PHPCon Tokyo - 2015 - Database Theory Models and Abstractions

Proper database theory and design seems to be an increasingly lost art. As abstraction layers, migration tools and ORM become more prevalent, less focus is being spent on properly architecting the database, relationships, indexes and constraints. As a result, many projects suffer a crisis of data or scalability as data sets grow.

In this workshop we'll cover the following: Table relationships and relationship tables Database Normalization with a focus on Third Normal Form (3NF) Database Indexes and Use Cases Database Keys and Composite Keys Database Optimization The difference between schema and schema-less databases The selection of the proper database to suit your requirements (hint: it may not just be one) The current DB landscape and use cases, including Redis, MongoDB, MySQL/MariaDB and Memcache (hint: some frameworks even use relational databases as a key-value store)

Transcript

1. EUGENE T. COOK PHPCON JAPAN 2015 DATABASE THEORY, MODELS AND ABSTRACTIONS
2. A BIT ABOUT ME Transactional and Start Up Attorney MBA - IT and
 Operations Management Polymathic Technologist JD - Rule of Law in
 Developing Nations Shameless Plugs
3. TWO PRIMARY TRENDS IN DB DESIGN SCHEMA NOSQL (SCHEMALESS)* MySQL MongoDB MariaDB RethinkDB PostgreSQL Redis Google Big Table * THERE ARE EXCEPTIONS TO MANY OF THE CHARACTERISTICS OF TYPICAL SCHEMALESS STORES
4. QUICK PRIMER DATA MODELING
5. DATA MODELING • Identifying the distinct entities that comprise your data’s architecture • Conceptualizing your data objects • Identifying the relationships between the data objects DATABASE ARCHITECTURE DATABASE DESIGN • Conversion of the data objects into an actual schema • Naming convention of the data and relationships • Deciding what constraints you should have
6. DATA MODELING - STRUCTURE PROJECT SCOPE YOU’VE BEEN ASKED BY HEAD MISTRESS GERTRUDE TO CREATE A SYSTEM FOR HER NEW BOARDING SCHOOL. SHE WANTS TO BE ABLE TO TRACK STUDENT SCHEDULES AND ALSO THEIR FINANCIAL ACCOUNT STATUS.
7. WHAT ARE THE LOGICAL OBJECTS COURSES STUDENTS ENROLLMENT GRADES HOW WOULD THESE LOOK? ACCOUNT TEACHERS
8. MONOLITHIC STUDENT CLASS 1 GRADE 1 CLASS 2 GRADE 2 DUE LAST PAY JOE LAW A SOCIAL B 500 1 MALCOLM SCIENCE B MATH A 250 1 MINDY GEO C SOCIAL D 350 2 JACK COMP A LAW A 600 12
9. THAT WAS EASY! ANY QUESTIONS?
10. GERTRUDE DOES NOT APPROVE WHAT ABOUT NEXT SEMESTER? WHAT IF THEY TAKE MORE THAN TWO CLASSES? HOW DO WE SAVE MORE INFORMATION ABOUT THE CLASSES?
11. I THOUGHT I WAS DONE
12. QUICK PRIMER DATABASE DESIGN
13. MONOLITHIC STUDENT CLASS 1 GRADE 1 CLASS 2 GRADE 2 DUE LAST PAY JOE LAW A SOCIAL B 500 1 MALCOLM SCIENCE B MATH A 250 1 MINDY GEO C SOCIAL D 350 2 JACK COMP A LAW A 600 12 NORMALIZATION ORGANIZATION TABLES AND COLUMNS TO MINIMIZE REDUNDANCY CARDINALITY THE FUNDAMENTAL RELATION OF ONE TABLE TO ANOTHER
14. NORMALIZATION CLASS 1 GRADE 1 CLASS 2 GRADE 2 DUE LAST PAY JOE LAW A SOCIAL B 500 1 MALCOLM SCIENCE B MATH A 250 1 MINDY GEO C SOCIAL D 350 2 JACK COMP A LAW A 600 12 WHAT ABOUT CLASS META INFORMATION? WHAT IF WE CHANGED THE CLASS NAME?
15. NORMALIZATION STUDENT CLASS 1 GRADE 1 CLASS 2 GRADE 2 DUE LAST PAY JOE LAW A SOCIAL B 500 1 MALCOLM SCIENCE B MATH A 250 1 MINDY GEO C SOCIAL D 350 2 JACK COMP A LAW A 600 12 CLASS DESC TEACHER LAW … SUSAN SCIENCE … RANDALL GEO … CRAIG COMP … SUSAN WE’VE ADDED META, BUT NOW WHAT?
16. ONE TO ONE CARDINALITIES (RELATIONSHIPS) BELONGS TO (FK) / HAS ONE ONE TO MANY BELONGS TO (FK) / HAS MANY MANY TO MANY HAS MANY THROUGH / HAS MANY THROUGH
17. TEACHERS CLASSES IDENTIFY THE RELATIONSHIPS CAN A CLASS HAVE MULTIPLE TEACHERS? CAN A TEACHER TEACH MULTIPLE CLASSES? M - 1
18. ONE TO MANY STUDENT CLASS 1 GRADE 1 CLASS 2 GRADE 2 DUE LAST PAY JOE 1 A 5 B 500 1 MALCOLM 2 A 6 A 250 1 MINDY 3 C 5 D 350 2 JACK 4 A 1 A 600 12 CLASS NAME DESC TEACHER 1 LAW … 1 2 SCIENCE … 2 3 GEO … 3 4 COMP … 1 TEACHER NAME HIRE DATE 1 SUSAN … 2 RANDALL … 3 CRAIG …
