Custom Layouts

Presented at Droidcon London 2014

Transcript

1. CUSTOM
   LAYOUTS
   Droidcon UK, 2014


   View Slide

2. LUCAS ROCHA
   +LucasRocha | @lucasratmundo


   View Slide

3. View Slide

4. LAYOUT
   is at the heart of every UI toolkit.


   View Slide

5. SIZE + POSITION


   View Slide

6. MEASURE
   LAYOUT
   DRAW


   View Slide

7. THE TRAVERSAL


   View Slide

8. THE TRAVERSAL
   http://devfest.gdg-london.com


   View Slide

9. PERFORMANCE
   1. Number of views
   2. Computational cost


   View Slide

10. # OF VIEWS
    Compound drawables, spannables,
    drawables, etc.


    View Slide

11. LAYOUT COST
    Avoid multi-pass layout features.
    Depth matters.


    View Slide

12. PROBE IT!
    Intercept view methods. Dissect layout
    traversals.
    https://github.com/lucasr/probe


    View Slide

13. WHY CUSTOM?
    Simplify view hierarchy, performance,
    missing features.


    View Slide

14. MANY SHAPES
    Composite, custom, flat, async flat.
    https://lucasr.org/?p=3920


    View Slide

15. BUILDING BLOCKS
    Methods
    LayoutParams MeasureSpec
    MATCH_PARENT
    WRAP_CONTENT
    DIMENSION
    EXACTLY
    AT_MOST
    UNSPECIFIED
    onMeasure()
    onLayout()
    measureChild*()
    ...


    View Slide

16. MINDSET
    Cheat & simplify. You're not creating a
    general-purpose layout.


    View Slide

17. THE ULTIMATE
    GUIDE FOR
    CUSTOM
    LAYOUT
    DEVELOPMENT


    View Slide

18. LET'S DO THIS
    https://github.com/lucasr/android-layout-samples


    View Slide

19. STRUCTURE
    public class TweetLayout extends ViewGroup {
    public TweetLayoutView(Context context, AttributeSet attrs) {
    super(context, attrs, defStyleAttr);
    LayoutInflater.from(context)
    .inflate(R.layout.tweet_layout, this, true);
    mProfileImage = (ImageView) findViewById(R.id.profile_image);
    ...
    }
    @Override
    protected void onMeasure(int widthMeasureSpec,
    int heightMeasureSpec) {
    ...
    }
    @Override
    protected void onLayout(boolean changed, int l, int t,
    int r, int b) {
    ...
    }
    }


    View Slide

20. LAYOUT FILE
    android:layout_width="match_parent"
    android:layout_height="match_parent">
    android:id="@+id/profile_image"
    android:layout_width="@dimen/tweet_profile_image_size"
    android:layout_height="@dimen/tweet_profile_image_size"
    android:scaleType="centerCrop"/>
    android:id="@+id/author_text"
    android:layout_width="fill_parent"
    android:layout_height="wrap_content"
    android:textSize="@dimen/tweet_author_text_size"
    android:singleLine="true"/>
    ...



    View Slide

21. onMeasure()
    1. Measure one child
    2. Update consumed width/height


    View Slide

22. MEASURE


    View Slide

23. MEASURE


    View Slide

24. MEASURE


    View Slide

25. MEASURE


    View Slide

26. MEASURE


    View Slide

27. MEASURE


    View Slide

28. MEASURE


    View Slide

29. MEASURE
    @Override
    protected void onMeasure(int widthMeasureSpec,
    int heightMeasureSpec) {
    ...
    int widthUsed = 0;
    int heightUsed = 0;
    measureChildWithMargins(mProfileImage, widthMeasureSpec,
    widthUsed, heightMeasureSpec, heightUsed);
    widthUsed += getMeasuredWidthWithMargins(mProfileImage);
    measureChildWithMargins(mAuthorText, widthMeasureSpec,
    WidthUsed, heightMeasureSpec, heightUsed);
    heightUsed += getMeasuredHeightWithMargins(mAuthorText);
    measureChildWithMargins(mMessageText, widthMeasureSpec,
    WidthUsed, heightMeasureSpec, heightUsed);
    heightUsed += getMeasuredHeightWithMargins(mMessageText);
    ...
    setMeasuredDimension(widthSize, heightSize);
    }


