Va debugger ton Python!

Cette presentation vous explique les bases de Pdb ainsi que GDB, afin de debugger plus facilement vos scripts Python.

Transcript

1. Va debugger ton
   par
   Stéphane Wirtel
   PyCon FR 2017 - Toulouse - 23/09/2017
   1 / 107


   View Slide

2. Salut, je suis Stéphane
   par ma fille
   1 / 107


   View Slide

3. Qui aime developper... ?
   2 / 107


   View Slide

4. Debugger c'est Hard!
   3 / 107


   View Slide

5. Que fait ce code ?
   # Example 1
   def main():
   for i in range(1, 4):
   i /= 4
   if i == 4:
   print('Salut PyConFR 2017')
   if __name__ == '__main__':
   main()
   4 / 107


   View Slide

6. Que fait ce code ?
   # Example 1
   def main():
   for i in range(1, 4):
   i /= 4
   if i == 4:
   print('Salut PyConFR 2017')
   if __name__ == '__main__':
   main()
   $ python example1.py
   $
   5 / 107


   View Slide

7. La sacro-sainte fonction print()
   6 / 107


   View Slide

8. La sacro-sainte fonction print()
   # Example 2
   def main():
   for i in range(1, 4):
   i /= 4
   print(i)
   if i == 4:
   print('Salut PyConFR 2017')
   7 / 107


   View Slide

9. La sacro-sainte fonction print()
   # Example 2
   def main():
   for i in range(1, 4):
   i /= 4
   print(i)
   if i == 4:
   print('Salut PyConFR 2017')
   $ python example2.py
   0
   0
   0
   $
   8 / 107


   View Slide

10. Le module logging
    9 / 107


    View Slide

11. Utilisons logging
    # Example 3
    import logging
    def main():
    logging.basicConfig(level=logging.INFO)
    logging.info('start program')
    logging.debug("before loop")
    for i in range(1, 4):
    i /= 4
    logging.debug(i)
    logging.debug("after loop")
    if i == 4:
    print("Hello PyConFR 2017")
    logging.debug("Hello PyConFR 2017")
    logging.info('end program')
    if __name__ == '__main__':
    main()
    10 / 107


    View Slide

12. Utilisons logging
    # Example 3
    import logging
    def main():
    logging.basicConfig(level=logging.INFO)
    logging.info('start program')
    logging.debug("before loop")
    for i in range(1, 4):
    i /= 4
    logging.debug(i)
    logging.debug("after loop")
    if i == 4:
    print("Hello PyConFR 2017")
    logging.debug("Hello PyConFR 2017")
    logging.info('end program')
    if __name__ == '__main__':
    main()
    INFO:root:start program
    INFO:root:end program
    11 / 107


    View Slide

13. Utilisons logging
    # Example 4
    import logging
    def main():
    logging.basicConfig(level=logging.DEBUG)
    logging.info('start program')
    logging.debug("before loop")
    for i in range(1, 4):
    i /= 4
    logging.debug(i)
    logging.debug("after loop")
    if i == 4:
    print("Hello PyConFR 2017")
    logging.debug("Hello PyConFR 2017")
    logging.info('end program')
    if __name__ == '__main__':
    main()
    12 / 107


    View Slide

14. Utilisons logging
    INFO:root:start program
    DEBUG:root:before loop
    DEBUG:root:0
    DEBUG:root:0
    DEBUG:root:0
    DEBUG:root:after loop
    INFO:root:end program
    13 / 107


    View Slide

15. Utilisons logging
    INFO:root:start program
    DEBUG:root:before loop
    DEBUG:root:0
    DEBUG:root:0
    DEBUG:root:0
    DEBUG:root:after loop
    INFO:root:end program
    Obligé de modifier le niveau de log pour voir ce qu'il se passe.
    14 / 107


    View Slide

16. Cool
    mais
    Modification du code
    Execution
    Oubli de supprimer le print en production...
    15 / 107


    View Slide

17. que faire, quoi utiliser...
    16 / 107


    View Slide

18. Un debugger!
    17 / 107


    View Slide

19. PDB
    Python Debugger est l'outil natif pour aider les développeurs à trouver et
    corriger les bugs de leur logiciel fétiche (ou celui que l'on récupère d'un ancien
    collègue ou prestataire...)
    18 / 107


