Cloud Native Conference - Warsaw - Sep 9th, 2019

Learn about Knative, open source serverless platform, its benefits, see demos how you can use it to build modern event-based solutions without the need to worry about the underlying infrastructure:

* Serverless more than Function
* Serverless and Container
* Serverless with Portability

Transcript

1. Serverless
   On Your Own Terms
   Using Knative
   Mark Chmarny
   Serverless at Google
   @mchmarny


   View Slide

2. Context


   View Slide

3. Serverless more than Function


   View Slide

4. Operator
   No Infra Management Managed Security Pay only for usage
   Service-based Event-driven Open
   Serverless Models
   Developer


   View Slide

5. Serverless and Container


   View Slide

6. .js .rb .go
   .py .sh …
   0 1 0
   1 0 0
   1 1 1
   Containers
   • Any Language, Library, Binary
   • Granular version control
   • Ecosystem of base images
   Common unit of workload
   description (Dockerfile) and
   delivery (Container Image)


   View Slide

7. Serverless with Portability


   View Slide

8. Portability
   Kubernetes
   Offered by virtually all
   Cloud Service Providers
   Knative
   Codifies serverless, broad
   contributor/user community


   View Slide

9. What is Knative?


   View Slide

10. Knative
    “Open source building blocks for
    serverless on Kubernetes”
    knative.dev
    [kay-native]


    View Slide

11. Confidential & Proprietary
    Knative Stack
    Build Serving
    Kubernetes
    Platform
    Products
    Primitives Events ...
    Serverless Containers on GCF GKE Serverless Add-on SAP Kyma
    Pivotal Function Service IBM Cloud Functions Red Hat Cloud Functions
    Pivotal riff OpenFaaS T-mobile Jazz
    Istio
    Service Mesh
    Knative Primitives
    Developer-facing Products
    Build Serving
    Kubernetes
    Events ...


    View Slide

12. Confidential & Proprietary
    Knative Stack
    Serverless Containers on GCF GKE Serverless Add-on SAP Kyma
    Knative Community
    55+
    Contributing
    Companies
    >6K
    Pull Requests
    ~450
    Individual
    Contributors
    9
    Working
    Groups
    v0.8
    Predictable
    Releases
    source: knative.teststats.cncf.io/d/8/dashboards


    View Slide

13. Confidential & Proprietary
    Knative Stack
    Serverless Containers on GCF GKE Serverless Add-on SAP Kyma
    Knative Today
    Products
    Google Cloud Run Red Hat OpenShift SAP Kyma
    Google Cloud Run on GKE IBM Cloud Kubernetes Service TriggerMesh
    Build Tekton
    Serving
    Kubernetes
    Platform
    Primitives Events ...


    View Slide

14. How to get Knative


    View Slide

15. Confidential & Proprietary
    Knative Stack
    Build Serving
    Kubernetes
    Platform
    Products
    Primitives Events ...
    Serverless Containers on GCF GKE Serverless Add-on SAP Kyma
    Pivotal Function Service IBM Cloud Functions Red Hat Cloud Functions
    Pivotal riff OpenFaaS T-mobile Jazz
    Istio
    Service Mesh
    # latest releases: https://knative.dev/docs/install/
    $ kubectl apply \
    -f https://github.com/knative/serving/releases/.../serving.yaml \
    -f https://github.com/knative/eventing/releases/.../eventing.yaml \
    -f https://github.com/knative/monitoring/releases/.../monitoring.yaml \
    -f https://github.com/knative/build/releases/.../build.yaml
    Install


    View Slide

16. Confidential & Proprietary
    Install
    $ gcloud beta container \
    clusters create my-cluster \
    --addons=CloudRun
    Also available for:
    ● AKS
    ● Docker
    ● Gardener
    ● IKS
    ● Minikube
    ● OpenShift/Minishift
    ● PCS
    Quick start: bit.ly/cr-gke


