  1. Chanintorn Asavavichairoj


    Lead Tech Specialist


    SCB TechX
    BREAKTHROUGH

    EVENT-DRIVEN ARCHITECTURE

    FOR CHATBOTS

    View full-size slide

  2. © 2021 SCB Tech X Co., Ltd.
    Jo, Tech Specialist at SCB TechX

    View full-size slide

  3. © 2021 SCB Tech X Co., Ltd.
    Agenda
    Breakthrough Event-Driven Architecture for Chatbot
    What is Event- Driven Architecture?
    01
    Loosely Coupled with LINE Webhook Event
    02
    Enabling Event-Driven by Kafka Family
    03
    Usecase : Message Sentiment Monitoring
    04

    View full-size slide

  4. © 2021 SCB Tech X Co., Ltd.
    Chain Reaction
    Event
    Software Design Pattern
    Rube Goldberg Machine (https://www. concordia.qld.edu.au/rube-goldberg-machine)

    View full-size slide

  5. © 2021 SCB Tech X Co., Ltd.
    What is Event-Driven Architecture (EDA)?
    Software Design Pattern
    Decision

    (OLAP)
    Events
    Events
    Events
    👨💼
    Customer Events
    Wired Context
    New / Existed

    Data
    Business
    Outcome



    Customer
    Experiences
    😋
    System Events
    👩💼

    Others Events
    📟
    🕹

    View full-size slide

  6. © 2021 SCB Tech X Co., Ltd.
    Transaction and Analytic Data Processing
    Event-Driven Architecture
    Business Processes
    Business

    Data Warehouse
    OLTP
    OLAP
    Business Decision
    Operation Data
    Bigdata
    Deep Learning
    Machine Learning
    Great Chatbot

    View full-size slide

  7. © 2021 SCB Tech X Co., Ltd.
    Monolith vs Microservices
    Software Design Pattern
    Local transactions within
    the same codebase
    Distributed transactions
    across services
    Monolith Microservices

    View full-size slide

  8. © 2021 SCB Tech X Co., Ltd.
    HTTP Response Message Response
    Feedback N/A
    Communication and Collaboration between Microservices
    Software Design Pattern
    Synchronous Asynchronous
    Communication
    Blocking Non-Blocking
    I/O
    REST Message Queue Event Source
    Pattern
    Command Driven Event Driven
    Collaboration
    N/A

    View full-size slide

  9. © 2021 SCB Tech X Co., Ltd.
    Request/Response vs Event Source
    Software Design Pattern
    > Request
    Response
    Produce
    Consume
    Consume
    ☎ ☎
    Request/Response
    Broker




    Topic
    >
    Event Source
    Topic
    Topic



    View full-size slide

  10. © 2021 SCB Tech X Co., Ltd.
    LINE Webhook Event
    LINE Messaging API
    NLU PROCESSING
    CHAT LOGS
    ACCOUNT LINK
    USER PROFILE
    BEACON MICRO LOCATION
    Follow / Unfollow
    Message
    Join / Leave Group
    Beacons
    Postback
    Account Link
    Device Link / Unlink
    ANALYTIC METRICS
    Webhook

    View full-size slide

  11. © 2021 SCB Tech X Co., Ltd.
    LINE Webhook Event
    LINE Messaging API
    NLU PROCESSING
    CHAT LOGS
    ACCOUNT LINK
    USER PROFILE
    BEACON MICRO LOCATION
    Follow / Unfollow
    Message
    Join / Leave Group
    Beacons
    Postback
    Account Link
    Device Link / Unlink
    ANALYTIC METRICS
    Webhook
    http://user-pro

    Coupling

    View full-size slide

  12. © 2021 SCB Tech X Co., Ltd.
    LINE Webhook Event
    LINE Messaging API
    NLU PROCESSING
    CHAT LOGS
    ACCOUNT LINK
    USER PROFILE
    BEACON MICRO LOCATION
    Follow / Unfollow
    Message
    Join / Leave Group
    Beacons
    Postback
    Account Link
    Device Link / Unlink
    ANALYTIC METRICS
    Event Broker
    Webhook

    View full-size slide

  13. © 2021 SCB Tech X Co., Ltd.
    LINE Webhook Event
    LINE Messaging API
    NLU PROCESSING
    CHAT LOGS
    ACCOUNT LINK
    USER PROFILE
    BEACON MICRO LOCATION
    Follow / Unfollow
    Message
    Join / Leave Group
    Beacons
    Postback
    Account Link
    Device Link / Unlink
    ANALYTIC METRICS
    Message,

    View full-size slide

  14. © 2021 SCB Tech X Co., Ltd.
    Introduce Kafka Family
    Event Source Middleware
    Connector / Connect
    Stream Processing
    Support
    Management
    Client / Schema /
    Development
    Connector / Connect
    KAFKA
    KAFKA
    PRODUCER
    Source
    KAFKA
    KAFKA
    CONSUMER
    Sink

    View full-size slide

  15. © 2021 SCB Tech X Co., Ltd.
    Stream Processing
    Realtime Processing with KSQL
    Coding Sophistication
    Dev in Java / Scala
    Dev in others languages
    Data Engineer, DevOps
    BI Analyst
    No Need for Technical Skill
    streams

    View full-size slide

  16. © 2021 SCB Tech X Co., Ltd.
    KSQL Concept : Message Filtering
    Realtime Processing with KSQL
    CREATE STREAM line-message AS

    SELECT *

    FROM line-webhook

    WHERE type=‘message';
    {

    type: ‘message’,

    text: ‘this is text’

    }
    {

    type: ‘message’,

    text: ‘this is text’

