つらくない(?) Bluetooth Low Energy on Android / TSURAI BLE on Android
kyobashi.dex #1 発表資料
http://kyobashi-android.connpass.com/event/18583/
izumin5210
September 07, 2015
Transcript
45 slides
-
Rekimoto Lab. at the University of Tokyo (2008-2015: Akashi-NCT)
Enginner at Wantedly, Inc. (2014.9-2015.2: Dmetlabel, Inc.) -
Android 4.3 (API Level 18) introduces built-in platform support for
Bluetooth Low Energy in the central role and provides APIs that apps can use to discover devices, query for services, and read/write characteristics. - Bluetooth Low Energy | Android Developers -
BluetoothGatt Bluetooth LE の周辺機器は、サーバとして、センサの値、動作設定 値、内部状態などを公開しています。Bluetooth LE は、ある機能を サービスという単位にまとめます。1 つのサービスは複数のキャラ クタリスティクスを持ちます。例えばエアコンであれば、室内温度
というサービスを作り、そのなかに気温センサの値というキャラク タリスティクスをもたせる設計をしたりします。 - BLE の通信仕様 - Reinforce-Lab.'s Blog* * http://reinforce-lab.github.io/blog/2013/08/13/blebook-ch2-ble-spec/ -
BluetootGatt GATT (Generic Attribute Profile) あらゆる BLE 端末は
GATT に基いて データの送受信を行う -
BluetootGatt GATT (Generic Attribute Profile) あらゆる BLE 端末は
GATT に基いて データの送受信を行う Android では BluetoothGatt クラスを利用する -
BluetootGatt GATT (Generic Attribute Profile) あらゆる BLE 端末は
GATT に基いて データの送受信を行う Android では BluetoothGatt クラスを利用する ↑ こいつが闇 -
BLE つらい問題 ちょっと触ってみた結果、どうにも悲しいことに 「1. 安定性がイケてない」 「2. SDK サンプルがイケてない」 「3. API
仕様がイケてない」 という三重苦です。 - Android の BLE で Characteristics の Read/Write サンプルを作ってみた - ReDo** ** http://greety.sakura.ne.jp/redo/2013/11/androidblecharacteristicsreadwrite.html -
BLE つらい問題 ちょっと触ってみた結果、どうにも悲しいことに 「1. 安定性がイケてない」 「2. SDK サンプルがイケてない」 「3. API
仕様がイケてない」 という三重苦です。 - Android の BLE で Characteristics の Read/Write サンプルを作ってみた - ReDo** ** http://greety.sakura.ne.jp/redo/2013/11/androidblecharacteristicsreadwrite.html -
BluetoothGattCallback onConnectionStateChange(BluetoothGatt gatt, int status, int newState) onServicesDiscovered(BluetoothGatt gatt, int
status) onCharacteristicRead(BluetoothGatt gatt, BluetoothGattCharacteristic characteristic, int status) onCharacteristicWrite(BluetoothGatt gatt, BluetoothGattCharacteristic characteristic, int status) onCharacteristicChanged(BluetoothGatt gatt, BluetoothGattCharacteristic characteristic) -
BluetoothGattCallback onConnectionStateChange(BluetoothGatt gatt, int status, int newState) onServicesDiscovered(BluetoothGatt gatt, int
status) onCharacteristicRead(BluetoothGatt gatt, BluetoothGattCharacteristic characteristic, int status) onCharacteristicWrite(BluetoothGatt gatt, BluetoothGattCharacteristic characteristic, int status) onCharacteristicChanged(BluetoothGatt gatt, BluetoothGattCharacteristic characteristic) -
BluetoothGattCallback 接続処理 BluetoothDevice#connectGatt() → onConnectionStateChange() Service 探し BluetoothGatt#discoverService()
→ onServiceDiscovered() 書き込み BluetoothGatt#writeCharacteristic() → onCharacteristicWrite() -
BluetoothGattCallback 接続処理 BluetoothDevice#connectGatt() → onConnectionStateChange() Service 探し BluetoothGatt#discoverService()
→ onServiceDiscovered() 書き込み BluetoothGatt#writeCharacteristic() → onCharacteristicWrite() 切断処理 BluetoothGatt#disconnect() → onConnectionStateChange() -
BluetoothGattCallback 接続処理 BluetoothDevice#connectGatt() → onConnectionStateChange() Service 探し BluetoothGatt#discoverService()