    View Slide

20. Eh oui, Python vient avec un debugger!
    19 / 107


    View Slide

21. Comment faire
    import pdb; pdb.set_trace()
    20 / 107


    View Slide

22. Comment faire
    import pdb; pdb.set_trace()
    # Example 5
    import pdb
    def main():
    for i in range(1, 4):
    i /= 4
    if i == 4:
    print("Hello PyConFR 2017")
    if __name__ == '__main__':
    pdb.set_trace()
    main()
    21 / 107


    View Slide

23. Comment faire
    import pdb; pdb.set_trace()
    # Example 5
    import pdb
    def main():
    for i in range(1, 4):
    i /= 4
    if i == 4:
    print("Hello PyConFR 2017")
    if __name__ == '__main__':
    pdb.set_trace()
    main()
    $ python example5.py
    > example5.py(7)main()
    -> for i in range(1, 4):
    22 / 107


    View Slide

24. Comment faire
    Example 6
    import pdb
    def do_something():
    raise Exception("bug")
    def main():
    try:
    do_something()
    except Exception:
    pdb.post_mortem()
    if __name__ == '__main__':
    main()
    23 / 107


    View Slide

25. Comment faire
    Example 6
    import pdb
    def do_something():
    raise Exception("bug")
    def main():
    try:
    do_something()
    except Exception:
    pdb.post_mortem()
    if __name__ == '__main__':
    main()
    > example6.py(4)do_something()
    -> raise Exception("bug")
    (Pdb) bt
    example6.py(8)main()
    -> do_something()
    > example6.py(4)do_something()
    -> raise Exception("bug")
    (Pdb) ll
    3 def do_something():
    4 -> raise Exception("bug")
    (Pdb)
    24 / 107


    View Slide

26. Comment faire
    On peut aussi charger pdb comme un module à la ligne de commande.
    $ python -m pdb
    $ python -m pdb -c "command"
    25 / 107


    View Slide

27. Prenons un exemple lisant un .csv
    26 / 107


    View Slide

28. Prenons un exemple lisant un .csv
    import pendulum
    import csv
    class Event:
    def __init__(self, name, date):
    self.name = name
    self.date = pendulum.parse(date)
    def get_events(stream):
    for row in csv.reader(stream):
    yield Event(*row)
    def main():
    with open('events.csv') as stream:
    for event in get_events(stream):
    print(event.name, event.date)
    if __name__ == '__main__':
    main()
    27 / 107


    View Slide

29. Prenons un exemple lisant un .csv
    import pendulum
    import csv
    class Event:
    def __init__(self, name, date):
    self.name = name
    self.date = pendulum.parse(date)
    def get_events(stream):
    for row in csv.reader(stream):
    yield Event(*row)
    def main():
    with open('events.csv') as stream:
    for event in get_events(stream):
    print(event.name, event.date)
    if __name__ == '__main__':
    main()
    PyCon France,2017-09-21
    PyCon Canada,2017-11-18
    PyCon US,2017-05-17
    Python FOSDEM,2018-02-03
    Python TOTO,x
    28 / 107


    View Slide

30. Prenons un exemple lisant un .csv
    $ python events.py
    Non d'un petit Python, CRASH avec deux exceptions :/
    PyCon France 2017-09-21T00:00:00+00:00
    PyCon Canada 2017-11-18T00:00:00+00:00
    PyCon US 2017-05-17T00:00:00+00:00
    Python FOSDEM 2018-02-03T00:00:00+00:00
    File "/home/stephane/.virtualenvs/flask/lib/python3.6/site-packages/dateutil/par
    raise ValueError("Unknown string format")
    ValueError: Unknown string format
    During handling of the above exception, another exception occurred:
    File "/home/stephane/.virtualenvs/flask/lib/python3.6/site-packages/pendulum/par
    raise ParserError('Invalid date string: {}'.format(text))
    pendulum.parsing.exceptions.ParserError: Invalid date string: x
    29 / 107


