Graph Processing using Apache Flink

Meetup-Vortrag über die Verarbeitung von Graphenstrukturen mit Apache Flink.

Transcript

1. Meetup, 02.11.2017 Kristian Kottke Graph Processing using Apache Flink
2. ©iteratec Whoami Kristian Kottke › Senior Software Engineer -> iteratec Interests › Software Architecture › Big Data Technologies Kristian.Kottke@iteratec.de github.com/kkottke xing.to/kkottke 02.11.2017 | Graph Processing using Apache Flink 2
3. ©iteratec Overview › Use Case › Apache Flink › Gelly › Demo › Alternative Processing Models › Wrap Up 02.11.2017 | Graph Processing using Apache Flink 3
4. ©iteratec History
5. ©iteratec Fraud Rings First-Party Fraud 02.11.2017 | Graph Processing using Apache Flink 5
6. ©iteratec Fraud Rings First-Party Fraud 02.11.2017 | Graph Processing using Apache Flink 6
7. ©iteratec Overview 02.11.2017 | Graph Processing using Apache Flink 7 Data Ingestion Graph Analytics Visualization/Persistence
8. ©iteratec 8 8 Graph Analytics Problem Definition › Determine Relations › Assign unique Identifier (RingId) Challenges › High, implicit Connectivity › Transitive Relations › Relations based on different Properties › -> Iterations 02.11.2017 | Graph Processing using Apache Flink 1 1 1 1 1 1 1 1 1 1 1 1 1 1
9. ©iteratec
10. ©iteratec Hadoop MapReduce 02.11.2017 | Graph Processing using Apache Flink 10 Input Output Map Reduce Shuffle & Sort
11. ©iteratec MapReduce -> Graph 02.11.2017 | Graph Processing using Apache Flink 11
12. ©iteratec Graph? What?! 02.11.2017 | Graph Processing using Apache Flink 12
13. ©iteratec Graph 02.11.2017 | Graph Processing using Apache Flink 13
14. ©iteratec Apache Flink › Platform for distributed stream and batch processing › Data Distribution › Communication › Fault Tolerance › Memory Management › Parallelizing and Optimization › Native Iteration Support › Fork of a research project › 03/2014: Apache Incubator › 12/2014: Apache Top-Level 02.11.2017 | Graph Processing using Apache Flink 14
15. ©iteratec Apache Flink 02.11.2017 | Graph Processing using Apache Flink 15 Files, HDFS, S3, JDBC, Kafka, ... Local Cluster Cloud DataStream API DataSet API FlinkML Gelly Table & SQL CEP Table & SQL Storage Deployment Runtime API Libraries following: https://ci.apache.org/projects/flink/flink-docs-release-1.2/
16. ©iteratec Apache Flink Structure 02.11.2017 | Graph Processing using Apache Flink 16 Execution Environment Load/Create Data Transformations Store Data Trigger Execution ExecutionEnvironment env = ExecutionEnvironment.getExecutionEnvironment(); DataSet text = env.readCsvFile(“inputFile.csv“); DataSet<Tuple2<String, Integer> counts = text.flatMap(new LineSplitter()) .groupBy(0).sum(1); counts.writeAsCsv(“outputFile.csv“); env.execute();
17. ©iteratec Apache Flink Execution 02.11.2017 | Graph Processing using Apache Flink 17 TaskManager TaskManager JobManager TaskSlot TaskSlot TaskSlot TaskSlot
18. ©iteratec 18 18 Pseudo Algorithm › Determine Relations › Assign unique Identifier (RingId) Algorithm › Create Graph › Generate potential RingId › Send RingId to all Neighbors › Receive smaller RingId › Update current RingId › Send new RingId to all Neighbors 02.11.2017 | Graph Processing using Apache Flink 1 1 1 1 1 1 1 1 1 1 1 1 1 1
19. ©iteratec Apache Flink Delta Iterations 02.11.2017 | Graph Processing using Apache Flink 19 Join Group Join Filter Solution Set Step Function Update Delta Iteration Result Working Set (Edges) Solution Set (Vertices)
20. ©iteratec 20 20 Gelly › High-Level Graph API › Graph Representation › Graph Transformations › Graph Mutations › Neighborhood Methods (Access/Processing) › Iterative Graph Processing › Vertex-Centric › Scatter-Gather › Gather-Sum-Apply 02.11.2017 | Graph Processing using Apache Flink
21. ©iteratec Gelly Vertex-Centric Iterations 02.11.2017 | Graph Processing using Apache Flink 21 1 2 3 4 1 2 3 4 2 4 3 inbox outbox 3 1 4 1 4 Superstep 1 2 4 4 4 4 1 2 3 1 3 2 4 3 inbox outbox 2 4 1 4 3 1 4 1 1 4 Superstep 2 barrier barrier following: https://ci.apache.org/projects/flink/flink-docs-release-1.2/ ......
22. ©iteratec Gelly Vertex-Centric Iterations: Code 02.11.2017 | Graph Processing using Apache Flink 22 // create graph Graph graph = Graph.fromTupleDataSet(vertices, edges, env); // run iterations Graph resultGraph = graph.runVertexCentricIteration( new ComputeFunction(), new MessageCombiner(), 100);
