Creating Cloud Native Buildpacks

Buildpacks have been the successful method for creating container images for a decade at Heroku and Cloud Foundry, before Dockerfiles existed. Cloud Native Buildpacks https://buildpacks.io are the latest set of tools and buildpacks to bring Buildpack methods for creating fast, secure images from your application source code.

In this talk I look at how to create new Cloud Native Buildpacks, how to test them, and how to distribute Builders for development teams to start using your buildpacks.

Transcript

1. Title Text
   Body Level One
   Body Level Two
   Body Level Three
   Body Level Four
   Body Level Five
   Creating

   Cloud Native Buildpacks
   Cloud Foundry Summit Hague 2019
   Dr Nic Williams @drnic


   View Slide

2. @drnic
   Nothing should change for CF users
   EXCEPT
   This is about future v3 buildpacks
   WARNING


   View Slide

3. @drnic
   History
   v2 - Supply and Finalize
   CF own buildpacks evolved API
   Cloud Foundry had no buildpacks
   v1 - Heroku Buildpacks
   Borrowed API; offline buildpacks
   Ɲ
   v3 - Cloud Native Buildpacks
   Heroku and CF work together
   CNCF Incubator project
   Buildpacks are going everywhere


   View Slide

4. Cloud Foundry buildpacks thanks to…


   View Slide

5. View Slide

6. @drnic
   Example
   NodeJS
   $ pack build starkandwayne/sample-app-nodejs
   [detector] ======== Results ========
   [detector] pass: Node Engine Buildpack
   [detector] pass: Yarn Buildpack
   …
   [builder] -----> Node Engine Buildpack 0.0.26
   [builder] Node Engine 10.16.2:
   [builder] Downloading from …
   …
   [builder] Process types:
   [builder] web: yarn start
   $ docker run -ti -p 8080:8080 \
   starkandwayne/sample-app-nodejs


   View Slide

7. @drnic
   Example
   Spring
   $ pack build starkandwayne/sample-app-java
   ===> DETECTING
   [detector] skip: org.cloudfoundry.archiveexpanding@1.0.0-RC02
   [detector] pass: org.cloudfoundry.openjdk@1.0.0-RC02
   [detector] pass: org.cloudfoundry.buildsystem@1.0.0-RC02
   [detector] pass: org.cloudfoundry.jvmapplication@1.0.0-RC02
   [detector] pass: org.cloudfoundry.tomcat@1.0.0-RC02
   [detector] pass: org.cloudfoundry.springboot@1.0.0-RC02
   [detector] skip: org.cloudfoundry.jdbc@1.0.0-RC02
   [detector] skip: org.cloudfoundry.jmx@1.0.0-RC02
   [detector] Resolving plan... (try #1)
   [detector] Success! (7)
   …
   [builder] Cloud Foundry OpenJDK Buildpack 1.0.0-RC02
   [builder] OpenJDK JDK 11.0.4: Contributing to layer
   $ docker run -ti -p 8080:8080 \
   starkandwayne/sample-app-java


   View Slide

8. @drnic
   Deploy CF
   $ docker push starkandwayne/sample-app-nodejs
   $ cf push myapp \
   -o starkandwayne/sample-app-nodejs \
   -k 1536M
   $ cf logs my-node-app --recent


   View Slide

9. @drnic
   Buildpack
   API
   bin/detect
   Could this buildpack help this app?
   What requirements did we learn?
   ?
   bin/build
   Install dependencies
   Setup configuration
   Processes to launch
   #


   View Slide

10. @drnic
    Builder
    $ pack inspect-builder cloudfoundry/cnb
    Run Images:
    cloudfoundry/run:full-cnb
    Buildpacks:
    org.cloudfoundry.node-engine
    org.cloudfoundry.npm
    org.cloudfoundry.yarn
    org.cloudfoundry.python
    org.cloudfoundry.pip
    …


    View Slide

11. @drnic
    Ordered
    Groups
    $ pack inspect-builder cloudfoundry/cnb
    …
    Group #2:
    org.cloudfoundry.node-engine@0.0.44
    org.cloudfoundry.yarn@0.0.23
    Group #3:
    org.cloudfoundry.node-engine@0.0.44
    org.cloudfoundry.npm@0.0.28
    Group #4:
    org.cloudfoundry.python@0.0.19
    org.cloudfoundry.pipenv@0.0.13 (optional)
    org.cloudfoundry.pip@0.0.19
    …


    View Slide

12. @drnic
    1, 2, 3, 4, 5, 6, 7, …, 15
    FIZZ BUZZ
    1, 2, fizz, 4, buzz, fizz, 7, …, fizzbuzz
    https://github.com/starkandwayne/fizzbuzz-cnb-builder


    View Slide

13. $ echo 1 > Count
    $ pack build myapp --builder fizzbuzz
    $ docker run myapp
    1
    $ echo 3 > Count
    $ pack build myapp --builder fizzbuzz
    $ docker run myapp
    fizz
    $ echo 15 > Count
    $ pack build myapp --builder fizzbuzz
    $ docker run myapp
    fizzbuzz
    https://github.com/starkandwayne/fizzbuzz-cnb-builder


    View Slide

14. @drnic
    FizzBuzz
    Buildpack
    bin/detect
    Does this app contain Count?
    ?
    bin/build
    Create executable to print Count
    or fizz, buzz, or fizzbuzz
    #


