  1. Elasticsearch - Speed is key
    Alexander Reelsen
    @spinscale

    View Slide

  2. www.elastic.co
    2
    • Introduction
    • Elasticsearch
    • Speed by Example
    • Search
    • Aggregations
    • Operating System
    • Distributed aspects
    Agenda

    View Slide

  3. www.elastic.co
    3
    • Me
    • joined in march 2013
    • working on Elasticsearch
    & Shield
    • Interested in all things
    scale & search
    About
    • Elastic
    • Founded in 2012
    • Behind: Elasticsearch, Logstash,
    Kibana, Marvel, Shield, ES for
    Hadoop, Elasticsearch clients
    • Support subscriptions
    • Public & private trainings

    View Slide

  4. www.elastic.co
    4
    • Me
    • joined in march 2013
    • working on Elasticsearch
    & Shield
    • Interested in all things
    scale & search
    About
    • Elastic
    • Founded in 2012
    • Behind: Elasticsearch, Logstash,
    Kibana, Marvel, Shield, ES for
    Hadoop, Elasticsearch clients
    • Support subscriptions
    • Public & private trainings

    View Slide

  5. www.elastic.co
    5
    Elasticsearch - High level overview
    Introduction

    View Slide

  6. www.elastic.co
    6
    an open source, distributed, scalable,
    highly available, document-oriented, RESTful
    full text search engine
    with real-time search and analytics capabilities
    Elasticsearch is...

    View Slide

  7. www.elastic.co
    7
    an open source, distributed, scalable, highly available, document-oriented,
    RESTful, full text search engine with real-time search and analytics capabilities
    Elasticsearch is...
    Apache 2.0 License
    https://www.apache.org/licenses/LICENSE-2.0

    View Slide

  8. www.elastic.co
    8
    an open source, distributed, scalable, highly available, document-oriented,
    RESTful, full text search engine with real-time search and analytics capabilities
    Elasticsearch is...

    View Slide

  9. www.elastic.co
    9
    an open source, distributed, scalable, highly available, document-oriented,
    RESTful, full text search engine with real-time search and analytics capabilities
    Elasticsearch is...

    View Slide

  10. www.elastic.co
    10
    an open source, distributed, scalable, highly available, document-oriented,
    RESTful, full text search engine with real-time search and analytics capabilities
    Elasticsearch is...

    View Slide

  11. www.elastic.co
    11
    an open source, distributed, scalable, highly available, document-oriented,
    RESTful, full text search engine with real-time search and analytics capabilities
    Elasticsearch is...
    {
    "name" : "Craft"
    "geo" : {
    "city" : "Budapest",
    "lat" : 47.49, "lon" : 19.04
    }
    }
    Source:  http://json.org/

    View Slide

  12. www.elastic.co
    12
    an open source, distributed, scalable, highly available, document-oriented,
    RESTful, full text search engine with real-time search and analytics capabilities
    Elasticsearch is...
    Source:  https://httpwg.github.io/asset/http.svg

    View Slide

  13. www.elastic.co
    13
    an open source, distributed, scalable, highly available, document-oriented,
    RESTful, full text search engine with real-time search and analytics capabilities
    Elasticsearch is...

    View Slide

  14. www.elastic.co
    14
    an open source, distributed, scalable, highly available, document-oriented,
    RESTful, full text search engine with real-time search and analytics capabilities
    Elasticsearch is...

    View Slide

  15. www.elastic.co
    15
    Getting up and running... is easy
    # wget https://download.elastic.co/elasticsearch/
    elasticsearch/elasticsearch-1.5.1.zip
    # unzip elasticsearch-1.5.1.zip
    # cd elasticsearch-1.5.1
    # ./bin/elasticsearch
    # curl http://localhost:9200

    View Slide

  16. www.elastic.co
    16
    Scaling

    View Slide

  17. www.elastic.co
    17
    Cluster: A collection of nodes
    node
    cluster

    View Slide

  18. www.elastic.co
    18
    Cluster: A collection of nodes
    node
    cluster
    node

    View Slide

  19. www.elastic.co
    cluster
    19
    Cluster: A collection of nodes
    node node

    View Slide

  20. www.elastic.co
    20
    Cluster: A collection of nodes
    node node node node
    cluster

