Coroutine + Flow = MVI ❤ by Étienne Caron

Coroutine + Flow = MVI ❤
Level: Intermediate
by Étienne Caron, Google Developer Expert, Shopify

Managing state in Android applications can be painful. Over the years, various architectural patterns have evolved to try and tame it: MVC, MVP, and MVVM. MVI (Model-View-Intent) is an evolution of these patterns. Thanks to Immutable State management and Unidirectional Data Flow, we can finally say goodbye to race conditions and rogue mutations. Combine the power of MVI with Kotlin Coroutines alongside the recently released Kotlin Flows library. The result? Real magic. No RxJava incantations required! In this session, you’ll learn how to build a Model-View-Intent (MVI) Android App, using both Kotlin Coroutines and Kotlin Flows. You’ll walk away understanding the core principles of this pattern, as well as its key benefits. Get ready to fall for MVI❤!
https://gdgmontreal.com/2019/07/26/kotlin-everywhere/

Transcript

1. Coroutine + Flow


   View Slide

2. Coroutine + Flow = MVI ❤


   View Slide

3. http://hannesdorfmann.com/android/mosby3-mvi-1


   View Slide

4. View Slide

5. https://xkcd.com/1312


   View Slide

6. https://xkcd.com/1312


   View Slide

7. View Slide

8. !


   View Slide

9. "


   View Slide

10. private val disposables = CompositeDisposable()
    disposables += streamA().subscribe(1)1
    disposables += streamB().subscribe(1)1
    disposables.clear()
    ♻


    View Slide

11. Photo source info here
    Coroutines & Flow


    View Slide

12. Photo source info here
    Coroutines & Flow
    ♻


    View Slide

13. Photo source info here
    Coroutines & Flow
    "


    View Slide

14. Photo source info here
    Coroutines & Flow
    !❓


    View Slide

15. output
    input
    input
    output
    user
    device


    View Slide

16. output
    input
    input
    output
    user
    device


    View Slide

17. output
    input
    input
    output
    user
    device


    View Slide

18. output
    input
    input
    output
    user
    device


    View Slide

19. input
    output
    input output
    user
    device


    View Slide

20. Model
    Intent
    View


    View Slide

21. Intent
    View
    View


    View Slide

22. Intent
    View


    View Slide

23. Intent
    View


    View Slide

24. View MainViewEvent Intent
    sealed class MainViewEvent {_
    object ThumbsUpClick :_MainViewEvent()
    object LoveItClick :_MainViewEvent()
    }_
    View


    View Slide

25.
    View
    sealed class MainViewEvent {_
    object ThumbsUpClick :_MainViewEvent()
    object LoveItClick :_MainViewEvent()
    }_
    MainViewEvent
    ThumbsUpClick
    LoveItClick
    +
    +❤
    ❤
    ❤


    View Slide

26. View
    ❤ ❤
    fun View.clicks(): Flow = callbackFlow {
    val listener = View.OnClickListener { offer(Unit) }
    setOnClickListener(listener)
    awaitClose {
    setOnClickListener(null)
    }
    }


    View Slide

27. View
    ❤ ❤
    fun View.clicks(): Flow = callbackFlow {
    val listener = View.OnClickListener { offer(Unit) }
    setOnClickListener(listener)
    awaitClose {
    setOnClickListener(null)
    }
    }


    View Slide

28. View
    ❤ ❤
    fun View.clicks(): Flow = callbackFlow {
    val listener = View.OnClickListener { offer(Unit) }
    setOnClickListener(listener)
    awaitClose {
    setOnClickListener(null)
    }
    }


    View Slide

29. View
    ❤ ❤
    fun View.clicks(): Flow = callbackFlow {
    val listener = View.OnClickListener { offer(Unit) }
    setOnClickListener(listener)
    awaitClose {
    setOnClickListener(null)
    }
    }
    ~