    View Slide

31. Je débugge
    $ python -m pdb events.py
    > events.py(1)()
    -> import pendulum
    (Pdb)
    30 / 107


    View Slide

32. Je liste mon code avec l ou ll
    (Pdb) ll
    1 -> import pendulum
    2 import csv
    3
    4 class Event:
    5 def __init__(self, name, date):
    6 self.name = name
    7 self.date = pendulum.parse(date)
    8
    9 def get_events(stream):
    10 for row in csv.reader(stream):
    11 yield Event(*row)
    12
    13 def main():
    14 with open('events.csv') as stream:
    15 for event in get_events(stream):
    16 print(event.name, event.date)
    17
    18 if __name__ == '__main__':
    19 main()
    31 / 107


    View Slide

33. J'avance d'une ligne
    (Pdb) next
    > events.py(2)()
    -> import csv
    32 / 107


    View Slide

34. J'avance d'une ligne
    (Pdb) next
    > events.py(2)()
    -> import csv
    (Pdb) ll
    1 import pendulum
    2 -> import csv
    3
    4 class Event:
    5 def __init__(self, name, date):
    6 self.name = name
    7 self.date = pendulum.parse(date)
    8
    9 def get_events(stream):
    10 for row in csv.reader(stream):
    11 yield Event(*row)
    12
    13 def main():
    14 with open('events.csv') as stream:
    15 for event in get_events(stream):
    16 print(event.name, event.date)
    17
    18 if __name__ == '__main__':
    19 main()
    33 / 107


    View Slide

35. On saute dans le code
    -> def main():
    (Pdb) ll
    15 -> def main():
    16 with open('events.csv') as stream:
    17 for event in get_events(stream):
    18 print(event.name, event.date)
    19 print(Event.id)
    (Pdb) step
    > events.py(16)main()
    -> with open('events.csv') as stream:
    (Pdb) ll
    15 def main():
    16 -> with open('events.csv') as stream:
    17 for event in get_events(stream):
    18 print(event.name, event.date)
    19 print(Event.id)
    34 / 107


    View Slide

36. On saute dans le code
    (Pdb) next
    > events.py(17)main()
    -> for event in get_events(stream):
    (Pdb) ll
    15 def main():
    16 with open('events.csv') as stream:
    17 -> for event in get_events(stream):
    18 print(event.name, event.date)
    19 print(Event.id)
    (Pdb) step
    --Call--
    > events.py(11)get_events()
    -> def get_events(stream):
    (Pdb) ll
    11 -> def get_events(stream):
    12 for row in csv.reader(stream):
    13 yield Event(*row)
    (Pdb) next
    > events.py(12)get_events()
    -> for row in csv.reader(stream):
    (Pdb) ll
    11 def get_events(stream):
    12 -> for row in csv.reader(stream):
    13 yield Event(*row)
    (Pdb)
    35 / 107


    View Slide

37. Breakpoints
    Je reprends le code de base
    36 / 107


    View Slide

38. Breakpoints
    (Pdb) ll
    1 import pendulum
    2 import csv
    3
    4 class Event:
    5 def __init__(self, name, date):
    6 self.name = name
    7 self.date = pendulum.parse(date)
    8
    9 def get_events(stream):
    10 for row in csv.reader(stream):
    11 yield Event(*row)
    12
    13 def main():
    14 with open('events.csv') as stream:
    15 for event in get_events(stream):
    16 print(event.name, event.date)
    17
    18 if __name__ == '__main__':
    19 main()
    37 / 107


    View Slide

39. Breakpoints
    Lister
    > events.py(1)()
    -> import pendulum
    (Pdb) break
    (Pdb)
    38 / 107


    View Slide

40. Breakpoints
    Ajouter
    > events.py(1)()
    -> import pendulum
    (Pdb) break 9
    Breakpoint 1 at events.py:9
    (Pdb) l
    4 class Event:
    5 id = 0
    6 def __init__(self, name, date):
    7 self.id += 1
    8 self.name = name
    9 B-> self.date = pendulum.parse(date)
    10
    11 def get_events(stream):
    12 for row in csv.reader(stream):
    13 yield Event(*row)
    39 / 107


