AWSをフル活用するサービスを保護するセキュリティの考え方とは / Secure with Cloud One for freee

AWSをフル活用するサービスを保護するセキュリティの考え方とは / Secure with Cloud One for freee

AWS Summit Online 2022 で登壇した際の資料です。
Trend Micro Cloud Oneを用いたAWS上のservice platformの守り方についてのお話です。

Eiji Sugiura

June 08, 2022
Tweet

More Decks by Eiji Sugiura

Other Decks in Technology

Transcript

  1.   2 2017-12 freeeにjoinし、CSIRT専属engineerとして、incident response、および、securityを担保する仕組みづくりを担当。 2020−07 product securityを専門とするPSIRT発足に伴い、 blue teamとして活動中

    その昔、jazz Guitarを弾けましたが、今は見る影なし 妻と1男1女の4人家族 杉浦 英史 PSIRT 機関長 Eiji Sugiura プロフィール画像の トリミング方法
  2.   9 freee PSIRT? Cloud One with Amazon EC2 Cloud

    One with Amazon EKS Cloud One with AWS 本日のアジェンダ 01 02 03 04
  3.   11 Defence In Depth 多層防御 外部からの攻撃 WAF、IPS、AntiMalware で検知 内部からの攻撃

    EDR、NGFW で検知 侵入後の水平展開、奪取 Risk Based Authenication CloudTrail、GuardDuty で検知 Log 集約 + Alert 発砲 + 解析 前後関係の把握、被害範囲の特定 DevSecOps Scanner で検知
  4.   12 日々の運用 freee PSIRT OODA loop Security Weekly もくもく会


    Incident Handling Kaizen hour Observe 担当者が集まって分析 気になるものは一緒に探ってみる 世話を焼いていくスタイル Decide CSIRT/PSIRT で情報共有 検知状況を解釈し、対処方針を決める あえて共有 理想ドリブン Act 改善してみる かっとなって、しゅっとやる Hack Everything Orient もしものときには 足りないものに気付く 失敗して攻めよう
  5. 14 Cloud One Workload Security with Amazon EC2 3年前の構成 AWS

    WAF EC2 instances Anti-Malware Intrusion Prevention Integrity Monitoring Log Inspection VPC flow log resolver log ALB access log application log GuardDuty CloudTrail Workload Security Agent
  6. 15 Amazon EC2 から Amazon EKS への移行 Service の物量に対応できない Service

    は動いてはいた security sensor の整備もひと段落 将来の需要に対応できない Micro-service 化に伴い、環境の数は増えてい く SREとApplication 開発者の融合 いろいろ遅い deploy が遅い、Auto scaling が遅い instance だと、単位が大きすぎる
  7. 16 Amazon EKS に移行して、DeepSecurity 動くの? Service の物量に対応できない Kernel module version

    が異なると、そもそも動かない packet capture や file scanできる? Signature 対応してる? k8s 向けの signature って、存在するのだろう か? Overhead 重いのでは? 通常の EC2 instance と比べて、 k8s 向けの処 理を行う分、負荷は増える DeepSecurity の負荷に耐えられる ?
  8. 18 Cloud One Workload Security with Amazon EKS Worker Node

    + Agent AWS WAF EKS cluster VPC flow log resolver log ALB GuardDuty CloudTrail Workload Security Agent access log application log
  9. 19 Amazon EKS に移行して、DeepSecurity 動くの? 回答編 Kernel module 用意されていた、OK! EC2

    typeを利用したのは、DeepSecurityを入れ るのに都合が良い面もあったため Signature 対応してる? 対応はしている remoteからk8s APIへの攻撃が届くのは、 master node worker nodeでの検知は少ない Overhead 重いのでは? 耐えられる EKSへの移行の利点はmaster nodeの運用負 荷軽減
  10.   20 Amazon EC2 → Amazon EKS への移行は簡単だった! Amazon EKSでもWorkload

    Securityは動作する Dashboard DeepSecurity の時から変わらぬ操作性 SIEM との統合 Amazon OpenSearch Serviceで threat hunting 継続的な運用 Log4Shell への対処
  11. 21 Log4Shell freeeの場合 2021-12-10(金) Log4jのZero-dayとして出回ってしまう freeeのrepository内に、log4jの直接の記述はないことを確認 2021-12-11(土) 12:20 CVE-2021-44228として開示される CVSS

    10 2021-12-12(日) 14:00 Log4Shell CloudOne Workload Security IPS signature 配布開始 17:00 に初の検知 2021-12-13(月) 難読化が施された攻撃が着弾し始める JAR/WAR fileをloadし回って、Log4jがloadされないことを確認
  12. 23 とりあえず、動いた でも、kubernetes cluster に最適化されていない 動作はしていた Anti-Malware、IPS に問題はない k8s の

    Security? k8s を secure にしたいのではなく Cloud 全体をsecureにしたい k8s の Overhead 同じ instance type で単純に動作させると、 concurrency は減ってしまう
  13. 25 Cloud One Workload Security with Amazon EKS Worker Node

    + Agent AWS WAF EKS cluster VPC flow log resolver log ALB GuardDuty CloudTrail Workload Security Agent access log application log Anti-Malware Intrusion Prevention Integrity Monitoring Log Inspection
  14. 26 IPS → Cloud One Network Security Worker Node +

    Agent EKS cluster VPC flow log resolver log GuardDuty CloudTrail Workload Security Agent access log application log Anti-Malware Intrusion Prevention Integrity Monitoring Log Inspection AWS WAF ALB Network Security IPS
  15. 27 Anti-Malware → File Storage Security Worker Node + Agent

    EKS cluster VPC flow log resolver log GuardDuty CloudTrail Workload Security Agent Anti-Malware Intrusion Prevention Integrity Monitoring Log Inspection AWS WAF ALB Network Security IPS access log application log receipt File Storage Security Malware Scan
  16. 28 Cloud One with AWS + Container Security AWS WAF

    EKS cluster VPC flow log resolver log ALB GuardDuty CloudTrail access log application log Network Security receipt File Storage Security Amazon ECR Container Security Malware Scan Image Scan IPS
  17. 29 Workload Security → Cloud One Worker Node だけではなく Cloud

    全体の Security を向上したい IPS → Network Security AWS Network Firewall suricata互換rule と比較して、運用が容易 Container Security deploy前にsecurity scan trivyも選択肢の一つ Anti-Malware →    File Storage Security ReadOnly mount構成への移行により file scanを外出し
  18.   30 できたこと、できそうなこと Cloud One と AWS を適材適所で組み合わせる ALB +

    Network Security 1年前だと、不可能だった 今だと、Transit gateway なしでも可能 File Storage Security S3 bucket上のMalware scanを実施 Amazon Macie の PII scan と併用 Container Runtime Security AWS の既存サービスでは カバーできていない領域
  19. 33 freee PSIRT 多層防御、OODA で日々の運用 Cloud One with Amazon EC2

    DeepSecurity の世界 Cloud One with Amazon EKS Workload Security への移行、ほぼそのまま動作する Cloud One with AWS instance、container、k8s を守るだけでなく、Cloud 全体を守る Summary