    View Slide

15. # bin/detect
    [ -f Count ]] || { echo "No Count file"; exit 1; }
    # bin/build
    cp -r $buildpack_dir/layer/* $layer_dir/
    !"" fizzbuzz
    # $"" bin
    # $"" display-count
    !"" fizzbuzz.toml
    $"" launch.toml
    https://github.com/starkandwayne/fizzbuzz-cnb-builder


    View Slide

16. # launch.toml
    [[processes]]
    command = "display-count"
    type = "web"
    # fizzbuzz.toml
    launch = true
    # fizzbuzz/bin/display-count
    #!/bin/bash
    count=$(cat Count)
    if [[ $(( $count % 15 )) == "0" ]]; then
    echo "fizzbuzz"
    elif [[ $(( $count % 5 )) == "0" ]]; then
    echo "buzz"
    elif [[ $(( $count % 3 )) == "0" ]]; then
    echo "fizz"
    else
    echo $count
    fi%
    https://github.com/starkandwayne/fizzbuzz-cnb-builder
    layer metadata layer contents


    View Slide

17. $ pack build app \
    --buildpack path/to/fizzbuzz \
    --path to/app
    ===> DETECTING
    [detector] ======== Results ========
    [detector] pass: fizzbuzz-standalone@1.0.0
    [detector] Resolving plan... (try #1)
    [detector] Success! (1)
    ===> BUILDING
    [builder] ---> FizzBuzz Buildpack
    ===> EXPORTING
    [exporter] *** Images:
    [exporter] …playtime:latest - succeeded


    View Slide

18. @drnic
    Print
    Message
    Buildpack
    bin/detect
    Does this app contain Message?
    ?
    bin/build
    Create executable to print Message
    #


    View Slide

19. $ rm Count
    $ echo "Hello World" > Message
    $ pack build myapp --builder fizzbuzz
    $ docker run myapp
    Hello World
    $ rm Count
    $ rm Message
    $ pack build myapp --builder fizzbuzz



    View Slide

20. # bin/detect
    [ -f Message ]] || { echo "No Message file"; exit 1; }
    # bin/build
    cp -r $buildpack_dir/layer/* $layer_dir/
    !"" launch.toml
    !"" print-message
    # !"" bin
    # # !"" display-message
    # # $"" show-message-twice
    # $"" profile.d
    # $"" message.sh
    $"" print-message.toml


    View Slide

21. $ pack build app \
    --buildpack path/to/print-message \
    --path to/app
    ===> DETECTING
    [detector] ======== Results ========
    [detector] pass: print-message@1.0.0
    [detector] Resolving plan... (try #1)
    [detector] Success! (1)
    ===> BUILDING
    [builder] ---> Print Message Buildpack
    ===> EXPORTING
    [exporter] *** Images:
    [exporter] …playtime:latest - succeeded


    View Slide

22. @drnic
    FizzBuzz
    Builder
    # builder.toml
    [[buildpacks]]
    id = "fizzbuzz"
    uri = "buildpacks/fizzbuzz"
    [[buildpacks]]
    id = "print-message"
    uri = "buildpacks/print-message"
    …


    View Slide

23. @drnic
    FizzBuzz
    Builder
    # builder.toml
    …
    [[order]]
    [[order.group]]
    id = "fizzbuzz"
    [[order]]
    [[order.group]]
    id = "print-message"
    …


    View Slide

24. @drnic
    FizzBuzz
    Builder
    # builder.toml
    …
    [stack]
    id = "io.buildpacks.stacks.bionic"
    build-image = "cloudfoundry/build:base-cnb"
    run-image = "cloudfoundry/run:base-cnb"


    View Slide

25. @drnic
    FizzBuzz
    Builder
    $ pack create-builder fizzbuzz -b builder.toml
    Creating builder fizzbuzz from
    build-image cloudfoundry/build:base-cnb
    $ pack build myapp
    --builder fizzbuzz
    Count app Message app
    Runnable OCI/docker image


    View Slide

26. @drnic
    FizzBuzz
    Builder
    $ pack inspect-builder fizzbuzz
    Run Images:
    cloudfoundry/run:base-cnb
    Buildpacks:
    com.starkandwayne.fizzbuzz
    com.starkandwayne.print-message
    Detection Order:
    Group #1:
    com.starkandwayne.fizzbuzz@1.0.0
    Group #2:
    com.starkandwayne.print-message@1.0.0


    View Slide

27. @drnic
    Example
    NodeJS
    $ pack build starkandwayne/sample-app-nodejs
    [detector] ======== Results ========
    [detector] pass: Node Engine Buildpack
    [detector] pass: Yarn Buildpack
    …
    [builder] -----> Node Engine Buildpack 0.0.26
    [builder] Node Engine 10.16.2:
    [builder] Downloading from …
    …
    [builder] Process types:
    [builder] web: yarn start
    $ docker run -ti -p 8080:8080 \
    starkandwayne/sample-app-nodejs


    View Slide

28. Nothing should change for CF users
    START MIGRATING
    Cloud Native (v3) buildpacks
    COMING SOON


    View Slide

29. @drnic
    CONTINUE
    TO FIZZBUZZ
    https://github.com/starkandwayne/fizzbuzz-cnb-builder
    https://buildpacks.io/docs/create-buildpack/


    View Slide
