MSA(Microservices Architecture):Harder, Better, Faster, Stronger

MSA(Microservices Architecture):Harder, Better, Faster, Stronger

LINE DEVDAY 2021
PRO

November 11, 2021
Tweet

More Decks by LINE DEVDAY 2021

Other Decks in Technology

Transcript

  1. View Slide

  2. Work it harder,
    Make it better,
    Do it faster,
    Makes us stronger
    - Daft punk

    View Slide

  3. How to build?
    with Armeria, GraphQL, gRPC and Zipkin

    View Slide

  4. Agenda
    - MSA on “SeriesOn” service
    - Ways to quickly build using Armeria
    - Why is it better using GraphQL
    - How to monitor the service?
    - Summary

    View Slide

  5. SeriesOn
    About
    OTT video streaming service of NAVER WEBTOON

    View Slide

  6. MSA on SeriesOn
    From the past…
    Monolithic
    SQL Driven
    Service
    Difficulty in
    service expansion

    View Slide

  7. MSA on SeriesOn
    Motivation
    FRONT API SERVICE
    APP
    WEB
    TV
    EXTERNAL
    APP SERVICE
    WEB SERVICE
    TV SERVICE
    EXTERNAL
    SERVICE
    AGGREGATION
    SERVICE
    META
    AUTH
    PAYMENT
    ETC
    (Components)
    CLIENTS AGGREGATION SERVICE BACKEND
    MICROSERVICE

    View Slide

  8. MSA on SeriesOn
    Motivation
    - Backend services does not directly called by client.
    - The role of aggregating each data after checking what data is required through front API services
    Aggregation services
    Backend services
    - Server components responsible for multiple business logic
    - Such as authorization, contents playing, payment and movie meta etc ..
    Front API services
    - Manage the client-specific authentication and API invocation

    View Slide

  9. SeriesOn MSA
    Important to consider while implementing components
    - gRPC + Protobuf , Cache …
    Light and fast
    Generate API auto-documentation
    - Swagger …
    Support asynchronous
    - Reactive, Coroutine …
    Support distributed tracing
    - Pinpoint, Zipkin …

    View Slide

  10. Apply Armeria and gRPC using boilerplate within the team
    Ways to quickly build using Armeria

    View Slide

  11. Ways to quickly build using Armeria
    Apply Armeria with gRPC
    Armeria (https://armeria.dev)
    - Powered by LINE (current version : 1.12.0)
    - Go-to microservice framework
    - Support gRPC, Thrift, Kotlin, Retrofit, Reactive Streams, Spring Boot and Dropwizard.

    View Slide

  12. Ways to quickly build using Armeria
    Apply Armeria with gRPC
    Armeria (https://armeria.dev)
    - Support HTTP/2
    - Integration with gRPC and Thrift
    - gRPC-over-HTTP/1 & 2
    - Thrift-over-HTTP/1 & 2
    - gRPC-Web
    - Essential features for building microservices
    - Metrics
    - Circuit breaker
    - Distributed call tracing via Zipkin
    - Completely asynchronous and reactive
    - Even higher performance on Linux

    View Slide

  13. Ways to quickly build using Armeria
    Armeria with productive combination
    Kotlin + Coroutine Spring DI
    gRPC

    View Slide

  14. Ways to quickly build using Armeria
    gRPC weakness
    - Limited browser support
    - Not human readable

    View Slide

  15. Ways to quickly build using Armeria
    Armeria with gRPC strength
    Enables automatic documentation
    - Can be called directly from the web without using a separate gRPC testing tool (e.g. bloomRPC)
    - Most frequently used features !
    Unlike the native gRPC server, it supports various mime-types with a single port.
    - application/grpc+proto
    - application/grpc-web+json
    - application/grpc-web+proto
    - application/grpc-web-text+proto
    - application/json; charset=utf-8; protocol=gRPC
    - application/protobuf; protocol=gRPC

    View Slide

  16. Ways to quickly build using Armeria
    Armeria with gRPC strength – Auto documentation
    Example protobuf
    e.g. LibraryService
    Auto documentation
    Automatic protobuf-based documentation and testing like
    Swaggers. Documenting time is greatly reduced

    View Slide

  17. Ways to quickly build using Armeria
    Armeria with gRPC strength – gRPC API Testing
    Human readable testing
    Enable to test gRPC using json body.

