Using Clocker with Project Calico Running Production Workloads in the
Cloud Andrew Kennedy, Software Circus, 11 September 2015

@grkvlt Agenda • Introduction • Application Management • Networking with
Calico • Demonstration • Roadmap • Questions Copyright 2015 by Cloudsoft Corporation Limited

Clocker Introduction

@grkvlt Clocker Statistics • Open Source • 1 Year Old
• 725 Commits • 153 Pull Requests • 11 Contributors • 2 External • 15 KLOC • 26 Releases http://www.redotheweb.com/CodeFlower/ Copyright 2015 by Cloudsoft Corporation Limited

@grkvlt • Application Management Platform • Deploy, Manage and Monitor
Blueprints • Provisioning, Installation and Customization • Management • AutoScaling, Resilience, Performance, Security Apache Brooklyn

@grkvlt Apache jclouds • Java Cloud Library • API Agnostic
• SoftLayer, OpenStack, AWS EC2, GCE… • Create Virtual Machines • Return SSH Endpoint • Create Containers • Docker REST API Copyright 2015 by Cloudsoft Corporation Limited

@grkvlt Docker • Containers • Isolation • Performance • Composable
• Huge Ecosystem • Compute Abstraction • Process Wrapper

@grkvlt • Software-‐Defined Networking • Calico • Weave • Storage
and Volume Management • Flocker • More Being Developed… • Native Plugins Docker Extras

@grkvlt What does it do? 1. Spins up and Manages
Docker Clusters in the Clouds 2. Serves up Containers on Demand 3. Manages Composite Application Deployments Copyright 2015 by Cloudsoft Corporation Limited

@grkvlt What does it provide? • Infrastructure Management • Docker
Hosts • Swarm Controller • Multi Host and Multi Container Applications • Seamless Networking • Communication Between Services • Orchestration and Clustering • Control of Containers • Container Management Copyright 2015 by Cloudsoft Corporation Limited

@grkvlt Clocker and Brooklyn Summary • What is it? •
Brooklyn Application • Brooklyn Location • What does it provide? • First Class Docker Support in Brooklyn • Optimized Brooklyn Blueprints for Docker • Container Orchestration Copyright 2015 by Cloudsoft Corporation Limited

Application Management

@grkvlt Brooklyn Blueprints • Describe Applications • OASIS CAMP Standard
• TOSCA and Compose in Development • List of Services • NoSQL Database Clusters • Web Servers and Load Balancers • Shell or Python Scripts • Targeting Multiple Destinations • VM, Container, Bare Metal • Sensors, Effectors and Policies Copyright 2015 by Cloudsoft Corporation Limited

@grkvlt Application Management • Sensors • Data from Services •
Effectors • Brooklyn Policies • Attached to Entities in Application • Nothing Docker Specific • Elastic Scaling and Cluster Resizing • Service Resilience and Replacement Copyright 2015 by Cloudsoft Corporation Limited

@grkvlt Blueprint Example 1 Copyright 2015 by Cloudsoft Corporation Limited
id: redis-‐service name: "Docker Hub Redis Service" origin: "https://registry.hub.docker.com/_/redis/" locations: -‐ my-‐docker-‐cloud services: -‐ type: docker:redis:3 openPorts: -‐ 6379 directPorts: -‐ 6379

@grkvlt Blueprint Example 2 Copyright 2015 by Cloudsoft Corporation Limited
id: redis-‐cluster name: "Redis Cluster" locations: -‐ jclouds:aws-‐ec2: region: eu-‐central-‐1 services: -‐ type: org.apache.brooklyn.entity.nosql.redis.RedisCluster initialSize: 3