    View Slide

41. Breakpoints
    Ajouter
    > events.py(1)()
    -> import pendulum
    (Pdb) break 9
    Breakpoint 1 at events.py:9
    (Pdb) l
    4 class Event:
    5 id = 0
    6 def __init__(self, name, date):
    7 self.id += 1
    8 self.name = name
    9 B-> self.date = pendulum.parse(date)
    10
    11 def get_events(stream):
    12 for row in csv.reader(stream):
    13 yield Event(*row)
    (Pdb) break
    Num Type Disp Enb Where
    1 breakpoint keep yes at events.py:9
    40 / 107


    View Slide

42. Breakpoints
    Désactiver un breakpoint
    (Pdb) disable 1
    Disabled breakpoint 1 at events.py:9
    41 / 107


    View Slide

43. Breakpoints
    Désactiver un breakpoint
    (Pdb) disable 1
    Disabled breakpoint 1 at events.py:9
    (Pdb) break
    Num Type Disp Enb Where
    1 breakpoint keep no at events.py:9
    42 / 107


    View Slide

44. Breakpoints
    Activer un breakpoint
    (Pdb) enable 1
    Enabled breakpoint 1 at events.py:9
    43 / 107


    View Slide

45. Breakpoints
    Activer un breakpoint
    (Pdb) enable 1
    Enabled breakpoint 1 at events.py:9
    (Pdb) break
    Num Type Disp Enb Where
    1 breakpoint keep yes at events.py:9
    44 / 107


    View Slide

46. Je continue
    (Pdb) continue
    > events.py(9)__init__()
    -> self.date = pendulum.parse(date)
    45 / 107


    View Slide

47. J'examine
    (Pdb) args
    self = <__main__.Event object at 0x7f23cf8cc908>
    name = 'PyCon France'
    date = '2017-09-21'
    46 / 107


    View Slide

48. J'examine
    (Pdb) args
    self = <__main__.Event object at 0x7f23cf8cc908>
    name = 'PyCon France'
    date = '2017-09-21'
    (Pdb) whatis name

    (Pdb) whatis self

    47 / 107


    View Slide

49. Nouvelles commandes avec alias
    alias d pp dir(%1)
    48 / 107


    View Slide

50. Nouvelles commandes avec alias
    alias d pp dir(%1)
    (Pdb) b 9
    Breakpoint 1 at events.py:9
    (Pdb) c
    > events.py(9)__init__()
    -> self.date = pendulum.parse(date)
    49 / 107


    View Slide

51. Nouvelles commandes avec alias
    alias d pp dir(%1)
    (Pdb) b 9
    Breakpoint 1 at events.py:9
    (Pdb) c
    > events.py(9)__init__()
    -> self.date = pendulum.parse(date)
    (Pdb) d self.__dict__
    ['__class__',
    '__contains__',
    '__delattr__',
    ...
    ]
    50 / 107


    View Slide

52. Nouvelles commandes avec alias
    alias loc !list(locals().keys())
    51 / 107


    View Slide

53. Nouvelles commandes avec alias
    alias loc !list(locals().keys())
    (Pdb) loc
    dict_keys(['date', 'name', 'self'])
    52 / 107


    View Slide

54. Nouvelles commandes avec alias
    alias printdict for key, value in %1.items(): print(f"{key}:{value}")
    53 / 107


    View Slide

55. Nouvelles commandes avec alias
    alias printdict for key, value in %1.items(): print(f"{key}:{value}")
    (Pdb) printdict self.__dict__
    id:1
    name:PyCon France
    date:2017-09-21T00:00:00+00:00
    54 / 107


    View Slide

56. Réutilisation d'alias
    alias pd printdict %1
    55 / 107


    View Slide

57. Réutilisation d'alias
    alias pd printdict %1
    (Pdb) pd self.__dict__
    id:1
    name:PyCon France
    date:2017-09-21T00:00:00+00:00
    56 / 107


    View Slide

58. Breakpoint et une action
    Possibilité de définir une action lors d'un breakpoint
    commands [bpnumber]
    p self.__dict__
    printdict self.__dict__
    end
    57 / 107


