Evolution of LINE Things and inside of released products

Sho Tachibana
LINE Technical Evangelism Team Technical Evangelist
https://linedevday.linecorp.com/jp/2019/sessions/F2-1

Transcript

1. 2019 DevDay
   Evolution of LINE Things and
   Inside of Released Products
   > Sho Tachibana
   > LINE Technical Evangelism Team Technical Evangelist


   View Slide

2. Sho Tachibana
   Technical Evangelist
   > Technical Support
   > Planning Support
   > Alliance Support
   > Biz Support
   Contact Me
   Anytime!


   View Slide

3. Nov 2018


   View Slide

4. Trial Products
   1,800+


   View Slide

5. MAU In TOP 4
   164,000,000


   View Slide

6. Install
   Signup
   Credit Card
   Unreachable User
   Useless Development
   NO


   View Slide

7. Install
   NO


   View Slide

8. Signup
   NO


   View Slide

9. Credit Card
   NO


   View Slide

10. Unreachable User
    NO


    View Slide

11. Useless Development
    NO


    View Slide

12. Agenda
    > Overview
    > New Feature: Automated BLE Communication
    > Service Prototypes by Developers
    > Products With LINE Things
    > Our Booth


    View Slide

13. Overview


    View Slide

14. Device link
    LIFF BLEʢLIFF SDK BLE pluginʣ
    New feature: Automated BLE communication
    LINE Things Features


    View Slide

15. LINE Things


    View Slide

16. LINE Things


    View Slide

17. LIFF - LINE Front-end Framework


    View Slide

18. Device Link & LIFF BLE


    View Slide

19. View Slide

20. LIFF BLE
    Device Link


    View Slide

21. How Does LIFF BLE Work?


    View Slide

22. Implementation
    const device = await liff.bluetooth.requestDevice();
    const gatt = await device.gatt.connect();
    const service = await gatt.getPrimaryService(
    'E625601E-9E55-4597-A598-76018A0D293D'
    );
    const characteristic = await service.getCharacteristic(
    '26E2B12B-85F0-4F3F-9FDD-91D114270E6E'
    );
    characteristic.addEventListener('characteristicvaluechanged', (e) => {
    console.log('value changed to:' + e.target.value);
    });
    await characteristic.startNotifications();


    View Slide

23. const device = await liff.bluetooth.requestDevice();
    const gatt = await device.gatt.connect();
    const service = await gatt.getPrimaryService(
    'E625601E-9E55-4597-A598-76018A0D293D'
    );
    const characteristic = await service.getCharacteristic(
    '26E2B12B-85F0-4F3F-9FDD-91D114270E6E'
    );
    const value = await characteristic.readValue();
    Connection Process


    View Slide

24. Data Access
    LINE app
    Device
    Read
    LINE app
    Device
    Write
    LINE app
    Device
    Notify


    View Slide

25. Data Access
    const device = await liff.bluetooth.requestDevice();
    const gatt = await device.gatt.connect();
    const service = await gatt.getPrimaryService(
    'E625601E-9E55-4597-A598-76018A0D293D'
    );
    const characteristic = await service.getCharacteristic(
    '26E2B12B-85F0-4F3F-9FDD-91D114270E6E'
    );
    const value = await characteristic.readValue();


    View Slide

26. Read
    const device = await liff.bluetooth.requestDevice();
    const gatt = await device.gatt.connect();
    const service = await gatt.getPrimaryService(
    'E625601E-9E55-4597-A598-76018A0D293D'
    );
    const characteristic = await service.getCharacteristic(
    '26E2B12B-85F0-4F3F-9FDD-91D114270E6E'
    );
    const value = await characteristic.readValue();


    View Slide

27. Write
    const device = await liff.bluetooth.requestDevice();
    const gatt = await device.gatt.connect();
    const service = await gatt.getPrimaryService(
    'E625601E-9E55-4597-A598-76018A0D293D'
    );
    const characteristic = await service.getCharacteristic(
    '26E2B12B-85F0-4F3F-9FDD-91D114270E6E'
    );
    await characteristic.writeValue(
    new TextEncoder(‘utf-8‘).encode(‘LIFF BLE’)
    );


