DEVNET-3627: Make Python applications faster with asyncio!

DEVNET-3627: Make Python applications faster with asyncio!

Have you ever needed to run some commands with Python across multiple network devices? Or may be you needed to call a slow API tens or hundreds of times and the script running time was approaching minutes or even hours? Are you curious how to achieve concurrency in Python? If you answered yes to any of these questions, then this session is for you!
This session will explain what concurrency is and what problems it solves. Advantages and disadvantages of main approaches to achieve concurrency in Python will be discussed. Python 3.5 built-in library asyncio will be introduced and some examples of use-cases for network engineers will be shown and explained.

Dmitry Figol

June 12, 2018
Tweet

More Decks by Dmitry Figol

Other Decks in Technology

Transcript

  1. #CLUS

    View Slide

  2. #CLUS
    Dmitry Figol, WW Enterprise Sales
    Systems Engineer - Programmability
    DEVNET-3627
    Make Python
    applications faster
    with asyncio!

    View Slide

  3. © 2018 Cisco and/or its affiliates. All rights reserved. Cisco Public
    #CLUS DEVNET-3627
    About me
    @dmfigol
    dmfigol
    dmfigol.me
    dmfigol
    dmfigol

    View Slide

  4. © 2018 Cisco and/or its affiliates. All rights reserved. Cisco Public
    #CLUS DEVNET-3627
    • Is Python slow?
    • Concurrency and parallelism in Python: threads, multiple processes,
    async
    • High-level overview of asyncio library building blocks
    • asyncio examples in networking: asynchronous REST and SSH calls
    Agenda

    View Slide

  5. Is Python slow?

    View Slide

  6. © 2018 Cisco and/or its affiliates. All rights reserved. Cisco Public
    #CLUS DEVNET-3627
    Python speed
    • Everyone says Python is slow, but …
    • Is it really?
    • What is the bottleneck?
    • 95% it is not CPU, it is input/output (I/O) – database queries, network
    • If Python was fast, it wouldn’t really help
    Takeaway: Python is actually slow, but it does not matter

    View Slide

  7. © 2018 Cisco and/or its affiliates. All rights reserved. Cisco Public
    #CLUS DEVNET-3627
    Python implementations
    There are different Python implementations:
    • CPython (default)
    • IronPython
    • PyPy – try this if you want faster Python!
    But this talk is about I/O

    View Slide

  8. © 2018 Cisco and/or its affiliates. All rights reserved. Cisco Public
    #CLUS DEVNET-3627
    I/O in Python - scenario
    • A network engineer just recently learned Python and how to interact
    with network devices using SSH or API
    • Needs to collect memory statistics and ARP table
    • One week of hacking and success! Working great for one device
    • ..but need to do the same for 1000 devices
    • Let’s add for loop and it should be fine… right?
    RIGHT??

    View Slide

  9. Demo – sequential SSH to network devices
    with netmiko

    View Slide

  10. © 2018 Cisco and/or its affiliates. All rights reserved. Cisco Public
    #CLUS DEVNET-3627
    I/O is what is really slow
    Especially multiplied by 100..10000 times

    View Slide

  11. © 2018 Cisco and/or its affiliates. All rights reserved. Cisco Public
    #CLUS DEVNET-3627
    Introducing concurrency
    • Concurrency – doing multiple things at once
    • Typical approaches:
    • Threads
    • Multiple processes
    • Asynchronous programming (async)

    View Slide

  12. © 2018 Cisco and/or its affiliates. All rights reserved. Cisco Public
    #CLUS DEVNET-3627
    Threading in Python
    • Running multiple threads (functions calls) at the same time
    • Shared state
    • Low overhead
    • Thread switching at random time by the scheduler
    • Global Interpreter Lock (GIL) – only one thread can run at the same time
    • Because of GIL, makes sense only for I/O heavy applications
    • Easy to add, hard to get right – shared state can cause racing conditions
    • Requires locks and queues to be safe, but most importantly experience

    View Slide

  13. Demo – SSH to network device with netmiko
    and threads

    View Slide

  14. © 2018 Cisco and/or its affiliates. All rights reserved. Cisco Public
    #CLUS DEVNET-3627
    Multiprocessing in Python
    • Spawns multiple Python interpreters as forks
    • Higher overhead than threads
    • Harder to communicate between processes
    • Higher memory footprint
    • Effective to distribute CPU heavy load across several cores

    View Slide

  15. Python asyncio

    View Slide

  16. © 2018 Cisco and/or its affiliates. All rights reserved. Cisco Public
    #CLUS DEVNET-3627
    Asynchronous programming
    • Intuition: when I am doing I/O and waiting for the response, I could
    do something else instead!
    • By default, runs a single thread and single process
    • Python 3.4 introduced new standard library: asyncio
    • Python 3.5 introduced new syntax: async/await
    • Completely different programming style which relies on Coroutines,
    Tasks and Event Loop

    View Slide

  17. © 2018 Cisco and/or its affiliates. All rights reserved. Cisco Public
    #CLUS DEVNET-3627
    Coroutines predecessor - generators
    • Let’s discuss generators first
    • Generator is a function that produces a sequence of results instead
    of a single value
    • Uses yield statement
    • yield produces a value and suspends the function
    • Calling generator does not start running the function

