Transcript

  1. Build Reliable and Scalable Chat Platform that Bot Compatible by

    Evan Purnama (CTO, Qiscus)

  2. What is Qiscus? We are a startup that help companies

    to enable conversations in their apps. #EnablingConversations

  3. What is Qiscus? #EnablingConversations

  4. Our Customers … and 100+ more apps already registered in

    our system ~ 6 millions chat users (on our cloud server) #EnablingConversations

  5. Use cases ◦ Connect user to user (doctor to patient,

    student to teacher) ◦ Connect between user to admin/agent (customer services) ◦ Connect between user to bot engine (chatbot) ◦ Create alternative of internal messaging (create WA-like App) #EnablingConversations

  6. Some of tech that we are using #EnablingConversations

  7. Chat System That Reliable and Scalable

  8. Reliability #EnablingConversations

  9. Uptime ◦ Measure of system reliability ◦ Service Level Agreement

    (SLA) #EnablingConversations

  10. Uptime #EnablingConversations

  11. Uptime #EnablingConversations > 99.9 %

  12. None

  13. Scalability #EnablingConversations

  14. Architecture & Infrastructure #EnablingConversations Frontend / Client Side Backend /

    Web Server / Middleware DB General IT System

  15. Architecture & Infrastructure #EnablingConversations Frontend / Client Side Backend /

    Web Server / Middleware DB General IT System

  16. Scalable General IT System #EnablingConversations Load Balancer

  17. Scalable General IT System : Frontend #EnablingConversations Content Delivery Network

    (CDN)

  18. Scalable General IT System : Frontend #EnablingConversations Server Side Rendering

  19. Scalable General IT System : Frontend #EnablingConversations Lazy Load Data

  20. Scalable General IT System : Backend #EnablingConversations

  21. Scalable General IT System : Backend #EnablingConversations

  22. Scalable General IT System : Database #EnablingConversations Optimise Query and

    Indexing

  23. Scalable General IT System : Database #EnablingConversations DB DB Vertical

    Scaling

  24. Scalable General IT System : Database #EnablingConversations Caching Backend /

    Web Server / Middleware DB Cache

  25. Scalable General IT System : Database #EnablingConversations Caching

  26. Scalable General IT System : Database #EnablingConversations DB DB Horisontal

    Scaling DB DB

  27. Scalable General IT System : Database #EnablingConversations Horisontal Scaling :

    Master / Slave

  28. Scalable General IT System : Database #EnablingConversations Horisontal Scaling :

    Sharding

  29. Scalable General IT System : Database #EnablingConversations Scaling Write (?)

    Backend / Web Server / Middleware DB

  30. Scalable General IT System : Database #EnablingConversations Throttle / Queue

    Backend / Web Server / Middleware DB PubSub

  31. Scalable General IT System : Database #EnablingConversations Distributed Database

  32. Scalable General IT System : Database #EnablingConversations Distributed Database

  33. Realtime Communication System #EnablingConversations Frontend / Client Side Backend /

    Web Server / Middleware DB Realtime Server Architecture & Infrastructure

  34. #EnablingConversations Realtime Server Scaling Realtime Server

  35. #EnablingConversations Load Balancer Scaling Realtime Server RealTime Server RealTime Server

    RealTime Server

  36. #EnablingConversations Load Balancer Scaling Realtime Server RealTime Server RealTime Server

    RealTime Server

  37. #EnablingConversations Scaling Realtime Server “DNS” Load Balancer RealTime Server RealTime

    Server RealTime Server Shared Memory

  38. #EnablingConversations Scaling Realtime Server “DNS” Load Balancer Distributed Realtime Server

  39. #EnablingConversations Scaling Realtime Server

  40. #EnablingConversations Scaling Realtime Server Cluster

  41. #EnablingConversations Scaling Realtime Server 10 MILLION CONCURRENT USERS

  42. None

  43. Chat System That Bot Compatible

  44. Chatbot #EnablingConversations

  45. #EnablingConversations And lot more …

  46. #EnablingConversations How Chatbot Works Request Response

  47. #EnablingConversations How Chatbot Works Response Instance AI Engine Request

  48. #EnablingConversations How Chatbot Works Request Response Middleware AI Engine Response

    Request

  49. #EnablingConversations How Chatbot Works Chat Platform Response Request Response Request

  50. #EnablingConversations How Chatbot Works Chat Platform Response Request Response Middleware

    AI Engine Request Webhook Post Message Server API

  51. #EnablingConversations Chat Platform Must Have Chat Platform Input Trigger Webhook

    Post Message Server API

  52. #EnablingConversations Chat Platform Nice to Have Chat Platform Typing API

    Read API Various event API

  53. #EnablingConversations Chat Platform Nice to Have

  54. #EnablingConversations Chat Platform Nice to Have

  55. Build a Scalable Chat Platform That Compatible with Bot Is

    NOT Easy

  56. Make it easier

  57. #EnablingConversations By Using

  58. We are hiring! Especially Backend, SRE Engineers, and Mobile Developers

    Contact Me : [email protected]

  59. Thank you. Let’s have a conversation.
