Abusing Async/Await (for fun and profit)

async/await was the hottest feature of C# 6 when it came out, bringing a radically improved way to write asynchronous code and cure us of callback hell. But how does it really work?

In this talk we will take a deeper look at the machinery behind async/await and take advantage of the lesser known tuning capabilities introduced with C# 7 to use async/await in ways you wouldn’t have thought of like re-implementing F# computation expressions and supporting mobile patterns on Android.

Transcript

1. Abusing async/await
   (for fun and profit)


   View Slide

2. Hi!
   I’m Jérémie
   @jeremie_laval
   @garuma


   View Slide

3. Fun fact
   Mono’s Task Parallel Library (TPL) and PLinq


   View Slide

4. Fun fact
   (2)


   View Slide

5. Async fact sheet
   • C# 6 (circa 2015)
   • Based on TPL’s Task primitive
   • State-machine compiler trickery (like yield)
   • A fancy way to chain callbacks


   View Slide

6. http://callbackhell.com/
   fs.readdir(source, function (err, files) {
   if (err) {
   console.log('Error finding files: ' + err)
   } else {
   files.forEach(function (filename, fileIndex) {
   console.log(filename)
   gm(source + filename).size(function (err, values) {
   if (err) {
   console.log('Error identifying file size: ' + err)
   } else {
   console.log(filename + ' : ' + values)
   aspect = (values.width / values.height)
   widths.forEach(function (width, widthIndex) {
   height = Math.round(width / aspect)
   console.log('resizing ' + filename + 'to ' + height + 'x' + height)
   this.resize(width, height).write(dest + 'w' + width + '_' + filename, function(err) {
   if (err) console.log('Error writing file: ' + err)
   })
   }.bind(this))
   }
   })
   })
   }
   })


   View Slide

7. The Async Trifecta
   • Awaiter/Awaitable
   • IAsyncStateMachine
   • AsyncMethodBuilder


   View Slide

8. Awaitable/Awaiter
   • Simpler abstractions than plain Task
   • Same concept as IEnumerable/IEnumerator
   • Convention based!


   View Slide

9. Awaitable Conventions
   interface IAwaitable
   {
   IAwaiter GetAwaiter ();
   }
   // Or
   struct StructAwaitable
   {
   IAwaiter GetAwaiter ();
   }
   // Or
   public static class Extensions
   {
   public static IAwaiter GetAwaiter (this MyClass self);
   }


   View Slide

10. Awaiter
    interface IAwaiter : INotifyCompletion
    {
    bool IsCompleted { get; }
    void OnCompleted (Action action);
    void GetResult ();
    // Or
    OtherType GetResult ();
    }


    View Slide

11. Async functions
    A method or anonymous function with the async modi3ier is
    called an async function. In general, the term async is used to
    describe any kind of function that has the async modi3ier.
    The return_type of an async method must be either void or a task
    type. The task types are System.Threading.Tasks.Task and types
    constructed from System.Threading.Tasks.Task
    C#6


    View Slide

12. Async rewriting
    class MainClass

    {

    public static async Task Main (string[] args)

    {

    Console.WriteLine ("Hello");

    await Task.Delay (200);

    Console.WriteLine ("World");

    }

    }
    [AsyncStateMachine (typeof(MainClass.d__0))]

    public static Task Main (string[] args)

    {

    MainClass.d__0 d__ = new MainClass.d__0 ();

    d__.args = args;

    d__.<>t__builder = AsyncTaskMethodBuilder.Create ();

    d__.<>1__state = -1;

    AsyncTaskMethodBuilder <>t__builder = d__.<>t__builder;

    <>t__builder.Startd__0> (ref d__);

    return d__.<>t__builder.Task;

    }
    [AsyncStateMachine (typeof(AutoGeneratedStateMachine))]

    public static Task Main (string[] args)

    {

    AutoGeneratedStateMachine stateMachine = new AutoGeneratedStateMachine ();

    stateMachine.args = args;

    stateMachine.builder = AsyncTaskMethodBuilder.Create ();

    stateMachine.state = -1;

