  1. Notes on multi-script

    typeface design
    Gerry Leonidas

    View Slide

  2. Introduction:
    A comment on the current state of
    typeface design for non-Latin scripts,
    summarising the points made on

    “Going Global” [next four slides]

    View Slide

  3. 1. two and a half steps

    View Slide

  4. 1) Providing basic,

    but correct, support

    View Slide

  5. 2) Covering mainstream

    genre requirements

    View Slide

  6. 3) Innovating in typeface design

    to support rich typography

    View Slide

  7. 2. Multi-script or Other-script?

    View Slide

  8. Distinguishing between designing
    typefaces for documents integrating
    more than one script, and designing
    typefaces for scripts that the designer

    is unfamiliar with, for overwhelmingly
    single-script use.

    View Slide

  9. One script:
    Typographic adaptation

    to typesetting processes

    View Slide

  10. In the case of new single-script
    typefaces, the main challenge has been
    the adaptation of script complexity to
    the limitations of type-making and
    typesetting systems developed for
    another context.

    View Slide

  11. Risk:
    research is time-consuming, costly,
    difficult, or even impossible

    View Slide

  12. Commercial pressures (time allocation,
    budget limits, lack of sufficient clarity at
    the project definition) and the variable
    access to trustworthy information and
    feedback jeopardise projects.

    View Slide

  13. Multi-script:
    Parallel texts or embedded

    words and sentences

    View Slide

  14. Distinguishing between one column

    of a script next to, or opposite to, one

    in another script (e.g. in a translated
    text) and embedded use (e.g. a word

    or a phrase in one script within
    sentences in another).

    View Slide

  15. Risk:
    the assumptions of the dominant

    script determine design decisions

    View Slide

  16. Features from the original script can be
    shoehorned onto the “secondary” script.
    These may include vertical proportions,
    stroke dimensions and modulation,
    terminal formation, handling of
    punctuation, and so on.

    View Slide

  17. Latinisation
    and / or
    Typographicisation*
    !
    !
    * invented word

    View Slide

  18. Latinisation: the design of a non-Latin
    script using design patterns and even
    specific formal elements from the Latin,
    usually with a mismatch between the
    typographic and stylistic connotations
    of the two scripts (e.g. “modern” ).

    View Slide

  19. Typographicisation: the adaptation of

    a script that has forms and behaviour
    determined by written forms to the
    constraints of a type-making and
    typesetting system. This script may

    often be used on its own.

    View Slide

  20. 3 Design challenges

    View Slide

  21. Type-making and typesetting tools
    Legacy “typewriter” fonts
    Latin-centric terminology

    View Slide

  22. Limitations examples: character sets,
    many-to-many substitutions.
    “Typewriter” fonts: from actual type-
    writers, to early digital. Of marginal
    formal quality, developed under extreme
    limitations, but still influential.

    View Slide

  23. Character set determinism
    Algorithmic line-level behaviours
    Changes within a community’s

    memory

    View Slide

  24. Character sets change over time, across
    documents, and communities. The
    “definitive” versions might not exist.
    Intensely context-dependent
    substitutions.
    Changes to a script across generations.

    View Slide

  25. Western type-family compositions
    Input conventions
    Minority scripts, dialects, and

    regional “parallel identities”

    View Slide

  26. Type family conventions for weight /
    width / style from Latin typefaces that
    do not transfer easily to another script.
    Communities sharing a complex script,
    but not a language, an orthography, or
    international visibility.

    View Slide

  27. Stroke modulation and proportions
    Range of curves and counters
    Range of in/out points
    Number of continuous strokes

    View Slide

  28. The variability of radii and counter
    shapes are most likely more complex
    than in the Latin; stroke dimensions
    tend to respond to these factors.
    Transferring the logic of the ductus into
    the typographic forms.

    View Slide

  29. Parity with existing styles
    Opportunities for expansion

    View Slide

  30. The fewer the existing relevant typefaces
    for a script, the more pressure for new
    ones to relate to them.
    Conventional ways to expand a type
    family may not apply to a non-Latin
    script, requiring innovative thinking.

    View Slide

  31. The cultural moment!
    Modernity vs. convention
    Variety and differentiation
    Identity and exploration

    View Slide

  32. Typefaces respond to and reflect the
    range from language preservation to
    mainstream textual communication,

    to imported / novel genres that express
    aspirational classes and generational
    identification.

    View Slide

  33. p.s. Where’s the intelligence?

    View Slide

  34. As a typeface project develops, how do
    we capture the design decisions and the
    knowledge generated? And how is this
    built upon across projects? Our current
    workflows aim at final outputs, not
    capturing and analysing processes.

    View Slide

  35. N.b.
    No part of this discussion

    needs to stem from the

    technology of type-making.

    View Slide

  36. We lack a clear, shared language

    to discuss typeface design decisions

    for shapes and behaviours that is
    independent of the means of making
    fonts.

    View Slide

  37. Thank you!
    !
    @gerryleonidas
    @typefacedesign

    View Slide
