Enterprise Kubernetes: Openshift Container Platform

Enterprise Kubernetes:
Openshift Container Platform
M. Aykut Bulgu
Technology Consultant, Software Architect
@systemcraftsman

View Slide

@systemcraftsman
Who am I ?
Was a child in the end of 80’s and beginning of 90’s
Married, has a daugther
Tech lover
Has been working for about 12 years in software/tech industry
Fond of Software Craftsmanship
Co-organiser of ScTurkey Community
Works as a Red Hatter; a Middleware Consultant

View Slide

An Overall History &
Why Openshift

View Slide

@systemcraftsman
https://www.slideshare.net/egg9/kubernetes-introduction
A Brief Kubernetes History

View Slide

@systemcraftsman
Jul 2014
Red Hat contributions start
https://www.slideshare.net/egg9/kubernetes-introduction
A Brief Kubernetes History

View Slide

@systemcraftsman
#1 - Google - 41,649
#2 - Red Hat - 14,410
#6 - IBM - 1230
#9 - CoreOS - 964*
#10 - Microsoft - 728
#13 - VMware - 433
#15 - Intel - 400
#23 - Cisco - 192
#26 - Pivotal - 141
#41 - Oracle - 36
#56 - Docker - 14
Amazon/AWS - ?
* Most CoreOS commits were done using personal email
addresses (Independent)
http://stackalytics.com/?metric=commits&project_type=kubernetes-group&release=all
Kubernetes Project Contributions

View Slide

@systemcraftsman
A Brief History of Openshift
Openshift v2 - Announced in 2013
Red Hat Contribution to K8s started in 2014
Openshift v3 dev. Preview is announced in 2016
Openshift v3.0 is announced in 2017 (end of v2)

View Slide

9
How Do We Deliver OpenShift?
CONTAINER PLATFORM
DEDICATED
ONLINE
Integrate OSS projects
Partner integration platform
No-cost validations for innovation
Community Distribution of Kubernetes
100+ Integrations
Align time with OSS trunk

View Slide

@systemcraftsman
Security fixes
100s of defect and performance fixes
200+ validated integrations
Middleware integrations
(container images, storage, networking, cloud services, etc)
9 year enterprise lifecycle management
Certified Kubernetes
Kubernetes
Release
OpenShift
Release
1-3 months
hardening
Openshift Is Kubernetes For The Enterprise

View Slide

@systemcraftsman
~250
Bugs Fixed
~190
Bugs Fixed
~30
Bugs Fixed
Between
K8s 1.* and
Openshift 3.*
Between
Openshift 3.* and
3.*.33
Since
3.*.33
Openshift Is Kubernetes For The Enterprise

View Slide

@systemcraftsman
Requires a Linux operating system
Requires a Container Runtime (CRI-O, Containerd, Docker, etc)
Requires image registry
Requires software deﬁned networking
Requires load‐balancer and routing
Requires log management
Requires container metrics and monitoring
OpenShift includes all these components fully integrated and fully tested as part of the platform.
Why Kubernetes Is Not Enough
For The Enterprise

View Slide

@systemcraftsman
Container Infrastructure and Management
Kubernetes OKD* OpenShift
Multi-host container scheduling ✔ ✔ ✔
Self-service provisioning ✔ ✔ ✔
Service discovery ✔ ✔ ✔
Enterprise Linux operating system ✔
Image registry ✔ ✔
Validated storage plugins ✔ ✔
Networking and validated networking plugins ✔ ✔
Log aggregation and monitoring ✔ ✔
Multi-tenancy ✔ ✔
Metering and chargeback ✔
* OKD is the open source project formerly known as OpenShift Origin

View Slide

@systemcraftsman
Developer Experience
Kubernetes OKD* OpenShift
Automated image builds
No developer or
application services
✔ ✔
CI/CD workflows and pipelines ✔ ✔
Certified application services ✔
Certified middleware ✔
Certified databases ✔
200+ certified ISV solutions ✔
* OKD is the open source project formerly known as OpenShift Origin