    View Slide

28. Notify
    const device = await liff.bluetooth.requestDevice();
    const gatt = await device.gatt.connect();
    const service = await gatt.getPrimaryService(
    'E625601E-9E55-4597-A598-76018A0D293D'
    );
    const characteristic = await service.getCharacteristic(
    '26E2B12B-85F0-4F3F-9FDD-91D114270E6E'
    );
    characteristic.addEventListener('characteristicvaluechanged', (e) => {
    console.log('value changed to:' + e.target.value);
    });
    await characteristic.startNotifications();


    View Slide

29. Automated BLE Communication


    View Slide

30. View Slide

31. How Does Automated BLE Communication Work?


    View Slide

32. Scenario
    {
    "autoClose": false,
    "suppressionInterval": 0,
    "scenarios": [
    {
    "trigger": {
    "type": "BLE_NOTIFICATION",
    "serviceUuid": "4812a0a6-10af-4afb-91f0-b4434e55763b",
    "characteristicUuid": "91a6fb1d-d365-4229-9d41-4358a96388e3"
    },
    "actions": [
    {
    "type": "GATT_WRITE",
    "serviceUuid": "4812a0a6-10af-4afb-91f0-b4434e55763b",
    "characteristicUuid": "91a6fb1d-d365-4229-9d41-4358a96388e3",
    "data": "Zm9vCg=="
    }
    ]
    }
    ]
    }


    View Slide

33. {
    "autoClose": false,
    "suppressionInterval": 0,
    "scenarios": [
    {
    "trigger": {
    "type": "BLE_NOTIFICATION",
    "serviceUuid": "4812a0a6-10af-4afb-91f0-b4434e55763b",
    "characteristicUuid": "91a6fb1d-d365-4229-9d41-4358a96388e3"
    },
    "actions": [
    {
    "type": "GATT_WRITE",
    "serviceUuid": "4812a0a6-10af-4afb-91f0-b4434e55763b",
    "characteristicUuid": "91a6fb1d-d365-4229-9d41-4358a96388e3",
    "data": "Zm9vCg=="
    }
    ]
    }
    ]
    }
    Scenario


    View Slide

34. {
    "autoClose": false,
    "suppressionInterval": 0,
    "scenarios": [
    {
    "trigger": {
    "type": "BLE_NOTIFICATION",
    "serviceUuid": "4812a0a6-10af-4afb-91f0-b4434e55763b",
    "characteristicUuid": "91a6fb1d-d365-4229-9d41-4358a96388e3"
    },
    "actions": [
    {
    "type": "GATT_WRITE",
    "serviceUuid": "4812a0a6-10af-4afb-91f0-b4434e55763b",
    "characteristicUuid": "91a6fb1d-d365-4229-9d41-4358a96388e3",
    "data": "Zm9vCg=="
    }
    ]
    }
    ]
    }
    Scenario


    View Slide

35. {
    "autoClose": false,
    "suppressionInterval": 0,
    "scenarios": [
    {
    "trigger": {
    "type": "BLE_NOTIFICATION",
    "serviceUuid": "4812a0a6-10af-4afb-91f0-b4434e55763b",
    "characteristicUuid": "91a6fb1d-d365-4229-9d41-4358a96388e3"
    },
    "actions": [
    {
    "type": "GATT_WRITE",
    "serviceUuid": "4812a0a6-10af-4afb-91f0-b4434e55763b",
    "characteristicUuid": "91a6fb1d-d365-4229-9d41-4358a96388e3",
    "data": "Zm9vCg=="
    }
    ]
    }
    ]
    }
    Scenario


    View Slide

36. Scenario
    {
    "autoClose": false,
    "suppressionInterval": 0,
    "scenarios": [
    {
    "trigger": {
    "type": "BLE_NOTIFICATION",
    "serviceUuid": "4812a0a6-10af-4afb-91f0-b4434e55763b",
    "characteristicUuid": "91a6fb1d-d365-4229-9d41-4358a96388e3"
    },
    "actions": [
    {
    "type": "GATT_WRITE",
    "serviceUuid": "4812a0a6-10af-4afb-91f0-b4434e55763b",
    "characteristicUuid": "91a6fb1d-d365-4229-9d41-4358a96388e3",
    "data": "Zm9vCg=="
    }
    ]
    }
    ]
    }


