1. THE TECHNOLOGY OF THE THINGS NETWORK Johan Stokking Tech Lead, The Things Network CTO and Co-Founder, The Things Industries johan@thethingsnetwork.org @johanstokking
2. INTERNET OF HUMANS VS INTERNET OF THINGS
4. 0 5 10 15 20 25 2016 2017 2018 2020 Number of Installed IoT Units (Billions) Consumer Business: Cross-Industry Business: Vertical-Specific Source: Gartner (January, 2017)
5. 0 10 20 30 40 50 60 70 80 COST AND SCALE Reduce TCO • Design • Development • Materials • Certification • Distribution • Commissioning • Installation • Connectivity • Maintenance • Support
6. Up to tens of thousands devices per gateway
7. Up to tens of thousands devices per gateway
8. so devices can run on solar panels for months or years on batteries Low power and small messages
9. Fast and quiet
10. Slow and loud
11. LORA Spread-spectrum; robust to interference, multipath and fading
12. LORA PERFORMANCE TX P (dBm) RX TX Power Connector loss Antenna gain Connector loss Antenna gain RX Power Path loss and fading 14 0 -100
13. LORA PERFORMANCE TX P (dBm) RX TX Power Connector loss Antenna gain Connector loss Antenna gain RX Power Path loss and fading 14 0 -100 Receiver sensitivity
14. LORA PERFORMANCE RX TX Power Connector loss Antenna gain Connector loss Antenna gain RX Power Path loss and fading Receiver sensitivity -137 dBm 151 dBm link budget
15. LORA PERFORMANCE Wi-Fi Unlicensed LPWAN Licensed LPWAN TX Power RX Sensitivity Link budget 20.5 dBm -75 dBm 95.5 dBm 14 dBm -137 dBm 151 dBm 23 dBm -129 dBm 152 dBm
16. LORA PERFORMANCE Theoretical maximum in free space
 is 850 km (US915 regulations) Wi-Fi is only 550 meters The Things Network
 Community set the
 world record: 702 km
 using a helium balloon
17. FREE SPACE? Attenuation Reflection and diffraction Fresnel zone
18. Sigfox IOT CONNECTIVITY Range Bandwidth NFC BLE Wi-Fi NB-IoT LoRa
19. Sigfox IOT CONNECTIVITY Range Bandwidth NFC BLE Wi-Fi NB-IoT LoRa Contactless payments, tag scanning
20. Sigfox IOT CONNECTIVITY Range Bandwidth NFC BLE Wi-Fi NB-IoT LoRa Wearables Contactless payments, tag scanning
21. Sigfox IOT CONNECTIVITY Range Bandwidth NFC BLE Wi-Fi NB-IoT LoRa Smart home and small office Wearables Contactless payments, tag scanning
22. Sigfox IOT CONNECTIVITY Range Bandwidth NFC BLE Wi-Fi NB-IoT LoRa Smart home and small office Outdoor use cases in coverage area, i.e. asset tracking, cars Wearables Contactless payments, tag scanning
23. Sigfox IOT CONNECTIVITY Range Bandwidth NFC BLE Wi-Fi NB-IoT LoRa Smart home and small office Agriculture, lighting, asset tracking, smart metering, utilities, maintenance, parking, smart buildings Outdoor use cases in coverage area, i.e. asset tracking, cars Wearables Contactless payments, tag scanning
24. LORAWAN
25. LORAWAN 40 BBAA0126 80 D204 2A A50EDB DB2A5FFA Uplink DevAddr FHDR FCnt FPort Payload AES 128-bit ECB maximum 51 to 222 bytes MIC AES 128-bit CMAC
26. LORAWAN SESSIONS Network Session Keys: Message Integrity, MAC commands Application Session Key: Payload Encryption and Decryption Devices Gateways Network Server Application
27. RED FLAGS • Use of ABP: not secure; keys cannot be changed, must be shared with network operator
 • Keys printed on paper or sent by email; keys should not be visible (use HSM), paper trail is impossible to clear
 • Unable to choose a Join Server or operate your own: platform lock-in, potentially unsafe storage of end device root keys
 • Unable to choose an Application Server or operate your own: application data may get compromised
 • Same keys for multiple end devices: end devices need unique keys
 • Hardcoded keys in end device: end devices should use a HSM