    View Slide

59. Démonstration
    58 / 107


    View Slide

60. PDB
    Récapitulatif des commandes
    59 / 107


    View Slide

61. Les importantes
    Commande Description
    h(elp) Affiche l'aide
    h(elp) command Affiche l'aide d'une commande
    q(uit) Quitte le debuggeur
    60 / 107


    View Slide

62. Examiner
    Commande Description
    p(rint) expr Affiche la valeur de l'expression
    pp expr Pretty-print de la valeur de l'expression
    l(ist) Affiche une partie du code
    ll Affiche toute le code de la fonction
    a(rgs) Affiche la liste des arguments de la fonction
    whatis arg Affiche le type de l'argument
    where Mais ou se trouve l'exception
    source Affiche la source d'une fonction
    61 / 107


    View Slide

63. Naviguer
    Commande Description
    n(ext) Exécute l'instruction
    s(tep) Exécute et rentre dans la fonction/méthode
    r(eturn) Continue l'exécution jusqu'au return
    c(ontinue) Continue l'exécution jusqu'à un breakpoint
    u(p) Remonte d'un niveau dans la stack trace
    d(own) Descend d'un niveau dans la stack trace
    j(ump) lineno Saute a la ligne
    62 / 107


    View Slide

64. Breakpoints
    Commande Description
    b(reak) Montre tous les breakpoints
    63 / 107


    View Slide

65. Breakpoints
    Commande Description
    b(reak) lineno Place un breakpoint à lineno
    b(reak) lineno,
    cond
    Place un breakpoint à lineo si cond est True
    b(reak)
    file:lineno
    Place un breakpoint dans le fichier file à la ligne
    lineno
    b(reak) func
    Place un breakpoint à la première ligne de la
    fonction func
    tbreak lineno Place un breakpoint et l'enleve dès que l'on y est
    64 / 107


    View Slide

66. Breakpoints
    Commande Description
    clear bpnumber Supprime un breakpoint
    disable bpnumber Désactive un breakpoint
    enable bpnumber Active un breakpoint
    ignore bpnumber count Ignore le breakpoint X fois
    condition bpnumber condition Permet de modifer le breakpoint
    65 / 107


    View Slide

67. Celles que vous ne connaissez pas ;-)
    Commande Description
    !expr
    Execute une expression dans l'interpreteur
    Python
    alias Créer une nouvelle commande PDB
    unalias Supprime un alias
    commands
    [bpnumber]
    Assigne des commandes à un breakpoint
    restart or run Redémarre le script
    66 / 107


    View Slide

68. Fichier de con guration
    alias d pp dir(%1)
    alias ps d self.__dict__
    alias loc !list(locals().keys())
    alias printdict for key, value in %1.items(): print(f"{key}:{value}")
    Voir $HOME/.pdbrc ou ./.pdbrc
    67 / 107


    View Slide

69. Il y a un truc amusant
    68 / 107


    View Slide

70. Ça fonctionne avec ipdb
    69 / 107


    View Slide

71. Les alternatives - ipdb
    Auto-completion
    Coloration syntaxique
    Meilleurs tracebacks
    Meilleur introspection
    Commandes supplémentaires
    https://github.com/gotcha/ipdb
    70 / 107


    View Slide

72. Les alternatives - pudb
    https://github.com/inducer/pudb
    71 / 107


    View Slide

73. Les alternatives - rdb
    import pdb, socket, sys # noqa --> Pas PEP8
    class Rdb(pdb.Pdb):
    def __init__(self, port=4444):
    self.old_stdout = sys.stdout
    self.old_stdin = sys.stdin
    self.skt = socket.socket(socket.AF_INET, socket.SOCK_STREAM)
    self.skt.bind(('localhost', port))
    self.skt.listen(1)
    (clientsocket, address) = self.skt.accept()
    handle = clientsocket.makefile('rw')
    pdb.Pdb.__init__(self, completekey='tab', stdin=handle, stdout=handle)
    sys.stdout = sys.stdin = handle
    def do_continue(self, arg):
    sys.stdout = self.old_stdout
    sys.stdin = self.old_stdin
    self.skt.close()
    self.set_continue()
    return 1
    do_c = do_cont = do_continue
    https://dzone.com/articles/remote-debugging-python-using
    72 / 107