    View Slide

17. Confidential & Proprietary
    Config
    $: kubectl get ns
    NAME STATUS
    default Active
    istio-system Active
    knative-build Active
    knative-eventing Active
    knative-monitoring Active
    knative-serving Active
    knative-sources Active
    kube-public Active
    kube-system Active
    $: kubectl get cm -n knative-serving
    NAME DATA
    config-autoscaler 1
    config-defaults 1
    config-deployment 2
    config-domain 1
    config-gc 1
    config-istio 1
    config-logging 1
    config-network 6
    config-observability 1
    config-tracing 1


    View Slide

18. How to use Knative


    View Slide

19. Knative Serving
    Functionality
    ● Activates/scales workload based
    on request (up/down to 0 pods)
    ● Manages revision code/config
    (update, rollback, split traffic)
    ● Request path/services access
    control (manage service mesh)
    ● Granular metrics, Custom
    domains, SSL support...
    Integration
    ● Connect with other services
    like GCP Cloud Build and
    Stackdriver
    ● Extend with partner
    integrations like Solo.io,
    GitLab, Datadog


    View Slide

20. Deployment (CLI)
    Knative CLI:
    github.com/knative/client
    kn service create service-name \
    --image registry/image-name
    Result:
    service-name.namespace.domain.dev


    View Slide

21. Deployment (YAML)
    kubectl apply -f service.yaml
    # service.yaml
    apiVersion: serving.knative.dev/v1beta1
    kind: Service
    metadata:
    name: service-name
    spec:
    template:
    spec:
    containers:
    - image: registry/image-name


    View Slide

22. Deployment (Google)
    gcloud beta run deploy service-name \
    --image=gcr.io/project/image-name
    Other providers:
    knctl, os, ibmcloud


    View Slide

23. Autoscaling


    View Slide

24. GitOps using Cloud Build, GitLab, Jenkins
    git tag ...; git push origin ...;
    # branch or release trigger to build/push (github.com/mchmarny/maxprime)
    Local Build using Dockerfile, deploy using kn or gcloud
    docker build -t ...; docker push ...
    kn service create my-service --image=user:image:sha
    On-cluster Build using Tekton Pipelines (github.com/tektoncd/pipeline)
    kubectl apply -f task.yaml
    ko for quick iteration, no Dockerfile, golang only - github.com/google/ko
    ko apply -f config.yaml
    Deployment Options


    View Slide

25. Knative Serving Usage Patterns
    Public Service
    • Website
    • API endpoint
    Internal Service
    • Backing Microservices
    • Eventing Targets
    • Mobile backend
    • Webhook


    View Slide

26. Request Path
    Kubernetes Cluster
    Knative
    Logo Service Vision API
    User
    HTTPS
    HTTPS
    curl -H "Content-Type: application/json" \
    -d '{"id":"test","url":"https://storage.googleapis.com/kdemo-logos/google.png"}' \
    -X POST https://klogo.demo.knative.tech/


    View Slide

27. Request Path
    Kubernetes Cluster
    Knative
    Frontend UI
    Logo Service
    User Service
    Vision API
    Firestore API
    User
    HTTPS
    demo
    OAuth
    HTTPS
    HTTPS


    View Slide

28. Request Path
    Kubernetes Cluster
    Knative
    Frontend UI
    Logo Service
    User Service
    Vision API
    Firestore API
    User
    HTTPS
    demo
    OAuth
    HTTPS
    HTTPS


    View Slide

29. # service.yaml
    apiVersion: serving.knative.dev/v1alpha1
    kind: Service
    metadata:
    name: klogo
    labels:
    serving.knative.dev/visibility: cluster-local
    ...
    Request Path
    github.com/mchmarny/kdemo


    View Slide

30. Request Path
    Kubernetes Cluster
    Knative
    Frontend UI
    Internal
    Logo Service
    Internal
    User Service
    Vision API
    Firestore API
    User
    HTTPS
    demo
    OAuth
    HTTPS
    HTTPS


