1. Break On Through To the Other Side adb_ >
2. http://eyal.fr Eyal Lezmy
3. Join us!
4. bit.ly/adb-chill Slides >
5. How adb works > Some adb commands > The internals > Dev on the adb project > The Android dev tools >
6. alias adb=“Android Debug Bridge”
7. A command line tool To communicate with Android devices physical or emulators
8. Part of the SDK on the platform-tools directory 2 versions distributed Stable & Preview channel
9. How adb works
10. adb daemon adb client adb server
11. adb client
12. adb client
13. adb_ > adb client
14. adb daemon
15. adb daemon
16. adb daemon Started at boot As background process Executes commands on the device
17. adb server
18. adb daemon adb client adb server
19. adb daemon adb client adb server
20. A practical case
21. adb client
22. adb client Is there an ADB Server?
23. adb client adb server Start adb server
24. adb client adb server Port 5037
25. adb client adb server Scan for Android devices and emulators
26. adb client adb server localhost 5555 5557 5681
27. adb client adb server localhost 5555 5557 5681 Is there a device bound here?
28. adb client adb server localhost 5555 5557 5681 Is there a device bound here?
29. adb client adb server localhost 5555 5557 5681 Is there a device bound here?
30. adb client adb server localhost adb daemon 5557 Android Studio Emulator
31. adb client adb server localhost adb daemon 5557 Android Studio Emulator Open a connection to the device
32. adb client adb server USB Interface
33. adb client adb server USB Interface /dev/… adb daemon Nexus 6P (USB)
34. adb client adb server adb daemon Nexus 6P adb daemon Network device adb daemon AS Emulator
35. adb client adb server adb daemon Nexus 6P adb daemon Network device adb daemon AS Emulator
36. Some adb commands
37. adb tcpip 5555 > Enable wireless debugging adb connect <device-ip> >
38. adb usb > Disable wireless debugging
39. adb tcpip 5555 >
40. adb tcpip 5555 > ADB Server asks the Daemon to enable the network connection “tcpip:5555”
41. adb tcpip 5555 > ADB Server asks the Daemon to enable the network connection The daemon sets a system property setprop service.adb.tcp.port 5555
42. adb tcpip 5555 > ADB Server asks the Daemon to enable the network connection The daemon sets a system property ADB Daemon closes itself exit(1)
43. adb tcpip 5555 > ADB Server asks the Daemon to enable the network connection The daemon sets a system property ADB Daemon closes itself The system restarts automatically ADB Daemon service adbd /sbin/adbd
44. adb tcpip 5555 > ADB Server asks the Daemon to enable the network connection The daemon sets a system property ADB Daemon closes itself The system restarts automatically ADB Daemon The Daemon will read the property at start and will listen to this port getprop service.adb.tcp.port
45. adb tcpip 5555 > setprop service.adb.tcp.port 5555 # stop adbd # start adbd #
46. adb tcpip 5555 > setprop persists.adb.tcp.port 5555 # stop adbd # start adbd # Remains after reboot
47. adb devices -l > 192.168.63.101:5555 device product:vbox86p model:myGenymotionNexus5 device:vbox86p F5AZFG013292 device usb:336592896X product:WW_Z00A model:ASUS_Z00AD device:Z00A HT4CNJT00728 device usb:336592896X product:volantis model:Nexus_9 device:flounder Detailed device list
48. adb -e shell > Filter the type of device Emulator or network device adb -d shell > USB device
49. adb -H <ip> -P <port> devices > Access a remote ADB Server
50. adb -H 10.5.0.5 -P 5037 devices >
51. adb client adb -H 10.5.0.5 -P 5037 devices >
52. adb client adb server 5037 adb -H 10.5.0.5 -P 5037 devices > Device farm server 10.5.0.5
53. adb client adb server Samsung S6 Genymotion Kitkat Pixel 2 XL 5037 adb -H 10.5.0.5 -P 5037 devices > Device farm server 10.5.0.5
54. adb reverse >
55. adb reverse > Backend Server Your app localhost localhost 2323 8181
56. adb reverse tcp:2323 tcp:8181 > Backend Server Your app localhost localhost 2323 8181
57. adb reverse tcp:2323 tcp:8181 > Backend Server Your app localhost localhost 2323 8181
58. adb reverse > Secured Backend Server Your app VPN
59. adb reverse > Secured Backend Server Your app VPN Proxy Proxy Setting
60. adb shell settings put global http_proxy localhost:3333 > adb reverse tcp:3333 tcp:3128 > docker run --name squid \ --publish 127.0.0.1:3128:3128 \ --volume $HOME/squid.conf:/etc/squid3/squid.conf \ --volume /tmp/squid/cache:/var/spool/squid3 \ --volume /tmp/squid/cache:/var/log/squid3 \ sameersbn/squid:3.3.8-12 >
61. adb >
62. adb > ... -p <name or path> - simple product name like 'sooner', or a relative/absolute path to a product out directory like 'out/target/product/sooner'. If -p is not specified, the ANDROID_PRODUCT_OUT environment variable is used, which must be an absolute path.
