  1. Energy Efficiency in Data Centers
    Marina Zapater

    Marina  Zapater  |    Going    Green
    1
    GreenLSI  –  Integrated  Systems  Lab
    Electronic  Engineering  Dept
    Green

    View Slide

  2. Green
    Marina  Zapater  |    Going  Green   2
    Data Centers

    View Slide

  3. Green
    Marina  Zapater  |    Going  Green   3
    Outline
    •  Why  Data  Centers  (DC)  in
    this  Workshop?
    •  The  DC  in  next-­‐genera?on
    applica?ons
    •  Energy  consump?on  at  the
    Data  Center
    •  Insight  on  op?miza?on
    strategies
    •  Conclusions

    View Slide

  4. Green
    Marina  Zapater  |    Going  Green   4
    Outline
    •  Why  Data  Centers  (DC)  in
    this  Workshop?
    •  The  DC  in  next-­‐genera?on
    applica?ons
    •  Energy  consump?on  at  the
    Data  Center
    •  Insight  on  op?miza?on
    strategies
    •  Conclusions

    View Slide

  5. Green
    Marina  Zapater  |    Going  Green   5
                       US  EPA  2007  Report  to  Congress  on  Server  and  Data  Center  Energy  Efficiency
    Why DC in this Workshop?
    Motivation

    View Slide

  6. Green
    Marina  Zapater  |    Going  Green   6
    Motivation
    •  Energy  consump?on  of  data  centers
    –  1.3%  of  worldwide  energy  produc?on  in  2010
    –  USA:  80  mill  MWh/year  in  2011  =  1,5  x  NYC
    –  1  data  center  =  25  000  houses
    •  More  than  43  Million  Tons  of  CO2
     emissions  per
    year  (2%  worldwide)
    •  More  water  consump?on  than  many  industries
    (paper,  automo?ve,  petrol,  wood,  or  plas?c)
                       Jonathan  Koomey.  2011.  Growth  in  Data  center  electricity  use  2005  to  2010

    View Slide

  7. Green
    Marina  Zapater  |    Going  Green   7
    Motivation
    José  M.Moya  |    Madrid  (Spain),  July  27,  2012   7
    •  It  is  expected  for  total  data
    center  electricity  use  to
    exceed  400  GWh/year  by
    2015.
    •  The  required  energy  for
    cooling  will  con?nue  to  be  at
    least  as  important  as  the
    energy  required  for  the
    computa?on.
    •  Energy  op?miza?on  of  future
    data  centers  will  require  a
    global  and  mul?-­‐disciplinary
    approach.
    0
    5000
    10000
    15000
    20000
    25000
    30000
    35000
    2000   2005   2010
    World  server  installed  base
    (thousands)
    High-­‐end  servers
    Mid-­‐range  servers
    Volume  servers
    0
    50
    100
    150
    200
    250
    300
    2000   2005   2010
    Electricity  use
    (billion  kWh/year)
    Infrastructure
    Communica?ons
    Storage
    High-­‐end  servers
    Mid-­‐range  servers
    Volume  servers
    5,75  Million  new  servers  per  year
    10%  unused  servers  (CO2
     emissions
    similar  to  6,5  million  cars)

    View Slide

  8. Green
    Marina  Zapater  |    Going  Green   8
    What about urban DC?
    •  50%  of  urban  DC  have  already  or  will  soon  reach  the
    maximum  capacity  of  the  power  grid

    View Slide

  9. Green
    Marina  Zapater  |    Going  Green   9
    Tier 4 Data Center

    View Slide

  10. Green
    Marina  Zapater  |    Going  Green   10
    Outline
    •  Why  Data  Centers  (DC)  in
    this  Workshop?
    •  The  DC  in  next-­‐generaNon
    applicaNons
    •  Energy  consump?on  at  the
    Data  Center
    •  Insight  on  op?miza?on
    strategies
    •  Our  vision  and  future  trends