    View Slide

30. ❤ ❤
    View.clicks():Flow
    View
    Flow


    View Slide

31. View
    thumbButton.clicks()
    map { MainViewEvent.ThumbsUpClick }

    Flow
    ❤ ❤


    View Slide

32. View
    heartButton.clicks()
    map { MainViewEvent.LoveItClick }
    ❤ ❤
    Flow
    ❤ ❤


    View Slide

33. val flows = listOf(
    heartButton.clicks().map { MainViewEvent.LoveItClick },
    thumbButton.clicks().map { MainViewEvent.ThumbsUpClick }
    )x
    return flows.asFlow().flattenMerge(flows.size)_
    Flow
    View
    ❤ ❤


    View Slide

34. View
    ❤ ❤
    class MainActivity {__
    override_fun_viewEvents(): Flow_{
    val flows = listOf(
    heartButton.clicks().map { MainViewEvent.LoveItClick },
    thumbButton.clicks().map { MainViewEvent.ThumbsUpClick }
    )x
    return flows.asFlow().flattenMerge(flows.size)_
    }_
    }__


    View Slide

35. View
    ❤ ❤
    class MainActivity {__
    override_fun_viewEvents(): Flow_{
    val flows = listOf(
    heartButton.clicks().map { MainViewEvent.LoveItClick },
    thumbButton.clicks().map { MainViewEvent.ThumbsUpClick }
    )x
    return flows.asFlow().flattenMerge(flows.size)_
    }_
    }__


    View Slide

36. View
    ❤ ❤
    class MainActivity {__
    override_fun_viewEvents(): Flow_{
    val flows = listOf(
    heartButton.clicks().map { MainViewEvent.LoveItClick },
    thumbButton.clicks().map { MainViewEvent.ThumbsUpClick }
    )x
    return flows.asFlow().flattenMerge(flows.size)_
    }_
    }__


    View Slide

37. class MainActivity {__
    override_fun_viewEvents(): Flow_{
    val flows = listOf(
    heartButton.clicks().map { MainViewEvent.LoveItClick },
    thumbButton.clicks().map { MainViewEvent.ThumbsUpClick }
    )x
    return flows.asFlow().flattenMerge(flows.size)_
    }_
    }__
    View
    ❤ ❤


    View Slide

38. /**
    * This allows us to group all the_viewEvents from
    * one view in a single Flow.
    */
    interface ViewEventFlow {
    funxviewEvents():xFlow
    }x
    class MainActivity_: ViewEventFlow {x_
    override_fun_viewEvents(): Flow_{
    val flows = listOf(
    heartButton.clicks().map { MainViewEvent.LoveItClick },
    thumbButton.clicks().map { MainViewEvent.ThumbsUpClick }
    )x
    return flows.asFlow().flattenMerge(flows.size)_
    }_
    }__
    View
    ❤ ❤


    View Slide

39. class MainActivity_: ViewEventFlow {x_
    val_scope: CoroutineScope_= MainScope()
    override_fun_onCreate(savedInstanceState: Bundle?)_{
    super.onCreate(savedInstanceState)
    // ...
    }1
    override_fun_onDestroy()_{
    super.onDestroy()
    scope.cancel()
    }2
    override_fun_viewEvents(): Flow_{
    // ...
    }_
    }__
    View Intent


    View Slide

40. class MainActivity_: ViewEventFlow {x_
    val_scope: CoroutineScope_= MainScope()
    override_fun_onCreate(savedInstanceState: Bundle?)_{
    super.onCreate(savedInstanceState)
    // ...
    }1
    override_fun_onDestroy()_{
    super.onDestroy()
    scope.cancel()
    }2
    override_fun_viewEvents(): Flow_{
    // ...
    }_
    }__
    View Intent


    View Slide

41. class MainActivity_: ViewEventFlow {x_
    val_scope: CoroutineScope_= MainScope()
    override_fun_onCreate(savedInstanceState: Bundle?)_{
    super.onCreate(savedInstanceState)
    // ...
    scope.launch_{
    viewEvents()
    .onEach { ?_}
    .collect()
    }
    }1
    override_fun_onDestroy()_{
    super.onDestroy()
    scope.cancel()
    }2
    override_fun_viewEvents(): Flow_{
    // ...
    }_
    }__
    View Intent