    View Slide

  18. © 2018 Cisco and/or its affiliates. All rights reserved. Cisco Public
    #CLUS DEVNET-3627
    Coroutines (pre-asyncio)
    • Bare yield is used
    • This allows the function to consume values
    • These functions are called coroutine functions
    • Objects returned by coroutine functions are called coroutines
    • Coroutines consume values
    • Generators produce values

    View Slide

  19. © 2018 Cisco and/or its affiliates. All rights reserved. Cisco Public
    #CLUS DEVNET-3627
    Coroutines (asyncio)
    • Python 3.5 - new async/await syntax for asyncio coroutines
    • await is similar to bare yield – it expects values from I/O (e.g. HTTP
    response)
    • I/O places in the code are marked explicitly using await
    • await is used only in asyncio coroutines marked by async def
    • Usual functions can’t call async functions, only async functions can call
    async functions
    How to call async functions?

    View Slide

  20. © 2018 Cisco and/or its affiliates. All rights reserved. Cisco Public
    #CLUS DEVNET-3627
    Task/Future (asyncio)
    • Future – an object that wraps coroutine
    • Returned immediately
    • Placeholder for the future result or exception
    • Can be cancelled if required
    • Task – subclass of Future
    • Has some extra methods to get the current stack
    • Has some differences how cancellation is handled compared to Future
    • The main primitive in asyncio world

    View Slide

  21. © 2018 Cisco and/or its affiliates. All rights reserved. Cisco Public
    #CLUS DEVNET-3627
    Event loop (asyncio)
    • Event loop – is a loop that executes tasks
    • Different ways to mix tasks, schedule, start and stop them
    • Directly impacts the performance
    • Different loop implementations:
    • asyncio base loop – default
    • uvloop – speed increase x2-x4
    • trio event loop
    • Other loops

    View Slide

  22. Demo – asynchronous SSH to network
    devices with netdev

    View Slide

  23. Demo – asynchronous HTTP using asyncio
    and aiohttp

    View Slide

  24. © 2018 Cisco and/or its affiliates. All rights reserved. Cisco Public
    #CLUS DEVNET-3627
    Real world use-case
    • Working on automated lab management system
    • Got 5 racks of gear, 100 devices, 700+ cables

    View Slide

  25. #CLUS © 2018 Cisco and/or its affiliates. All rights reserved. Cisco Public
    DEVNET-3627

    View Slide

  26. © 2018 Cisco and/or its affiliates. All rights reserved. Cisco Public
    #CLUS DEVNET-3627
    Real world use-case (cont.)
    • 2 weeks for racking and stacking
    • Did we actually do cabling correctly?
    • Wrote a script to check that using CDP

    View Slide

  27. Demo – compare actual cabling from desired
    cabling using CDP output asynchronously

    View Slide

  28. Wrap-up

    View Slide

  29. © 2018 Cisco and/or its affiliates. All rights reserved. Cisco Public
    #CLUS DEVNET-3627
    Problems with asyncio
    • Documentation has room for improvement
    • Not many good learning resources available
    • API is not clean
    • Paradigm change
    • Not mature yet
    • Hard to migrate from existing codebase
    • Requires different library for any I/O operation: aiohttp (HTTP client),
    asyncssh and netdev (SSH), aiofiles (files read/write), etc.

    View Slide

  30. © 2018 Cisco and/or its affiliates. All rights reserved. Cisco Public
    #CLUS DEVNET-3627
    Summary: Why use asyncio
    1. Explicit control for task switching using await keyword
    2. Less overhead and slightly faster than threads
    3. Great scalability approach
    4. Not hard for simple use-cases

    View Slide

  31. © 2018 Cisco and/or its affiliates. All rights reserved. Cisco Public
    #CLUS DEVNET-3627
    Get Started with asyncio
    • Raymond Hettinger - Keynote on Concurrency - PyBay 2017
    • Miguel Grinberg - Asynchronous Python for the Complete Beginner -
    PyCon 2017
    • Łukasz Langa - Thinking In Coroutines - PyCon 2016
    • Armin Ronacher – I don’t understand Python’s Asyncio
    • asyncio documentation
    • Nathaniel J Smith - Python Concurrency for Mere Mortals - Pyninsula #10
    • Libraries: aiohttp, asyncssh, netdev

    View Slide

  32. © 2018 Cisco and/or its affiliates. All rights reserved. Cisco Public
    #CLUS DEVNET-3627
    Code
    https://github.com/dmfigol/devnet-3627.git

    View Slide

  33. © 2018 Cisco and/or its affiliates. All rights reserved. Cisco Public
    #CLUS DEVNET-3627
    Cisco Webex Teams
    Questions?
    Use Cisco Webex Teams (formerly Cisco Spark)
    to chat with the speaker after the session
    Find this session in the Cisco Events App
    Click “Join the Discussion”
    Install Webex Teams or go directly to the team space
    Enter messages/questions in the team space
    How
    Webex Teams will be moderated
    by the speaker until June 18, 2018.
    cs.co/ciscolivebot#DEVNET-3627