    View Slide

  11. Green
    Marina  Zapater  |    Going  Green   11
    The DC in next generation
    applications
    •  Tradi?onal  uses  of  Data  Centers:
    –  Webmail,  Web  search,  Databases,  Social  networking  or  distributed
    storage,  High-­‐performance  compu?ng  (HPC),  Cloud  compu?ng
    •  Next-­‐genera?on  applica?ons:
    –  Popula?on  monitoring  applica?ons:  e-­‐Health,  Ambient  Assisted  Living
    –  Smart  ci?es
    •  Next-­‐genera?on  applica?ons  generate  huge  amounts  of  data
    •  Need  to  store,  analize  and  generate  knowledge

    View Slide

  12. Green
    Marina  Zapater  |    Going  Green   12
    Global energy optimization
    •  Solu?on:  GoingGreen!
    •  How:  Global  energy  op?miza?on  strategies
    –  Proposal  of  a  holis?c  energy  op?miza?on  framework
    –  Minimizing  overall  power  consump?on
    –  Mul?-­‐level  op?miza?on:  WBSN,  Personal  Servers  and  Data  Centers

    View Slide

  13. Green
    Marina  Zapater  |    Going  Green   13
    Global energy optimization
    •  Execu?ng  part  of  the  workload  in  the  Personal  Servers
    –  Classifying  tasks  depending  on  their  demand
    –  Resource  management  techniques  based  on  fast  run?me  alloca?on
    algorithms  executed  on  the  Personal  Servers
    –  Execu?ng  some  tasks  in  Personal  Servers  instead  of  forwarding  load  to  DC.
    –  Up  to  10%  in  energy  savings  and  15%  execu?on  ?me  savings

    View Slide

  14. Green
    Marina  Zapater  |    Going  Green   14
    Outline
    •  Why  Data  Centers  (DC)  in  this
    Workshop?
    •  The  DC  in  next-­‐genera?on
    applica?ons
    •  Energy  consumpNon  at  the
    Data  Center
    •  Insight  on  op?miza?on
    strategies
    •  Conclusions

    View Slide

  15. Green
    Marina  Zapater  |    Going  Green   15
    Energy Consumption at the DC
    What is really a Data Center?
    hjp://cesvima.upm.es
    WORKLOAD
    Scheduler   Resource
    Manager
    ExecuNon

    View Slide

  16. Green
    Marina  Zapater  |    Going  Green   16
    Energy Consumption at the DC
    How does cooling work?
    •  Typical  raised-­‐floor  air-­‐cooled  Data  Center:

    View Slide

  17. Green
    Marina  Zapater  |    Going  Green   17
    Energy Consumption at the DC
    Power consumption breakdown
    •  The  major  contributors  to  electricity  costs  are:
    –  Cooling  (around  50%)
    –  Servers  (around  30-­‐40%)
    •  The  most  common  metric  to  measure  efficiency  in
    Data  Centers  is  PUE  (Power  Usage  Effec?veness)

    View Slide

  18. Green
    Marina  Zapater  |    Going  Green   18
    Power Usage Effectiveness
    (PUE)
    •  Average  PUE  ≈  2
    •  State  of  the  Art:    PUE  ≈  1,2
    –  The  important  part  is  IT  energy  consump?on
    –  Current  work  in  energy  efficient  data  centers  is  focused  in
    decreasing  PUE
    –  Decreasing  PIT
    does  not  decrease  PUE,  but  it  has  in  impact
    on  the  electricity  bill
    !"# =
    1
    !"#$
    =
    !!"!#$
    !!"
    =!
    !
    !!!!!!!!!!=
    !!"#$%
    + !!""#$%&
    + !!"#
    !!"#$%

    !!""#$%&
    + !!"
    !!"
    !