View Slide

@systemcraftsman
Enterprise Support and Community
Kubernetes OKD OpenShift
Community forums and resources ✔ ✔ ✔
Zero downtime patching and upgrades ✔
Enterprise 24/7 support ✔
9 year support lifecycle ✔
Security response team ✔
External review: 10 most important differences between OpenShift and Kubernetes

View Slide

@systemcraftsman
That’s Why:

View Slide

@systemcraftsman
Kubernetes is a project, Openshift is a product
That’s Why:

View Slide

Myths

View Slide

@systemcraftsman
Myth: Openshift Is Too Far Behind K8s OSS

View Slide

@systemcraftsman
Myth: Openshift Is Too Heavy | It’s a PaaS
KUBERNETES
RED HAT ENTERPRISE LINUX | RED HAT COREOS
SDN NETWORKING STORAGE LOGGING MONITORING
CI/CD PIPELINES SERVICE CATALOG
CONTAINER REGISTRY SECURITY | AUTH OPS CONSOLE
BARE METAL VIRTUAL PRIVATE PUBLIC
SERVICE BROKERS | ANSIBLE | AWS | AZURE | GCP
CLOUD-NATIVE
AI / ML
BIG DATA
IOT SERVERLESS
OPERATOR LIFECYCLE MANAGER | PLATFORM | APPLICATIONS
RED HAT MIDDLEWARE SERVICES
TRADITIONAL WINDOWS
ISTIO - SERVICE MESH
CONTAINERS
AS A SERVICE
(CaaS)
PLATFORM
AS A SERVICE
(PaaS)
[OPTIONAL TO USE]

View Slide

Openshift Architecture

View Slide

@systemcraftsman
Automated Operations
Kubernetes
Red Hat Enterprise Linux or Red Hat CoreOS
Application
Services
CaaS PaaS
Best IT Ops Experience Best Developer Experience
Cluster
Services
Developer
Services
Middleware, Service Mesh, Functions, ISV Metrics, Chargeback, Registry, Logging Dev Tools, Automated Builds, CI/CD, IDE
Openshift Container Platform

View Slide

@systemcraftsman
EXISTING
AUTOMATION
TOOLSETS
SCM
(GIT)
CI/CD
SERVICE LAYER
ROUTING LAYER
PERSISTENT
STORAGE
REGISTRY
RHEL
NODE
c
RHEL
NODE
RHEL
NODE
RHEL
NODE
RHEL
NODE
RHEL
NODE
C
C
C C
C
C
C C
C C
RED HAT
ENTERPRISE LINUX
MASTER
API/AUTHENTICATION
DATA STORE
SCHEDULER
HEALTH/SCALING
PHYSICAL VIRTUAL PRIVATE PUBLIC HYBRID

View Slide

@systemcraftsman
https://medium.com/levvel-consulting/the-differences-between-kubernetes-and-openshift-ae778059a90e

View Slide

Openshift Installation Architectures

View Slide

@systemcraftsman
Proof-of-Concept Architecture
Application
Trafﬁc
Dev and Ops
User
INFRA
MASTER
NODE NODE
An infrastructure node is a node that is dedicated to infrastructure
pods such as router, image registry, metrics, and logs

View Slide

@systemcraftsman
App High-Availability Architecture
ENTERPRISE
LOAD-BALANCER
Application
Trafﬁc
Dev and Ops
User
INFRA
MASTER INFRA
NODE NODE NODE NODE

View Slide

@systemcraftsman
Full High-Availability Architecture
ENTERPRISE LOAD-BALANCER
Application
Trafﬁc
Dev and Ops
User
NODE
MASTER MASTER INFRA
MASTER INFRA
NODE NODE NODE NODE
NODE
INFRA
NODE

View Slide

Technical Deep Dive

View Slide

Application Health

View Slide

@systemcraftsman
Auto-Healing Failed Pods
RHEL
NODE
RHEL
NODE
c
RHEL
NODE
RHEL
NODE
c
RHEL
NODE
C
C
RHEL
NODE
C
C
RED HAT
ENTERPRISE LINUX
MASTER
API/AUTHENTICATION
DATA STORE
SCHEDULER
HEALTH/SCALING
C

