Oblivious Data Abstractions: Circuit Structures and Square-Root ORAM

Tutorial at Summer School on Secure and Oblivious Computation and Outsourcing
Notre Dame University, 10 May 2016

Transcript

1. Data-Oblivious Data David Evans www.cs.virginia.edu/evans 10 May 2016
2. Plan Memory for Data-Oblivious Computation Special-Purpose Data Structures: Circuit Structures Aside: Programming Secure Computations: Obliv-C General-Purpose Memory: Square-Root ORAM
3. Crazy Things in Typical Code 3 a[i] = x SameeZahur and David Evans. Circuit Structures for Improving Efficiency of Security & Privacy Tools. IEEE Security and Privacy (Oakland) 2013.
4. Circuit for Array Update 4 a[i] = x i == 0 a[0] x a'[0] i == 1 a[1] x a’[1] i == 2 a[2] x a’[2] …
5. Easy (and Common) Case 5 for (i = 0; i < n; i++) a[i] += 1 a[0] a[1] a[2] a[n-1] … +1 +1 +1 +1
6. Locality: Stacks and Queues 6 if (x != 0) a[i] += 1 if (a[i] > 10) i += 1 a[i] = 5 t := a.top() + 1 a.cond_update(x != 0, t) a.cond_push(x != 0 && t > 10, *) a.cond_update(x != 0, 5) Data-oblivious code No branching allowed
7. Naïve Conditional Push 7 … p x a[0] a[1] a[2] … a’[0] a’[1] a’[2] …
8. Naïve Conditional Push 8 … True 7 2 9 3 … 7 2 9 …
9. More Efficient Stack 9 Level 0: 2 9 3 t = 3 Level 1: 4 7 t = 2 5 4 Level 2: 8 8 2 3 8 6 … Block size = 2level Each level has 5 blocks, at least 2 full and 2 empty t = 3
10. 10 2 9 3 t = 3 4 7 t = 2 5 4 Level 0 t = 3 Level 1 Level 2 Conditional push (True, 7) 7 2 9 3 t = 4 4 7 t = 2 5 4 t = 3 Conditional push (True, 8) 8 7 2 9 3 t = 5 4 7 t = 2 5 4 t = 3 Shift 8 2 7 t = 3 4 7 t = 3 5 4 9 3 t = 3
11. 11 2 9 3 t = 3 4 7 t = 2 5 4 Level 0 t = 3 Level 1 Level 2 Conditional push (True, 7) 7 2 9 3 t = 4 4 7 t = 2 5 4 t = 3 Conditional push (True, 8) 8 7 2 9 3 t = 5 4 7 t = 2 5 4 t = 3 Shift 8 2 7 t = 3 4 7 t = 3 5 4 9 3 t = 3 Amortized Θ(log n) gates per operation
12. Efficient queue operations
13. Evaluation
14. Spatial Locality Not just for stacks and queues Access cost Θ log
15. Temporal Batching
16. 0 2 7 9 'A' 'U' 'M' 'R' 'D' 'Y' 'K' 'C' Batching Array Accesses 16 m[0] = 'A' m[2] = 'U' m[9] = 'M' m[7] = 'R' m[0] = 'D' m[9] = 'Y' m[9] = 'K' m[7] = 'C' Execution trace: indexes and values are private values
17. 17 m[0] = 'A' m[2] = 'U' m[9] = 'M' m[7] = 'R' m[0] = 'D' m[9] = 'Y' m[9] = 'K' m[7] = 'C' Sort by Key m[0] = 'A' m[0] = 'D' m[2] = 'U' m[7] = 'R' m[7] = 'C' m[9] = 'M' m[9] = 'Y' m[9] = 'K' stable sort! Batching Updates
18. 18 m[0] = 'A' m[2] = 'U' m[9] = 'M' m[7] = 'R' m[0] = 'D' m[9] = 'Y' m[9] = 'K' m[7] = 'C' Sort by Key m[0] = 'A' m[0] = 'D' m[2] = 'U' m[7] = 'R' m[7] = 'C' m[9] = 'M' m[9] = 'Y' m[9] = 'K' stable sort! Batching Updates
19. 19 m[0] = 'A' m[2] = 'U' m[9] = 'M' m[7] = 'R' m[0] = 'D' m[9] = 'Y' m[9] = 'K' m[7] = 'C' Sort by Key m[0] = 'A' m[0] = 'D' m[2] = 'U' m[7] = 'R' m[7] = 'C' m[9] = 'M' m[9] = 'Y' m[9] = 'K' stable sort! Compare Adjacent m[0] = 'A' m[0] = 'D' m[2] = 'U' m[7] = 'R' m[7] = 'C' m[9] = 'M' m[9] = 'Y' m[9] = 'K' Batching Updates
20. 20 m[0] = 'A' m[2] = 'U' m[9] = 'M' m[7] = 'R' m[0] = 'D' m[9] = 'Y' m[9] = 'K' m[7] = 'C' Sort by Key m[0] = 'A' m[0] = 'D' m[2] = 'U' m[7] = 'R' m[7] = 'C' m[9] = 'M' m[9] = 'Y' m[9] = 'K' stable sort! Compare Adjacent m[0] = 'A' m[0] = 'D' m[2] = 'U' m[7] = 'R' m[7] = 'C' m[9] = 'M' m[9] = 'Y' m[9] = 'K' Batching Updates