    View Slide

  19. Green
    Marina  Zapater  |    Going  Green   19
    “Traditional” approaches
    What would Google do?
    PUE  =  1.2

    View Slide

  20. Green
    Marina  Zapater  |    Going  Green   20
    Research trends
    Abstrac?on  level
    •  Higher  levels  of
    abstrac?on  bring
    more  benefits
    •  Some  areas  have
    brought  more
    benefits  than
    others
    Solu?ons  proposed  by  the  State  of  the  Art

    View Slide

  21. Green
    Marina  Zapater  |    Going  Green   21
    Outline
    •  Why  Data  Centers  (DC)  in  this
    Workshop?
    •  The  DC  in  next-­‐genera?on
    applica?ons
    •  Energy  consump?on  at  the
    Data  Center
    •  Insight  on  opNmizaNon
    strategies
    •  Conclusions

    View Slide

  22. Green
    Marina  Zapater  |    Going  Green   22
    Our approach
    •  Global  strategy  to  allow  the
    use  of  mul?ple  informa?on
    sources  to  coordinate
    decisions  in  order  to  reduce
    the  total  energy  consump?on
    •  Use  of  knowledge  about  the
    energy  demand
    characteris?cs  of  the
    applicaNons,  and
    characteris?cs  of  compuNng
    and  cooling  resources  to
    implement  proacNve
    opNmizaNon  techniques

    View Slide

  23. Green
    Marina  Zapater  |    Going  Green   23
    Energy Optimization:
    Holistic Approach
    Chip   Server   Rack   Room   MulN-­‐
    room
    Sched  &  alloc   2   1
    ApplicaNon
    OS/middleware
    Compiler/VM   3   3
    architecture   4   4
    technology   5

    View Slide

  24. Green
    Marina  Zapater  |    Going  Green   24
    Resource Management at
    the Room level
    Chip   Server   Rack   Room   MulN-­‐
    room
    Sched  &  alloc   2   1
    ApplicaNon
    OS/middleware
    Compiler/VM   3   3
    architecture   4   4
    technology   5

    View Slide

  25. Green
    Marina  Zapater  |    Going  Green   25
    Resource Management at the Room level
    Leveraging heterogeneity – IT perspective
    •  Use  heterogeneity  to  minimize  energy  consump?on  from  a
    sta?c/dynamic  point  of  view
    –  StaNc:  Finding  the  best  data  center  set-­‐up,  given  a  number  of
    heterogeneous  machines
    –  Dynamic:  Op?miza?on  of  task  alloca?on  in  the  Resource  Manager
    •  We  show  that  the  best  solu?on  implies  an  heterogeneous  data
    center
    –  Most  data  centers  are  heterogeneous  (several  genera?ons  of
    computers)
    –  5  to  22%  energy  savings  for  sta?c  solu?on
    –  24%  to  47%  energy  savings  for  dynamic  solu?on
    M.  Zapater,  J.M.  Moya,  J.L.  Ayala.  Leveraging  Heterogeneity  for
    Energy  Minimiza?on  in  Data  Centers,  CCGrid  2012

    View Slide

  26. Green
    Marina  Zapater  |    Going  Green   26
    Resource Management at the Room level
    Leveraging heterogeneity – IT perspective
    •  Energy  profiling  of  tasks  of  the  SPEC  CPU  2006  benchmark
    •  Usage  of  MILP  algorithms  to  schedule  tasks  in  servers  where
    they  consume  less  energy
    •  Implemented  in  a  real  resource  manager  (SLURM)

    View Slide

  27. Green
    Marina  Zapater  |    Going  Green   27
    Resource Management at the Room level
    IT + Cooling perspective
    •  Genera?ng  a  thermal  model  for
    the  data  room:
    –  Data  Center  environmental
    monitoring  to  gather  temperature,
    humidity,  differen?al  pressure
    –  Predict  server  temperature  and
    room  temperature
    •  Op?mum  resource
    management  ajending  to
    cooling  and  IT  power
    –  Real  environment  with
    heterogeneous  servers
    –  SLURM  resource  manager

    View Slide

  28. Green
    Marina  Zapater  |    Going  Green   28
    Resource Management at
    the Server level
    Chip   Server   Rack   Room   MulN-­‐
    room
    Sched  &  alloc   2   2   1
    ApplicaNon
    OS/middleware
    Compiler/VM   3   3
    architecture   4   4
    technology   5

