Best Practices of Infrastructure-as-Code with Terraform

Join this webinar to learn why Infrastructure as Code is the answer to managing large scale, distributed systems and service-oriented architectures. We will cover key use cases, a demo of how to use Infrastructure as Code to provision your infrastructure and more.

Agenda:

Intro to Infrastructure as Code: Challenges & Use cases
Writing Infrastructure as Code with Terraform
Collaborating with Teams on Infrastructure

Transcript

1. Copyright © 2019 HashiCorp
   Best Practices of
   Infrastructure-as-
   Code with Terraform
   DevOps.com | December 13, 2019
   1


   View Slide

2. Presenter
   Rosemary Wang
   Developer Advocate at HashiCorp
   she/her
   @joatmon08
   joatmon08
   linkedin.com/in/rosemarywang/
   2


   View Slide

3. The shift to
   provisioning
   dynamic
   infrastructure
   ⁄ USING TERRAFORM IN DYNAMIC
   INFRASTRUCTURE Copyright © 2018 HashiCorp ⁄ 3
   Static
   Homogeneous, Private
   Dynamic
   Heterogeneous, Distributed


   View Slide

4. ⁄ USING TERRAFORM IN DYNAMIC
   INFRASTRUCTURE Copyright © 2018 HashiCorp ⁄ 4
   Dynamic
   Heterogeneous, Distributed
   Static
   Homogeneous, Private
   The shift to
   provisioning
   dynamic
   infrastructure


   View Slide

5. 475 def update
   476 return update_api if api_request?
   477
   478 if authorized_action(@account, @current_user, :manage_account_settings)
   479 respond_to do |format|
   480
   481 custom_help_links = params[:account].delete :custom_help_links
   482 if custom_help_links
   483 @account.settings[:custom_help_links] = custom_help_links.select{|k, h| h['state'] != 'delete
   484 hash = index_with_hash[1]
   485 hash.delete('state')
   486 hash.assert_valid_keys ["text", "subtext", "url", "available_to"]
   487 hash
   488 end
   489 end
   490
   491 params[:account][:turnitin_host] = validated_turnitin_host(params[:account][:turnitin_host])
   492 enable_user_notes = params[:account].delete :enable_user_notes
   493 allow_sis_import = params[:account].delete :allow_sis_import
   494 params[:account].delete :default_user_storage_quota_mb unless @account.root_account? && !@accou
   495 unless @account.grants_right? @current_user, :manage_storage_quotas
   496 [:storage_quota, :default_storage_quota, :default_storage_quota_mb,
   497 :default_user_storage_quota, :default_user_storage_quota_mb,
   498 :default_group_storage_quota, :default_group_storage_quota_mb].each { |key| params[:account]
   499 end
   500 if params[:account][:services]
   501 params[:account][:services].slice(*Account.services_exposed_to_ui_hash(nil, @current_user, @a
   502 @account.set_service_availability(key, value == '1')
   503 end
   504 params[:account].delete :services
   505 end
   506 if @account.grants_right?(@current_user, :manage_site_settings)
   507 # If the setting is present (update is called from 2 different settings forms, one for notifi
   508 if params[:account][:settings] && params[:account][:settings][:outgoing_email_default_name_op
   509 # If set to default, remove the custom name so it doesn't get saved
   510 params[:account][:settings][:outgoing_email_default_name] = '' if params[:account][:setting
   511 end
   512
   513 google_docs_domain = params[:account][:settings].try(:delete, :google_docs_domain)
   514 if @account.feature_enabled?(:google_docs_domain_restriction) &&
   515 @account.root_account? &&
   516 !@account.site_admin?
   517 @account.settings[:google_docs_domain] = google_docs_domain.present? ? google_docs_domain :
   518 end
   519
   520 @account.enable_user_notes = enable_user_notes if enable_user_notes
   521 @account.allow_sis_import = allow_sis_import if allow_sis_import && @account.root_account?
   522 if @account.site_admin? && params[:account][:settings]
   523 # these shouldn't get set for the site admin account
   524 params[:account][:settings].delete(:enable_alerts)
   525 params[:account][:settings].delete(:enable_eportfolios)
   526 end
   527 else
   528 # must have :manage_site_settings to update these
   529 [ :admins_can_change_passwords,
   530 :admins_can_view_notifications,
   531 :enable_alerts,
   532 :enable_eportfolios,
   533 :enable_profiles,
   534 :show_scheduler,
   535 :global_includes,
   536 :gmail_domain
   537 ].each do |key|
   538 params[:account][:settings].try(:delete, key)
   5
   Infrastructure-as-Code


