1. Introduction to the Linux Block I/O Layer Johannes Thumshirn – SUSE Labs jthumshirn@suse.de
2. 2 Agenda • I/O Architecture • Scalability issues • Single Queue vs. Multi Queue • Queue depth vs. Multiple queues
3. 3 I/O Architecture (simplified) Buffer cache VFS File System Disk Block Layer Device Driver SCSI ML Application Userspace Kernel
4. 4 Submission Handling (SQ) • Per-process pluglist ‒ Analogy of a plug in a kitchen sink • I/O – Scheduler ‒ NOOP ‒ Deadline ‒ CFQ • Dispatch queue
5. 5 Scalability Issues App CPU 1 App CPU 2 App CPU 3 App CPU 4 File System Block Layer Driver
6. 6 Single Queue vs. Multiple Queues • Software queues are per-cpu ‒ No more globally shared state → no lock contention • Software queues are mapped to hardware queues ‒ Only very few devices support multiple queues • Completion IRQs on “submission-local” CPU ‒ Reduction of IPIs ‒ Keep cache lines hot • Drawback: No I/O scheduler
7. 7 Queue Depth vs. Multiqueue CPU CPU CPU CPU CPU Req “ classic” single queue CPU CPU Req 1 Req 2 Req 3 Req 4 Req 5 Req N ... Req 1 Req 2 Req 3 Req 4 Req 5 Req N ... Req 1 Req 2 Req 3 Req 4 Req 5 Req N ... Req 1 Req 2 Req 3 Req 4 Req 5 Req N ... single queue with TCQ/NCQ ... ... ... ... ... ... ... multi queue
8. 8 Request tagging https://upload.wikimedia.org/wikipedia/commons/6/6a/Peg_dhcp_from_what_the_hack_holland_2005.jpg
9. 9 Software Queues vs. Hardware Queues APP SW Q SW Q SW Q SW Q HW Q HW Q HW Q HW Q APP SW Q SW Q SW Q SW Q
10. 10 References • Jan Kara @ Kernel recipes 2015 ‒ https://youtu.be/2tu__ZHC0mI • Jens Axboe @ Kernel recipes ‒ https://youtu.be/VIdKBD9-Ozg
11. Questions?