    }
    {

    type: ‘postback’,

    data: ‘this is data’

    }
    {

    type: ‘message’,

    text: ‘hello’

    }
    {

    type: ‘message’,

    text: ‘hello’

    }
    {

    type: ‘sticker’,

    stickerid: 123

    }

    View full-size slide

  17. © 2021 SCB Tech X Co., Ltd.
    KSQL Concept : Data Transformation
    Realtime Processing with KSQL
    CREATE STREAM line-message AS

    SELECT text

    FROM line-webhook

    WHERE type=‘message';
    {

    type: ‘message’,

    text: ‘this is text’

    }
    {

    text: ‘this is text’

    }
    {

    type: ‘postback’,

    data: ‘this is data’

    }
    {

    type: ‘message’,

    text: ‘hello’

    }
    {

    text: ‘hello’

    }
    {

    type: ‘sticker’,

    stickerid: 123

    }

    View full-size slide

  18. © 2021 SCB Tech X Co., Ltd.
    KSQL Concept : Data Aggregation
    Realtime Processing with KSQL
    CREATE STREAM line-message AS

    SELECT COUNT(*) AS count

    FROM line-webhook WINDOW TUMBLING (SIZE 1 HOUR)

    GROUP BY type;
    {

    type: ‘message’,

    text: ‘this is text’

    }
    {

    type: ‘postback’,

    data: ‘this is data’

    }
    {

    type: ‘message’,

    text: ‘hello’

    }
    {

    type: ‘sticker’,

    stickerid: 123

    }
    {

    type: ‘message’,

    count: 2

    }
    {

    type: ‘postback’,

    count: 1

    }
    {

    type: ‘sticker’,

    count: 1

    }

    View full-size slide

  19. © 2021 SCB Tech X Co., Ltd.
    Realtime LINE Events Processing with KSQL
    Sample Use Case




    NLU PROCESSING
    Webhook
    Messaging API
    1 2
    3
    4
    5
    6
    7
    8

    View full-size slide

  20. © 2021 SCB Tech X Co., Ltd.
    Pain Point from Chatbot False Positive
    Sample Use Case
    False Positive
    Missed Classi
    fi
    cation
    0% 100%
    X %
    Ambiguous Con
    fi
    dent Level
    Fallback
    Y %
    🤥
    🥺 🤥 🤥
    🥺
    🥺 😇
    Sorry, I don’t know
    🤖
    #@%&{]!~]){>=+*?

    View full-size slide

  21. © 2021 SCB Tech X Co., Ltd.
    Enriching chatbot journey


    with live chat experiences
    Related Sessions ..

    LINE THAILAND DEVELOPER CONFERENCE 2020
    LINE Developer Thailand
    Pain Point from Chatbot False Positive
    Sample Use Case
    Manual Labeling
    Satisfaction Survey
    Tone and Sentiment
    Bot Training Effort

    View full-size slide

  22. © 2021 SCB Tech X Co., Ltd.
    Message Sentiment Monitoring
    Sample Use Case
    🤖
    Message

    Events
    SENTIMENT

    ANALYZER
    1

    2

    3

    4

    5

    6

    7

    8

    9

    10
    {

    2

    3

    4

    5

    6

    7

    8

    9

    10
    List of up to 15
    keywords describing
    the sticker
    {


    View full-size slide

  23. © 2021 SCB Tech X Co., Ltd.
    Message Sentiment Monitoring
    Sample Use Case


    NOTIFY SERVICE
    3
    4
    0



    SENTIMENT

    ANALYZER

    View full-size slide

  24. © 2021 SCB Tech X Co., Ltd.
    1

    2

    3

    4

    5

    6

    7

    8

    9

    10

    11

    12

    13

    14

    15

    16

    17

    18

    19

    20

    21

    22

    23

    24

    25

    26

    27
    consumer = KafkaConsumer(



    SENTIMENT

    ANALYZER
    🤖
    sentiment_analyzer.py (Sample Code)
    Kafka Consumer

    View full-size slide

  25. © 2021 SCB Tech X Co., Ltd.
    1

    2

    3

    4

    5

    6

    7

    8

    9

    10

    11

    12

    13

    14

    15

    16

    17

    18

    19

    20

    21

    22

    23

    24

    25

    26

    27
    const client = new kafka.KafkaClient({


    "kafkaHost": "localhost:9092"


    });


    const consumer = new kafka.Consumer(client,


    [ { topic: ‘SENTIMENT-ALERT’ } ],


    {


    autoCommit: true,


    groupId: 'line-notify-group'


    });


    consumer.on('message', function (message) {


    var sentiment_stats = JSON.parse(message.value);


    request({


    method: 'POST',


    uri: 'https://notify-api.line.me/api/notify',


    headers: {


    'Content-Type': 'application/x-www-form-urlencoded'


    },


    auth: {


    'bearer': token


    },


    form: {


    message: sentiment_stats.sentiment


    }


    }, (err, httpResponse, body) => {


    if (err) {



    Message Sentiment Monitoring
    Sample Use Case


    NOTIFY
    SERVICE
    line-notify.js (Sample Code)
    Send Notify to admin

    View full-size slide

  26. © 2021 SCB Tech X Co., Ltd.
    Let’s start short demo!

    View full-size slide

  27. © 2021 SCB Tech X Co., Ltd.
    Deal with Automated Test ?
    Event-Driven Challenge
    Integration test in

    event driven architecture
    Related Sessions ..

    LINE THAILAND DEVELOPER CONFERENCE 2021
    > Request
    Response
    HTTP(S) Server
    Request/Response
    >
    Produce
    📮
    Message Broker
    Response
    Event Source

    View full-size slide
