Client VPNの使いどころ 2020/6/23 Tue Masaru Ogura
自己紹介 • 小倉 大 (マサル) Facebook : https://www.facebook.com/masaru.ogura.71 Twitter :
@MasaruOgura • 株式会社サーバーワークス – YouTubeで動画配信しています • ススキノが生んだエンジニア • 2020 APN ALL AWS Certifications Engineer
AWS Client VPN AWSリソースに安全にアク セスできるようにする、ク ライアントベースのマネー ジドVPNサービス
AWS(VPC)への接続 インターネット経由 専用線/VPN経由 AWS Cloud VPC Private subnet Public subnet
Corporate data center IGW VGW データセンターや オフィスなど 自宅など Internet
AWS Cloud VPC Private subnet Public subnet Corporate data center
IGW VGW Client VPN接続 データセンターや オフィスなど 自宅など Client VPN Endpoint Internet VPN経由 ENI
Client VPN(認証と認可) AWS Cloud VPC Private subnet Public subnet Corporate
data center IGW VGW データセンターや オフィスなど 自宅など Client VPN Endpoint Internet ENI 認証 ・Active Directory認証 ・相互認証 ・シングルサインオン 認可 ・セキュリティグループ ・承認ルール new
AWS Cloud VPC Private subnet Public subnet Corporate data center
IGW VGW Client VPN(通信経路) データセンターや オフィスなど 自宅など Client VPN Endpoint Internet ENI NATGW VPC Peering インターネット、オンプレミス、VPCピアリングにアクセス可能
AWS Cloud VPC Private subnet Public subnet Corporate data center
IGW Client VPN(インターネットアクセス) データセンターや オフィスなど 自宅など Client VPN Endpoint Internet ENI NATGW ネットワーク宛先 ネットマスク ゲートウェイ インターフェイス メトリック 0.0.0.0 0.0.0.0 192.168.86.1 192.168.86.22 40 0.0.0.0 128.0.0.0 10.200.0.129 10.200.0.130 25 128.0.0.0 128.0.0.0 10.200.0.129 10.200.0.130 25
Client VPN(スプリットトンネル)
AWS Cloud VPC Private subnet Public subnet Corporate data center
IGW Client VPN(スプリットトンネル) データセンターや オフィスなど 自宅など Client VPN Endpoint Internet ENI NATGW ネットワーク宛先 ネットマスク ゲートウェイ インターフェイス メトリック 0.0.0.0 0.0.0.0 192.168.86.1 192.168.86.22 40 172.31.0.0 255.255.0.0 10.200.0.129 10.200.0.130 25
AWS Cloud VPC Private subnet Public subnet IGW VGW Client
VPNの使いどころ① データセンターや オフィスなど 自宅など Client VPN Endpoint Internet ENI ①リモートワーク時の接続 プライベートサブネットの社内システムにアクセスできる Corporate data center
AWS Cloud VPC Private subnet Public subnet IGW VGW Client
VPNの使いどころ② データセンターや オフィスなど 自宅や 保守ベンダー拠点 など Client VPN Endpoint Internet ENI ②VPNサーバからのリプレイス リプレイスすることで運用負荷が軽減できる Corporate data center VPN サーバ
AWS Cloud VPC Private subnet Public subnet IGW VGW Client
VPNの使いどころ③ データセンターや オフィスなど 自宅など Client VPN Endpoint Internet ENI ③踏み台サーバからのリプレイス 踏み台サーバのセキュリティグループを広く開けなくてもよくなる Corporate data center Bastion
AWS Client VPN AWSリソースに安全にアク セスできるようにする、ク ライアントベースのマネー ジドVPNサービス
ご清聴ありがとうございました。
