  1. Gareth Rushgrove
    What’s inside that
    container? (redux)

    View Slide

  2. View Slide

  3. @garethr

    View Slide

  4. This talk
    What is this all about?

    View Slide

  5. - Some research
    - Some tools
    - Some live demos

    View Slide

  6. - Some research into container usage
    - Some tools for container analysis
    - Some live demos of said tools

    View Slide

  7. Setting the scene
    Some background

    View Slide

  8. Configuration management camp talk

    View Slide

  9. The New Stack coverage

    View Slide

  10. Caveat, this data is from February

    View Slide

  11. Let’s grab downloads from Hub
    $ curl -s https://registry.hub.docker.com/v2/...
    ...repositories/library/ubuntu/ | jq .pull_count

    View Slide

  12. View Slide

  13. What about other popular official
    images? Node (32,523,647),
    Java (16,635,049), etc. Currently
    based on Debian too

    View Slide

  14. A quick non-scientific poll

    View Slide

  15. Data from GitHub and Google bigquery

    View Slide

  16. The majority of people using
    Docker are using images
    containing an entire operating
    system filesystem

    View Slide

  17. View Slide

  18. Scratch, or other approaches
    like Nix, appear to occupy a
    small niche

    View Slide

  19. Alpine usage is growing more
    rapidly than others, but starting
    from a much smaller install base

    View Slide

  20. Why does this matter?

    View Slide

  21. Images vary in size

    View Slide

  22. Count files on images
    $ find -maxdepth 1 -type d | while read -r dir; do
    printf "%s:\t" "$dir"; find "$dir" -type f | wc
    -l; done

    View Slide

  23. Count packages in images
    $ dpkg -l | grep ^ii | wc -l
    $ dnf list installed
    $ rpm -qa | wc -l
    $ apk info | wc -l

    View Slide

  24. View Slide

  25. Can you tell me all the versions
    of OpenSSL you have in
    production right now?

    View Slide

  26. You mentioned tools
    Anything that can help with these problems?

    View Slide

  27. Option 1: Rebuild everything

    View Slide

  28. Option 2: Something messier

    View Slide

  29. Skopeo from Red Hat

    View Slide

  30. Query registry data without
    downloading the image
    $ skopeo inspect docker://docker.io/fedora

    View Slide

  31. $ skopeo inspect docker://docker.io/fedora
    {
    "Name": "docker.io/library/fedora",
    "Tag": "latest",
    "Digest": "sha256:cfd8f0466748f522406f7ae5908d002af1b1a1",
    "RepoTags": [
    "20",
    "21",
    "22",
    "23",
    "heisenbug",
    "latest",
    "rawhide"
    ],

    View Slide

  32. But what about running
    containers? Or the
    contents of the image?

    View Slide

  33. Lumogon

    View Slide

  34. Open source and on GitHub

    View Slide

  35. Get package and version
    information (and more) from
    Docker containers with:
    $ lumogon scan

    View Slide

  36. $ lumogon scan
    {"$schema":"http://puppet.com/lumogon/core/draft-01/schema#1
    ","generated":"2017-08-07 11:35:16.6517922 +0000
    UTC","owner":"default","group":["default"],"client_version":
    {"BuildVersion":"development","BuildTime":"2017-05-11
    08:24:20
    UTC","BuildSHA":"a7f2943697f83ba74514a0169890ecf8ad1cfacb"},
    "reportid":"c6a8731e-9681-4758-9151-9c2699769418","container
    s":{"8c8024760f3e4692e93c6f4f76dc56eaab879e56ace06f876afeccc
    5c615ac28":{"$schema":"http://puppet.com/lumogon/containerre
    port/draft-01/schema#1","generated":"2017-08-07
    11:35:16.1308581 +0000
    UTC","container_report_id":"2e65f6e7-371d-4bae-9336-85b14b0b
    19c0","container_id":"8c8024760f3e4692e93c6f4f76dc56eaab879e
    56ace06f876afeccc5c615ac28","container_name":"/p

    View Slide

  37. - Packages (rpm, apk, dpkg)
    - Host info (eg. linux distro)
    - Labels and other metadata
    - Extensible with new capabilities

    View Slide

  38. How we have all the data, what
    can we do with it?

    View Slide

  39. List all the debian containers
    $ lumogon scan | jq -r '.containers[] |
    select(.capabilities.host.payload.platformfamily
    == "debian") | .container_name'

    View Slide

  40. $ lumogon scan | jq -r '.containers[] | .container_name + " "
    + .capabilities.dpkg.payload.bash + " " +
    .capabilities.rpm.payload.bash'
    /fixtures_debian-jessie_1 4.3-11+deb8u1
    /fixtures_centos7_1 4.2.46-21.el7_3-x86_64
    /fixtures_fedora_1 4.3.43-4.fc25-x86_64
    /fixtures_debian-wheezy_1 4.2+dfsg-0.1+deb7u4
    /fixtures_ubuntu-xenial_1 4.3-14ubuntu1.1
    List versions of bash in all my containers

    View Slide

  41. A hack for finding packages with CVEs

    View Slide

  42. Query our list of package
    for known CVEs
    $ lumogon scan | findcve lumogon

    View Slide

  43. $ lumogon scan | findcve lumogon
    ==> Scanning /peaceful_goldberg
    apt has vulnerabilities
    Currently installed 1.0.9.8.4
    Latest version 1.0.9.8.4
    CVE-2011-3374 is unimportant
    bash has vulnerabilities
    Currently installed 4.3-11+deb8u1
    Latest version 4.3-11+deb8u1
    CVE-2016-9401 is low**
    TEMP-0841856-B18BAF is unimportant
    coreutils has vulnerabilities
    Currently installed 8.23-4
    Latest version 8.23-4
    CVE-2016-2781 is low**
    dpkg has vulnerabilities

    View Slide

  44. Manifesto from Aqua Security

    View Slide

  45. Store and query metadata
    about Docker images, stored
    alongside the image on Hub

    View Slide

  46. Save Lumogon data
    with manifesto
    $ ./scan-image.sh > /tmp/lumogon.json
    $ manifesto put lumogon /tmp/lumogon.json

    View Slide

  47. See what manifesto data is
    available for our image
    $ manifesto list puppet/puppet-agent
    Metadata types stored for image 'puppet/puppet-agent:latest':
    lumogon

    View Slide

  48. $ manifesto get puppet/puppet-agent lumogon | head -n 10
    {
    "$schema": "http://puppet.com/lumogon/core/draft-01/schema#1",
    "generated": "2017-07-26 16:25:19.858671545 +0000 UTC",
    "owner": "default",
    "group": [
    "default"
    ],
    "client_version": {
    "BuildVersion": "20170612091728-",
    "BuildTime": "2017-06-12 08:17:28 UTC",

    View Slide

  49. Blog post with more examples

    View Slide

  50. Live demo klaxon

    View Slide

  51. Summary
    If all you remember is...

    View Slide

  52. Container adoption needs to
    be a gentle slope, not a base
    jump with a parachute
    marked experimental

    View Slide

  53. The real world is messier than
    the cloud native ideal

    View Slide

  54. We need to consider the
    situation where we are running
    unknown artefacts

    View Slide

  55. Small, composable tools
    point us to higher-level, more
    comprehensive, solutions

    View Slide

  56. I heartily recommend finding out
    what’s inside your containers

    View Slide

  57. Any questions?
    And thanks for listening

    View Slide
