k8s-batch-sig - Dask on Kubernetes

k8s-batch-sig - Dask on Kubernetes

Overview of running Dask on Kubernetes

Jacob Tomlinson

March 16, 2023
Tweet

More Decks by Jacob Tomlinson

Other Decks in Technology

Transcript

  1. Overview and Kubernetes
    integration
    Jacob Tomlinson
    Dask developer
    Senior Software Engineer at NVIDIA

    View Slide

  2. Jacob Tomlinson
    Senior Software Engineer
    NVIDIA

    View Slide

  3. Dask’s Features
    Overview

    View Slide

  4. General purpose Python library for parallelism
    Scales existing libraries, like Numpy, Pandas, and Scikit-Learn
    Flexible enough to build complex and custom systems
    Accessible for beginners, secure and trusted for institutions

    View Slide

  5. PyData Community adoption
    “Once Dask was working properly with
    NumPy, it became clear that there was
    huge demand for a lightweight parallelism
    solution for Pandas DataFrames and
    machine learning tools, such as
    Scikit-Learn.
    Dask then evolved quickly to support
    these other projects where appropriate.”
    Matthew Rocklin
    Dask Creator
    Source https://coiled.io/blog/history-dask/
    Image from Jake VanderPlas’ keynote, PyCon 2017

    View Slide

  6. Deferring Python execution
    import dask
    @dask.delayed
    def inc(x):
    return x + 1
    @dask.delayed
    def double(x):
    return x * 2
    @dask.delayed
    def add(x, y):
    return x + y
    data = [1, 2, 3, 4, 5]
    output = []
    for x in data:
    a = inc(x)
    b = double(x)
    c = add(a, b)
    output.append(c)
    total = dask.delayed(sum)(output)
    Dask allows users to construct
    custom graphs with the delayed and
    futures APIs.

    View Slide

  7. Distributed Task Graphs
    Constructing tasks in a DAG allows
    tasks to executed by a selection of
    schedulers.
    The distributed scheduler allows a
    DAG to be shared by many workers
    running over many machines to
    spread out work.

    View Slide

  8. Out-of-core computation
    Dask’s data structures are chunked or
    partitioned allowing them to be swapped
    in and out of memory.
    Operations run on chunks independently
    and only communicate intermediate
    results when necessary

    View Slide

  9. Dask’s distributed scheduler
    “For the first year of Dask’s life it was
    focused on single-machine parallelism.
    But inevitably, Dask was used on
    problems that didn’t fit on a single
    machine. This led us to develop a
    distributed-memory scheduler for Dask
    that supported the same API as the
    existing single-machine scheduler.
    For Dask users this was like magic.
    Suddenly their existing workloads on
    50GB datasets could run comfortably on
    5TB (and then 50TB a bit later).”
    Matthew Rocklin
    Dask Creator
    Source https://coiled.io/blog/history-dask/

    View Slide

  10. Scheduler Dashboard
    # Connect a Dask client
    >>> from dask.distributed import Client
    >>> client = Client(cluster)
    # Do come computation
    >>> import dask.array as da
    >>> arr = da.random.random((10_000, 1_000, 1_000),
    chunks=(1000, 1000, 100))
    >>> result = arr.mean().compute()

    View Slide

  11. Dashboard
    Dask’s dashboard gives you key
    insights into how your cluster is
    performing.
    You can view it in a browser or
    directly within Jupyter Lab to see
    how your graphs are executing.
    You can also use the built in
    profiler to understand where the
    slow parts of your code are.

    View Slide

  12. Elastic scaling
    Dask’s adaptive scaling allows a Dask
    scheduler to request additional workers
    via whatever resource manager you are
    using (Kubernetes, Cloud, etc).
    This allows computations to burst out onto
    more machines and complete the overall
    graph in less time.
    This is particularly effective when you
    have multiple people running interactive
    and embarrassingly parallel workloads on
    shared resources.

    View Slide

  13. Dask accelerates the existing Python ecosystem
    Built alongside with the current community
    import numpy as np
    x = np.ones((1000, 1000))
    x + x.T - x.mean(axis=0
    import pandas as pd
    df = pd.read_csv(“file.csv”)
    df.groupby(“x”).y.mean()
    from scikit_learn.linear_model \
    import LogisticRegression
    lr = LogisticRegression()
    lr.fit(data, labels)
    Numpy Pandas Scikit-Learn

    View Slide

  14. 14
    RAPIDS
    https://github.com/rapidsai
    Jacob Tomlinson
    Cloud Deployment Lead
    RAPIDS

    View Slide

  15. 15
    Minor Code Changes for Major Benefits
    Abstracting Accelerated Compute through Familiar Interfaces
    In [1]: import pandas as pd
    In [2]: df = pd.read_csv(‘filepath’)
    In [1]: from sklearn.ensemble import
    RandomForestClassifier
    In [2]: clf =
    RandomForestClassifier(n_estimators=10
    0,max_depth=8, random_state=0)
    In [3]: clf.fit(x, y)
    In [1]: import networkx as nx
    In [2]: page_rank=nx.pagerank(graph)
    In [1]: import cudf
    In [2]: df = cudf.read_csv(‘filepath’)
    In [1]: from cuml.ensemble import
    RandomForestClassifier
    In [2]: cuclf =
    RandomForestClassifier(n_estimators=10
    0,max_depth=8, random_state=0)
    In [3]: cuclf.fit(x, y)
    In [1]: import cugraph
    In [2]:
    page_rank=cugraph.pagerank(graph)
    GPU
    CPU
    pandas scikit-learn NetworkX
    cuDF cuML cuGraph
    Average Speed-Ups: 150x Average Speed-Ups: 250x
    Average Speed-Ups: 50x

