Clair: A container image security analyzer

Wercker meetup, Rackspace Geekdom SF: http://www.meetup.com/wercker/events/229673565/

Transcript

1. Clair: A Container Image Security Analyzer Josh Wood DocOps at CoreOS @joshixisjosh9
3. We’re hiring in all departments! Email: careers@coreos.com Positions: coreos.com/ careers 90+ Projects on GitHub, 1,000+ Contributors OPEN SOURCE CoreOS.com - @coreoslinux - github/coreos Secure solutions, support plans, training + more ENTERPRISE sales@coreos.com - tectonic.com - quay.io CoreOS Runs the World’s Containers
4. The smartest way to run your container infrastructure. tectonic.com @tectonic
5. Build, Store and Distribute your Containers quay.io
7. Clair - A container image security analyzer - Not heuristic AV - Based on distro, package, container layer - REST HTTP API - Open source - Apache License - Base of Quay container image analysis features
8. Insecurities • Security vulnerabilities today affect an increasing number of systems Source: https://www.cvedetails.com/browse-by-date.php
9. Security before containers Operating System Package Manager Package A Package B Package C Application Code
10. Security before containers Operating System Package Manager Package A Package B Package C Application Code Developers Ops
11. Containers and Security • Applications today are being moved into containers • Applications run multiple microservices, each with its own container • Each container has its full compliment of packages and dependencies
12. Containers and Security Operating System Container Runtime Container Container Container Container Container Developers Ops
13. Containers and Security Operating System Package Manager Package A Package B Package C Microservice code Container Runtime Package Manager Package A Package D Package C Microservice code
14. Vulnerabilities inside container images How common is it really?
15. ORIGINAL PHOTO (CC) BY IAN KLUFT CVE-2015-0235 aka GHOST “GHOST is a buffer overflow bug affecting the gethostbyname() and gethostbyname2() function calls in the glibc library. This vulnerability allows a remote attacker that is able to make an application call to either of these functions to execute arbitrary code.”
16. ORIGINAL PHOTO (CC) BY IAN KLUFT CVE-2015-0235 aka GHOST “GHOST is a buffer overflow bug affecting the gethostbyname() and gethostbyname2() function calls in the glibc library. This vulnerability allows a remote attacker that is able to make an application call to either of these functions to execute arbitrary code.” 66.6 % of analyzed images on Quay.io Coincidence? I think not !
17. CVE-2014-0160 aka Heartbleed “The TLS and DTLS implementations in OpenSSL do not properly handle Heartbeat Extension packets, which allows remote attackers to obtain sensitive information from process memory via crafted packets that trigger a buffer over-read.” ORIGINAL PHOTO (CC) BY IAN KLUFT
18. CVE-2014-0160 aka Heartbleed “The TLS and DTLS implementations in OpenSSL do not properly handle Heartbeat Extension packets, which allows remote attackers to obtain sensitive information from process memory via crafted packets that trigger a buffer over-read.” ORIGINAL PHOTO (CC) BY IAN KLUFT 80 % of analyzed images on Quay.io
19. Why are these vulnerabilities so common?
20. Most containers built on same base layers
21. Most containers built on same base layers
22. How do we make this better for developers?
23. Automated detection of vulnerabilities • Check every new image pushed to Quay.io for vulnerabilities • Check every existing image against new or updated vulnerabilities • Notify developers when an image is vulnerable
24. Goal: • Analyze millions of containers in a minimum amount of time and cost How do we analyze the containers ?
25. Goal: • Analyze millions of containers in a minimum amount of time and cost Solution: • Do not run any of these containers • Extract required knowledge from their static content • Analyze only once, for known and future vulnerabilities How do we analyze the containers ?
26. 1. MAINTAINER Quentin Machu <quentin.machu@coreos.com> 2. FROM ubuntu:trusty 3. RUN apt−get update && apt−get upgrade −y 4. EXPOSE 22 5. CMD ["/usr/sbin/sshd", "-D"] What is a container image ? Container Layer • Metadata (id, parent id, command, environment, …) • Filesystem diff (which files have been added/modified/removed)
27. What is extracted exactly ? For each container layer, find the: • Operating system ◦ /etc/.*-release, /etc/apt/sources.list, ... • Package list ◦ /var/lib/dpkg/status, /var/lib/rpm/Packages
28. What is extracted exactly ? For each container layer, find the: • Operating system ◦ /etc/.*-release, /etc/apt/sources.list, ... • Package list ◦ /var/lib/dpkg/status, /var/lib/rpm/Packages And store an improved diff ! • Metadata (id, parent id, command, environment, …) • Filesystem diff (which files have been added/modified/removed) + Operating system + Package list diff (which packages have been installed/upgraded/removed)
30. 1. MAINTAINER Quentin Machu <quentin.machu@coreos.com>
31. 1. MAINTAINER Quentin Machu <quentin.machu@coreos.com>
32. 2. FROM ubuntu:trusty
33. 2. FROM ubuntu:trusty
34. 2. FROM ubuntu:trusty
35. 2. FROM ubuntu:trusty
36. 3. RUN apt-get update && apt-get upgrade -y
37. 3. RUN apt-get update && apt-get upgrade -y
38. 3. RUN apt-get update && apt-get upgrade -y
39. 4. EXPOSE 22
40. 5. CMD [“/usr/sbin/sshd”, “-D”]
43. What about the vulnerabilities ? • Periodically update from distro-specific vulnerability trackers ◦ Ubuntu CVE Tracker launchpad.net/ubuntu-cve-tracker/ ◦ Debian Security Bug Tracker security-tracker.debian.org/tracker/ ◦ Red Hat Errata rhn.redhat.com/errata/ • Each source has its own format, and its own parser • Accurate because each distro knows exactly when they fix a vulnerability
44. 16 500 vulnerabilities - fixed by 92 000 package versions 4100 High / Critical vulnerabilities const ( [...] // High vulnerability is a real problem, exploitable for many people // in a default installation. Includes serious remote denial of // services, local root privilege escalations, or data loss. High Priority = "High" // Critical vulnerability is a world-burning problem, exploitable for // nearly all people in a default installation of Linux. Includes // remote root privilege escalations, or massive data loss. Critical Priority = "Critical" ) What about the vulnerabilities ?
64. coreos.com/fest - @coreosfest May 9 & 10, 2016 - Berlin, Germany and San Francisco satellite!
65. See also: • quay.io • github.com/coreos/clair • github.com/coreos/clair#kubernetes
66. Thank you! Josh Wood @joshixisjosh9 | j@coreos.com | github.com/joshix We’re hiring in all departments! Email: careers@coreos.com Positions: coreos.com/ careers