    View Slide

74. Les alternatives - rdb (2)
    # Example usage - connect with 'telnet 4444'
    if __name__=='__main__':
    def buggy_method():
    x = 3
    remote_debug = Rdb()
    remote_debug.set_trace()
    print(x)
    buggy_method()
    https://dzone.com/articles/remote-debugging-python-using
    73 / 107


    View Slide

75. Les alternatives - rdb (3)
    telnet localhost 4444
    Trying 127.0.0.1...
    Connected to localhost.
    Escape character is '^]'.
    > rdb.py(32)buggy_method()
    -> print(x)
    (Pdb) ll
    28 def buggy_method():
    29 x = 3
    30 remote_debug = Rdb()
    31 remote_debug.set_trace()
    32 -> print(x)
    (Pdb) p x
    3
    (Pdb) quit
    Connection closed by foreign host.
    Meilleure implémentation dans
    https://github.com/celery/celery/blob/master/celery/contrib/rdb.py
    https://dzone.com/articles/remote-debugging-python-using
    74 / 107


    View Slide

76. Les alternatives - wdb
    https://github.com/Kozea/wdb
    75 / 107


    View Slide

77. Les alternatives - pdbpp
    https://github.com/antocuni/pdb
    76 / 107


    View Slide

78. pdb ou ipdb avec du dev Web
    Par exemple, Django
    django-pdb avec --ipdb ou --pdb
    ou simplement
    python -m pdb ./manage.py test
    python -m ipdb ./manage.py test
    python -m pudb ./manage.py test
    77 / 107


    View Slide

79. GNU Debugger
    Également nommé gdb, GNU Debugger, est le débuggeur standard du projet
    GNU, portable et fonctionne pour plusieurs langages, comme le C, le C++ et aussi
    le Python ;-)
    78 / 107


    View Slide

80. GNU Debugger
    gdb >= 7 , support natif de Python
    79 / 107


    View Slide

81. GNU Debugger
    Avoir les symboles de debug de Python
    $ dnf install python3-debug
    80 / 107


    View Slide

82. GNU Debugger
    Avoir les symboles de debug de Python
    $ dnf install python3-debug
    ou
    $ ./configure --prefix=$PWD-build --with-pydebug
    $ make
    $ make install
    81 / 107


    View Slide

83. GNU Debugger
    Python + gdb = ?
    82 / 107


    View Slide

84. GNU Debugger
    Python + gdb = ?
    1. il y a une librairie pour debugger votre script Python depuis gdb
    83 / 107


    View Slide

85. GNU Debugger
    Python + gdb = ?
    1. il y a une librairie pour debugger votre script Python depuis gdb
    2. gdb est extensible via Python
    84 / 107


    View Slide

86. Que faire avec gdb ?
    Commande Description
    py-bt Montre la stack trace Python
    py-bt-full py-bt mais en plus verbeux
    py-list Liste le code Python
    py-print Affiche le contenu d'une variable Python
    py-locals Affiche les locals
    py-up Remonte d'une frame
    py-down Descend d'une frame
    85 / 107


    View Slide

87. Le code
    import time
    import os
    def next(i):
    print(f"{os.getpid()} {time.strftime('%H:%M:%S')}")
    time.sleep(10)
    i = 1 - i
    i = 1
    while True:
    next(i)
    86 / 107


    View Slide

88. Le code
    import time
    import os
    def next(i):
    print(f"{os.getpid()} {time.strftime('%H:%M:%S')}")
    time.sleep(10)
    i = 1 - i
    i = 1
    while True:
    next(i)
    $ python ex_loop1.py
    10619 06:14:24
    10619 06:14:34
    10619 06:14:44
    10619 06:14:54
    10619 06:15:04
    10619 06:15:14
    PID 10619
    87 / 107