    View Slide

  29. Green
    Marina  Zapater  |    Going  Green   29
    Resource Management at the Server level
    Leakage-temperature tradeoffs - Cooling
    •  Exploring  the  leakage-­‐temperature  tradeoffs  at  the  server  level
    –  At  higher  temperatures,  CPU  increases  power  consump?on  due  to
    leakage
    –  To  decrease  CPU  temperature,  fan  speed  raises,  increasing  server
    cooling  consump?on.
    M.  Zapater,  J.L.  Ayala.,  J.M.  Moya,  K.  Vaidyanathan,  K.  Gross,  and  A.  K.  Coskun,  “Leakage  and
    temperature  aware  server  control  for  improving  energy  efficiency  in  data  centers”,  DATE  2013

    View Slide

  30. Green
    Marina  Zapater  |    Going  Green   30
    Resource Management at the Server level
    Leakage-temperature tradeoffs - Cooling
    •  Implemented  fan  speed  controllers  that  reduce  server  power
    consump?on  by  10%.
    Fig. 4. Test 3 temperature sensor readings for the three different controllers
    0.1
    0.2
    kWh)
    Energy difference between 1800RPM and 2400RPM for clustered allocation
    analytical model for leakage p
    fan speeds for varying utilization
    model, we implement a cooling
    Fig. 4. Test 3 temperature sensor readings for the three different controllers
    nd 2400RPM for clustered allocation
    analytical model for leakage power and find the optimum
    fan speeds for varying utilization values. Based our analytical
    model, we implement a cooling controller that adjusts the fan

    View Slide

  31. Green
    Marina  Zapater  |    Going  Green   31
    Resource Management at
    the Chip level
    Chip   Server   Rack   Room   MulN-­‐
    room
    Sched  &  alloc   2   2   1
    ApplicaNon
    OS/middleware
    Compiler/VM   3   3
    architecture   4   4
    technology   5

    View Slide

  32. Green
    Marina  Zapater  |    Going  Green   32
    Scheduling and resource allocation policies
    in MPSoCs
    A.  Coskun  ,  T.  Rosing  ,  K.  Whisnant  and  K.  Gross    "Sta(c  and  dynamic  temperature-­‐
    aware  scheduling  for  mul(processor  SoCs",    IEEE  Trans.  Very  Large  Scale  Integr.  Syst.,
    vol.  16,    no.  9,    pp.1127  -­‐1140  2008
    Fig. 3. Distribution of thermal hot spots, with DPM (ILP).
    A. Static Scheduling Techniques
    We next provide an extensive comparison of the ILP based
    techniques. We refer to our static approach as Min-Th&Sp.
    As discussed in Section III, we implemented the ILP for min-
    imizing thermal hot spots (Min-Th), energy balancing (Bal-
    En), and energy minimization (Min-En) to compare against
    Fig. 4. Distribution of spatial gradients, with DPM (ILP).
    hot spots. While Min-Th reduces the high spatial differentials
    above 15 C, we observe a substantial increase in the spatial
    gradients above 10 C. In contrast, our method achieves lower
    and more balanced temperature distribution in the die.
    In Fig. 5, we show how the magnitudes of thermal cycles vary
    with the scheduling method. We demonstrate the average per-
    Fig. 3. Distribution of thermal hot spots, with DPM (ILP).
    A. Static Scheduling Techniques
    We next provide an extensive comparison of the ILP based
    techniques. We refer to our static approach as Min-Th&Sp.
    As discussed in Section III, we implemented the ILP for min-
    imizing thermal hot spots (Min-Th), energy balancing (Bal-
    Fig. 4. Distribution of spatial gradients, with DPM (ILP).
    hot spots. While Min-Th reduces the high spatial differentials
    above 15 C, we observe a substantial increase in the spatial
    gradients above 10 C. In contrast, our method achieves lower
    and more balanced temperature distribution in the die.
    In Fig. 5, we show how the magnitudes of thermal cycles vary
    UCSD – System Energy Efficiency Lab