    View Slide

37. Scenario
    {
    "autoClose": true,
    "suppressionInterval": 600000,
    "scenarios": [
    {
    "trigger": {
    "type": "IMMEDIATE",
    },
    "actions": [
    {
    "type": "GATT_READ",
    "serviceUuid": "4812a0a6-10af-4afb-91f0-b4434e55763b",
    "characteristicUuid": "91a6fb1d-d365-4229-9d41-4358a96388e3"
    }
    ]
    }
    ]
    }


    View Slide

38. Webhook
    {
    "events": [
    {
    "type": "things",
    ...
    "things": {
    "type": "scenarioResult",
    "deviceId": "tXXX",
    "result": {
    "scenarioId": "XXX",
    "revision": 2,
    "startTime": 1547817845950,
    "endTime": 1547817845952,
    "resultCode": "success",
    "bleNotificationPayload": "AQ==",
    "actionResults": [
    {
    "type": "binary",
    "data": "/w=="
    }
    ......


    View Slide

39. {
    "events": [
    {
    "type": "things",
    ...
    "things": {
    "type": "scenarioResult",
    "deviceId": "tXXX",
    "result": {
    "scenarioId": "XXX",
    "revision": 2,
    "startTime": 1547817845950,
    "endTime": 1547817845952,
    "resultCode": "success",
    "bleNotificationPayload": "AQ==",
    "actionResults": [
    {
    "type": "binary",
    "data": "/w=="
    }
    ......
    Webhook


    View Slide

40. > Background communication works(with a few expetions)
    > Sleep action must be less than 5 seconds
    > autoClose = true with just BLE_NOTIFICATION trigger does not works
    Important Notes
    Regarding Automated BLE Communication
    > Background Behavior of BLE depends on OS


    View Slide

41. > Background communication works(with a few expetions)
    > Sleep action must be less than 5 seconds
    > autoClose = true with just BLE_NOTIFICATION trigger does not works
    Important Notes
    Regarding Automated BLE Communication
    > Background Behavior of BLE depends on OS


    View Slide

42. > Background communication works(with a few expetions)
    > Sleep action must be less than 5 seconds
    > autoClose = true with just BLE_NOTIFICATION trigger does not works
    Important Notes
    Regarding Automated BLE Communication
    > Background Behavior of BLE depends on OS


    View Slide

43. > Background communication works(with a few expetions)
    > Sleep action must be less than 5 seconds
    > autoClose = true with just BLE_NOTIFICATION trigger does not works
    Important Notes
    Regarding Automated BLE Communication
    > Background Behavior of BLE depends on OS


    View Slide

44. > Background communication works.(with a few expetions)
    > Sleep action must be less than 5 seconds
    > autoClose = true with just BLE_NOTIFICATION trigger does not works
    Important Notes
    Regarding Automated BLE Communication
    > Background Behavior of BLE depends on OS


    View Slide

45. Service Prototypes
    By Developers


    View Slide

46. Car Battery Checker
    LIFF BLE Automated


    View Slide

47. LINE Things Drink Bar
    LIFF BLE Messaging API


    View Slide

48. LINE Beacon Bacon
    LIFF BLE Automated


    View Slide

49. Mirai Gomibako
    LINE Pay API


    View Slide

50. Quiz Buzzer
    LIFF BLE
    LIFF


    View Slide

51. Products With LINE Things


    View Slide

52. View Slide

53. Smart Pen


    View Slide

54. Our Booth


    View Slide

55. View Slide

56. View Slide

57. View Slide

58. > Will be charged from the second year, but calculated based on the number
    of users
    > Push message of LINE Messaging API will be charged, and we plan to
    monetize by them
    > Free for the first year after submission for the production plan
    Price of LINE Things Platform
    > The campaign will go on for a limited time


    View Slide

59. Last but at Least


    View Slide

60. LINE Things
    WebApp Messanger Payment
    Social


    View Slide

61. Life on LINE


    View Slide

62. Thank You