View Slide

@systemcraftsman
RHEL
NODE
RHEL
NODE
c
RHEL
NODE
RHEL
NODE
c
RHEL
NODE
C
C
RHEL
NODE
C
C
RED HAT
ENTERPRISE LINUX
MASTER
API/AUTHENTICATION
DATA STORE
SCHEDULER
HEALTH/SCALING
C
Auto-Healing Failed Pods

View Slide

@systemcraftsman
RHEL
NODE
RHEL
NODE
c
RHEL
NODE
RHEL
NODE
c
RHEL
NODE
C
C
RHEL
NODE
C
C
RED HAT
ENTERPRISE LINUX
MASTER
API/AUTHENTICATION
DATA STORE
SCHEDULER
HEALTH/SCALING
C
Auto-Healing Failed Containers

View Slide

@systemcraftsman
RHEL
NODE
RHEL
NODE
RHEL
NODE
RHEL
NODE
C
C
RHEL
NODE
C
C
c
RED HAT
ENTERPRISE LINUX
MASTER
API/AUTHENTICATION
DATA STORE
SCHEDULER
HEALTH/SCALING
C
c
Auto-Healing Failed Containers

View Slide

Routing

View Slide

@systemcraftsman
Built-in Service Discovery
Internal Load-Balancing
SERVICE
app=payroll role=frontend
POD
app=payroll
role=frontend
POD
app=payroll
role=frontend
Name: payroll-frontend
IP: 172.10.1.23
Port: 8080
POD
app=payroll
role=backend
version=1.0 version=1.0

View Slide

@systemcraftsman
SERVICE
app=payroll role=frontend
POD
app=payroll
role=frontend
POD
app=payroll
role=frontend
Name: payroll-frontend
IP: 172.10.1.23
Port: 8080
POD
app=payroll
role=backend
version=2.0 version=1.0
POD
app=payroll
role=frontend
version=1.0
Built-in Service Discovery
Internal Load-Balancing

View Slide

@systemcraftsman
SERVICE
POD POD
ROUTER
POD
EXTERNAL TRAFFIC
INTERNAL TRAFFIC
Route Exposes Services Externally

View Slide

@systemcraftsman
ROUTING AND EXTERNAL LOAD-BALANCING
Pluggable routing architecture
HAProxy Router
F5 Router
Multiple-routers with trafﬁc sharding
Router supported protocols
HTTP/HTTPS
WebSockets
TLS with SNI
Non-standard ports via cloud load-balancers, external IP, and NodePort

View Slide

@systemcraftsman
ROUTE SPLIT TRAFFIC
SERVICE A
App A App A
SERVICE B
App B App B
ROUTE
10% traffic
90% traffic
Split Traffic Between
Multiple Services For
A/B Testing,
Blue/Green and
Canary Deployments

View Slide

Logging & Metrics

View Slide

@systemcraftsman
Central Log Management with EFK
EFK stack to aggregate logs for hosts and applications
Elasticsearch:
a search and analytics engine to
store logs
Fluentd:
gathers logs and sends to
Elasticsearch.
Kibana:
A web UI for Elasticsearch.

View Slide

@systemcraftsman
APPLICATION LOGS
OPERATION LOGS
ELASTIC
ELASTIC
RHEL
NODE
POD POD
POD
POD
FLUENTD
RHEL
NODE
POD POD
POD
POD
FLUENTD
ELASTICSEARCH
RHEL
NODE
POD POD
POD
POD
FLUENTD
USER
ELASTIC
ELASTIC
KIBANA
ELASTIC
ELASTIC
ELASTICSEARCH
ELASTIC
ELASTIC
KIBANA
ADMIN
Central Log Management with EFK

View Slide

@systemcraftsman
CONTAINER METRICS
RHEL
NODE
POD POD
POD
POD
FLUENTD
Container Metrics
RHEL
NODE
POD POD
POD
POD
FLUENTD
HEAPSTER
RHEL
NODE
POD POD
POD
POD
CADVISOR
HAWKULAR
OPENSHIFT
WEB CONSOLE
ELASTIC
ELASTIC
CASSANDRA
RED HAT
CLOUDFORMS
CUSTOM
DASHBOARDS
API
USER