23. ©iteratec Gelly Vertex-Centric Iterations: Code public void compute(Vertex vertex, MessageIterator messages) { String ringId = vertex.getValue(); if (getSuperstepNumber() == 1) { sendMessageToAllNeighbors(ringId); } else { for (String message : messages) { if (message.compareTo(ringId) < 0) { ringId = message; } } if (!vertex.getValue().equals(ringId)) { setNewVertexValue(ringId); sendMessageToAllNeighbors(ringId); } } } 02.11.2017 | Graph Processing using Apache Flink 23
24. ©iteratec Gelly Vertex-Centric Iterations: Execution Plan 02.11.2017 | Graph Processing using Apache Flink 24
25. ©iteratec Demo
26. ©iteratec Gelly Scatter-Gather Iterations 02.11.2017 | Graph Processing using Apache Flink 26 1 2 3 4 1 2 3 4 2 4 3 outbox 3 1 4 1 4 2 4 4 4 barrier 4 1 2 3 1 3 inbox 2 1 3 1 3 2 4 ...... Scatter Gather Superstep
27. ©iteratec Gelly Scatter-Gather Iterations: Code // scatter function public void sendMessages(Vertex vertex) { sendMessageToAllNeighbors(vertex.getValue()); } 02.11.2017 | Graph Processing using Apache Flink 27
28. ©iteratec Gelly Scatter-Gather Iterations: Code 02.11.2017 | Graph Processing using Apache Flink 28 // gather function public void updateVertex(Vertex vertex, MessageIterator messages) { String ringId = vertex.getValue(); for (String message : messages) { if (message.compareTo(ringId) < 0) { ringId = message; } } if (!vertex.getValue().equals(ringId)) { setNewVertexValue(ringId); } }
29. ©iteratec Gelly Gather-Sum-Apply Iterations 02.11.2017 | Graph Processing using Apache Flink 29 1 2 3 4 1 2 3 4 2 4 3 outbox 3 1 4 1 4 2 4 4 4 barrier 1 2 3 3 inbox 1 1 ...... Gather Sum Superstep 4 1 1 3 inbox 2 1 3 1 3 2 4 3 1 1 1 Apply inbox
30. ©iteratec Gelly Gather-Sum-Apply Iterations: Code 02.11.2017 | Graph Processing using Apache Flink 30 // gather function public String gather(Neighbor neighbor) { return neighbor.getNeighborValue(); }
31. ©iteratec Gelly Gather-Sum-Apply Iterations: Code 02.11.2017 | Graph Processing using Apache Flink 31 // sum function public String sum(String rindId1, String ringId2) { return ringId1.compareTo(ringId2) < 0 ? ringId1 : ringId2; }
32. ©iteratec Gelly Gather-Sum-Apply Iterations: Code 02.11.2017 | Graph Processing using Apache Flink 32 // apply function public void apply(String newRingId, String currentRingId) { if (newRingId.compareTo(currentRingId) < 0) { setResult(newRingId); } }
33. ©iteratec Gelly Iteration Abstractions Vertex-Centric › Most generic model (computation & messaging) Scatter-Gather & Gather-Sum-Apply › Separated iteration phases › Maintainability › Performance › No concurrent access to inbox and outbox › Scatter: parallelized over vertices › Gather: parallelized over edges 02.11.2017 | Graph Processing using Apache Flink 33
34. ©iteratec Appendix Iteration Abstractions Iteration Model Update Function Update Logic Communication Scope Communication Logic Vertex-Centric arbitrary arbitrary any vertex arbitrary Scatter-Gather arbitrary based on received messages any vertex based on vertex state Gather-Sum-Apply associative & commutative based on reduced message neighborhood based on vertex state 02.11.2017 | Graph Processing using Apache Flink 34 following: https://ci.apache.org/projects/flink/flink-docs-release-1.2/
35. ©iteratec 35 35 Gelly Library Methods › Community Detection › Label Propagation › PageRank › Single Source Shortest Path › Triangle Listing ... › Connected Components 02.11.2017 | Graph Processing using Apache Flink // create graph Graph graph = Graph.fromTupleDataSet( vertices, edges, env); // run iterations DataSet<Vertex> result = graph.run( new GSAConnectedComponents(100));
36. ©iteratec Graphs are everywhere 02.11.2017 | Graph Processing using Apache Flink 36
37. ©iteratec Graphs are everywhere Fraud Rings 02.11.2017 | Graph Processing using Apache Flink 37
38. ©iteratec Graphs are everywhere Social Networks 02.11.2017 | Graph Processing using Apache Flink 38
39. ©iteratec Graphs are everywhere Recommendations 02.11.2017 | Graph Processing using Apache Flink 39
40. ©iteratec Graphs are everywhere IT Networks 02.11.2017 | Graph Processing using Apache Flink 40
41. ©iteratec Wrap Up › Data (often) have high and complex connectivity › Relationships are (at least as) important than the single records › Graph Processing › Intuitiveness › Speed › Scalability › Processing vs. Storing › Alternatives › Giraph › Spark GraphX 02.11.2017 | Graph Processing using Apache Flink 41
42. ©iteratec Q&A 02.11.2017 | Graph Processing using Apache Flink 42