    View Slide

  18. Ways to quickly build using Armeria
    Apply boilerplate within the team
    Add Title 40pt
    - Add your Text here / Arial, normal, 35pt
    - Add your Text here / Arial, normal, 35pt
    Add Title 40pt
    Add Title 40pt
    - Set of common frameworks and library
    dependencies.
    - Initialize project using a single-line command
    - Helm charts for Kubernetes
    - Gradle based project
    A set of common rules within the team
    auth-service
    payment-service
    meta-service

    View Slide

  19. Ways to quickly build using Armeria
    Apply boilerplate within the team
    Helm chart structure
    Gradle6 based project structure
    Logstash
    App Filebeat
    Zipkin Brave
    SpringBoot2
    gRPC + Protobuf
    Nelo2
    Helm chart + Ingress
    Aremria

    View Slide

  20. Ways to quickly build using Armeria
    Summary
    - Templates of component specifications within the team
    - No more confusion on project settings
    - Building up knowledge on Boilerplate can reduce related errors later on.
    Applying boilerplate within the team
    Applying Armeria with gRPC
    - Most of the MSA’s concerns are included, so it can be developed quickly
    - Possible to focus on business logics
    - Can develop REST API as well as gRPC
    - [email protected] : Useful DocService function

    View Slide

  21. Why is it better?
    How to solve aggregating microservices using GraphQL

    View Slide

  22. Why is it better?
    Backend service aggregation - motivation
    - E.g. Team A (APP) : “We need meta information in API A”
    - E.g. Team B (TV) : “Please include coupon information in API B”
    - E.g. Team C (Player) : “In the C API … .. lol”
    GraphQL is the best consideration for clients (APP, PC, MOBILE, and TV)
    Apply GraphQL for requirement implementation faster
    - It is always a controversial part of service development.
    Considered the ways to make the API faster, and easier to use
    - REST API + HATEOAS vs GraphQL

    View Slide

  23. Why is it better?
    Backend service aggregation – generic GraphQL services
    - Each client can call the required schema using
    GraphQL query
    Strength
    Weakness
    - Hard to track and debug requests from clients
    APP
    WEB
    TV
    GQL query A
    GQL query B
    GQL query C
    GraphQL

    View Slide

  24. Why is it better?
    Backend service aggregation – Apply the front API service layer
    Manage the GraphQL queries
    and support the authentication.
    APP
    WEB
    TV
    EXTERNAL
    APP SERVICE
    WEB SERVICE
    TV SERVICE
    EXTERNAL
    SERVICE
    GraphQL
    META
    AUTH
    PAYMENT
    ETC
    ETC
    ETC
    Uses GraphQL as a
    microservices aggregator
    GQL query

    View Slide

  25. Why is it better?
    Backend service aggregation – Apply the front API service layer
    E.g. API-Request of the purchased list on TV
    TV TV SERVICE
    GraphQL
    META
    AUTH
    PAYMENT
    ETC
    ETC
    ETC
    /v1/libraries GQL query Meta
    Library, Auth
    libraryGroups {

    rightContext {
    deviceUseContext {

    }
    },
    product {
    title
    }
    }

    View Slide

  26. Why is it better?
    Backend service aggregation – Apply the front API service layer
    E.g. API-Request of the purchased list on TV

    View Slide

  27. Why is it better?
    Backend service aggregation – Summary
    - Possible for versioning GraphQL query and history management for each client
    - Both of the strengths of GraphQL and the Rest API can be utilized (hybrid).
    Apply to the front API service layer
    Use GraphQL as a microservices aggregator
    - Get closer to the client team (?)
    - Elegantly solve N+1 problems using the graphql batch dataLoader
    - The more dataLoader for the model, the faster speed in development
    - Since GraphQL is flexible, it is necessary to design the initial schema well

    View Slide

  28. How to monitor?
    Monitoring tips on the microservice using Zipkin and Elasticsearch.

    View Slide

  29. How to monitor?
    motivation
    - ELK (Elasticsearch, Logstash, Kibana) based logging on Kubernetes
    Components access logs
    Distributed tracing & monitoring
    - Zipkin with ELK (Elasticsearch, Logstash, Kibana)
    Exception tracing & alarm
    - Nelo2