21. 21 Batching Updates m[0] = 'A' m[2] = 'U' m[9] = 'M' m[7] = 'R' m[0] = 'D' m[9] = 'Y' m[9] = 'K' m[7] = 'C' Sort by Key m[0] = 'A' m[0] = 'D' m[2] = 'U' m[7] = 'R' m[7] = 'C' m[9] = 'M' m[9] = 'Y' m[9] = 'K' stable sort! Compare Adjacent m[0] = 'A' m[0] = 'D' m[2] = 'U' m[7] = 'R' m[7] = 'C' m[9] = 'M' m[9] = 'Y' m[9] = 'K'
22. 22 = 'A' = 'U' = 'M' = 'R' = 'D' = 'Y' = 'K' = 'C' Sort by Key m[0] = 'A' m[0] = 'D' m[2] = 'U' m[7] = 'R' m[7] = 'C' m[9] = 'M' m[9] = 'Y' m[9] = 'K' stable sort! Compare Adjacent m[0] = 'A' m[0] = 'D' m[2] = 'U' m[7] = 'R' m[7] = 'C' m[9] = 'M' m[9] = 'Y' m[9] = 'K' m[0] = 'D' m[2] = 'U' m[7] = 'C' m[9] = 'K' m[0] = 'A' m[7] = 'R' m[9] = 'M' m[9] = 'Y' Sort by Liveness output wires Discarded
23. Temporal Batching Θ(n log2 n)
24. Example Application: DBScan 24 Density-based clustering: depth-first search to find dense clusters Martin Ester, Hans-Peter Kriegel, Jörg Sander, Xiaowei Xu. KDD 1996 Alice’s Data Bob’s Data Joint Clusters
25. 25 Private Input: P – array of points (combines private points from both parties) Public inputs:minpts, radius Output:cluster number for each point Conditional Push! Array update!
26. 26 0 5000 10000 15000 20000 25000 30000 35000 40000 60 120 240 480 Execution Time (seconds) Data Size Optimized Structures Normal Data Structures 9.7 hours 55 minutes
27. Data-Oblivious Memory Specialized memory access Circuit structures, protocol agnostic Stacks, queues, batched map operations General random access Oblivious RAM But first…Obliv-C
28. Tools for Building Secure Computations Library-based frameworks: Circuit-level programs Full control Low-level programming Little type safety High-level Languages Little control High-level programming Strong type safety
29. Tools for Building Secure Computations Library-based frameworks: Circuit-level programs Full control Low-level programming Little type safety High-level Languages Little control High-level programming Strong type safety PICCO
30. Library-based frameworks: Circuit-level programs Full control Low-level programming Little type safety High-level Languages Little control High-level programming Strong type safety High-level programming Low-level customizability Helpful, escapabletype checking Tools for Building Secure Computations
31. Obliv-C
32. Obliv-C
33. Obliv-C
34. Obliv-C
35. Obliv-C #include <million.h> int main (int argc, char ∗argv[]) { ProtocolDesc pd; ProtocolIO io; int p = (argv[1] == ’1’ ? 1 : 2); sscanf(argv[2], "%d", &io.myinput); // ... set up TCP connections setCurrentParty(&pd, p); execYaoProtocol(&pd, millionaire, &io); printf("Result: %d\n", io->cmp); // ... cleanup }
36. Oblivious Conditionals from obinary_search
37. Actual code…with all the ugly parts
38. Escaping ~obliv(var) { … } Code inside ~obliv always executes regardless of oblivious condition var is Boolean: oblivious condition Programmer has control! But, not security risk: all private data is still encrypted
39. Implementing Oblivious Queue
41. http://oblivc.org/
42. Historical Excursion Journal of the ACM, January 1968
43. Delay Lines 43
44. Mercury Delay Lines 44 0/1
45. Why Mercury? 45 Speed of Sound Air 343 m/s Mercury 1450 m/s (40° C) Water 1500 m/s (25° C)
46. Why Mercury? 46 Speed of Sound Air 343 m/s Mercury 1450 m/s (40° C) Water 1500 m/s (25° C)
48. 48 (In same Jan 1968 JACM as Waksman Network!)