    View Slide

89. Comment faire ?
    $ gdb -p 10619
    GNU gdb (GDB) Fedora 8.0.1-26.fc26
    ...
    For help, type "help".
    Type "apropos word" to search for commands related to "word".
    Attaching to process 10619
    Reading symbols from /usr/bin/python3.6dm...Reading symbols from /usr/lib/debug/us
    Reading symbols from /lib64/libpython3.6dm.so.1.0...Reading symbols from /usr/lib/d
    Reading symbols from /lib64/libpthread.so.0...Reading symbols from /usr/lib/debug/
    [Thread debugging using libthread_db enabled]
    Using host libthread_db library "/lib64/libthread_db.so.1".
    Reading symbols from /lib64/libdl.so.2...Reading symbols from /usr/lib/debug/usr/li
    Reading symbols from /lib64/libutil.so.1...Reading symbols from /usr/lib/debug/usr
    Reading symbols from /lib64/libm.so.6...Reading symbols from /usr/lib/debug/usr/li
    Reading symbols from /lib64/libc.so.6...Reading symbols from /usr/lib/debug/usr/li
    Reading symbols from /lib64/ld-linux-x86-64.so.2...Reading symbols from /usr/lib/de
    0x00007f40dc696ce3 in __select_nocancel () at ../sysdeps/unix/syscall-template.S:84
    84 T_PSEUDO (SYSCALL_SYMBOL, SYSCALL_NAME, SYSCALL_NARGS)
    (gdb)
    88 / 107


    View Slide

90. A cher le code
    (gdb) py-list
    1 import time
    2 import os
    3
    4 def next(i):
    5 print(f"{os.getpid()} {time.strftime('%H:%M:%S')}")
    >6 time.sleep(10)
    7 i = 1 - i
    8
    9 i = 1
    10 while True:
    11 next(i)
    (gdb)
    89 / 107


    View Slide

91. A cher la traceback
    (gdb) py-bt
    Traceback (most recent call first):

    File "ex_loop1.py", line 6, in next
    time.sleep(10)
    File "ex_loop1.py", line 11, in
    next(i)
    90 / 107


    View Slide

92. A cher la traceback avec plus d'infos
    (gdb) py-bt-full
    #3
    #7 Frame 0x55c890804748, for file ex_loop1.py, line 6, in next (i=1)
    time.sleep(10)
    #12 Frame 0x55c890804458, for file ex_loop1.py, line 11, in ()
    next(i)
    91 / 107


    View Slide

93. A cher la traceback avec plus d'infos
    (gdb) py-bt-full
    #3
    #7 Frame 0x55c890804748, for file ex_loop1.py, line 6, in next (i=1)
    time.sleep(10)
    #12 Frame 0x55c890804458, for file ex_loop1.py, line 11, in ()
    next(i)
    (gdb) select-frame 7
    (gdb) info locals
    tstate = 0x55c8907a3cf0
    (gdb) select-frame 3
    (gdb) info locals
    func = 0x7f40d5974418
    meth = 0x7f40dd57c6c6
    self =
    result = 'sleep'
    flags = 8
    __PRETTY_FUNCTION__ = "_PyCFunction_FastCallDict"
    92 / 107


    View Slide

94. Examiner une frame
    (gdb) py-bt-full
    #3
    #7 Frame 0x55706036f748, for file ex_loop1.py, line 6, in next (i=1)
    time.sleep(10)
    #12 Frame 0x55706036f458, for file ex_loop1.py, line 11, in ()
    next(i)
    (gdb) select-frame 7
    (gdb) py-list
    1 import time
    2 import os
    3
    4 def next(i):
    5 print(f"{os.getpid()} {time.strftime('%H:%M:%S')}")
    >6 time.sleep(10)
    7 i = 1 - i
    8
    9 i = 1
    10 while True:
    11 next(i)
    (gdb) py-print i
    local 'i' = 1
    (gdb) py-locals
    i = 1
    93 / 107


    View Slide

95. Navigation
    (gdb) py-down
    Unable to find a newer python frame
    (gdb) py-up
    #7 Frame 0x55c890804748, for file ex_loop1.py, line 6, in next (i=1)
    time.sleep(10)
    (gdb) py-down
    #3
    94 / 107


