Deno: an experimental approach on V8 interoperability

Transcript

1. Deno: an experimental
   approach on V8 interop
   Matías Insaurralde - @matias_baruch


   View Slide

2. Intro
   • 23 years old, living in Asunción, Paraguay !
   • Engineer at (we’re building an open
   source API gateway!).
   • I love FOSS and security topics.
   • Hobbies: meet random people, improvise
   music, eat pasta.


   View Slide

3. Agenda
   • Overview of NodeJS syscalls.
   • What’s deno?
   • Go versus Rust: interop constraints
   • My HTTP experiment
   • What’s next?


   View Slide

4. fs.ReadFileSync


   View Slide

5. fs.readFileSync(“file.txt”)
   fd = fs.openSync(“file.txt”, …)
   tryStatSync(fd)
   tryReadSync(fd)
   fs.closeSync(fd)
   fs.js


   View Slide

6. fs.readFileSync(“file.txt”)
   fd = fs.openSync(“file.txt”, …)
   tryStatSync(fd)
   tryReadSync(fd)
   fs.closeSync(fd)
   fs.js


   View Slide

7. fs.readFileSync(“file.txt”)
   fd = fs.openSync(“file.txt”, …)
   fs.js


   View Slide

8. fs.readFileSync(“file.txt”)
   fd = fs.openSync(“file.txt”, …)
   fs.js


   View Slide

9. binding.open(…)
   node_file.cc


   View Slide

10. binding.open(…)
    node_file.cc


    View Slide

11. Open(…)
    “uv_fs_open” is the “open”
    wrapper provided by libuv.
    node_file.cc


    View Slide

12. node_file.cc
    Open(…)
    “uv_fs_open” is the “open”
    wrapper provided by libuv.


    View Slide

13. http://docs.libuv.org/en/v1.x/guide/filesystem.html


    View Slide

14. http://man7.org/linux/man-pages/man2/open.2.html


    View Slide

15. fs.readFileSync(“file.txt”)
    fd = fs.openSync(“file.txt”, …)
    binding.open(…) (node_file.cc)
    uv_fs_open(…) (libuv)
    open(…) (posix)


    View Slide

16. What’s deno?
    • It’s a TypeScript runtime focused on
    security, built on V8.
    • No explicitly compatible with NodeJS
    (also: no npm, no package.json, etc.).
    • The initial prototype used a Golang
    backend, current one is written in Rust.
    C++ is used in a minimal way to bind V8
    to these alternative backends.


    View Slide

17. What’s deno?
    • Network access, local FS access and env
    access disabled by default.
    • Syscalls are easier to audit and could
    provide a good security framework for
    some applications.
    • Minimal number of V8 interactions: send,
    recv (used for in-memory message
    passing).


    View Slide

18. Ryan’s diagram from the initial presentation:

    http://tinyclouds.org/jsconf2018.pdf


    View Slide

19. deno.readFileSync(…) (TS wrapper/V8)
    ReadFileSync(…) (Golang)
    open(…) (posix)


    View Slide

20. deno.readFileSync(…) (TS wrapper/V8)
    ReadFileSync(…) (Golang)
    open(…) (posix)
    fs.readFileSync(“file.txt”)
    fd = fs.openSync(“file.txt”, …)
    binding.open(…) (node_file.cc)
    uv_fs_open(…) (libuv)
    open(…) (posix)
    deno
    node


    View Slide

21. deno
    os.ts
    fs.readFileSync(“file.txt”)
    deno.readFileSync(…) (TS wrapper/V8)
    ReadFileSync(…) (Golang)
    open(…) (posix)


    View Slide

22. deno
    os.go
    fs.readFileSync(“file.txt”)
    deno.readFileSync(…) (TS wrapper/V8)
    ReadFileSync(…) (Golang)
    open(…) (posix)


    View Slide

23. in-memory

    pubusb

    message passing
    fs.readFileSync(“file.txt”)
    deno.readFileSync(…) (TS wrapper/V8)
    ReadFileSync(…) (Golang)
    open(…) (posix)
    Golang V8
    Channels
    os
    deno.readFileSync(…)

    Publishes a message
    containing the
    filename and other
    parameters.