63. adb > ... -p <name or path> - simple product name like 'sooner', or a relative/absolute path to a product out directory like 'out/target/product/sooner'. If -p is not specified, the ANDROID_PRODUCT_OUT environment variable is used, which must be an absolute path. Sooner??
65. Andy Rubin Holy crap, I guess we’re not going to ship that phone. ” “
66. The adb internals
67. adb daemon adb client adb server
68. adb daemon adb client adb server C-S S-D
69. Client-Server
70. adb shell ls >
71. adb shell ls > adb client adb server
72. adb shell ls > adb client adb server What’s your protocol version?
73. adb client adb server adb shell ls > What’s your protocol version? host:version
74. adb client adb server adb shell ls > It’s version 36 host:version OKAY 36
75. adb client adb server adb shell ls > host:version OKAY 36
76. adb client adb server adb shell ls > host:transport-any I want to talk to any kind of device
77. adb client adb server adb shell ls > host:transport-any OKAY OKAY!
78. adb client adb server adb shell ls > shell:ls Please execute the shell service with the parameter “ls”
79. adb client adb server adb shell ls > shell:ls “ls output” cache charge config ...
80. adb client adb server adb shell ls > host:version OKAY 36 host:transport-any OKAY shell:ls “ls output”
81. Service execution Startup Device selection
82. adb devices > adb server version (32) doesn't match this client (36); killing… adb devices > adb server is out of date. killing...
83. adb > At device selection host:transport-any
84. adb > adb -s <serial> > At device selection adb -d > adb -e > host:transport:<serial> host:transport-any host:transport-usb host:transport-local
85. adb client Requests a service execution
86. adb client adb server Requests a service execution Executes host services
87. adb daemon adb client adb server Requests a service execution Executes host services Executes local services
88. host:version Get the ADB Server version host:kill Kill the ADB Server host:devices List the connected devices host:devices-l List the connected devices with details host:track-devices Track the list of the connected devices host:transport* Target a device to interact with Some host services
89. shell:<command> Run a shell command shell: Open an interactive shell session remount: Remount the filesystem in r-w mode framebuffer: Get framebuffer snapshots jdwp:<pid> Connects to the JDWP thread of a process track-jdwp Track the list of all processes in debug sync: Specific service used for push & pull Some local services