    View Slide

  33. Green
    Marina  Zapater  |    Going  Green   33
    Scheduling and resource allocation
    policies in MPSoCs
    •  Energy  characteriza?on  of  applica?ons  allows  to
    define  proac?ve  scheduling  and  resource  alloca?on
    policies,  minimizing  hotspots
    •  Hotspot  reduc?on  allows  to  raise  cooling
    temperature
    +1oC  means  around  7%  cooling  energy  savings

    View Slide

  34. Green
    Marina  Zapater  |    Going  Green   34
    Energy Optimization:
    Holistic Approach
    Chip   Server   Rack   Room   MulN-­‐
    room
    Sched  &  alloc   2   2   1
    ApplicaNon
    OS/middleware
    Compiler/VM   3   3
    architecture   4   4
    technology   5

    View Slide

  35. Green
    Marina  Zapater  |    Going  Green   35
    JIT Compilation in Virtual
    Machines
    •  Virtual  machines  compile
    (JIT  compila?on)  the
    applica?ons  into  na?ve  code
    for  performance  reasons
    •  The  op?mizer  is  general-­‐
    purpose  and  focused  in
    performance  opNmizaNon

    View Slide

  36. Green
    Marina  Zapater  |    Going  Green   36
    Back-­‐end
    JIT compilation for
    energy minimization
    •  Applica?on-­‐aware  compiler
    –  Energy  characteriza?on  of  applica?ons  and  transforma?ons
    –  Applica?on-­‐dependent  op?mizer
    –  Global  view  of  the  data  center  workload
    •  Energy  op?mizer
    –  Currently,  compilers  for  high-­‐end  processors  oriented  to  performance
    op?miza?on
    Front-­‐end
    Op?mizer   Code  generator

    View Slide

  37. Green
    Marina  Zapater  |    Going  Green   37
    Energy saving potential for the
    compiler (MPSoCs)
    T.  Simunic,  G.  de  Micheli,  L.  Benini,  and  M.  Hans.  “Source  code  op?miza?on  and
    profiling  of  energy  consump?on  in  embedded  systems,”  Interna?onal  Symposium  on
    System  Synthesis,  pages  193  –  199,  Sept.  2000
    – 77%  energy  reduc?on  in  MP3  decoder
    Fei,  Y.,  Ravi,  S.,  Raghunathan,  A.,  and  Jha,  N.  K.  2004.  Energy-­‐op?mizing  source  code
    transforma?ons  for  OS-­‐driven  embedded  sovware.  In  Proceedings  of  the  Interna?onal
    Conference  VLSI  Design.  261–266.
    – Up  to  37,9%  (mean  23,8%)  energy  savings  in
    mul?process  applica?ons  running  on  Linux

    View Slide

  38. Green
    Marina  Zapater  |    Going  Green   38
    Global Management of
    Low Power Modes
    Chip   Server   Rack   Room   MulN-­‐
    room
    Sched  &  alloc   2   2   1
    ApplicaNon
    OS/middleware
    Compiler/VM   3   3
    architecture   4   4
    technology   5

    View Slide

  39. Green
    Marina  Zapater  |    Going  Green   39
    Global Management of
    Low-power modes (DVFS)
    •  DVFS  (Dynamic  Voltage  and  Frequency  Scaling)  is  based  upon:
    –  As  suppy  voltage  decreases,  power  decreases  quadra?cally
    –  But  delay  increases  (performance  decreases)  only  linearly
    –  The  maximum  frequency  also  decreases  linearly
    •  Currently,  low-­‐power  modes,  if  used,  are  ac?vated  by
    inac?vity  of  the  server  opera?ng  system
    •  To  minimize  energy  consump?on,  changes  between  modes
    should  be  minimized
    •  On  the  other  hand,  workload  knowledge  allows  to  globally
    schedule  low-­‐power  modes  without  any  impact  in
    performance

    View Slide

  40. Green
    Marina  Zapater  |    Going  Green   40
    Global Management of
    Low-power modes (DVFS)
    •  By  using  a  thermal  model,
    we  can  predict  the
    behaviour  of  a  workload
    under  each  power  mode
    •  We  can  use  resource
    management  algorithms
    to  change  DVFS  on
    run?me,  adap?ng  to  our
    workload.

