !
    interface Tunnel 0
    tunnel protection ipsec profile DMVPN
    !

    View Slide

  15. NAT-Transparency
    15
    • IPsec tunnel mode may not work in some NAT combinations
    • All DMVPN spokes must have a unique IP address after they have been
    NAT translated
    • Spokes can use Port Address Translation (PAT), Hub is allowed to use
    only Static NAT
    • UDP Port 4500 (non-isakmp) should be opened across the path
    • In show ip nhrp claimed NBMA address is IP address before NAT,
    NBMA address is IP address after NAT
    • Enabled by default, to disable use:
    (config)# no crypto ipsec nat-transparency udp-encapsulation

    View Slide

  16. Miscellaneous
    16
    • Set IP MTU and TCP Adjust MSS statically to the recommended value to
    avoid issues with fragmentation:
    interface Tunnel 0
    ip mtu 1400
    ip tcp adjust-mss 1360
    !

    View Slide

  17. DMVPN Phase 1
    17
    • Only Hub-to-Spoke tunnels, no dynamic Spoke-to-Spoke tunnels
    • All traffic between the spokes is always going through the hub
    regardless if the next hop is hub or spoke
    • Summarization on the hub is allowed
    • Tunnel mode on NHC is gre ip instead of gre multipoint
    • tunnel destination must be specified as well

    View Slide

  18. DMVPN Phase 1 – RIP
    18
    • Disable RIP split horizon on hub’s tunnel interface (if no summarization of
    spokes’ prefixes):
    • (config-if)# no ip split-horizon

    View Slide

  19. DMVPN Phase 1 – EIGRP
    19
    • Disable EIGRP split horizon on hub’s tunnel interface (if no
    summarization of spokes’ prefixes):
    (config-if)# no ip split-horizon eigrp 100

    View Slide

  20. DMVPN Phase 1 – OSPF
    20
    • The following OSPF network types can be used for automatic neighbor
    discovery:
    • Point-to-multipoint (most common)
    • Broadcast
    • If broadcast is used, make sure to exclude spokes from participation in
    DR/BDR election (set DR priority to 0)
    • Remember that default OSPF network type on tunnel interface is point-
    to-point which can result in OSPF adjacencies’ flapping on the hub

    View Slide

  21. DMVPN Phase 1 – BGP
    21
    • Both eBGP and iBGP can be used
    • eBGP needs an individual AS number per branch (you can use 4-byte AS
    numbers) or allowas-in should be used on the spokes (careful!)
    • For iBGP each Hub should be Route-Reflector (RR)
    • Options above are not needed if summarization on the Hub is used

    View Slide

  22. DMVPN Phase 2
    22
    • Dynamic Spoke-to-Spoke tunnels on demand based on Next Hop
    received from routing protocols
    • Routing protocols should support Third Party Next Hop feature
    • Summarization on the hub of Spokes’ prefixes is not allowed -
    summarization changes next hop to the Hub
    • Tunnel mode must be gre multipoint on spokes

    View Slide

  23. DMVPN Phase 2 (cont.)
    23
    • If the packet is supposed to go out of the tunnel interface, the Spoke
    looks into its NHRP cache to find NBMA address for the next hop
    • If not found, the packet is sent to the Hub
    • Also, NHRP Resolution Request is sent to the Hub which should forward
    it to the remote Spoke
    • Remote Spoke replies with NHRP Resolution Reply containing its own
    NBMA address directly to the source spoke. If IPsec is used, remote
    spoke will initiate IPsec tunnel first.
    • Source spoke adds a mapping to NHRP cache and subsequent packets
    are going via spoke-to-spoke tunnel

    View Slide

  24. DMVPN Phase 2 – RIP
    24
    • Advertises third party next hop automatically
    • Remember to disable split horizon on the hub

    View Slide

  25. DMVPN Phase 2 – EIGRP
    25
    • Remember to disable split horizon on the hub
    • To use third party next hop configure the following command on hub’s
    tunnel interface:
    (config-if)# no ip next-hop-self eigrp 100