View Slide

@systemcraftsman
Container Metrics

View Slide

Security

View Slide

@systemcraftsman
NODE
MASTER
Secret Management
Container
Distributed Store
Container
Secure mechanism for holding sensitive data e.g.
Passwords and credentials
SSH Keys
Certiﬁcates
Secrets are made available as
Environment variables
Volume mounts
Interaction with external systems

View Slide

@systemcraftsman
Certificate Management
Check
Expiry
Redeploy
Certs
Certificates are used to provide secure connections
to
Master and nodes
Router and registry
Etcd
Ansible playbooks to automate redeployment
Redeploy all at once or specific components
Certificate expiry report generator
MASTER
NODES
ROUTER
REGISTRY
ETCD
✓
✓
✓
✓
✓
Ansible
Playbook

View Slide

Persistent Storage

View Slide

@systemcraftsman
Persistent Storage
NFS
GlusterFS
OpenStack Cinder
Ceph RBD
AWS EBS
GCE Persistent
Disk
iSCSI
Fiber Channel
Azure Disk
Azure File
FlexVolume
VMWare
vSphere VMDK
Container Storage
Interface (CSI)**
* Shipped and supported by NetApp via TSANet
** Tech Preview
NetApp Trident*
Persistent Volume (PV) is tied to a piece of network storage
Provisioned by an administrator (static or dynamically)
Allows admins to describe storage and users to request storage
Assigned to pods based on the requested size, access mode, labels and type

View Slide

@systemcraftsman
PROJECT
POOL OF PERSISTENT VOLUMES
Persistent Storage
NFSP
V
iSCSI
PV
NFSP
V
Admin
User
register PV
create claim
NFSP
V
GlusterFS
PV
Pod
claim
Pod
claim
Pod
claim
Ceph
RBD
PV

View Slide

@systemcraftsman
Dynamic Volume Provisioning
Admin
User
deﬁne StorageClass
create claim: Fastest
Slow
Azure-Disk
Fast
AWS-SSD
Fastest
NetApp-Flash
NetApp
Provisioner
AWS
Provisioner
Pod
claim
PV
OpenShift
PV Controller
provision
Azure
Provisioner
bound

View Slide

Service Brokers

View Slide

@systemcraftsman
What Is A Service Broker?
SERVICE
CONSUMER
SERVICE
PROVIDER
SERVICE
CATALOG
SERVICE
BROKER
Automated, Standard and Consistent

View Slide

@systemcraftsman
Why A Service Broker?
SERVICE
CONSUMER
SERVICE
PROVIDER
☑ Open ticket
☑ Wait for allocation
☑ Receive credentials
☑ Add to app
☑ Deploy app
Manual, Time-consuming and Inconsistent

View Slide

@systemcraftsman
A multi-vendor project to
standardize how services
are consumed on
cloud-native platforms
across service providers

View Slide

@systemcraftsman
Openshift Service Catalog
OPENSHIFT SERVICE CATALOG
OpenShift
Automation
Broker
OpenShift
Template
Broker
AWS
Service
Broker
Other
Service
Brokers
ANSIBLE
OPENSHIFT
AWS
OTHER COMPATIBLE SERVICES
Ansible
Playbook
Bundles
OpenShift
Templates
AWS
Services
Other
Services

View Slide

Operator Framework

View Slide

@systemcraftsman
Kubernetes Operator Framework
Operator Framework is an open source toolkit to manage application instances on
Kubernetes in an effective, automated and scalable way.
Installation Upgrade Backup
Failure
recovery
Metrics
& insights
Tuning
AUTOMATED LIFECYCLE MANAGEMENT

View Slide

@systemcraftsman
Operators codify operational
knowledge and workﬂows to
automate lifecycle management
of containerized applications
with Kubernetes
SDK LIFECYCLE
MANAGEMENT
METERING
Kubernetes Operator Framework

View Slide

@systemcraftsman
Why Operator Framework?
DEVELOPER
DEPLOY
STATEFUL APP
A WHILE
LATER
APP SERVICES
OPERATIONS
UPDATE
PATCH
BACKUP
REBALANCE
SCALE
DEPLOY
STATEFUL APP
UPDATE
PATCH
BACKUP
REBALANCE
SCALE
APP
OPERATOR
DEVELOPER