   View Slide

6. Agenda Infrastructure-as-Code Challenges
   Solving Challenges with Terraform
   Collaboration & Scaling
   6


   View Slide

7. ⁄
   Infrastructure-as-Code
   Challenges
   7


   View Slide

8. Goals
   ▪ Unify the view of resources
   ▪ Support the modern data center (IaaS, PaaS, SaaS)
   ▪ Expose a way for individuals and teams to safely and predictably change
   infrastructure
   ▪ Provide a workflow that is technology agnostic
   ▪ Manage anything with an API
   8


   View Slide

9. Initial Challenges
   ▪ Need to learn to code
   ▪ Can’t automate a resource
   ▪ Can’t track changes
   ▪ Don’t know change impact
   ▪ Need to revert a change
   9


   View Slide

10. Scaling Challenges
    ▪ Multiple environments for infrastructure
    ▪ Duplicate code
    ▪ “Ball of Mud” configuration
    ▪ Too many working on code
    ▪ Dry run doesn’t reflect change impact
    ▪ Upgrades are disruptive
    10


    View Slide

11. ⁄
    Solving Challenges with
    Terraform
    11


    View Slide

12. Initial Challenges
    ▪ Need to learn to code
    ▪ Can’t automate a resource
    ▪ Can’t track changes
    ▪ Don’t know change impact
    ▪ Need to revert a change
    12


    View Slide

13. Need to
    learn to
    code?
    CODE EDITOR
    resource "google_compute_instance" "default" {
    name = "test"
    machine_type = "n1-standard-1"
    zone = "us-central1-a"
    tags = ["foo", "bar"]
    boot_disk {
    initialize_params {
    image = "debian-cloud/debian-9"
    }
    }
    // omitted for clarity
    }
    13


    View Slide

14. Need to learn to code?
    ▪ HashiCorp Configuration Language
    ▪ Language describes intent
    ▪ Declarative (I declare, therefore I am.)
    ▪ Handles logic of calling APIs in proper order
    14
    terraform.io/docs/configuration/syntax.html


    View Slide

15. Can’t
    automate
    a
    resource?
    15


    View Slide

16. 16
    terraform.io/docs/providers/


    View Slide

17. ▪ Many providers
    community-
    maintained
    ▪ Write your own with
    the Terraform
    Plugin SDK!
    CODE EDITOR
    # Create a new Datadog monitor
    resource "datadog_monitor" "foo" {
    name = "Name for monitor foo"
    type = "metric alert"
    message = "Monitor triggered."
    // omitted for clarity
    thresholds = {
    ok = 0
    warning = 2
    warning_recovery = 1
    critical = 4
    critical_recovery = 3
    }
    // omitted for clarity
    }
    17
    hashicorp.com/resources/everything-as-code-with-terraform


    View Slide

18. Can't
    track
    changes?
    18


    View Slide

19. Can't track changes?
    ▪ Track state of existing infrastructure resources
    ▪ State updates when changes applied
    IMPORTANT NOTE
    ▪ Non-Terraform resources not automatically added
    ▪ Configuration not automatically generated
    ▪ Manual changes get overwritten
    19
    terraform.io/docs/state/index.html