    View Slide

  26. DMVPN Phase 2 – OSPF
    26
    • Only broadcast/non-broadcast network types are allowed as it is the
    only way to advertise third party next hop in the same area – DR will
    keep next hop unchanged

    View Slide

  27. DMVPN Phase 2 – BGP
    27
    • Both eBGP and iBGP (RR) advertise third party next hop automatically

    View Slide

  28. DMVPN Phase 3
    28
    • Supports dynamic Spoke-to-Spoke tunnels
    • They are triggered by the Hub using NHRP, not by routing protocols
    • All routes on spokes now point to the Hub
    • Summarization is now allowed on the Hub

    View Slide

  29. DMVPN Phase 3 (cont.)
    29
    • Route to remote spoke’s subnet points to the Hub
    • The packet is sent to the Hub
    • Hub forwards the packet out of the same tunnel interface towards the
    spoke, recognizes this and sends NHRP Redirect message to the spoke
    • NHRP Redirect contains the original packet
    • Local Spoke now sends Resolution Request querying about destination
    IP towards the Hub
    • Hub forwards it to the remote Spoke

    View Slide

  30. DMVPN Phase 3 (cont.)
    30
    • Remote Spoke replies directly to the local Spoke with NBMA address
    for the whole subnet from the RIB
    • If the NHRP shortcut is enabled, the route with received subnet is
    installed in the routing table as NHRP (AD 250) or if the same route
    already exists to the hub, next hop override (nho) is installed into CEF
    table and is shown with % in the routing table

    View Slide

  31. DMVPN Phase 3 configuration
    31
    • On NHS:
    (config-if)# ip nhrp redirect
    • On NHC:
    (config-if)# ip nhrp shortcut
    • Verification of next hop override:
    # show ip route next-hop-override

    View Slide

  32. DMVPN Phase 3 – RIP
    32
    • Summarization is required on the Hub towards the spoke

    View Slide

  33. DMVPN Phase 3 – EIGRP
    33
    • Summarization can be used on the hub or
    • Split horizon should be disabled and next-hop-self should be enabled
    on the hub

    View Slide

  34. DMVPN Phase 3 – OSPF
    34
    • Only point-to-multipoint network type is allowed because broadcast
    changes next hop

    View Slide

  35. DMVPN Phase 3 – BGP
    35
    • You can use aggregation on the hub for both eBGP and iBGP otherwise
    you need to change NH to the hub
    • For eBGP you need to use the following configuration on the hub:
    (config-router)# neighbor 155.1.4.4 next-hop-self
    • For iBGP RR you need to use the following configuration on the hub:
    (config-router)# neighbor 155.1.4.4 next-hop-self all

    View Slide

  36. DMVPN EIGRP Design
    36
    • EIGRP is the easiest choice for DMVPN:
    • Summarization anywhere
    • Next hop can be easily changed
    • Filtering can be performed anywhere
    • Traffic engineering can be achieved using filtering/offset-lists
    • Stub feature limits unnecessary queries to the spokes

    View Slide

  37. DMVPN OSPF Design
    37
    • With OSPF you can have the following design:
    • One area 0 in the whole network: in DMVPN cloud, behind the spokes, behind
    the hub
    • Area 0 behind the hub; DMVPN cloud + networks behind the spokes in another
    area
    • Area 0 is for DMVPN cloud and networks behind the spokes, while the networks
    behind the hub are in another area
    • Area 0 is only in DMVPN cloud, all networks behind the spokes and the hub are
    in their own areas