    View Slide

  21. www.elastic.co
    21
    Shards: Unit of scale
    a0 a1 a2
    a3
    # curl -X PUT http://localhost:9200/a -d '
    { "index.number_of_shards" : 4 }'

    View Slide

  22. www.elastic.co
    22
    Shards: Unit of scale
    a0 a1 a2 a3
    # curl -X PUT http://localhost:9200/a -d '
    { "index.number_of_shards" : 4 }'

    View Slide

  23. www.elastic.co
    23
    Shards: Unit of scale
    a0 a1 a2 a3
    # curl -X PUT http://localhost:9200/a/_settings -d '
    { "index.number_of_replicas" : 1 }'

    View Slide

  24. www.elastic.co
    24
    Replication
    a0 a1 a2 a3
    # curl -X PUT http://localhost:9200/a/_settings -d '
    { "index.number_of_replicas" : 1 }'
    a0
    a3 a2
    a1

    View Slide

  25. www.elastic.co
    25
    Search

    View Slide

  26. www.elastic.co
    26
    CRUD
    PUT books/book/1
    {
    "name" : "Elasticsearch - The definitive guide",
    "authors" : [ "Clinton Gormley", "Zachary Tong" ],
    "pages" : 722,
    "published_at" : "2015/01/31"
    }

    View Slide

  27. www.elastic.co
    27
    CRUD
    PUT books/book/1
    {
    "name" : "Elasticsearch - The definitive guide",
    "authors" : [ "Clinton Gormley", "Zachary Tong" ],
    "pages" : 722,
    "published_at" : "2015/01/31"
    }
    GET books/book/1

    View Slide

  28. www.elastic.co
    28
    CRUD
    PUT books/book/1
    {
    "name" : "Elasticsearch - The definitive guide",
    "authors" : [ "Clinton Gormley", "Zachary Tong" ],
    "pages" : 722,
    "published_at" : "2015/01/31"
    }
    GET books/book/1
    DELETE books/book/1

    View Slide

  29. www.elastic.co
    29
    CRUD
    PUT books/book/1
    {
    "name" : "Elasticsearch - The definitive guide",
    "authors" : [ "Clinton Gormley", "Zachary Tong" ],
    "pages" : 722,
    "published_at" : "2015/01/31"
    }
    GET books/book/1
    DELETE books/book/1
    GET books/book/_search?q=elasticsearch

    View Slide

  30. www.elastic.co
    30
    Searching
    GET books/book/_search
    {
    "query" : { "filtered" : {
    "query" : { "match" : { "name" : "elasticsearch" }},
    "filter" : {
    "range" : { "published_at" : { "gte" : "now-1y" } }
    }
    }}
    }

    View Slide

  31. www.elastic.co
    31
    Searching
    GET books/book/_search
    {
    "query" : { "filtered" : {
    "query" : { "match" : { "name" : "elasticsearch" }},
    "filter" : {
    "range" : { "published_at" : { "gte" : "now-1y" } }
    }
    }}
    }
    {
    "took": 3, "timed_out": false,
    "_shards": { "total": 5, "successful": 5, "failed": 0 },
    "hits": {
    "total": 1, "max_score": 0.15342641,
    "hits": [ {
    "_index": "books", "_type": "book", "_id": "1",
    "_score": 0.15342641,
    "_source": {
    "name": "Elasticsearch - The definitive guide",
    "authors": [ "Clinton Gormley", "Zachary Tong" ],
    "pages": 722, "category": "search"
    "published_at": "2015/01/31",
    } } ] } }

    View Slide

  32. www.elastic.co
    32
    Searching
    GET books/book/_search
    {
    "query" : { "filtered" : {
    "query" : { "match" : { "name" : "elasticsearch" }},
    "filter" : {
    "range" : { "published_at" : { "gte" : "now-1y" } }
    }
    }},
    "aggs" : {
    "category" : { "terms" : { "field" : "category" } }
    }
    }

    View Slide

  33. www.elastic.co
    GET books/book/_search
    {
    "query" : { "filtered" : {
    "query" : { "match" : { "name" : "elasticsearch" }},
    "filter" : {
    "range" : { "published_at" : { "gte" : "now-1y" } }
    }
    }},
    "aggs" : {
    "category" : { "terms" : { "field" : "category" } }
    }
    }
    33
    Searching
    {
    "took": 3, "timed_out": false,
    "_shards": { "total": 5, "successful": 5, "failed": 0 },
    "hits": {
    "total": 1, "max_score": 0.15342641,
    "hits": [ ... ]
    },
    "aggregations": {
    "category": {
    "buckets": [
    { "key": "search", "doc_count": 1 },
    { ... }
    ] } } }