    View Slide

24. in-memory

    pubusb

    message passing
    fs.readFileSync(“file.txt”)
    deno.readFileSync(…) (TS wrapper/V8)
    ReadFileSync(…) (Golang)
    open(…) (posix)
    Golang V8
    Channels
    os
    deno.readFileSync(…)

    Publishes a message
    containing the
    filename and other
    parameters.
    After receiving
    the message, the
    dispatcher calls
    ReadFileSync(…)


    View Slide

25. in-memory

    pubusb

    message passing
    fs.readFileSync(“file.txt”)
    deno.readFileSync(…) (TS wrapper/V8)
    ReadFileSync(…) (Golang)
    open(…) (posix)
    Golang V8
    Channels
    os
    ReadFileSync(…)

    Reads the file
    and publishes a
    message to the
    “os” channel,
    containing the
    file contents.
    We get the file
    contents!


    View Slide

26. in-memory

    pubusb

    message passing
    fs.readFileSync(“file.txt”)
    deno.readFileSync(…) (TS wrapper/V8)
    ReadFileSync(…) (Golang)
    open(…) (posix)
    Golang V8
    Channels
    os
    net
    http
    The runtime can
    implement
    different
    channels for each
    required module.
    The messages are
    serialized using
    Protocol Buffers*.


    View Slide

27. in-memory

    pubusb

    message passing
    fs.readFileSync(“file.txt”)
    deno.readFileSync(…) (TS wrapper/V8)
    ReadFileSync(…) (Golang)
    open(…) (posix)
    Rust V8
    Channels
    os
    net
    http


    View Slide

28. Golang vs Rust:

    interop constraints
    • Go is a GCed language and doesn’t allow
    passing Go pointers to the native side
    (the opposite is possible though), this
    might result in unnecessary allocations
    under some circumstances.
    • Using deno with a Go backend involved
    two GCs! This is a potential issue ry
    mentioned and one of the reasons to
    replace Go with Rust, which it’s not
    GCed.


    View Slide

29. Golang vs Rust:

    interop constraints
    • deno was able to start multiple V8
    workers but there’s no easy way of
    accessing these workers from the Go
    side, a “worker table” was used, involving
    a mutex as you can find in: https://
    github.com/ry/v8worker2
    • I did a Rust port of this library to continue
    my experiment: https://github.com/
    matiasinsaurralde/rust-v8worker2


    View Slide

30. Golang vs Rust:

    interop constraints
    • The Rust port is way more efficient as you
    can handle interactions with the native
    world easily and keep passing pointers!
    • This is what my port looked like:


    View Slide

31. Golang vs Rust:

    interop constraints


    View Slide

32. Golang vs Rust:

    interop constraints
    • This is my hacky reimplementation of
    deno in rust (it’s called reno):

    https://github.com/matiasinsaurralde/reno


    View Slide

33. My HTTP experiment
    • I began researching the architecture and
    initial implementation after the project was
    announced in JSConf (June 6, 2018).
    • The initial implementation used Golang
    and a simple dispatcher (very similar to the
    current one).


    View Slide

34. My HTTP experiment


    View Slide

35. View Slide

36. View Slide

37. HTTP in deno?


    View Slide

38. What’s next?
    • The current implementation uses a new
    Rust backend.
    • Everything is contained on a single binary
    (a minimal V8 build is embedded into
    this).
    • Roadmap here: https://github.com/
    denoland/deno/blob/master/Roadmap.md


    View Slide

39. What’s next?
    • The current implementation replaced
    Protocol Buffers with Flatbuffers: this is a
    great thing in terms of memory usage!
    • Browser compatibility is planned.
    • Experimental binaries are being released
    from time to time (Linux, Windows and
    OS X).


    View Slide

40. What’s next?
    • Current implementation uses Tokio, an
    async runtime for Rust, replacing libuv in
    some ways.
    • HTTP support using the new Rust
    backend is in progress…


    View Slide

41. What’s next?


    View Slide

42. Thanks!
    Find deno here:
    https://github.com/denoland/deno
    Find me on:

    Twitter: @matias_baruch

    Github: matiasinsaurralde

    E-mail: matias@insaurral.de


    View Slide