    View Slide

  38. DMVPN OSPF Design (cont.)
    38
    • OSPF has the following issues with DMVPN:
    • The whole DMVPN cloud should be in one area, because it is one subnet: every
    link flap on the spoke will be propagated through the whole area.
    • You can summarize only networks behind the hub if it is ABR
    • Routing updates (LSA) can’t be filtered within an area
    • It is hard to enforce traffic engineering in DMVPN + OSPF (one of the tricks is to
    use network type point-to-multipoint non-broadcast with individual cost per
    neighbor)
    • For Phase 2 only broadcast and non-broadcast network types can be used
    (which introduces risk of misconfiguration of DR priority on the spoke, which
    can bring the whole network down)

    View Slide

  39. DMVPN BGP Design
    39
    • BGP is also a good choice:
    • Increased routing policy granularity
    • As a compromise, increased administrative burden
    • iBGP vs eBGP:
    • iBGP RR concept perfectly matches Hub and Spoke model
    • eBGP requires individual AS number per branch, which may be problematic
    • Depends on requirements
    • BGP dynamic neighbors feature can be used on the hub:
    (config-router)# bgp listen [limit max-number] network/length
    peer-group peer-group-name

    View Slide

  40. Front Door VRF DMVPN
    40
    • What if the route towards NBMA address is in VRF RIB?
    • Front door VRF DMVPN feature comes to the rescue
    • Instead of crypto isakmp key, configure vrf-aware keyring and let tunnel
    interface know in which VRF to perform lookup for NBMA address:
    crypto keyring keyring-name vrf vrf-name
    pre-shared-key address key
    !
    interface tunnel
    tunnel vrf
    !

    View Slide

  41. Per-Tunnel QoS for DMVPN
    41
    • Different QoS policies are defined on the Hub
    • Spoke requests specific QoS policy using a group string in the
    Registration Request
    • Hub applies requested QoS policy on per-spoke basis
    • Configuration:
    • on the Spoke:
    (config-if)# ip nhrp group
    • on the Hub:
    (config-if)# ip nhrp map group service-policy output policy>

    View Slide

  42. Per-Tunnel QoS for DMVPN Verification
    42
    • # show ip nhrp
    • # show dmvpn detail
    • # show ip nhrp group-map
    • # show policy-map multipoint

    View Slide

  43. IPv6 over DMVPN
    43
    • IPv6 over IPv4 underlay (can be run simultaneously with IPv4)
    • IPv4 over IPv6 underlay
    • IPv6 over IPv6 underlay

    View Slide

  44. IPv4 over IPv6 underlay
    44
    • All NBMA addresses should be IPv6
    • IKEv2 should be used for IPsec
    • Tunnel mode should be gre multipoint ipv6

    View Slide

  45. IPv6 over IPv4 underlay
    45
    • IPv6 address configured on the tunnel interface
    • Instead of ip nhrp syntax use ipv6 nhrp
    • New optional syntax for NHS

    View Slide

  46. IPv6 over IPv4 underlay – configuration example
    46
    interface Tunnel0
    ipv6 address 2001::1/64
    ipv6 nhrp network-id 1
    ipv6 nhrp authentication cisco
    ! NHS mapping with 3 commands
    ipv6 nhrp map 2001::5/128 169.254.100.5
    ipv6 nhrp map multicast 169.254.100.5
    ipv6 nhrp nhs 2001::5
    ! or with single command
    ipv6 nhrp nhs 2001::5 nbma 169.254.100.5 multicast
    ipv6 nhrp shortcut
    !

    View Slide

  47. IPv6 over IPv6 underlay
    47
    • All NBMA addresses should be IPv6
    • IKEv2 should be used for IPsec
    • Tunnel mode should be gre multipoint ipv6
    • All other configuration is similar to IPv6 over IPv4 underlay

    View Slide

  48. Additional Resources
    48
    • DMVPN Explained
    • DMVPN Phase 3
    • NHRP Feature Guide
    • Cisco DMVPN: Choosing The Right Routing Protocol
    • Dynamic Multipoint IPsec VPNs (Using Multipoint GRE/NHRP to Scale
    IPsec VPNs) White Paper
    • DMVPN Overview
    • DMVPN Configuration Guide

    View Slide

  49. Thank you

    View Slide