    View Slide

20. Don't know
    change
    impact?
    TERMINAL
    > terraform plan
    Terraform will perform the following
    actions:
    # aws_vpc.app_vpc will be created
    + resource "aws_vpc" "app_vpc" {
    + arn = (known after apply)
    + cidr_block = “10.128.0.0/25"
    // omitted for clarity
    }
    Plan: 1 to add, 0 to change, 0 to destroy.
    20


    View Slide

21. 21
    terraform.io/docs/internals/graph.html


    View Slide

22. TERMINAL
    + resource will be created
    - resource will be destroyed
    ~ resource will be updated in-place
    -/+ resources will be destroyed and re-created
    22


    View Slide

23. Need to
    revert a
    change?
    CODE EDITOR
    terraform {
    backend "remote" {
    organization = “"
    workspaces {
    name = “”
    }
    }
    }
    23


    View Slide

24. Need to revert a change?
    ▪ Version control working configuration
    ▪ Remote state and if possible, versioned
    ▪ Update to previous working version
    ▪ Add toggle for easier revert
    IMPORTANT NOTE
    ▪ More like “roll forward”
    24
    terraform.io/docs/backends/index.html


    View Slide

25. ⁄
    Collaborating & Scaling
    25


    View Slide

26. Scaling Challenges
    ▪ Multiple environments for infrastructure
    ▪ Duplicate code
    ▪ “Ball of Mud” configuration
    ▪ Too many working on code
    ▪ Dry run doesn’t reflect change impact
    ▪ Upgrades are disruptive
    26


    View Slide

27. Multiple
    environ-
    ments?
    TERMINAL
    > terraform workspace list
    default
    dev
    * prod
    > tree terraform.tfstate.d
    terraform.tfstate.d
    ├── dev
    └── prod
    27


    View Slide

28. Workspaces
    ▪ Each workspace isolates state
    ▪ Map environment to workspace prevents state contamination
    IMPORTANT NOTE
    ▪ More functionality for Terraform Cloud
    ▪ Manages state, access control, runs, etc.
    28
    terraform.io/docs/state/workspaces.html


    View Slide

29. TERMINAL
    > cd dev
    > terraform workspace dev
    > terraform init
    > terraform plan
    > terraform apply
    29


    View Slide

30. Duplicate
    code?
    TERMINAL
    hello_world
    ├── dev
    │ ├── network.tf
    │ ├── kubernetes.tf
    │ ├── app.tf
    │ └── database.tf
    └── prod
    ├── network.tf
    ├── kubernetes.tf
    ├── app.tf
    └── database.tf
    30
    Evolving Your Infrastructure with Terraform (Nicki Watts)


    View Slide

31. ▪ Use modules
    ▪ Divide resource
    types into
    different files
    ▪ Other sources
    – Version Control
    (submodules)
    – Module registry
    TERMINAL
    hello_world
    ├── base // can be separately maintained
    │ ├── network
    │ │ ├── subnets.tf
    │ │ └── vpc.tf
    │ ├── kubernetes
    │ │ └── cluster.tf
    │ ├── database
    │ │ └── database.tf
    │ └── app
    │ └── app.tf
    ├── dev
    │ └── main.tf
    └── prod
    └── main.tf
    31


    View Slide

32. When building
    modules…
    ▪ Set provider
    version in
    consumer
    ▪ Version with
    tagging
    CODE EDITOR
    provider "aws" {
    region = var.region
    version = "~> 2.41"
    }
    module "elb" {
    source = "terraform-aws-modules/elb/aws"
    version = "2.3.0"
    health_check = var.health_check
    listener = var.listener
    // omitted for clarity
    }
    output "dns" {
    value = module.elb.this_elb_dns_name
    }
    32
    terraform.io/docs/configuration/modules.html


    View Slide

33. “Ball of
    Mud”
    Config?
    TERMINAL
    > terraform plan
    Terraform will perform the following
    actions:
    // omitted for clarity
    Plan: 300 to add, 0 to change, 0 to
    destroy.
    33