View Slide

@systemcraftsman
Operator Lifecycle Manager

View Slide

@systemcraftsman
Operator Metering
Based on Prometheus
Reports namespace, pods and
custom label query
Easy to process by accounting or
custom software

View Slide

Build and Deploy Container Images

View Slide

@systemcraftsman
DEPLOY YOUR
SOURCE CODE
DEPLOY YOUR
CONTAINER IMAGE
DEPLOY YOUR
APP BINARY
Build and Deploy Container Images

View Slide

@systemcraftsman
Deploy Source Code With Source-to-Image (S2I)
Git
Repository
BUILD APP
(OpenShift)
Developer
code
Source-to-Image
(S2I)
Builder
Registry
BUILD IMAGE
(OpenShift)
DEPLOY
(OpenShift)
deploy
Application
Container
OpenShift Does
User/Tool Does

View Slide

@systemcraftsman
Application
Binary
(e.g. WAR)
BUILD APP
(Build Infra) Existing Build
Process
build
Source-to-Image
(S2I)
Builder
Registry
BUILD IMAGE
(OpenShift)
DEPLOY
(OpenShift)
deploy
Application
Container
OpenShift Does
User/Tool Does
Deploy App Binary With Source-to-Image (S2I)

View Slide

@systemcraftsman
DEPLOY
(OpenShift)
Deploy Docker Image
build
Application
Container
deploy
Application
Registry
BUILD IMAGE
(Build Infra) Existing Image
Build Process
PUSH
(Build Infra)
OpenShift Does
User/Tool Does

View Slide

@systemcraftsman
BUILD STAGE 3
BUILD STAGE 2
BUILD STAGE 1
Build Images in Multiple Stages

View Slide

CI/CD

View Slide

@systemcraftsman
Continuous Delivery with Containers
source
repository
CI/CD
engine
dev container
physical
virtual
private cloud
public cloud

View Slide

@systemcraftsman
CI/CD with Builds and Deployments
BUILDS
Webhook triggers: build the app image whenever the code changes
Image trigger: build the app image whenever the base language or app
runtime changes
Build hooks: test the app image before pushing it to an image registry
DEPLOYMENTS

View Slide

@systemcraftsman
Openshift Loves CI/CD
JENKINS-AS-A SERVICE
ON OPENSHIFT
HYBRID JENKINS INFRA
WITH OPENSHIFT
EXISTING CI/CD
DEPLOY TO OPENSHIFT

View Slide

@systemcraftsman
JENKINS-AS-A-SERVICE ON OPENSHIFT
Plugins
Jobs
Configuration
Jenkins
(S2I)
Custom
Jenkins
Jenkins
Certified Jenkins images with pre-configured plugins
Provided out-of-the-box
Follows Jenkins 1.x and 2.x LTS versions
Jenkins S2I Builder for customizing the image
Install Plugins
Configure Jenkins
Configure Build Jobs
OpenShift plugins to integrate authentication with OpenShift and also
CI/CD pipelines
Dynamically deploys Jenkins slave containers

View Slide

@systemcraftsman
HYBRID JENKINS INFRA WITH OPENSHIFT
OPENSHIFT
APP APP
run job
JENKINS
SLAVE
Run Job
JENKINS
SLAVE
Run Job
build
JENKINS
MASTER
deploy
Scale existing Jenkins infrastructure by dynamically provisioning Jenkins slaves on
OpenShift
Use Kubernetes plug-in on existing Jenkin servers

View Slide

@systemcraftsman
EXISTING CI/CD DEPLOY TO OPENSHIFT
OPENSHIFT
APP
EXISTING
CI/CD INFRA
Jenkins, Bamboo,
TeamCity, etc
APP
build
deploy
S2I
Build
run job
Existing CI/CD infrastructure outside OpenShift performs operations against OpenShift
OpenShift Pipeline Jenkins Plugin for Jenkins
OpenShift CLI for integrating other CI Engines with OpenShift
Without disrupting existing processes, can be combined with previous alternative