    View Slide

96. Backtrace de CPython
    (gdb) bt
    #0 0x00007f40dc696ce3 in __select_nocancel () at ../sysdeps/unix/syscall-template
    #1 0x00007f40dd57e7f8 in pysleep (secs=10000000000)
    at /usr/src/debug/Python-3.6.2/Modules/timemodule.c:1438
    #2 0x00007f40dd57c73d in time_sleep (self=, obj=
    at /usr/src/debug/Python-3.6.2/Modules/timemodule.c:235
    #3 0x00007f40dd39a9af in _PyCFunction_FastCallDict (
    func_obj=,
    args=0x55c8908048e0, nargs=1, kwargs=0x0)
    at /usr/src/debug/Python-3.6.2/Objects/methodobject.c:209
    #4 0x00007f40dd39ada6 in _PyCFunction_FastCallKeywords (
    func=,
    stack=0x55c8908048e0, nargs=1, kwnames=0x0)
    at /usr/src/debug/Python-3.6.2/Objects/methodobject.c:294
    #5 0x00007f40dd4b046e in call_function (pp_stack=0x7ffd7bcab7b8, oparg=1, kwnames=
    at /usr/src/debug/Python-3.6.2/Python/ceval.c:4809
    #6 0x00007f40dd4a8046 in _PyEval_EvalFrameDefault (
    f=Frame 0x55c890804748, for file ex_loop1.py, line 6, in next (i=1), throwflag=
    at /usr/src/debug/Python-3.6.2/Python/ceval.c:3295
    #7 0x00007f40dd494118 in PyEval_EvalFrameEx (
    f=Frame 0x55c890804748, for file ex_loop1.py, line 6, in next (i=1), throwflag=
    at /usr/src/debug/Python-3.6.2/Python/ceval.c:718
    95 / 107


    View Slide

97. Threads
    (gdb) info threads
    Id Target Id Frame
    1 Thread 0x7f40ddaef700 (LWP 10619) "python3-debug" 0x00007f40dd39a9af in _PyC
    args=0x55c8908048e0, nargs=1, kwargs=0x0)
    at /usr/src/debug/Python-3.6.2/Objects/methodobject.c:209
    96 / 107


    View Slide

98. Dumper les stack traces des threads
    (gdb) thread apply all py-bt
    Thread 1 (Thread 0x7f40ddaef700 (LWP 10619)):
    Traceback (most recent call first):

    File "ex_loop1.py", line 6, in next
    time.sleep(10)
    File "ex_loop1.py", line 11, in
    next(i)
    (gdb)
    97 / 107


    View Slide

99. Débugger à distance
    98 / 107


    View Slide

100. Mode Remote - gdbserver
     $ gdbserver --multi host:2345
     #
     # ou ces modes-ci
     #
     $ gdbserver host:2345 process_name
     $ gdbserver host:2345 --attach PID
     99 / 107


     View Slide

101. Mode Remote - gdbserver
     $ gdbserver --multi host:2345
     #
     # ou ces modes-ci
     #
     $ gdbserver host:2345 process_name
     $ gdbserver host:2345 --attach PID
     $ gdb
     (gdb) target extended-remote host:2345
     (gdb) attach PID
     100 / 107


     View Slide

102. Mode Remote - gdbserver
     $ gdbserver --multi host:2345
     #
     # ou ces modes-ci
     #
     $ gdbserver host:2345 process_name
     $ gdbserver host:2345 --attach PID
     $ gdb
     (gdb) target extended-remote host:2345
     (gdb) attach PID
     (gdb) py-list
     1 import time
     2 import os
     3
     4 def next(i):
     5 print(f"{os.getpid()} {time.strftime('%H:%M:%S')}")
     >6 time.sleep(10)
     7 i = 1 - i
     8
     9 i = 1
     10 while True:
     11 next(i)
     (gdb)
     101 / 107


     View Slide

103. Extensible ?
     102 / 107


     View Slide

104. Extensible ? - Oui
     https://github.com/cyrus-and/gdb-dashboardOui
     103 / 107


     View Slide

105. Alternatives
     104 / 107


     View Slide

106. gdbgui
     pip install gdbgui
     105 / 107


     View Slide

107. Prochaines talks pour 2018
     SystemTap et DTrace pour mon Python
     Que fait mon débuggeur Python?
     GDB en profondeur
     106 / 107


     View Slide

108. Questions ?
     stephane@mgx.io
     107 / 107


     View Slide