→ onServiceDiscovered() 書き込み BluetoothGatt#writeCharacteristic() → onCharacteristicWrite() 切断処理 BluetoothGatt#disconnect() → onConnectionStateChange() -
BluetoothGattCallback 接続処理 BluetoothDevice#connectGatt() → onConnectionStateChange() Service 探し BluetoothGatt#discoverService()
→ onServiceDiscovered() 書き込み BluetoothGatt#writeCharacteristic() → onCharacteristicWrite() 切断処理 BluetoothGatt#disconnect() → onConnectionStateChange() ↓ 切断は disconnect() して, callback を待ってから close() -
イケてない API すべての操作は非同期・コールバックベース 登録できる Callback インスタンスは 1 つ
ドキュメントにない仕様(disconnect → close とか) -
対策①: 状態を意識する private static final int STATE_DISCONNECTED = 0; private
static final int STATE_CONNECTING = 1; private static final int STATE_CONNECTED = 2; 公式サンプル -
対策①: 状態を意識する private static final int STATE_DISCONNECTED = 0; private
static final int STATE_CONNECTING = 1; private static final int STATE_CONNECTED = 2; 公式サンプル たりない -
対策①: 状態を意識する enum State { DISCONNECTED, CONNECTING, CONNECTED, SERVICE_DISCOVERING, SERVICE_DISCOVERED,
DISCONNECTING } ※ READING / WRITING 等も必要かもしれない -
対策②: e.g. Enum でハンドリング @Override public onCharacteristicWrite() { CharacteristicHandler.valueOf(characteristic.getUuid()) .handle(characteristic);
} enum CharacteristicHandler { DIGITAL_WRITE(/* ... */), DIGITAL_READ(/* ... */) UNKNOWN(null); public static CharacteristicHandler valueOf(UUID uuid) { /* ... */ } public UUID getUUID() { /* ... */ } public void handle() { /* ... */ } } -
対策②: e.g. Enum でハンドリング @Override public onCharacteristicWrite() { CharacteristicHandler.valueOf(characteristic.getUuid()) .handle(characteristic);
} enum CharacteristicHandler { DIGITAL_WRITE(/* ... */), DIGITAL_READ(/* ... */) UNKNOWN(null); public static CharacteristicHandler valueOf(UUID uuid) { /* ... */ } public UUID getUUID() { /* ... */ } public void handle() { /* ... */ } } -
対策②: e.g. Enum でハンドリング @Override public onCharacteristicWrite(/* ... */) {
CharacteristicHandler.valueOf(characteristic.getUuid()) .handle(characteristic); } enum CharacteristicHandler { DIGITAL_WRITE(/* ... */), DIGITAL_READ(/* ... */) UNKNOWN(null); public static CharacteristicHandler valueOf(UUID uuid) { /* ... */ } public UUID getUUID() { /* ... */ } public void handle() { /* ... */ } } -
対策②: e.g. Enum でハンドリング @Override public onCharacteristicWrite(/* ... */) {
CharacteristicHandler.valueOf(characteristic.getUuid()) .handle(characteristic); } enum CharacteristicHandler { DIGITAL_WRITE(/* ... */), DIGITAL_READ(/* ... */) UNKNOWN(null); public static CharacteristicHandler valueOf(UUID uuid) { /* ... */ } public UUID getUUID() { /* ... */ } public void handle() { /* ... */ } } -
対策②: Callback のハンドリング どの操作のコールバックかを判断するには, 引数に入ってるインスタンス見るしかない 普通にやると Callback Hell
不可避 上手く処理を移譲させないとヤバい (数千行のなんちゃら Manager クラスとかと対峙するはめに…) -
イイ感じのパターンでラップしちゃうのもある e.g. Rx, Promise, Observer, flux 出回ってる BLE
デバイスの SDK はつらい (ハッカソンとかではそのことを念頭に置いた方がいい) 余談 -
イイ感じのパターンでラップしちゃうのもある e.g. Rx, Promise, Observer, flux 出回ってる BLE
デバイスの SDK はつらい (ハッカソンとかではそのことを念頭に置いた方がいい) BLE まわり,ユニットテストどうするの? (BluetoothGatt は final なので… ラッパー書くしかない?) 余談 -
BLE,基本的にはつらいです 公式はあまり信用出来ない(過激派) 状態遷移を意識しよう ガバガバ Callback からどうやって処理を
ハンドリングしていくかが重要 Conclusion