    View Slide

  34. www.elastic.co
    34
    • Hits all relevant shards
    • Searches for top-N results per shard
    • Reduces to top-N total
    • Gets top-N documents/data from relevant shards
    • Returns data to requesting client
    Search

    View Slide

  35. www.elastic.co
    35
    • Lucene is doing the heavy lifting
    • A single shard is a Lucene index
    • Each field is its own inverted index and can be searched in
    Search on a single shard
    term docid
    clinton 1
    gormley 1
    tong 1
    zachary 1

    View Slide

  36. www.elastic.co
    36
    • It is very hard to reconstruct the original data from the inverted
    index
    • Solution: Just store the whole document in its own field and
    retrieve it, when returning data to the client
    Example: Return original JSON in search response
    {
    "name" : "Elasticsearch - The definitive guide",
    "authors" : [ "Clinton Gormley", "Zachary Tong" ],
    "pages" : 722,
    "published_at" : "2015/01/31"
    }
    _source

    View Slide

  37. www.elastic.co
    Elasticsearch - The definitive guide
    Clinton Gormley Zachary Tong
    722
    2015/01/31
    37
    Example: _all field
    {
    "name" : "Elasticsearch - The definitive guide",
    "authors" : [ "Clinton Gormley", "Zachary Tong" ],
    "pages" : 722,
    "published_at" : "2015/01/31"
    }
    _all

    View Slide

  38. www.elastic.co
    Elasticsearch - The definitive guide
    Clinton Gormley Zachary Tong
    38
    Example: copy_to field (name & authors)
    {
    "name" : "Elasticsearch - The definitive guide",
    "authors" : [ "Clinton Gormley", "Zachary Tong" ],
    "pages" : 722,
    "published_at" : "2015/01/31"
    }
    copy_to

    View Slide

  39. www.elastic.co
    39
    • Filters do not contribute to score & can be cached using a BitSet
    • range filter for a date/price
    • term filter for a category
    • geo filter for a bounding box
    Search: Using filters
    0 1 1 0 0 1 { "term" : { "category" : "search" } }
    0 1 0 0 1 0 { "term" : { "category" : "reduced" } }

    View Slide

  40. www.elastic.co
    40
    • Problem: How to search in an inverted index for non-existing fields
    (exists & missing filter)?
    • Costly: Need to merge postings lists of all existing terms
    (expensive for high-cardinality fields!)
    • Solution: Index document field names under _field_names
    Filters: Missing fields

    View Slide

  41. www.elastic.co
    41
    Aggregations

    View Slide

  42. www.elastic.co
    42
    • Aggregations: Buckets & metrics
    • Aggregations cannot make use of the inverted index
    • Meet Fielddata: Uninverting the index
    • Inverted index: Maps term to document id
    • Fielddata: Maps document id to terms
    Aggregations

    View Slide

  43. www.elastic.co
    43
    Aggregations
    docid term
    1 Clinton Gormley,
    Zachary Tong
    Inverted Index
    Fielddata
    term docid
    clinton 1
    gormley 1
    tong 1
    zachary 1

    View Slide

  44. www.elastic.co
    44
    Aggregations
    docid term
    1 Clinton Gormley,
    Zachary Tong
    Inverted Index
    Fielddata
    term docid
    Clinton Gormley 1
    Zachary Tong 1

    View Slide

  45. www.elastic.co
    45
    • Fielddata is an in-memory data structure, lazily constructed
    • Easy to go OOM (wrong field or too many documents)
    • Solution:
    • circuit breaker
    • doc_values: index-time data structure, no heap, uses the file
    system cache, better compression
    Aggregations: Fielddata

    View Slide

  46. www.elastic.co
    46
    • Problem: Count distinct elements
    • Naive: Load all data into a set, then check the size (distributed?)
    • Solution: cardinality Aggregation, that uses HyperLogLog++
    • configurable precision, allows to trade memory for accuracy
    • excellent accuracy on low-cardinality sets
    • fixed memory usage: no matter if there are tens or billions of unique values, memory usage only
    depends on configured precision
    Aggregations: Probabilistic data structures