    View Slide

34. ▪ Decouple with
    data sources
    ▪ Run separately
    CODE EDITOR
    data "aws_vpc" "selected" {
    filter {
    name = "owner"
    values = [var.owner]
    }
    }
    resource "aws_subnet" "example" {
    vpc_id = data.aws_vpc.selected.id
    availability_zone = "us-west-2a"
    cidr_block =
    cidrsubnet(data.aws_vpc.selected.cidr_block, 4,
    1)
    }
    34
    sysadvent.blogspot.com/2019/12/day-5-break-up-your-terraform-project.html


    View Slide

35. Too many
    working
    on code?
    35


    View Slide

36. Software Development Patterns
    36


    View Slide

37. Establish Collaboration Patterns
    ▪ Adopt a software development pattern
    ▪ Put it in a CI pipeline
    ▪ Apply and audit changes based on code push
    ▪ Lock state during changes to prevent overrides
    37
    terraform.io/docs/state/locking.html


    View Slide

38. Dry run
    doesn’t
    reflect
    change
    impact?
    TERMINAL
    > kitchen test
    -----> Starting Kitchen (v2.3.3)
    …
    Waiting for SSH service on
    54.93.35.169:22, retrying in 3 seconds
    Waiting for SSH service on
    54.93.35.169:22, retrying in 3 seconds
    Waiting for SSH service on
    54.93.35.169:22, retrying in 3 seconds
    Waiting for SSH service on
    54.93.35.169:22, retrying in 3 seconds
    Waiting for SSH service on
    54.93.35.169:22, retrying in 3 seconds
    38


    View Slide

39. Integration Tests
    Contract Tests
    Unit Tests
    Infrastructure
    Testing
    Manual
    Testing
    Cost
    (Time, $$$)
    End-to-End Tests
    hashicorp.com/resources/test-driven-development-tdd-for-infrastructure


    View Slide

40. View Slide

41. Upgrades
    are
    disruptive?
    TERMINAL
    > terraform-0.7.13 apply
    Terraform doesn't allow running any
    operations against a state
    that was written by a future Terraform
    version. The state is
    reporting it is written by Terraform
    '0.8.8'.
    Please run at least that version of
    Terraform to continue
    41


    View Slide

42. 42
    0.8 0.9 0.10 0.11 0.12
    CHANGELOG
    Upgrade Guide
    Template files & string
    interpolation changes
    AWS provider attribute
    deprecations
    CHANGELOG
    Upgrade Guide
    Migrating to Backends
    Deprecate Remote for
    Backend Configuration
    State Locking
    AWS provider changes
    may trigger recreation
    Providers separated as
    plugins from core
    repository & versioned
    Interactive approval for
    apply (breaks
    pipelines, add -auto-
    approve flag)
    CHANGELOG
    Upgrade Guide
    Changes to module
    inheritance of providers
    Always use splat (*)
    operator for count
    references
    CHANGELOG
    Upgrade Guide
    CHANGELOG
    Upgrade Guide
    Adds rich type system to a
    previously string-typed
    system
    Includes automated upgrade
    tool (with caveats)
    AWS Provider CHANGELOG
    AWS v2 Upgrade Guide
    speakerdeck.com/joatmon08/the-semi-ultimate-terraform-upgrade-guide


    View Slide

43. Ease Upgrade Path by…
    ▪ Pinning provider versions
    ▪ Using known functions and not creative hacks
    ▪ Decoupling configuration across providers (i.e., separate Kubernetes
    from GCP)
    ▪ Avoid provisioners or complicated lifecycle customizations
    43
    hashicorp.com/resources/closing-keynote-terraform-at-google


    View Slide

44. Resources
    ▪ Terraform Cloud | app.terraform.io/signup/account
    ▪ Learn Terraform | learn.hashicorp.com/terraform
    ▪ Community Forum | discuss.hashicorp.com
    44


    View Slide

45. Rosemary Wang
    Developer Advocate at HashiCorp
    she/her
    @joatmon08
    joatmon08
    linkedin.com/in/rosemarywang/
    45
    joatmon08.github.io


    View Slide