    View Slide

42. class MainActivity_: ViewEventFlow {x_
    val_scope: CoroutineScope_= MainScope()
    override_fun_onCreate(savedInstanceState: Bundle?)_{
    super.onCreate(savedInstanceState)
    // ...
    scope.launch_{
    viewEvents()
    .onEach { ?_}
    .collect()
    }
    }1
    override_fun_onDestroy()_{
    super.onDestroy()
    scope.cancel()
    }2
    override_fun_viewEvents(): Flow_{
    // ...
    }_
    }__
    View Intent
    ~


    View Slide

43. class MainActivity_: ViewEventFlow {x_
    val_scope: CoroutineScope_= MainScope()
    override_fun_onCreate(savedInstanceState: Bundle?)_{
    super.onCreate(savedInstanceState)
    // ...
    scope.launch_{
    viewEvents()
    .onEach { ?_}
    .collect()
    }
    }1
    override_fun_onDestroy()_{
    super.onDestroy()
    scope.cancel()
    }2
    override_fun_viewEvents(): Flow_{
    // ...
    }_
    }__
    View Intent
    ~


    View Slide

44. class MainActivity_: ViewEventFlow {x_
    val_scope: CoroutineScope_= MainScope()
    override_fun_onCreate(savedInstanceState: Bundle?)_{
    super.onCreate(savedInstanceState)
    // ...
    scope.launch_{
    viewEvents()
    .onEach { ?_}
    .collect()
    }
    }1
    override_fun_onDestroy()_{
    super.onDestroy()
    scope.cancel()
    }2
    override_fun_viewEvents(): Flow_{
    // ...
    }_
    }__
    View Intent
    ~


    View Slide

45. class MainActivity_: ViewEventFlow {x_
    val_scope: CoroutineScope_= MainScope()
    override_fun_onCreate(savedInstanceState: Bundle?)_{
    super.onCreate(savedInstanceState)
    // ...
    scope.launch_{
    viewEvents()
    .onEach { ?_}
    .collect()
    }
    }1
    override_fun_onDestroy()_{
    super.onDestroy()
    scope.cancel()
    }2
    override_fun_viewEvents(): Flow_{
    // ...
    }_
    }__
    View Intent
    ~


    View Slide

46. class MainActivity_: ViewEventFlow {x_
    val_scope: CoroutineScope_= MainScope()
    override_fun_onCreate(savedInstanceState: Bundle?)_{
    super.onCreate(savedInstanceState)
    // ...
    viewEvents()
    .onEach { ? }
    .launchIn(scope)
    }1
    override_fun_onDestroy()_{
    super.onDestroy()
    scope.cancel()
    }2
    override_fun_viewEvents(): Flow_{
    // ...
    }_
    }__ View Intent


    View Slide

47. class MainActivity_: ViewEventFlow {x_
    val_scope: CoroutineScope_= MainScope()
    override_fun_onCreate(savedInstanceState: Bundle?)_{
    super.onCreate(savedInstanceState)
    // ...
    viewEvents()
    .onEach { event -> ? }
    .launchIn(scope)
    }1
    override_fun_onDestroy()_{
    super.onDestroy()
    scope.cancel()
    }2
    override_fun_viewEvents(): Flow_{
    // ...
    }_
    }__ View Intent


    View Slide

48. View Intent

    class MainActivity_: ViewEventFlow {x_
    val_scope: CoroutineScope_= MainScope()
    override_fun_onCreate(savedInstanceState: Bundle?)_{
    super.onCreate(savedInstanceState)
    // ...
    viewEvents()
    .onEach { event ->
    MainViewIntentFactory.process(event)
    }
    .launchIn(scope)
    }1
    override_fun_onDestroy()_{
    super.onDestroy()
    scope.cancel()
    }2
    override_fun_viewEvents(): Flow_{
    // ...
    }_
    }__
    ~


    View Slide

49. ModelState
    store
    x
    Intent
    View

    ❓
    Model


    View Slide

50. ModelState
    store
    Model
    val ❤:Int
    val :Int


    View Slide

51. ModelState
    store
    Model
    val ❤:Int
    val :Int
    data class UpvoteModel(val hearts:Int, val thumbs:Int)
    (Don’t mind me. My
    turn is coming up
    soon.)