90. Server-Daemon
91. What the message looks like?
92. amessage
93. amessage data
94. amessage data struct amessage { unsigned command; /* command identifier constant */ unsigned arg0; /* first argument */ unsigned arg1; /* second argument */ unsigned data_length; /* length of payload (0 is allowed) */ unsigned data_crc32; /* crc32 of data payload */ unsigned magic; /* command ^ 0xffffffff */ };
95. amessage data struct amessage { unsigned command; /* command identifier constant */ unsigned arg0; /* first argument */ unsigned arg1; /* second argument */ unsigned data_length; /* length of payload (0 is allowed) */ unsigned data_crc32; /* crc32 of data payload */ unsigned magic; /* command ^ 0xffffffff */ }; The verb of the action
96. amessage data struct amessage { unsigned command; /* command identifier constant */ unsigned arg0; /* first argument */ unsigned arg1; /* second argument */ unsigned data_length; /* length of payload (0 is allowed) */ unsigned data_crc32; /* crc32 of data payload */ unsigned magic; /* command ^ 0xffffffff */ }; The arguments of the action
97. amessage data struct amessage { unsigned command; /* command identifier constant */ unsigned arg0; /* first argument */ unsigned arg1; /* second argument */ unsigned data_length; /* length of payload (0 is allowed) */ unsigned data_crc32; /* crc32 of data payload */ unsigned magic; /* command ^ 0xffffffff */ }; The size of the data
99. adb connect <ip:port> >
100. adb daemon adb server adb connect <ip:port> >
101. adb daemon adb server adb connect <ip:port> > CNXN, 0x01000000, 256K
102. adb daemon adb server adb connect <ip:port> > CNXN, 0x01000000, 256K Command Arg 1 Arg 2
103. adb daemon adb server adb connect <ip:port> > CNXN, 0x01000000, 256K CONNECT command
104. adb daemon adb server adb connect <ip:port> > CNXN, 0x01000000, 256K Protocol version
105. adb daemon adb server adb connect <ip:port> > CNXN, 0x01000000, 256K Max payload size
106. adb daemon adb server adb connect <ip:port> > CNXN, 0x01000000, 256K device::ro.product...
107. adb daemon adb server adb connect <ip:port> > CNXN, 0x01000000, 256K device::ro.product... Command Arg 1 Arg 2
108. adb daemon adb server adb connect <ip:port> > CNXN, 0x01000000, 256K device::ro.product... Data
109. adb daemon adb server adb connect <ip:port> > CNXN, 0x01000000, 256K device::ro.product... Device identity string
110. adb shell ls >
111. adb daemon adb server adb shell ls >
112. adb daemon adb server adb shell ls > OPEN, server-id, 0, shell:ls
113. adb daemon adb server adb shell ls > OPEN, server-id, 0, shell:ls Command Arg1 Arg2 Data
114. adb daemon adb server adb shell ls > OPEN, server-id, 0, shell:ls The ADB service to execute
115. adb daemon adb server adb shell ls > OPEN, server-id, 0, shell:ls OKAY, daemon-id, server-id
116. adb daemon adb server adb shell ls > OPEN, server-id, 0, shell:ls OKAY, daemon-id, server-id WRITE, daemon-id, server-id “DATA”
117. adb daemon adb server adb shell ls > OPEN, server-id, 0, shell:ls OKAY, daemon-id, server-id WRITE, daemon-id, server-id “DATA” OKAY, server-id, daemon-id
118. adb daemon adb server adb shell ls > OPEN, server-id, 0, shell:ls OKAY, daemon-id, server-id WRITE, daemon-id, server-id “DATA” OKAY, server-id, daemon-id WRITE, daemon-id, server-id “DATA” CLOSE, daemon-id, server-id
119. adb daemon adb server adb shell ls > OPEN, server-id, 0, shell:ls OKAY, daemon-id, server-id WRITE, daemon-id, server-id “DATA” OKAY, server-id, daemon-id WRITE, daemon-id, server-id “DATA” OKAY, server-id, daemon-id CLOSE, server-id, daemon-id CLOSE, daemon-id, server-id