View Slide

@systemcraftsman
OPENSHIFT PIPELINES
apiVersion: v1
kind: BuildConfig
metadata:
name: app-pipeline
spec:
strategy:
type: JenkinsPipeline
jenkinsPipelineStrategy:
jenkinsfile: |-
node('maven') {
stage('build app') {
git url: 'https://git/app.git'
sh "mvn package"
}
stage('build image') {
sh "oc start-build app --from-file=target/app.jar
}
stage('deploy') {
openshiftDeploy deploymentConfig: 'app'
}
}
Provision a
Jenkins slave for
running Maven
OpenShift Pipelines allow defining a CI/CD
workflow via a Jenkins pipeline which can be
started, monitored, and managed similar to other
builds
Dynamic provisioning of Jenkins slaves
Auto-provisioning of Jenkins server
OpenShift Pipeline strategies
Embedded Jenkinsfile
Jenkinsfile from a Git repository

View Slide

@systemcraftsman
OpenShift
Pipelines in
Web Console

View Slide

@systemcraftsman
Continuous Delivery Pipeline
OPENSHIFT
REGISTRY
OPENSHIFT
CLUSTER
DEVELOPER GIT SERVER ARTIFACT REPOSITORY
OPENSHIFT
CI/CD PIPELINE
(JENKINS)
IMAGE BUILD
& DEPLOY
OPENSHIFT
REGISTRY
OPENSHIFT
CLUSTER
NON-PROD PROD
DEV

View Slide

@systemcraftsman
OPENSHIFT
REGISTRY
OPENSHIFT
CLUSTER
OPENSHIFT
CI/CD PIPELINE
(JENKINS)
IMAGE BUILD
& DEPLOY
OPENSHIFT
REGISTRY
OPENSHIFT
CLUSTER
PROMOTE
TO TEST
NON-PROD PROD
DEV TEST

View Slide

@systemcraftsman
OPENSHIFT
REGISTRY
OPENSHIFT
CLUSTER
OPENSHIFT
CI/CD PIPELINE
(JENKINS)
IMAGE BUILD
& DEPLOY
OPENSHIFT
REGISTRY
OPENSHIFT
CLUSTER
PROMOTE
TO TEST
PROMOTE
TO UAT
NON-PROD PROD
DEV TEST UAT

View Slide

@systemcraftsman
ServiceNow
JIRA Service Desk
Zendeks
BMC Remedy
OPENSHIFT
REGISTRY
OPENSHIFT
CLUSTER
OPENSHIFT
CI/CD PIPELINE
(JENKINS)
IMAGE BUILD
& DEPLOY
OPENSHIFT
REGISTRY
OPENSHIFT
CLUSTER
GO
LIVE?
PROMOTE
TO TEST
PROMOTE
TO UAT
RELEASE MANAGER
NON-PROD PROD
☒
☑
DEV TEST UAT

View Slide

@systemcraftsman
OPENSHIFT
REGISTRY
OPENSHIFT
CLUSTER
GIT SERVER ARTIFACT REPOSITORY
OPENSHIFT
CI/CD PIPELINE
(JENKINS)
IMAGE BUILD
& DEPLOY
OPENSHIFT
REGISTRY
OPENSHIFT
CLUSTER
GO
LIVE?
PROMOTE
TO TEST
PROMOTE
TO UAT
PROMOTE
TO PROD
RELEASE MANAGER
NON-PROD PROD
DEV TEST UAT
☒
☑
DEVELOPER

View Slide

Application Services

View Slide

@systemcraftsman
CrunchyData
GitLab
Iron.io
Couchbase
Sonatype
EnterpriseDB
NuoDB
Fujitsu
and many more
...and virtually
any docker
out there!
True Polyglot Platform
PHP
Python
Java NodeJS Perl Ruby
.NET
Core
Apache
HTTP
Server
MySQL Redis
nginx Tomcat
Varnish
JBoss
EAP
JBoss
A-MQ
JBoss
Fuse
JBoss
BRMS
JBoss
BPMS
JBoss
Data Grid
JBoss
Data Virt
RH
Mobile
RH SSO
3SCALE
API mgmt
JBoss
Web
Server
Spring
Boot
Wildﬂy
Swarm
Vert.x
PostgreSQL MongoDB
Phusion
Passenger
Third-party
Language
Runtimes
Third-party
Databases
Third-party
App
Runtimes
Third-party
Middleware
Third-party
Middleware
LANGUAGES
DATABASES
WEB SERVERS
MIDDLEWARE