@grkvlt Blueprint Example 3 id: appserver-‐with-‐policy name: "Tomcat
Scaling Webapp Server" location: jclouds:aws-‐ec2:eu-‐west-‐1 services: -‐ type: org.apache.brooklyn.entity.webapp.ControlledDynamicWebAppCluster initialSize: 3 memberSpec: $brooklyn:entitySpec: type: org.apache.brooklyn.entity.webapp.tomcat.Tomcat8Server brooklyn.config: wars.root: https:// s3-‐eu-‐west-‐1.amazonaws.com/brooklyn-‐clocker/brooklyn-‐example-‐hello-‐world-‐sql-‐webapp-‐0.6.0.war http.port: 8080+ java.sysprops: brooklyn.example.db.url: $brooklyn:formatString("jdbc:%s%s?user=%s\\&password=%s", component("db").attributeWhenReady("datastore.url"), "visitors", "brooklyn", "br00k11n") brooklyn.policies: -‐ policyType: org.apache.brooklyn.policy.autoscaling.AutoScalerPolicy brooklyn.config: metric: $brooklyn:sensor("org.apache.brooklyn.entity.webapp.DynamicWebAppCluster", "webapp.reqs.perSec.windowed.perNode") metricLowerBound: 10 metricUpperBound: 100 minPoolSize: 1 maxPoolSize: 5 -‐ type: org.apache.brooklyn.entity.database.mysql.MySqlNode id: db name: DB HelloWorld Visitors brooklyn.config: datastore.creation.script.url: https:// s3-‐eu-‐west-‐1.amazonaws.com/brooklyn-‐clocker/visitors-‐creation-‐script.sql Copyright 2015 by Cloudsoft Corporation Limited

@grkvlt Docker Cloud • Brooklyn Blueprint for Docker Cluster •
Docker Engine on Cloud VM or Bare Metal • Configuration for Host • TLS Certificates • Setup Volumes • Logging • Install SDN Agents • Manage Capacity or Headroom Copyright 2015 by Cloudsoft Corporation Limited

@grkvlt Headroom • Ensure resources available • Based on MaxContainers
strategy limit • Or Percentage Utilisation • Or CPU and RAM allocation • Scale Docker Host Cluster Automatically • Add new Docker hosts • Remove empty Docker hosts Copyright 2015 by Cloudsoft Corporation Limited

@grkvlt Docker Cloud 1. On-demand 2. Multi-Tenant 3. Hardware Independent
4. Application Level Copyright 2015 by Cloudsoft Corporation Limited

@grkvlt Clocker Features • Docker Extensions to Brooklyn –Docker Image
as First-Class Service Type –Placement Strategies for Containers –Create Docker Images and Networks • Manages Docker Engine and Swarm –Deployment and Management –Installation and Configuration –Software-Defined Networking Copyright 2015 by Cloudsoft Corporation Limited

@grkvlt Container Management • Sources • Docker Image Definition •
Docker Hub or Registry • Dockerfile • Brooklyn Entity Definition • Create Image Automatically • Commit or Push for Reuse Copyright 2015 by Cloudsoft Corporation Limited

@grkvlt Clocker Orchestration Copyright 2015 by Cloudsoft Corporation Limited Docker
Engine Virtual Machine Container Clocker Network Segment SDN Provider Cloud Provider Brooklyn

Clocker Networking

@grkvlt Software-Defined Networking • Needed for Seamless Provisioning • Host
to Host Communication • Same LAN Segment • No Port Forwarding • Natural Application Configuration • Initial Driver was EPMD Applications • Useful for any opinionated applications Copyright 2015 by Cloudsoft Corporation Limited

@grkvlt Networking Providers • Implementation Agnostic • L2 overlay, L3
routing etc. • Similar to Hypervisor in Clouds • Generic Interfaces • Host Component • Service Component (or Endpoint) • Same idea as Docker Network Plugins Copyright 2015 by Cloudsoft Corporation Limited

@grkvlt Networking Capabilities • Attach Containers to Networks • Create
Networks as Required • Also Attach to VMs and Metal • Provide Multiple Networks • Per-Application or Shared • Segmented Private Address Space • Docker Port Forwarding for Ingress Copyright 2015 by Cloudsoft Corporation Limited

@grkvlt Network Provisioning • Minimal (Zero!) Configuration • Use Sensible
Defaults • Allows SDN or Cloud Specific Configuration • Allocate Address Space on Demand • IP Pool Controlled by Clocker -‐ type: brooklyn.networking.VirtualNetwork networkId: database-‐net cidr: 192.168.34.0/24 gateway: 192.168.34.1 dnsServers: -‐ $brooklyn:entity("bind-‐server").attributeWhenReady("host.address") addIptablesRules: true -‐ type: brooklyn.networking.OpenStackVirtualNetwork networkId: couchbase-‐net Copyright 2015 by Cloudsoft Corporation Limited

@grkvlt Clocker Networking Container Host SDN Bridge Container Internet SDN
Gateway Copyright 2015 by Cloudsoft Corporation Limited