    View Slide

52. ModelState
    store
    Intent
    View

    Model
    data class UpvoteModel(val hearts:Int, val thumbs:Int)
    newState = oldState.copy(thumbs = thumbs + 1) // 0, 1
    newState = newState.copy(hearts = hearts + 1) // 1, 1
    newState = newState.copy(hearts = hearts + 1) // 2, 1
    val ❤ :Int
    val :Int
    ❓


    View Slide

53. ModelState
    store
    Intent
    View

    Model
    data class UpvoteModel(val hearts:Int, val thumbs:Int)
    interface Intent {x
    fun reduce(oldState: T): T
    }x
    val ❤ :Int
    val :Int


    View Slide

54. ModelState
    store
    Intent
    View

    Model
    data class UpvoteModel(val hearts:Int, val thumbs:Int)
    interface Intent {x
    fun reduce(oldState: T): T
    }x
    class AddHeart():Intent {y
    override fun reduce(oldState: UpvoteModel)_=
    oldState.copy(hearts =_oldState.hearts_+ 1)
    }y
    val ❤ :Int
    val :Int


    View Slide

55. ModelState
    store
    Intent
    View

    Model
    data class UpvoteModel(val hearts:Int, val thumbs:Int)
    fun_toIntent(viewEvent: MainViewEvent):Intent_{
    return when (viewEvent) {z
    MainViewEvent.LoveItClick ->_AddHeart()
    MainViewEvent.ThumbsUpClick ->_AddThumb()
    }z
    }z2
    val ❤ :Int
    val :Int


    View Slide

56. interface IntentFactory_{
    suspend fun_process(viewEvent:E)
    }y
    object MainViewIntentFactory :-IntentFactory_{
    override suspend fun_process(viewEvent: MainViewEvent)_{
    UpvoteModelStore.process(toIntent(viewEvent))
    }x
    private fun_toIntent(viewEvent: MainViewEvent):Intent_{
    return when (viewEvent) {z
    MainViewEvent.LoveItClick ->_AddHeart()
    MainViewEvent.ThumbsUpClick ->_AddThumb()
    }z
    }z2
    }w
    Intent
    View

    ~


    View Slide

57. Intent
    View

    ~
    interface IntentFactory_{
    suspend fun_process(viewEvent:E)
    }y
    object MainViewIntentFactory :-IntentFactory_{
    override suspend fun_process(viewEvent: MainViewEvent)_{
    UpvoteModelStore.process(toIntent(viewEvent))
    }x
    private fun_toIntent(viewEvent: MainViewEvent):Intent_{
    return when (viewEvent) {z
    MainViewEvent.LoveItClick ->_AddHeart()
    MainViewEvent.ThumbsUpClick ->_AddThumb()
    }z
    }z2
    }w


    View Slide

58. Intent
    View

    ~
    interface IntentFactory_{
    suspend fun_process(viewEvent:E)
    }y
    object MainViewIntentFactory :-IntentFactory_{
    override suspend fun_process(viewEvent: MainViewEvent)_{
    UpvoteModelStore.process(toIntent(viewEvent))
    }x
    private fun_toIntent(viewEvent: MainViewEvent):Intent_{
    return when (viewEvent) {z
    MainViewEvent.LoveItClick ->_AddHeart()
    MainViewEvent.ThumbsUpClick ->_AddThumb()
    }z
    }z2
    }w


    View Slide

59. Intent
    View

    ~
    interface IntentFactory_{
    suspend fun_process(viewEvent:E)
    }y
    object MainViewIntentFactory :-IntentFactory_{
    override suspend fun_process(viewEvent: MainViewEvent)_{
    UpvoteModelStore.process(toIntent(viewEvent))
    }x
    private fun_toIntent(viewEvent: MainViewEvent):Intent_{
    return when (viewEvent) {z
    MainViewEvent.LoveItClick ->_AddHeart()
    MainViewEvent.ThumbsUpClick ->_AddThumb()
    }z
    }z2
    }w