    View Slide

30. onLayout()
    1. Layout one child
    2. Update current vert/hor offset


    View Slide

31. LAYOUT
    @Override
    protected void onLayout(boolean changed, int l, int t, int r, int b)
    {
    int currentTop = paddingTop;
    layoutView(mProfileImage, paddingLeft, currentTop,
    mProfileImage.getMeasuredWidth(),
    mProfileImage.getMeasuredHeight());
    final int contentLeft =
    getWidthWithMargins(mProfileImage) + paddingLeft;
    final int contentWidth = r - l - contentLeft - getPaddingRight();
    layoutView(mAuthorText, contentLeft, currentTop, contentWidth,
    mAuthorText.getMeasuredHeight());
    currentTop += getHeightWithMargins(mAuthorText);
    layoutView(mMessageText, contentLeft, currentTop,
    contentWidth, mMessageText.getMeasuredHeight());
    currentTop += getHeightWithMargins(mMessageText);
    ...
    }


    View Slide

32. PROFIT.
    Before
    After


    View Slide

33. RECYCLING
    Hard to implement. No extensible
    layout API—until recently.


    View Slide

34. RECYCLER VIEW
    Framework for view recycling layouts.


    View Slide

35. LOW-LEVEL
    1. Track visible viewport
    2. Recycle views out of bounds
    3. Appearing/disappearing views
    4. Scroll to position
    5. State restoration
    ...


    View Slide

36. TWOWAY VIEW
    RecyclerView made simple.
    https://github.com/lucasr/twoway-view


    View Slide

37. SIMPLE BASE
    TwoWayLayoutManager to the rescue!


    View Slide

38. HOW IT WORKS
    measureChild()
    START
    END
    layoutChild()
    canAddMoreViews()
    Direction


    View Slide

39. LET'S DO THIS
    http://bit.ly/twowayview-simplelistlayout


    View Slide

40. STRUCTURE
    public class SimpleListLayout extends TwoWayLayoutManager {
    public SimpleListLayout(Context context,
    Orientation orientation) {
    super(context, orientation);
    }
    @Override
    protected void measureChild(View child, Direction direction) {
    ...
    }
    @Override
    protected void layoutChild(View child, Direction direction) {
    ...
    }
    @Override
    protected boolean canAddMoreViews(Direction direction,
    int limit) {
    ...
    }
    }


    View Slide

41. MEASURE
    @Override
    protected void measureChild(View child, Direction direction) {
    measureChildWithMargins(child, 0, 0);
    }


    View Slide

42. LAYOUT
    @Override
    protected void layoutChild(View child, Direction direction) {
    final int width = getDecoratedMeasuredWidth(child);
    final int height = getDecoratedMeasuredHeight(child);
    final int l, t, r, b;
    if (getOrientation() == Orientation.VERTICAL) {
    l = getPaddingLeft();
    t = direction == Direction.END ?
    getLayoutEnd() : getLayoutStart() - height;
    } else {
    l = direction == Direction.END ?
    getLayoutEnd() : getLayoutStart() - width;
    t = getPaddingTop();
    }
    r = l + width;
    b = t + height;
    layoutDecorated(child, l, t, r, b);
    }


    View Slide

43. VIEWPORT CONTROL
    @Override
    protected boolean canAddMoreViews(Direction direction, int limit) {
    if (direction == Direction.END) {
    return getLayoutEnd() < getEndWithPadding();
    } else {
    return getLayoutStart() > getStartWithPadding();
    }
    }


    View Slide

44. NOT JUST THAT
    Scroll to position, state restoration,
    accessibility, keyboard nav, etc.


    View Slide

45. QUESTIONS?
    +LucasRocha | @lucasratmundo