120. Why ADB is now faster?
124. data (256KB) amessage Now
125. data (256KB) amessage amessage data (4KB) Now Before
126. adb daemon adb server WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA”
127. adb daemon adb server WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA” WRITE, “256KB DATA” OKAY OKAY WRITE, “256KB DATA”
128. Develop on the ADB project
129. Configure your environment Fetch the source code Make it! Build your own ADB
130. repo init \ -u https://android.googlesource.com/platform/manifest \ -b master repo sync -c --force-sync source build/envsetup.sh lunch make -j24 adb > > > > >
131. adbd adb libadb
132. adb The client host binary Bundle in the Android SDK The one you use everyday Output path ./out/host/<your-platform>/bin/adb
133. adbd The device’s daemon binary Bundle in the Android OS The one you use everyday Maybe without noticing
134. Adb static library libadb Contains the common files
135. Originally written in C
136. Aimed to be written in C++
137. Actually written in C+
138. Actually written in C~++
139. Actually written in C++--
140. ADB sources are ubiquitous
141. ADB sources are ubiquitous
142. ADB sources are ubiquitous adb daemon adb client adb server
143. ADB sources are ubiquitous adb daemon adb client adb server
144. adb client adb server adb daemon Nexus 6P adb daemon Network device adb daemon AS Emulator adb client adb client
145. #if ADB_HOST ... #else // !ADB_HOST ... #endif // ADB_HOST
146. #if ADB_HOST ... #else // !ADB_HOST ... #endif // ADB_HOST 62 times
147. #if defined(_WIN32) ... #endif
148. #if defined(_WIN32) ... #endif 51 times
149. adb kill-server > export ADB_TRACE=adb > Debug ADB adb start-server >
150. adb devices > ... adb I 39295 1708488 adb_client.cpp:135] _adb_connect:host:devices adb I 39295 1708488 adb_io.cpp:99] writex: fd=3 len=16 30303063686f73743a64657669636573 000chost:devices ... ADB Client logs tail -f /tmp/adb.log Linux tail -f $TMPDIR/adb.*.log Mac ADB Server logs > >
151. ADB & The Android Dev Tools
152. Android Studio
153. repo init \ -u https://android.googlesource.com/platform/manifest \ -b studio-master-dev repo sync -c --force-sync cd ./tools/idea > > > Get the source code
154. Android Studio does not use adb
155. Android Studio does not use adb…almost
156. Android Studio uses ddmlib
157. ddmlib A Java library Behaves as an ADB Client Part of the AOSP tools/base/ddmlib
158. ddmlib does not use adb
159. ddmlib does not use adb…almost
160. ddmlib adb server adb daemon Nexus 6P adb daemon Network device adb daemon AS Emulator 5037
161. What’s the difference between ddmlib and adb binary?
162. What’s the difference between ddmlib and adb binary? one of s
163. What’s the difference between ddmlib and adb binary? one of s The backward compatibility
164. adb binary ddmlib Latest version only From ADB 1.0.20
165. adb binary ddmlib Latest version only From ADB 1.0.20 (October 2008)
166. ddmlib as library Maintained by Google Open source Many thousands of daily users Still need the adb binary
167. ddmlib as library Maintained by Google Open source Many thousands of daily users Still need the adb binary Possibly a good tool for your project
168. repositories { google() } dependencies { implementation 'com.android.tools.ddms:ddmlib:26.1.0' }
169. The Android Gradle Plugin
170. repo init \ -u https://android.googlesource.com/platform/manifest \ -b gradle_3.0.0 repo sync -c --force-sync cd ./tools/base/build-system/ > > > Get the source code
171. The Android Gradle Plugin uses ddmlib
172. The Android Gradle Plugin uses ddmlib Like Android Studio
173. The Android Gradle Plugin uses ddmlib How does ?
174. When there is an interaction with a device Install an APK Launch instrumented tests Get devices information
175. Manages the list of connected devices Interacts with the device through ddmlib DeviceProvider ConnectedDevice
176. gradlew <yourTask> --debug > Make ddmlib verbose from the build.gradle import com.android.ddmlib.DdmPreferences DdmPreferences.setLogLevel("verbose")
177. Make ddmlib verbose from the build.gradle V/ddms: execute: running pm install-create -r -S 945819 V/ddms: execute: running pm install-write -S 945819 26732 0_binocle-flavor1-debug - V/ddms: execute: running pm install-commit 1802739235 … V/ddms: execute: running am instrument -w -r com.genymotion.binocle.test/android.test.InstrumentationTestRunner V/InstrumentationResultParser: INSTRUMENTATION_STATUS: numtests=5 V/InstrumentationResultParser: INSTRUMENTATION_STATUS: stream= V/InstrumentationResultParser: com.genymotion.binocle.test.TestBattery: V/InstrumentationResultParser: INSTRUMENTATION_STATUS: id=InstrumentationTestRunner V/InstrumentationResultParser: INSTRUMENTATION_STATUS: test=testBatteryWarning …
178. Inject ADB options from the build.gradle for all the tasks android.adbOptions { timeOutInMs 5000 // 5 seconds installOptions “-g” }
179. Inject ADB options from the build.gradle for a single task android.testVariants.all { variant -> variant.connectedInstrumentTest.installOptions = ["-g"] }
180. Thank you! http://eyal.fr bit.ly/adb-chill Slides > >
