Digital Making & Physical Computing for Parents

Digital Making & Physical Computing for Parents

Because you have no idea what just happened but now your kids are enthusiastic and keep asking questions….

Carrie Anne Philbin

September 17, 2016
Tweet

More Decks by Carrie Anne Philbin

Other Decks in Education

Transcript

  1. Digital Making
    is for everyone

    View Slide

  2. View Slide

  3. View Slide

  4. View Slide

  5. View Slide

  6. View Slide

  7. View Slide

  8. The computing curriculum
    “From 5, children will learn to code and program, with algorithms,
    sequencing, selection and repetition;
    from 11, how to use at least 2 programming languages to solve
    computational problems; to design … computational abstractions that
    model the state and behaviour of real-world problems and physical
    systems; and how instructions are stored and executed within a computer
    system.”
    Michael Gove - UK Secretary for Education
    new
    ex
    v
    v

    View Slide

  9. The Raspberry Pi Foundation
    The Raspberry Pi Foundation is a registered educational
    charity (registration number 1129409) based in the UK.
    The Raspberry Pi Foundation works to put the power of digital making
    into the hands of people all over the world, so they are capable of
    understanding and shaping our increasingly digital world, able to solve
    the problems that matter to them, and equipped for the jobs of the future.

    View Slide

  10. Raspberry Pi 3 Raspberry Pi Zero BBC micro:bit
    - A desktop replacement
    - $35
    - Bluetooth wifi
    - Plug into a TV or monitor
    with HDMI
    - USB keyboard & Mouse
    - 40 GPIO pins
    - A desktop replacement
    - $5
    - Camera port
    - Requires an accessories
    kit to use with HDMI and
    USB
    - Need to solder the GPIO
    pins
    - Not a desktop
    replacement.
    - Free (for yr 7 students in
    2016) or £14
    - Can be programmed from
    another computer
    - LED matrix, buttons, GPIO
    Physical computing devices

    View Slide

  11. Physical computing devices
    Code Bug Arduino Adafruit Circuit Playground
    - Works in the same way as
    Microbit
    - £14
    - Lots of free resources
    - Has some cool accessories
    like the star
    - Coin cell battery holder
    - Used for more advanced
    electronics and robotics
    - Different boards available
    - Programmed using C or
    Processing
    - Some python libraries
    available
    - Works in the same way as
    Microbit.
    - Great for wearables
    - Includes light sensors
    temp sensor, microphone
    and neopixels
    - Programmed using C or
    Processing.

    View Slide

  12. Let’s get Physical
    with Raspberry Pi and Python

    View Slide

  13. View Slide

  14. Hello World with LEDs
    from gpiozero import LED
    import time
    led = LED(17)
    led.on()
    time.sleep(1)
    led.off()

    View Slide

  15. Fart machines with buttons
    from gpiozero import Button
    import time
    import os, random
    Button = Button(2)
    trumps = ['silly.wav', 'wind.wav', 'raspb.wav']
    while True:
    button.wait_for_press()
    parp = random.choice(trumps)
    os.system("aplay {0}".format(parp))
    time.sleep(2)

    View Slide

  16. Resources

    View Slide

  17. Open
    Source
    is
    Awesom
    e Sauce

    View Slide

  18. View Slide

  19. What do children think?

    View Slide

  20. View Slide

  21. Books to help

    View Slide

  22. The future?

    View Slide

  23. Carrie Anne Philbin
    Award Winning Educator, Author & YouTuber
    @MissPhilbin
    @GeekGurlDiaries
    Director of Education
    Raspberry Pi Foundation

    View Slide

  24. Carrie Anne Philbin
    @MissPhilbin

    View Slide