50. 50 MIT Project Whirlwind, 1951 2K 16-bit words with “no waiting”! Magnetic Core Memory
51. Oblivious RAM
52. Linear Scan Doesn’t Scale Writing a single 32-bit integer: 32 logic gates Raw Yao’s performance ≈ 1 million gates per second Write speed ≈ 31,250 elements per second (not hiding access pattern) For hiding access pattern, 216 elements per write Around 2 seconds per access
53. SC-ORAM in Practice • Only faster than linear scan for large memories (> 214 blocks) • Expensive to initialize: – Repeated writes – 2 weeks! From Yan’s talk this morning
54. Circuit ORAM Access time Xiao Wang, Hubert Chan, and Elaine Shi. Circuit ORAM: On Tightness of the Goldreich-Ostrovsky Lower Bound. In ACM CCS 2015.
55. SC-ORAM in Practice • Only faster than linear scan for large memories (> 214 blocks) • Expensive to initialize: – Repeated writes – 2 weeks! From Yan’s talk this morning Circuit ORAM Square-Root ORAM
56. Results Summary (Not including initialization cost)
57. Classical Square-Root ORAM
58. Problems with SQ-ORAM Design • Requires a PRF for each ORAM access – PRF is a big circuit in MPC • Initialization requires PRF evaluations • Requires oblivious sort twice: – Shuffling memory according to PRF – Removing dummy blocks
59. Problems with GO’s SQ-ORAM • Requires a PRF for each ORAM access – PRF is a big circuit in MPC • Initialization requires PRF evaluations • Requires oblivious sort twice: – Shuffling memory according to PRF – Removing dummy blocks Solution strategy: use random permutation instead of PRF
60. Shuffling Network [Waksman 1968] Cost per shuffle: 5B
61. 4-Block ORAM
62. 4-Block ORAM Cost: 5B + B +2B +3B + … = 11B every 3 accesses
63. Linear scan Cost: 4B = 12B/3 Our scheme Cost: 11B/3 Less expensive than linear scan for 4 blocks (8 with overhead)
65. Logical index/4 Logical index/2
66. Logical index/4 Logical index/2
67. Logical index/4 Logical index/2 read a[8] First Access
68. Logical index/4 Logical index/2 read a[8] First Access
69. Logical index/4 Logical index/2 read a[8] First Access
70. Logical index/4 Logical index/2 read a[8] First Access
71. Logical index/4 Logical index/2 read a[8] First Access
72. AfterFirst Access Used
73. Second Access read a[9]
74. Second Access read a[9]
75. Second Access read a[9] Randomly select unused element
76. Second Access read a[9] Randomly select unused element Randomly select unused element
77. Second Access read a[9] Randomly select unused element Randomly select unused element
78. Second Access read a[9] Randomly select unused element Randomly select unused element
79. After Second Access
80. Third Access read a[8]
81. Third Access read a[8]
82. Third Access read a[8]
83. Amortized cost: Θ log9 per access
84. Inexpensive (Re-)Initialization
86. Creating position map
87. Creating position map
88. Inverse permutation
89. Inverse permutation
90. 16-byte blocks 32-byte blocks Pre-Access Cost (not counting initialization)
91. 16-byte blocks 32-byte blocks Whirlwind I (1951) 30 s, 2048 x 16-bit words
92. 16-byte blocks 32-byte blocks Z3 (1941) Whirlwind I (1951) 30 s, 2048 x 16-bit words
93. Wall-clock time in seconds for full protocol between two EC2 C4.2xlarge nodes (1.03 Gbps)
94. ∼32 minutes 55,000x standard execution Wall-clock time in seconds for full protocol between two EC2 C4.2xlarge nodes (1.03 Gbps)
95. ∼33 hours (“wikipedia” version) Improved to ∼1 hour with custom structures Wall-clock time in seconds for full protocol between two EC2 C4.2xlarge nodes (1.03 Gbps)
96. Open Problems • Scalability: poly-logarithmic hierarchical ORAM design • Automatic optimization: using custom data structures when memory access predictable • Stronger security models: active security – All results are semi-honest model • Establishing Meaningful Trust 64 KB memory 1 s access (∼2000x improvement)
97. Collaborators Samee Zahur (UVA) Jack Doerner (UVA) Adrià Gascón (U of Edinburgh) Jonathan Katz (U Maryland) Mariana Raykova (SRI, Yale) Xiao Wang (U Maryland) Paper: Revisiting Square-Root ORAM Efficient Random Access in Multi-Party Computation IEEE Symposium on Security and Privacy (Oakland), May 2016 http://oblivc.org/docs/sqoram.pdf Code: http://oblivc.org
98. David Evans evans@virginia.edu www.cs.virginia.edu/evans OblivC.org mightBeEvil.org