    View Slide

60. ModelStore
    RxModelStore
    UpvoteModelStore
    FlowModelStore
    Intent
    interface_ModelStore_{y
    suspend_fun process(intent: Intent)
    fun modelState(): Flow
    }yy
    override suspend fun_process(viewEvent: MainViewEvent)_{
    UpvoteModelStore.process(toIntent(viewEvent))
    }x
    (Don’t mind me. My
    turn is coming up soon
    too.)
    Model
    val ❤ :Int
    val :Int
    ModelState
    store
    + +
    +


    View Slide

61. Intent
    interface_ModelStore_{y
    suspend_fun process(intent: Intent)
    fun modelState(): Flow
    }yy
    Model
    val ❤ :Int
    val :Int
    ModelState
    store
    + +
    +
    ModelStore
    RxModelStore
    UpvoteModelStore
    FlowModelStore
    (Don’t mind me. My
    turn is coming up soon
    too.)


    View Slide

62. x
    +❤ +❤
    +
    Intent

    ModelState
    store
    Hi again!
    interface_ModelStore_{y
    suspend_fun process(intent: Intent)
    fun modelState(): Flow
    }yy


    View Slide

63. x
    val intents = Channel>()
    +❤ +❤
    +
    Intent

    ModelState
    store
    suspend fun process(intent: Intent) {
    intents.send(intent)
    }
    ~


    View Slide

64. x
    val intents = Channel>()
    +❤ +❤
    +
    Intent

    ModelState
    store
    suspend fun process(intent: Intent) {
    intents.send(intent)
    }
    ~
    val store = ConflatedBroadcastChannel(startingState)
    override fun modelState(): Flow {
    return store.asFlow()
    }


    View Slide

65. val intents = Channel>()
    +❤ +❤
    +
    Intent

    ModelState
    store
    ❓❓❓
    val store = ConflatedBroadcastChannel(startingState)


    View Slide

66. +❤ +❤
    +
    Intent

    0❤, 0
    0❤, 0
    1❤, 1 2❤, 1
    ModelState
    store
    store.offer(intents.receive().reduce(store.value))
    val store = ConflatedBroadcastChannel(startingState)
    val intents = Channel>()
    0❤, 1


    View Slide

67. open class FlowModelStore(startingState: S) : ModelStore {
    private val scope = MainScope()
    private val intents = Channel>()
    private val store = ConflatedBroadcastChannel(startingState)
    init {
    // Reduce from MainScope()
    scope.launch {
    while (isActive) store.offer(intents.receive().reduce(store.value))
    }
    }
    // Could be called from any coroutine scope/context.
    override suspend fun process(intent: Intent) {
    intents.send(intent)
    }
    override fun modelState(): Flow {
    return store.asFlow()
    }
    fun close() {
    intents.close()
    store.close()
    scope.cancel()
    }
    }
    ModelStore
    RxModelStore
    UpvoteModelStore
    FlowModelStore


    View Slide

68. interface_ModelStore_{
    suspend fun process(intent: Intent)
    fun modelState(): Flow
    }x
    object UpvoteModelStore :_
    FlowModelStore(UpvoteModel(0, 0))
    open class FlowModelStore(startingState: S) : ModelStore {
    // ...
    }
    ModelStore
    FlowModelStore
    UpvoteModelStore


    View Slide

69. object UpvoteModelStore :_
    FlowModelStore(UpvoteModel(0, 0))
    UpvoteModelStore


    View Slide

70. Intent
    View

    Model
    val ❤ :Int
    val :Int
    ModelState
    store
    object UpvoteModelStore


    View Slide

71. Intent
    View

    Model
    val ❤ :Int
    val :Int
    ModelState
    store
    interface_ModelStore_{
    fun process(intent: Intent)
    fun modelState(): Flow
    }x
    fun modelState(): Flow
    object UpvoteModelStore


    View Slide

72. View
    Model
    fun Flow.forCounterTextView() =
    onEach { model ->
    counterTextView.text =
    }
    // Input(s)
    UpvoteModelStore
    .modelState()
    .forCounterTextView()
    .launchIn(scope)
    0❤, 1
    0❤, 0 1❤, 1 2❤, 1


    View Slide

73. Live demo?


    View Slide

74. https://github.com/kanawish/upvote


    View Slide

75. Photo source info here
    Thank you!
    https://github.com/kanawish/upvote


    View Slide