    View Slide

  30. How to monitor?
    Microservices monitoring - gRPC access logs
    When pods are deployed on Kubernetes, that bundle app container with
    Filebeat and Logstash
    Ingress Armeria APP Filebeat Logstash Elasticsearch

    View Slide

  31. How to monitor?
    Microservices monitoring - gRPC access logs

    View Slide

  32. How to monitor?
    Microservices monitoring - using Zipkin and Elasticsearch
    - Provides Zipkin Tracing Integration from Armeria
    - Easily connects to existing legacy Springboot
    components (using Sleuth, Brave)
    - Support storages : Cassandra, MySQL,
    Elasticsearch
    - Can be easily setup using zipkin-server, zipkin-ui
    and zipkin-dependency
    - Combination of Zipkin and Elasticsearch is
    considered the most flexible
    Zipkin (https://zipkin.io)

    View Slide

  33. How to monitor?
    Microservices monitoring - using Zipkin and Elasticsearch
    Filter by requested service, spanName, and tagQuery

    View Slide

  34. How to monitor?
    Microservices monitoring - using Zipkin and Elasticsearch
    Trace which GraphQL query is called from which services

    View Slide

  35. How to monitor?
    Microservices monitoring - using Zipkin and Elasticsearch
    Both Kibana dashboard setup and alert are possible based on data stored in Elasticsearch

    View Slide

  36. How to monitor?
    Microservices monitoring - Distributed tracing on asynchronous components
    - Request from the same thread are not guaranteed.
    - (Important) Should try not to lose the TraceContext in the same request.
    In an asynchronous environment (Reactive, Coroutine)

    View Slide

  37. How to monitor?
    Microservices monitoring - Distributed tracing on asynchronous components
    E.g. Case in which TraceContext was delivered normally
    TV SERVICE
    GraphQL
    META
    AUTH
    CONFIG
    (Thread-1) Parent spanA + spanB
    (Thread-2) Parent spanA + spanC
    (Thread-3) Parent spanA + spanD
    /v1/libraries - spanA
    spanA + spanB
    spanA + spanC
    spanA + spanD
    Traceable
    /v1/libraries spanA

    View Slide

  38. How to monitor?
    Microservices monitoring - Distributed tracing on asynchronous components
    E.g. Case in which TraceContext was delivered abnormally (losing TraceContext)
    TV SERVICE
    GraphQL
    META
    AUTH
    CONFIG
    (Thread-1) spanB (losing spanA)
    /v1/libraries spanA
    (Thread-2) spanC (losing spanA)
    (Thread-3) spanD (losing spanA)
    /v1/libraries - spanA
    spanB
    spanC
    spanC
    Untraceable – Each request is recognized as one request

    View Slide

  39. How to monitor?
    Microservices monitoring - Distributed tracing on asynchronous components
    - When converting to Mono or Flux, need to pass TraceContext if running in different
    ThreadPool
    - Or pre-specify with subscribeOn so that it can be executed in one Thread
    In reactive

    View Slide

  40. How to monitor?
    Microservices monitoring - Distributed tracing on asynchronous components
    - Like reactive, this can be solved by injecting a CoroutineContext
    - Armeria will support coroutine context injection in version 1.12.0
    In coroutine

    View Slide

  41. Summary
    final microservices architecture
    APP SERVICE
    TV SERVICE
    PC SERVICE
    Zipkin API
    Elasticsearch Logstash
    GraphQL
    GraphQL query
    Zipkin SPAN LOG
    API GATEWAY
    Kibana
    DASHBOARD VISUALIZATION
    Filebeat
    gRPC/HTTP
    Zipkin
    DEPENDENCY
    NELO2
    ERROR LOG
    FRONT API LAYER AGG LAYER BACKEND LAYER
    GRPC ACCESS LOG

    View Slide

  42. Faster
    project settings
    &
    development
    Better enhanced
    gRPC usability
    Summary
    with Armeria, GraphQL, gRPC and Zipkin
    More
    flexible
    aggregation
    Stronger support
    distributed tracing

    View Slide

  43. Thank you

    View Slide

  44. Reference
    gRPC weaknesses
    - https://docs.microsoft.com/en-us/aspnet/core/grpc/comparison?view=aspnetcore-5.0
    Armeria architecture
    - https://armeria.dev
    - https://engineering.linecorp.com/ko/blog/reactive-streams-with-armeria-2/
    - https://deview.kr/2019/schedule/283

    View Slide