@grkvlt Metaswitch Project Calico • SDN for Bare Metal, VMs
and Containers • Layer 3 • Uses OS IP routing and forwarding • Configuration in an etcd Cluster • Version 0.4.9 in Clocker • 0.6.0 with libnetwork when Docker stable • Spans VMs and Containers • OpenStack Neutron network driver Copyright 2015 by Cloudsoft Corporation Limited

@grkvlt Networking Capabilities • Wide Area and Multi Region SDN
• VPN or IPIP and NAT configuration • Cross Platform SDN • Both VMs and Containers on one VLAN • Name Resolution and Service Discovery • Contributing to Weave DNS for orchestration • Use traditional external BIND service entity • Brooklyn can inject correct endpoint address Copyright 2015 by Cloudsoft Corporation Limited

Demonstration

@grkvlt Application Blueprint 1 Copyright 2015 by Cloudsoft Corporation Limited
id: my-‐application location: my-‐docker-‐cloud services: -‐ type: docker:redis:3 id: redis-‐service openPorts: 6379 -‐ type: docker:dnmonster:latest id: dnmonster-‐service openPorts: 8080 -‐ type: docker:grkvlt/myapp:latest id: app-‐service mappedPorts: 80: 8080 links: redis: $brooklyn:component("redis-‐service") dnmonster: $brooklyn:component("dnmonster-‐service")

id: my-‐application location: my-‐docker-‐cloud services: -‐ type: org.apache.brooklyn.entity.nosql.RedisStore id: redis-‐service install.version: 3.0.0 -‐ type: docker:dnmonster:latest id: dnmonster-‐service openPorts: 8080 -‐ type: docker:grkvlt/myapp:latest id: app-‐service mappedPorts: 80: 8080 links: redis: $brooklyn:component("redis-‐service") dnmonster: $brooklyn:component("dnmonster-‐service")

id: my-‐application location: my-‐docker-‐cloud services: -‐ type: org.apache.brooklyn.entity.nosql.RedisStore location: jclouds:aws-‐ec2:eu-‐west-‐1 id: redis-‐service install.version: 3.0.0 -‐ type: docker:dnmonster:latest id: dnmonster-‐service openPorts: 8080 -‐ type: docker:grkvlt/myapp:latest id: app-‐service mappedPorts: 80: 8080 links: redis: $brooklyn:component("redis-‐service") dnmonster: $brooklyn:component("dnmonster-‐service")

id: my-‐application location: jclouds:aws-‐ec2:eu-‐west-‐1 services: -‐ type: org.apache.brooklyn.entity.nosql.RedisStore id: redis-‐service install.version: 3.0.0 -‐ type: docker:dnmonster:latest id: dnmonster-‐service openPorts: 8080 -‐ type: docker:grkvlt/myapp:latest id: app-‐service mappedPorts: 80: 8080 links: redis: $brooklyn:component("redis-‐service") dnmonster: $brooklyn:component("dnmonster-‐service")

@grkvlt • Orchestrated Docker deployment and configuration, with Project Calico
SDN • Brooklyn application blueprints deployed with network topology linked to OpenStack using Project Calico • Automated attachment of containers to multiple dynamic networks • Zero Config Multi-Target Deployment Copyright 2015 by Cloudsoft Corporation Limited Features

Clocker 1.x

Apache Mesos ... • Distributed Systems Kernel • Cluster Management
• Resource Sharing and Placement • Calico SDN Support • Frameworks • Aurora and Marathon • Riak, Spark, Hadoop, Storm et al • Brooklyn Scheduler

@grkvlt Roadmap • Mesos Integration • Deploy the Mesos infrastructure
• Brooklyn as a Mesos framework • Provide Mesos as another Brooklyn endpoint • Container Mobility • Stateless Services • Brooklyn Core Integration Copyright 2015 by Cloudsoft Corporation Limited

Clocker Solves: – Docker Cloud Networking – Container Placement and
Provisioning – Composite Application Management Summary

Questions?

@grkvlt Resources http://clocker.io/ http://brooklyn.io/ https://github.com/brooklyncentral/clocker/ https://github.com/apache/incubator-‐brooklyn/ https://github.com/weaveworks/weave/ https://github.com/Metaswitch/calico-‐docker/ http://blog.abstractvisitorpattern.co.uk/