View Slide

OPENSHIFT TECHNICAL OVERVIEW
89
Modern, Cloud-Native Application Runtimes and
an Opinionated Developer Experience
OPENSHIFT
SUPPORTED RUNTIMES
Eclipse Vert.x WildFly Swarm Node.js
LAUNCH
Spring Boot JBoss EAP

View Slide

Openshift Service Mesh
Tech Preview available

View Slide

@systemcraftsman
The Need For a Service Mesh
SERVICE MESH SOLVES THE
CHALLENGES OF:
● Ensuring reliability
● Troubleshooting
● Performance
● Security
● Dynamic topology
USE CASE: Difficulty identifying root cause of
performance issues
DISTRIBUTED TRACING provides service
dependency analysis for different microservices and
tracking for requests traced through multiple
microservices. It also identiﬁes performance
bottlenecks and calls out particular requests,
identifying the cause to the latency of a request or
the service that created an error.

View Slide

@systemcraftsman
Microservices Without Istio
Container
JVM
service A
discovery
load-balancer
resiliency
metrics
tracing
app logic
JVM
service B
discovery
load-balancer
resiliency
metrics
tracing
app logic
Container
JVM
service C
discovery
load-balancer
resiliency
metrics
tracing
app logic

View Slide

@systemcraftsman
Microservices With Istio
Container
JVM
service C
app logic
Pod
Sidecar Container
Envoy
Container
JVM
service A
app logic
Pod
Sidecar Container
Envoy
Container
JVM
service B
app logic
Pod
Sidecar Container
Envoy

View Slide

@systemcraftsman
Istio - Jaeger
discovery resiliency metrics tracing
OpenShift
App Container
Pod
Sidecar Container
Envoy
Pod
Sidecar Container
Envoy
App Container
Sidecar Container
Envoy
App Container
load-balancer

View Slide

@systemcraftsman
Making service-to-service communication safe, performant, and reliable
OBSERVABILITY
POLICY ENFORCEMENT
SERVICE IDENTITY
& SECURITY
TRAFFIC MANAGEMENT
DIST. TRANSACTION
MONITORING
SERVICE DEPENDENCY
ANALYSIS
ROOT CAUSE ANALYSIS
DISTRIBUTED CONTEXT
PROPAGATION
PERFORMANCE /
LATENCY OPTIMIZATION
ISTIO JAEGER
DISTRIBUTED TRACING
CONFIGURATION
VALIDATION
METRICS COLLECTION
AND GRAPHS
SERVICE GRAPH
REPRESENTATION
SERVICE DISCOVERY &
HEALTH COMPUTATION
KIALI

View Slide

@systemcraftsman
Release Details
● Supported distribution of Istio, Jaeger, Kiali,
Prometheus, and Grafana
● Upstream project called Maistra
● Integrated with Red Hat OpenShift Application
Runtimes (RHOAR)
● OpenShift Service Mesh comes included with any
OCP subscription
September
• Istio and Jaeger
• Istio Operator for
install/uninstall
• Installation docs
TP 1
October
• Kiali added
TP 2
• Full support on OpenShift 4.0
• Istio Operator for updates
GA
Q1 CY19
TP releases every
few weeks
TP N
TP 4
TP 3
OPENSHIFT
SERVICE MESH

View Slide

Resources

View Slide

@systemcraftsman
learn.openshift.com
Interactive Learning Scenarios provide you with a pre-conﬁgured OpenShift instance,
accessible from your browser without any downloads or conﬁguration.

View Slide

@systemcraftsman
developers.redhat.com

View Slide

@systemcraftsman

View Slide

THANK YOU

View Slide

Enterprise Kubernetes: Openshift Container Platform

Enterprise Kubernetes: Openshift Container Platform

Aykut Bulgu

More Decks by Aykut Bulgu

Other Decks in Technology

Featured

Transcript