19. CLASSES STUDENTS IDENTIFY THE RELATIONSHIPS CAN A STUDENT BE IN MULTIPLE CLASSES? CAN A CLASS HAVE MULTIPLE STUDENTS? M - M
20. MANY TO MANY STUDENT NAME 1 JOE 2 MALCOLM 3 MINDY 4 JACK CLASS NAME 1 MATH 2 SCIENCE 3 GYM 4 LANGUAGE ENROLLED_IN STUDENT_ID CLASS_ID 1 1 2 2 1 3 3 4 1 4 2 4 5 3 1 6 2 1
21. VISUALIZING THE RELATIONSHIPS
22. QUICK PRIMER OPTIMIZATION
23. INDEXES DATA OPTIMIZATIONS HIGHLY EFFICIENT COPY OF SELECT COLUMNS WHICH TYPICALLY INCLUDE DIRECT ADDRESSING STORED PROCEDURES ROUTINES RUN WITHIN THE DATABASE THAT CAN SOMETIMES MORE EFFICIENTLY MANIPULATE DATA OR REDUCE DB TRAFFIC VIEWS STORED QUERIES OF DATA WHICH CAN BE INDEXED SEPARATELY AND IN SOME DATABASES, THE RESULTING DATASET IS INDEXED AS A CLUSTER, DRAMATICALLY INCREASING PERFORMANCE
24. INDEXES CREATE AN INDEX FOR ATTRIBUTES THAT YOU QUERY AGAINST THE MOST. INDEXES ARE UPDATED DYNAMICALLY, AND WILL RESULT IN DRAMATICALLY IMPROVED QUERIES.
25. DATA MODELING • Identifying the distinct entities that comprise your data’s architecture • Conceptualizing your data objects • Identifying the relationships between the data objects DATABASE ARCHITECTURE DATABASE DESIGN • Conversion of the data objects into an actual schema • Naming convention of the data and relationships • Deciding what constraints you should have
26. STORED PROCEDURES CREATE STORED PROCEDURES FOR STATICALLY CALLED SQL THAT MANIPULATES OR QUERIES LARGE DATASETS FOR SUBSETS VIEWS USE VIEWS FOR COMMON JOINS, WHICH MANY RDBS’ KEEP IN THE A SEPARATE TABLE CACHE. THIS WILL ALLOW DIRECT QUERIES TO THE JOINED TABLE.
27. QUICK PRIMER NOSQL
28. SCHEMA-LESS? • NoSQL databases don’t have an internal schema • NoSQL databases are dynamically typed, meaning attributes can even have different types • Uses documents instead of records, which can be thought of as objects or arrays • Documents have no inherent schema • Schemas, constraints and types are all “soft.” They rely on programming or abstractions rather than “hard” in the DB. WHAT’S NOSQL?
29. OK - BUT WHY?
30. • Flexible documents • Fast iteration • More agile • No “migrations” required • “Web Read” (JSON/BSON) • “Web Scale” (Performance) • Data fidelity • Soft constraints are programmatic • Most NoSQL not built for joins • Requires optimization of writes for reads
31. WEB SCALE11!!1!1!ELEVENTYONE!
32. BRO, DO YOU EVEN WEBSCALE? • “Web Scale” - delivering scalable, consistent performance, especially through distributed reads. • Achieved through denormalization. • Relational data is kept in the document itself rather than separated out into separate tables.
33. DENORMALIZATION? YOU JUST WASTED THE LAST 20 MINS.
34. RDBS • Sophisticated joins • Fidelity of data is paramount • Complex relationships • Static data model • Multi-row transactions • Less sophisticated DBA • Can boost performance with followers (slaves) WHEN TO USE NOSQL • Complex data (E.g. geo-spatial) • Changing data model • Horizontal inconsistency not necessarily an issue • Some great features specifically for webapps (E.g. oplog in MongoDB) • Distributed read performance is critical • More sophisticated DBA willing to maintain, cleanse data and normalize types.
35. WHAT’S THE POINT? • No right or wrong answer. • Not mutually exclusive - can be used together with great effect. • E.g. Comments system might be on NoSQL but your HR system might be on RDBS.
36. QUICK PRIMER ABSTRACTIONS
37. ABSTRACTIONS • API or library which obfuscates some of the raw querying or manipulation of the database. • Can allow for easy drop in of other database types (E.g. MySQL to Postgres) • Some add validation or schema support to databases that might not have them by default. • Some abstractions also offer data migrations, handling the table structure for you and can even build your original data model from an existing schema. ABSTRACTIONS EXAMPLES • Propel • Doctrine • PDO • Mongoose • Monk
38. LOOK FORWARD DON’T BE AFRAID TO BROADEN YOUR HORIZONS YOUR APP WILL THANK YOU
39. KEEP IN TOUCH @ETC ECOOK E@LAW.FM
40. QUESTIONS?
41. THANK YOU