    View Slide

  16. 16
    Lightning-Fast End-to-End Performance
    Reducing Data Science Processes from Hours to Seconds
    *CPU approximate to n1-highmem-8 (8 vCPUs, 52GB memory) on Google Cloud Platform. TCO calculations-based on Cloud instance costs.
    A100s Provide More Power
    than 100 CPU Nodes
    16
    More Cost-Effective than
    Similar CPU Configuration
    20x
    Faster Performance than
    Similar CPU Configuration
    70x

    View Slide

  17. 17
    RAPIDS on Kubernetes
    Unified Cloud Deployments
    GPU
    Operator
    Kubernetes
    GPU
    GPU
    GPU
    GPU
    GPU
    GPU
    GPU
    GPU

    View Slide

  18. Deploying Dask
    A brief history and some context

    View Slide

  19. 19
    19
    19
    Creating a Cluster manually

    View Slide

  20. 20
    LocalCluster
    ● Convenience class to create
    subprocesses
    ● Inspects local system and
    creates workers to maximise
    hardware use
    ● Has helper methods for
    managing the cluster

    View Slide

  21. 21
    dask-jobqueue
    ● Convenience class to create
    HPC Dask Clusters
    ● Intended to be used from the
    head node of an HPC
    ● Scheduler runs in subprocess
    on the head node
    ● Workers are submitted as HPC
    jobs to the queue
    ● Assumes network connectivity
    between all nodes and head
    node

    View Slide

  22. 22
    dask-kubernetes (classic)
    ● Convenience class to create
    Kubernetes Dask Clusters
    ● Intended to be used from within
    the Kubernetes cluster
    ● Scheduler runs as subprocess
    in user Pod
    ● Workers are created as Pods
    (via service account auth)
    ● Assumes network connectivity
    between all Pod IPs

    View Slide

  23. 23
    23
    23
    Helm Chart
    ● Chart deploys a Dask Cluster
    and a Jupyter service
    ● Scheduler, Workers and
    Jupyter are all Deployments
    ● Jupyter is preconfigured to
    connect to the Dask cluster
    ● Dask worker Deployment
    presents a scaling challenge
    due to semi-stateful nature of
    Dask Workers

    View Slide

  24. 24
    24
    24
    dask-gateway
    ● Dask cluster provisioning
    service
    ● Has multiple backends
    including HPC, Kubernetes and
    Hadoop
    ● All Dask traffic is proxied via a
    single ingress
    ● Users are abstracted away
    front he underlying platform

    View Slide

  25. Dask Operator
    Kubernetes Native

    View Slide

  26. 26
    26
    26
    Built with kopf
    Dask is a Python community so it made
    sense to build the controller in Python too.
    We also evaluated the Operator
    Framework for Golang but using it would
    hugely reduce the number of active Dask
    maintainers who could contribute.

    View Slide

  27. 27
    # cluster.yaml
    apiVersion: kubernetes.dask.org/v1
    kind: DaskCluster
    metadata:
    name: simple-cluster
    spec:
    worker:
    replicas: 3
    spec:
    containers:
    - name: worker
    image: "ghcr.io/dask/dask:latest"
    imagePullPolicy: "IfNotPresent"
    args:
    - dask-worker
    - --name
    - $(DASK_WORKER_NAME)
    scheduler:
    spec:
    containers:
    - name: scheduler
    image: "ghcr.io/dask/dask:latest"
    imagePullPolicy: "IfNotPresent"
    args:
    - dask-scheduler
    ports:
    - name: tcp-comm
    containerPort: 8786
    protocol: TCP
    - name: http-dashboard
    containerPort: 8787
    protocol: TCP
    readinessProbe:
    httpGet:
    port: http-dashboard
    path: /health
    initialDelaySeconds: 5

    The Dask Operator has four custom
    resource types that you can create via
    kubectl.
    ● DaskCluster to create whole clusters.
    ● DaskWorkerGroup to create
    additional groups of workers with
    various configurations (high memory,
    GPUs, etc).
    ● DaskJob to run end-to-end tasks like
    a Kubernetes Job but with an
    adjacent DaskCluster.
    ● DaskAutoscaler behaves like an HPA
    but interacts with the Dask scheduler
    to make scaling decisions
    Create Dask Clusters
    with kubectl

    View Slide

  28. 28
    DaskJob
    ● Inspired by Kubeflow
    PyTorchJob, et al
    ● DaskJob contains a Pod spec
    to run the workload and a
    nested DaskCluster resource
    ● Workload Pod is pre configured
    to connect to the DaskCluster
    ● Users can submit a batch job
    with attached autoscaling Dask
    Cluster via kubectl

    View Slide

  29. Create Dask Clusters with Python
    # Install dask-kubernetes
    $ pip install dask-kubernetes
    # Launch a cluster
    >>> from dask_kubernetes.operator \
    import KubeCluster
    >>> cluster = KubeCluster(name="demo")
    # List the DaskCluster custom resource that
    was created for us under the hood
    $ kubectl get daskclusters
    NAME AGE
    demo 6m3s

    View Slide

  30. Flyte
    Integration success

    View Slide

  31. 31
    31
    31

    View Slide

  32. 32
    32
    32

    View Slide

  33. Read Documentation: docs.dask.org
    See Examples: examples.dask.org
    Engage Community: github.com/dask

    View Slide