    View Slide

  41. Green
    Marina  Zapater  |    Going  Green   41
    Temperature-aware
    floorplanning of MPSoCs
    Chip   Server   Rack   Room   MulN-­‐
    room
    Sched  &  alloc   2   2   1
    ApplicaNon
    OS/middleware
    Compiler/VM   3   3
    architecture   4   4
    technology   5

    View Slide

  42. Green
    Marina  Zapater  |    Going  Green   42
    Temperature-aware
    floorplanning of MPSoCs

    View Slide

  43. Green
    Marina  Zapater  |    Going  Green   43
    Potential energy savings
    with floorplanning
    –  Up  to  21oC  reduc?on  of  maximum  temperature
    –  Mean:  -­‐12oC  in  maximum  temperature
    –  Bejer  results  in  the  most  cri?cal  examples
    Y.  Han,  I.  Koren,  and  C.  A.  Moritz.  Temperature  Aware  Floorplanning.  In  Proc.  of  the
    Second  Workshop  on  Temperature-­‐Aware  Computer  Systems,  June  2005

    View Slide

  44. Green
    Marina  Zapater  |    Going  Green   44
    Temperature-aware
    floorplanning in 3D chips
    •  3D  chips  are  gewng  interest  due  to:
    –  ↑  ↑    Scalability:  reduces  2D
    equivalent  area
    –  ↑  ↑    Performance:  shorter  wire
    length
    –  ↑  Reliability:  less  wiring

    •  Drawback:
    –  Huge  increment  of  hotspots
    compared  with  2D  equivalent  designs

    View Slide

  45. Green
    Marina  Zapater  |    Going  Green   45
    Temperature-aware
    floorplanning in 3D chips
    •  Up  to  30oC  reduc?on  per  layer  in  a  3D  chip  with  4  layers  and
    48  cores

    View Slide

  46. Green
    Marina  Zapater  |    Going  Green   46
    Outline
    •  Why  Data  Centers  (DC)  in  this
    Workshop?
    •  The  DC  in  next-­‐genera?on
    applica?ons
    •  Energy  consump?on  at  the
    Data  Center
    •  Insight  on  op?miza?on
    strategies
    •  Conclusions

    View Slide

  47. Green
    Marina  Zapater  |    Going  Green   47
    There is still much more
    to be done
    •  Smart  Grids
    – Consume  energy  when  everybody  else  does  not
    – Decrease  energy  consump?on  when  everybody
    else  is  consuming
    •  Reducing  the  electricity  bill
    – Variable  electricity  rates
    – Reac?ve  power  coefficient
    – Peak  energy  demand

    View Slide

  48. Green
    Marina  Zapater  |    Going  Green   48
    Conclusions
    •  Reducing  PUE  is  not  the  same  than  reducing  energy
    consump?on
    –  IT  energy  consump?on  dominates  in  state-­‐of-­‐the-­‐art  data
    centers
    •  Applica?on  and  resources  knowledge  can  be  effec?vely
    used  to  define  proacNve  policies  to  reduce  the  total  energy
    consump?on
    –  At  different  levels
    –  In  different  scopes
    –  Taking  into  account  cooling  and  computa?on  at  the  same  ?me
    •  Proper  management  of  the  knowledge  of  the  data  center
    thermal  behavior  can  reduce  reliability  issues
    •  Reducing  energy  consump?on  is  not  the  same  than
    reducing  the  electricity  bill

    View Slide

  49. Green
    Marina  Zapater  |    Going  Green   49
    Thank you for your attention
    Marina Zapater
    [email protected]
    hjp://greenlsi.die.upm.es
    (+34)  91  549  57  00    x-­‐4227

    ETSI de Telecomunicación, B105
    Avenida Complutense, 30
    Madrid 28040, Spain
    Thanks  to  our  collaborators:

    View Slide
