1. Statsd
   Measure anything


   View Slide

2. Measurement From Outside
   UI & API
   Internal API
   Core
   Measurement


   View Slide

3. Sending Statistics From System
   UI & API
   Internal API
   Core
   Measurement


   View Slide

4. Statsd
   ● Proposed by Etsy
   ● No Standard/RFC (yet)
   ● Send data from within system
   ● Least affect on performance
   ● Metrics: Name, Value, Type over UDP


   View Slide

5. Metrics
   ● Counter
   ● Timing
   ● Gauge
   ● Set


   View Slide

6. Statsd
   App
   Statsd
   Backend
   Storage Metrics
   (UDP)
   Aggregate
   and Persist


   View Slide

7. UI
   API
   Core
   Statsd
   Service
   DB
   Carbon
   (Graphite)
   Custom
   Backend


   View Slide

8. UDP/TCP
   UDP
   ● Faster, Lightweight
   ● Unreliable
   ● Connectionless
   TCP
   ● Slower
   ● Reliable
   ● Connection oriented


   View Slide

9. Statsd and Carbon (Graphite)
   App
   Statsd
   Carbon
   Metrics
   (UDP)
   Flush every
   often (TCP)


   View Slide

10. Graphite
    Carbon
    Time Series
    Database Files
    Whisper
    Graphite
    (Web app)
    Data Metrics via Carbon Protocol
    (text lines over TCP)


    View Slide