28. #include <TheThingsNetwork.h> const char *appEui = "0000000000000000"; const char *appKey = "00000000000000000000000000000000"; #define loraSerial Serial1 #define debugSerial Serial TheThingsNetwork ttn(loraSerial, debugSerial, TTN_FP_EU868); void setup() { loraSerial.begin(57600); debugSerial.begin(9600); ttn.join(appEui, appKey); ttn.showStatus(); } void loop() { float temp = analogRead(1); int16_t temp100 = temp * 100; byte payload[2]; payload[0] = temp100 ">> 8; payload[1] = temp100 & 0xff; ttn.sendBytes(payload, sizeof(payload)); delay(10000); } 25,42 °C "=> 0x09EE
29. function Decoder(payload) { var temp100; if (payload[0] & 0x80) { temp100 = (0xffff "<< 16) | (payload[0] "<< 8) | payload[1]; } else { temp100 = (payload[0] "<< 8) | payload[1]; } return { temperature: temp100 / 100 } } 0x09EE "=> 25,42 °C
30. var ttn = require(“ttn") var appID = "foo" var accessKey = "ttn-account-v2.eiPq8mEeYRL_PNBZsOpPy-O3ABJXYWulODmQGR5PZzg" ttn.data(appID, accessKey) .then(function (client) { client.on("uplink", function (devID, payload) { console.log("uplink from ", devID) console.log(payload) }) }) .catch(function (error) { console.error("whoops", error) process.exit(1) }) { “temperature”: 25.42 }
34. Insert old picture here
37. REGULATED CHAIN 3–4 weeks between harvesting and consumption Very delicate product: maturity and shape when harvesting, and bruises and ripening during transportation Ripening is between 4 days (17,8 °C) to 8 days (14,5 °C) with ethylene gas
39. CONNECTED CHAIN Banana Ripening App The Things Network: public and private
40. CONNECTED CHAIN Banana Ripening App The Things Network: public and private Control temperature, humidity and ethylene gas throughout the chain
41. CONNECTED CHAIN Banana Ripening App Farm Ship Transport Storage Shop The Things Network: public and private Control temperature, humidity and ethylene gas throughout the chain
42. CONNECTED CHAIN Banana Ripening App Farm Ship Transport Storage Shop The Things Network: public and private Control temperature, humidity and ethylene gas throughout the chain Private
 + Public Private offline or satellite Private pico + Public Private Private
43. CHOOSE YOUR DEPLOYMENT Private Networks • Hosted
 The Things Industries V3 SaaS • Private Cloud: AWS, Azure, GCP, etc
 The Things Industries V3 Private Cloud • Images: Docker, VMware, OpenStack, binaries, etc
 The Things Industries V3 Images • Development
 The Things Network V3 Stack for LoRaWAN Public Networks • Operator networks • Collaborative networks
44. Public network Private SaaS Private on-premises Private pico/offline LoRaWAN development V3: 2018 V2: 2017 V1: 2016 V0: 2015 THE THINGS NETWORK STACK V3
46. V3 GATEWAY SERVER • Maintains connections with gateways • Supports gRPC, MQTT and UDP protocols • Authenticated and encrypted connection • Manages gateway’s duty cycle • Forwards uplink traffic to a Network Server or Peering Broker • Serves frequency plan to the gateway • Supports standard or custom frequency plans
47. V3 NETWORK SERVER • Handles LoRAWAN MAC layer: 1.1, 1.0.3, 1.0.2 and 1.0 • Supports class A, B and C • Keeps MAC state per device • LoRaWAN and Regional Parameters versions • Radio settings, including RX1 timings, RX2 data rates, etc
48. V3 APPLICATION SERVER • Extended support for payload formats • Encoder and decoder JavaScript payload functions are there to stay • Adding an open source device repository on GitHub with payload functions for off-the-shelf devices • Set the payload format per device to allow for different models and versions • Manage devices in groups • Integrate third-party geo-localization services using LoRa TDOA, LoRa/ WiFi/BLE RSSI
49. V3 INTEGRATIONS • V3 features the popular MQTT and HTTP web hook integrations • Commercial cloud platform integration; • AWS IoT • Azure IoT Hub • Google Cloud IoT Core • More optional, zero effort, commercial integrations for leading IoT platforms • Easy to integrate directly in your application through HTTP web hooks