    View Slide

31. Day 2-n
    Service
    v2
    v1
    Initial deployment
    Traffic


    View Slide

32. Knative Object Model
    Revision 1
    Revision 2
    Revision 3
    Configuration
    Route
    Service
    Route - named endpoint and a
    mechanism for routing traffic
    Revisions - immutable snapshots
    of code + config
    Configuration - stream of
    environments for Revisions
    Service - top-level wrapper for
    managing Route/Configurations sets


    View Slide

33. # List current revisions in demo namespace (filter on service name)
    kubectl get revisions -n demo -l serving.knative.dev/service=maxprime
    NAME SERVICE NAME GENERATION READY
    maxprime-vq25k maxprime-vq25k-service 3 True
    maxprime-wtz1g maxprime-wtz1g-service 2 True
    maxprime-qtz5p maxprime-qtz5p-service 1 True
    # Edit revision in service traffic section
    # (status/traffic[n]/revisionName)
    kubectl edit ksvc maxprime -n demo
    Simple Revision Management


    View Slide

34. Blue/Green Revision Management
    Traffic
    Live Service
    Traffic
    # Initial state
    # Spin up “Blue”
    # version with
    # new code/features
    Live Service
    Traffic
    # Shift traffic over
    # from “Green” version
    # to new “Blue” version
    New Revision
    Live Service Old Revision (or Rollback)


    View Slide

35. apiVersion: serving.knative.dev/v1beta1
    kind: Service
    metadata:
    name: bg
    namespace: demo
    spec:
    template:
    spec:
    containers:
    - image: gcr.io/knative-samples/knative-route-demo
    Blue/Green (deployment)
    Service
    100%
    Revision
    Source: github.com/mchmarny/knative-demos


    View Slide

36. spec:
    template:
    metadata:
    name: bg-2
    ...
    traffic:
    - tag: current
    revisionName: bg-1
    percent: 100
    - tag: candidate
    revisionName: bg-2
    percent: 0
    - tag: latest
    latest Revision: true
    percent: 0
    Blue/Green (update)
    Service
    Revision (bg-2)
    Revision (bg-1)
    0% - bg-candidate.demo.knative.tech
    100% - bg.demo.knative.tech


    View Slide

37. ...
    traffic:
    - tag: current
    revisionName: bg-1
    percent: 50
    - tag: candidate
    revisionName: bg-2
    percent: 50
    - tag: latest
    latest Revision: true
    percent: 0
    Blue/Green (traffic split)
    Service
    Revision (bg-1)
    Revision (bg-2)
    90%
    80%
    70%
    60%
    50%
    40%
    60%
    50%
    40%
    30%
    20%
    10%


    View Slide

38. ...
    traffic:
    - tag: previous
    revisionName: bg-1
    percent: 100
    - tag: current
    revisionName: bg-2
    percent: 0
    - tag: latest
    latestRevision: true
    percent: 0
    Blue/Green (rollback)
    Service
    Revision (bg-1)
    Revision (bg-2)
    100%
    0%


    View Slide

39. gcloud alpha run services set-traffic maxprime \
    --to-revision maxprime-v1=90,maxprime-v2=10
    # Split traffic
    # across multiple
    # revisions
    Simpler Traffic Management
    source:
    github.com/mchmarny/ab-test-demo


    View Slide

40. Knative Eventing
    Functionality
    ● Orchestrates on/off cluster
    event sources
    ● Declaratively binds importers,
    brokers, triggers, and services
    ● Scales from just few events to
    live streaming pipelines
    ● Uses standard CloudEvents
    (CNCF Project)
    Integration
    ● Use existing event sources
    available or build your own
    ● Plugable channel provisioners
    (e.g. PubSub. Kafka, NATS,
    In-Memory)


    View Slide

41. Name Description
    Apache Camel Allows to use Apache Camel components for pushing events into Knative
    Apache Kafka Brings Apache Kafka messages into Knative
    AWS SQS Brings AWS Simple Queue Service messages into Knative
    Cron Job Uses an in-memory timer to produce events on the specified Cron schedule.
    GCP PubSub Brings GCP PubSub messages into Knative
    GitHub Brings GitHub organization/repository events into Knative
    GitLab Brings GitLab repository events into Knative.
    Google Cloud Scheduler Google Cloud Scheduler events in Knative when jobs are triggered
    Google Cloud Storage Brings Google Cloud Storage bucket/object events into Knative
    Kubernetes Brings Kubernetes cluster/infrastructure events into Knative
    source: https://github.com/knative/docs/tree/master/docs/eventing/sources
    Knative Event Importers (aka Sources)