    View Slide

  47. www.elastic.co
    47
    • Problem: Calculate percentiles
    • Naive: Maintain a sorted list of all values
    • Solution: percentiles Aggregation, that uses T-Digest
    • extreme percentiles are more accurate
    • small sets can be up to 100% accurate
    • while values are added to a bucket, the algorithm trades accuracy for memory savings
    Aggregations: Probabilistic data structures

    View Slide

  48. www.elastic.co
    48
    Operating system
    & Hardware

    View Slide

  49. www.elastic.co
    49
    • CPU
    Indexing, searching, highlighting
    • I/O
    Indexing, searching, merging
    • Memory
    Aggregation, indices
    • Network
    Relocation, Snapshot & Restore
    Elasticsearch can easily max out...

    View Slide

  50. www.elastic.co
    50
    • CPU: Threadpools are sized on number of cores
    • Disk: SSD
    • Memory: ∞
    • Network: GbE or better
    Hardware

    View Slide

  51. www.elastic.co
    51
    • file system cache
    • file handles
    • memory locking: bootstrap.mlockall
    • dont swap, no OOM killer
    Operating system

    View Slide

  52. www.elastic.co
    52
    Distributed aspects

    View Slide

  53. www.elastic.co
    53
    • The network is reliable
    • Latency is zero
    • Bandwidth is infinite
    • The network is secure
    Fallacies of distributed computing
    • Topology doesn't change
    • There is one administrator
    • Transport cost is zero
    • The network is homogeneous
    by  Peter  Deutsch
    https://en.wikipedia.org/wiki/Fallacies_of_distributed_computing

    View Slide

  54. www.elastic.co
    54
    Wrapup

    View Slide

  55. www.elastic.co
    55
    • Speed is key!
    • Search is a tradeoff: Query time vs. index time
    • Benchmark your use-case
    • http://benchmarks.elasticsearch.org/
    Summary

    View Slide

  56. www.elastic.co
    56
    • Automatic I/O throttling
    • Clusterstate incremental updates
    • Faster recovery
    • Aggregations 2.0
    • Merge queries and filters
    • Reindex API
    • Changes API
    • Expression scripting engine
    Elasticsearch 2.x

    View Slide

  57. www.elastic.co
    57
    • Speed improvements in queries (must_not, sloppy phrase)
    • Automated caching
    • BitSet compression vastly improved (roaring bitsets)
    • Index compression (on disk + memory)
    • Indexing performance (adaptive merge throttling, SSD detection)
    • Index safety: atomic commits, segment commit identifiers, verify
    integrity at merge
    • ...
    Lucene 5.x

    View Slide

  58. www.elastic.co
    58
    Alexander Reelsen
    [email protected]
    @spinscale
    Thanks for listening! Questions?
    We’re  hiring
    https://www.elastic.co/about/careers
    We’re  helping
    https://www.elastic.co/subscriptions

    View Slide

  59. www.elastic.co
    59
    http://www.elastic.co/guide/en/elasticsearch/reference/current/mapping-source-field.html
    http://www.elastic.co/guide/en/elasticsearch/reference/current/mapping-all-field.html
    http://www.elastic.co/guide/en/elasticsearch/reference/current/mapping-field-names-field.html
    http://www.elastic.co/guide/en/elasticsearch/reference/current/mapping-core-types.html#copy-to
    http://www.elastic.co/guide/en/elasticsearch/reference/current/search-aggregations-metrics-cardinality-aggregation.html
    http://www.elastic.co/guide/en/elasticsearch/guide/current/cardinality.html
    http://www.elastic.co/guide/en/elasticsearch/guide/current/percentiles.html
    http://www.elastic.co/guide/en/elasticsearch/reference/current/search-aggregations-metrics-percentile-aggregation.html
    http://www.elastic.co/elasticon/2015/sf/elasticsearch-architecture-amusing-algorithms-and-details-on-data-structures/
    http://speakerdeck.com/elastic/all-about-aggregations
    http://www.elastic.co/elasticon/2015/sf/updates-from-lucene-land
    http://speakerdeck.com/elastic/resiliency-in-elasticsearch-and-lucene
    http://www.elastic.co/elasticon/2015/sf/level-up-your-clusters-upgrading-elasticsearch
    http://speakerdeck.com/elasticsearch/maintaining-performance-in-distributed-systems
    References

    View Slide