    AsyncTaskMethodBuilder builder = stateMachine.builder;

    builder.Start (ref stateMachine);

    return stateMachine.builder.Task;

    }


    View Slide

13. Where’s my code?


    View Slide

14. Customizing async
    • TaskCompletionSource
    • Custom awaiter/awaitable
    • Custom AsyncMethodBuilder C#7


    View Slide

15. Custom Awaiters
    • Tasks have their own TaskAwaiter
    • Task.Yield() is a custom awaiter

    • Represent any form of async operations
    • … Or not!
    public static System.Runtime.CompilerServices.YieldAwaitable Yield ();


    View Slide

16. The story of an optimization
    interface IAwaiter : INotifyCompletion
    {
    bool IsCompleted { get; }
    void OnCompleted (Action action);
    void GetResult ();
    // Or
    OtherType GetResult ();
    }


    View Slide

17. Midori
    Joe Duffy
    The 3irst key optimization, therefore, is that an async
    method that doesn’t await shouldn’t allocate anything.
    We were able to share this experience with .NET in time
    for C#’s await to ship.
    http://joeduffyblog.com/2015/11/19/asynchronous-everything/


    View Slide

18. var awaiter = /*awaitable*/.GetAwaiter ();
    if (!awaiter.IsCompleted) {
    // Indirectly call awaiter.OnCompleted
    this.builder.AwaitOnCompleted (/**/);
    return;
    }
    Allocations in there usually


    View Slide

19. Demo: ThreadPoolAwaiter


    View Slide

20. Customizing async
    • Custom awaiter/awaitable
    • Custom AsyncMethodBuilder C#7


    View Slide

21. Async functions
    A method or anonymous function with the async modi3ier is
    called an async function. In general, the term async is used to
    describe any kind of function that has the async modi3ier.
    The return_type of an async method must be either void or a task
    type. The task types are System.Threading.Tasks.Task and types
    constructed from System.Threading.Tasks.Task
    C#6


    View Slide

22. Another Optimization Story
    https://github.com/dotnet/roslyn/issues/7169


    View Slide

23. Another Optimization Story
    https://github.com/dotnet/corefx/pull/10201


    View Slide

24. ValueTask
    async Task Get404IntegerAsync ()
    {
    if (conditionThatsAlmostAlwaysTrue)
    return 404;
    return await Expensive404Async ();
    }
    Reference type Value type
    Allocation


    View Slide

25. Custom AsyncMethodBuilder
    •Created to (predominantly) support ValueTask
    •Optimize fast path to remove Task allocation
    •Can be used by us too!
    C#7


    View Slide

26. Demo: FancyTask


    View Slide

27. ActivityTask
    • async/await totally supported by Xamarin.Android
    • Async needs to understand Android lifecycle
    • Problem 1: Android Activity survival not guaranteed!
    • Problem 2: Activity are pausable/freezable!
    https://blog.neteril.org/blog/2017/05/22/activitytask-async-await-android-cornercases/


    View Slide

28. Demo: ActivityTask


    View Slide

29. View Slide

30. F# computation expression
    let divideBy bottom top = if bottom = 0 then None else Some(top/bottom)
    type MaybeBuilder() =
    member this.Bind(m, f) = Option.bind f m
    member this.Return(x) = Some x
    let maybe = new MaybeBuilder()
    let divideByWorkflow x y w z = maybe {
    let! a = x |> divideBy y
    let! b = a |> divideBy w
    let! c = b |> divideBy z
    return c
    }
    // test
    let good = divideByWorkflow 12 3 2 1
    let bad = divideByWorkflow 12 3 0 1
    https://fsharpforfunandprofit.com/series/computation-expressions.html


    View Slide

31. Demo: F# Option
    computation expression
    https://blog.neteril.org/blog/2017/04/26/maybe-computation-expression-csharp/


    View Slide

32. Take-away
    C# async/await is a generic facility
    to create chainable continuations
    and apply cool stuff in-between


    View Slide