    View Slide

42. CloudEvents
    {
    "specversion": "0.2",
    "type": "com.github.pull.create",
    "source": "https://github.com/cloudevents/spec/pull/123",
    "id": "A234-1234-1234",
    "time": "2019-04-08T17:31:00Z",
    "datacontenttype": "application/json",
    "data": "{ GitHub Payload... }"
    }
    FTP
    GitHub
    GCS
    Broker
    FTP Event Importer
    GitHub Event Importer
    GCS Event Importer
    CloudEvent


    View Slide

43. Namespace
    subscribe
    Trigger
    Service
    (Callable)
    Broker
    Trigger
    Service
    (Callable)
    subscribe
    filter=
    filter=
    Importer
    Events
    Importer
    Events
    ingress
    ingress
    publish
    ✓
    ✓ ✓
    Knative Eventing Objects


    View Slide

44. Knative Event Broker
    apiVersion: eventing.knative.dev/v1alpha1
    kind: Broker
    metadata:
    name: b1
    namespace: demo
    spec: {}
    status:
    address:
    hostname: b1-broker.demo.svc.cluster.local
    Simple Broker
    - 1-n per NS by default
    - Discoverable endpoint
    - Manages
    ● Channels
    ● Ingress filter/policy


    View Slide

45. Knative Event Trigger
    apiVersion: eventing.knative.dev/v1alpha1
    kind: Trigger
    metadata:
    name: build-status-slack-notifier
    spec:
    filter:
    sourceAndType:
    type: com.google.build.status
    subscriber:
    ref:
    apiVersion: serving.knative.dev/v1alpha1
    kind: Service
    name: slack-sender
    Simple Trigger
    - Uses CloudEvents
    - Supports Filtering
    - Can produce new events
    Build status Slack notifications demo: https://github.com/mchmarny/knative-build-status-notifs


    View Slide

46. Knative
    Eventing
    Demo
    Twitter
    Event Importer
    query: knative
    type: com.twitter
    Broker (default)
    Trigger
    type filter:
    com.twitter
    .negative
    Slack
    Publishing
    Service
    Slack
    Channel
    (#twitterback)
    Trigger
    type filter:
    com.twitter
    Sentiment
    Scoring
    Service
    Trigger
    type filter:
    com.twitter
    Event Store
    Service
    FireStore
    Collection
    knative-tweets
    Trigger
    type filter:
    com.twitter.
    positive
    Event Viewer
    (WebSocket)
    1. Save all tweets
    for reference
    2. Classify tweets
    based on sentiment
    4. Send negative to
    Slack for review
    5. Display positive
    tweets in UI
    1 2 4 5
    bit.ly/kn-tw-event
    Natural
    Language API
    replay


    Trigger
    type filter:
    com.twitter
    .noneng
    Sentiment
    Scoring
    Service
    3. Translate
    non-English tweets
    3
    Translation
    API


    View Slide

47. * Cron job importer to wire up weekly report
    * Process IoT Core events
    * GCP PubSub (connector to many other GCP event sources)
    * Actuate on Kubernetes events (beyond webhook)
    * Declarative GitHub webhook processing
    ...
    # samples
    bit.ly/kn-event-samples
    Knative Eventing Use-cases


    View Slide

48. In Closing
    Infrastructure
    Primitives Knative
    Kubernetes
    Knative-based Products
    Optimized
    Experience


    View Slide

49. Docs, Blog, Community
    knative.dev
    Quick Start
    bit.ly/cr-gke
    Source & Samples
    github.com/knative
    Questions?
    slack.knative.dev
    Anything else
    @mchmarny


    View Slide