50. V3 CONSOLE • Can be deployed in any cluster scenario: • NS + AS + JS + Console • NS + AS + Console • NS + Console • AS + JS + Console • AS + Console • JS + Console • New look and improved navigation • Realtime insight in data and events • Enhanced filtering capabilities
51. V3 CONSOLE • Can be deployed in any cluster scenario: • NS + AS + JS + Console • NS + AS + Console • NS + Console • AS + JS + Console • AS + Console • JS + Console • New look and improved navigation • Realtime insight in data and events • Enhanced filtering capabilities
52. V3 IDENTITY SERVER • Issues security tokens, implements OAuth 2.0 server • Supports integration with enterprise SAML identity provider • Contains user, application and gateway registry • Supports organizations and inheriting rights • The Things Industries private offerings include a multi-tenant Identity Server: separate environments
53. V3 JOIN SERVER AND SECURITY • Stores the LoRaWAN root keys and derives session keys • You can deploy the Join Server inside or outside a V3 cluster, i.e. a private cloud or on-premises in a trusted domain • Control your security keys in your Join Server while using any V3 deployment scenario • Gives you the power to switch V3 clusters: public to private, private to public and private to private
54. V3 LORA ALLIANCE INTEROP
55. TRUSTED THIRD PARTY JOIN SERVERS • The Things Network Stack V3 supports the LoRaWAN Backend Interfaces 1.0, allowing interoperability with external Join Servers • Next generation devices contain secure elements • Pre-provisioned with symmetric LoRaWAN root keys that will never be exposed • Session keys are derived from the root keys, required by the Network Server and Application Server • The Join Server keeps the root keys safe, and only issues session keys
56. V3 PUBLIC COMMUNITY NETWORK The Things Network Foundation "#$% Open Network Infrastructure Association & Meshed ' Digital Catapult (
57. V3 PUBLIC COMMUNITY NETWORK The Things Network Foundation "#$% Open Network Infrastructure Association & Meshed ' Digital Catapult ( In progress or RFP )*+,-#"
58. MULTI TENANT CONSOLE NOC & BILLING API GEO LOCATION FIRMWARE UPDATES MONITORING AND CONFIGURATION THE THINGS NETWORK STACK JOIN SERVER APPLICATION SERVER INTEGRATIONS NETWORK SERVER GATEWAY SERVER
59. MULTI TENANT CONSOLE NOC & BILLING API GEO LOCATION FIRMWARE UPDATES MONITORING AND CONFIGURATION THE THINGS NETWORK STACK JOIN SERVER APPLICATION SERVER INTEGRATIONS NETWORK SERVER GATEWAY SERVER
60. LORAWAN 1.1 COMPLIANT MULTI TENANT CONSOLE NOC & BILLING API LORAWAN 1.0.x AND 1.1 + ALL REGIONS MONITORING AND CONFIGURATION THE THINGS NETWORK STACK APPLICATION SERVER INTEGRATIONS GATEWAY SERVER NETWORK SERVER ROOT KEY STORE JOIN SERVER
61. LORAWAN 1.1 COMPLIANT MULTI TENANT CONSOLE NOC & BILLING API GEO LOCATION FIRMWARE UPDATES MONITORING AND CONFIGURATION THE THINGS NETWORK STACK INTEGRATIONS GATEWAY SERVER NETWORK SERVER JOIN SERVER ROOT KEY STORE LORAWAN DECODING DECRYPTION KEY STORE APPLICATION SERVER
62. ROOT KEY STORE PAYLOAD ENCODING AND DECODING SESSION KEYS LORAWAN 1.1 COMPLIANT MULTI TENANT CONSOLE NOC & BILLING API GEO LOCATION FIRMWARE UPDATES MONITORING AND CONFIGURATION THE THINGS NETWORK STACK INTEGRATIONS GATEWAY SERVER NETWORK SERVER JOIN SERVER APPLICATION SERVER
63. ROOT KEY STORE LORAWAN DECODING DECRYPTION KEY STORE LORAWAN 1.1 COMPLIANT MULTI TENANT CONSOLE NOC & BILLING API GEO LOCATION FIRMWARE UPDATES MONITORING AND CONFIGURATION THE THINGS NETWORK STACK GATEWAY SERVER NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS
64. ROOT KEY STORE LORAWAN DECODING DECRYPTION KEY STORE LORAWAN 1.1 COMPLIANT MULTI TENANT CONSOLE NOC & BILLING API GEO LOCATION FIRMWARE UPDATES MONITORING AND CONFIGURATION THE THINGS NETWORK STACK GATEWAY SERVER NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS
65. ROOT KEY STORE LORAWAN DECODING DECRYPTION KEY STORE LORAWAN 1.1 COMPLIANT MULTI TENANT CONSOLE NOC & BILLING API GEO LOCATION FIRMWARE UPDATES MONITORING AND CONFIGURATION THE THINGS NETWORK STACK GATEWAY SERVER NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS
66. NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS GATEWAY SERVER
67. NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS GATEWAY SERVER
68. NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS GATEWAY SERVER NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS GATEWAY SERVER
69. PEERING NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS GATEWAY SERVER NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS GATEWAY SERVER
70. NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS GATEWAY SERVER NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS GATEWAY SERVER CLOUD PEERING
71. PEERING NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS GATEWAY SERVER NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS GATEWAY SERVER ON PREMISE
72. PEERING NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS GATEWAY SERVER NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS GATEWAY SERVER ON PREMISE
73. PEERING NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS GATEWAY SERVER NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS GATEWAY SERVER ON PREMISE
74. PEERING NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS GATEWAY SERVER NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS GATEWAY SERVER ON PREMISE
75. PEERING NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS GATEWAY SERVER NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS GATEWAY SERVER ON PREMISE
76. PEERING NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS GATEWAY SERVER NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS GATEWAY SERVER ON PREMISE
77. PEERING NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS GATEWAY SERVER NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS GATEWAY SERVER ON PREMISE
78. PEERING NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS GATEWAY SERVER NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS GATEWAY SERVER ON PREMISE
79. PEERING NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS GATEWAY SERVER NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS GATEWAY SERVER ON PREMISE
80. PEERING NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS GATEWAY SERVER NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS GATEWAY SERVER ON SITE NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS GATEWAY SERVER
81. PEERING PEERING NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS GATEWAY SERVER NETWORK SERVER JOIN SERVER APPLICATION SERVER INTEGRATIONS GATEWAY SERVER ON SITE JOIN SERVER
82. Public Networks • Operator networks • Collaborative networks CHOOSE YOUR DEPLOYMENT Private Networks • Hosted
 The Things Industries V3 SaaS • Private Cloud: AWS, Azure, GCP, etc
 The Things Industries V3 Private Cloud • Images: Docker, VMware, OpenStack, binaries, etc
 The Things Industries V3 Images • Development
 The Things Network V3 Stack for LoRaWAN
83. DEPLOYMENT MODELS Private gateways Multi- tenant Multi- region Auto- scaling FOTA SLA Support Available TTN PCN N N Y Y N N N 2019 Q1 TTI Hosted Y Y Y Y Y Y Y 2019 Q1 TTI Private Cloud Y Y Y N Y N Y 2018 Q4 TTI Images and Binaries Y Y Y N Y N Y 2018 Q4 TTN Open Source Y N N N N N N 2018 Q4
84. Peering allows for exchanging traffic between a private network and the public network This enables sharing of coverage, while staying in full control of infrastructure
85. PRIVATE-PRIVATE PEERING
86. v v v PRIVATE-PRIVATE PEERING
87. v v v PRIVATE-PRIVATE PEERING
88. YOU ARE THE NETWORK
