Fully asynchronous queue solution with Kafka

Ondrej Vesely at Kiwi.com Brno-Moscow Python Meetup

"Showcase: Let's say we want to have an API endpoint which saves data stream with very variable flow to Postgresql. We'll use Kafka queue and various async modules like asyncio, aiokafka and aiopg with Python 3.6 syntax sugar. Based on real-case scenario"

Video: http://www.moscowpython.ru/meetup/1/fully-asynchronous-queue-solution-with-kafka/

Transcript

1. Queue with
   asyncio and Kafka
   Showcase
   Ondřej Veselý Kiwi.com


   View Slide

2. What kind of data we have


   View Slide

3. Problem:
   store JSON to database
   Just a few records
   per second.
   But
   ● Slow database
   ● Unreliable database
   ● Increasing traffic (20x)


   View Slide

4. def save_data(conn, cur, ts, data):
   cur.execute(
   """INSERT INTO data (timestamp, data)
   VALUES (%s,%s) """, (ts, ujson.dumps(data)))
   conn.commit()
   @app.route('/store', method=['PUT', 'POST'])
   def logstash_route():
   data = ujson.load(request.body)
   conn = psycopg2.connect(**config.pg_logs)
   t = datetime.now()
   with conn.cursor(cursor_factory=DictCursor) as cur:
   for d in data:
   save_data(conn, cur, t, d)
   conn.close()
   Old code


   View Slide

5. Architecture
   internet
   Kafka producer
   /store
   Kafka consumer
   Kafka queue
   Postgres
   … time to kill consumer ...


   View Slide

6. Asyncio, example
   import asyncio
   async def factorial(name, number):
   f = 1
   for i in range(2, number+1):
   print("Task %s: Compute factorial(%s)..." % (name, i))
   await asyncio.sleep(1)
   f *= i
   print("Task %s: factorial(%s) = %s" % (name, number, f))
   loop = asyncio.get_event_loop ()
   tasks = [
   asyncio.ensure_future(factorial("A", 2)),
   asyncio.ensure_future(factorial("B", 3)),
   asyncio.ensure_future(factorial("C", 4))]
   loop.run_until_complete (asyncio.gather(*tasks))
   loop.close()
   Task A: Compute factorial(
   2)...
   Task B: Compute factorial(
   2)...
   Task C: Compute factorial(
   2)...
   Task A: factorial(
   2) = 2
   Task B: Compute factorial(
   3)...
   Task C: Compute factorial(
   3)...
   Task B: factorial(
   3) = 6
   Task C: Compute factorial(
   4)...
   Task C: factorial(
   4) = 24


   View Slide

7. What we used
   Apache Kafka
   Not ujson
   Concurrency - doing lots of slow things at once.
   No processes, no threads.
   Producer
   from aiohttp import web
   import json
   Consumer
   import asyncio
   import json
   from aiokafka import AIOKafkaConsumer
   import aiopg


   View Slide

8. Producer #1
   async def kafka_send(kafka_producer , data, topic):
   message = {
   'data': data,
   'received': str(arrow.utcnow())
   }
   message_json_bytes = bytes(json.dumps(message), 'utf-8')
   await kafka_producer .send_and_wait(topic, message_json_bytes )
   async def handle(request):
   post_data = await request .json()
   try:
   await kafka_send (request.app['kafka_p'], post_data,
   topic=settings.topic)
   except:
   slog.exception("Kafka Error")
   await destroy_all ()
   return web.Response(status=200)
   app = web.Application()
   app.router.add_route('POST', '/store', handle)


   View Slide

9. Destroying the loop
   async def destroy_all():
   loop = asyncio.get_event_loop ()
   for task in asyncio.Task.all_tasks():
   task.cancel()
   await loop .stop()
   await loop .close()
   slog.debug("Exiting.")
   sys.exit()
   def get_kafka_producer ():
   loop = asyncio.get_event_loop ()
   producer = AIOKafkaProducer (
   loop=loop,
   bootstrap_servers =settings.queues_urls,
   request_timeout_ms =settings.kafka_timeout,
   retry_backoff_ms =1000)
   loop.run_until_complete (producer.start())
   return producer
   Getting producer
   Producer #2


   View Slide

10. Consume
    … time to resurrect consumer ...
    DB
    connected
    1. Receive data record from Kafka
    2. Put it to the queue
    start
    yes
    no
    Flush
    queue full enough
    or
    data old enough
    Store data from queue to DB
    yes
    no
    Connect to DB
    start
    asyncio.Queue()
    Consumer #1


    View Slide

11. def main():
    dbs_connected = asyncio.Future()
    batch = asyncio.Queue(maxsize=settings.batch_max_size )
    asyncio.ensure_future(consume(batch, dbs_connected ))
    asyncio.ensure_future(start_flushing (batch, dbs_connected ))
    loop.run_forever()
    async def consume(queue, dbs_connected ):
    await asyncio .wait_for(dbs_connected, timeout=settings.wait_for_databases )
    consumer = AIOKafkaConsumer (
    settings .topic, loop=loop, bootstrap_servers =settings.queues_urls,
    group_id ='consumers'
    )
    await consumer .start()
    async for msg in consumer:
    message = json.loads(msg.value.decode("utf-8"))
    await queue .put((message.get('received'), message.get('data')))
    await consumer .stop()
    Consumer #2


    View Slide

12. async def start_flushing(queue, dbs_connected):
    db_logg = await aiopg.create_pool(settings.logs_db_url)
    while True:
    async with db_logg.acquire() as logg_conn, logg_conn.cursor() as logg_cur:
    await keep_flushing
    (dbs_connected, logg_cur, queue)
    await asyncio
    .sleep(2)
    async def keep_flushing(dbs_connected, logg_cur, queue):
    dbs_connected.set_result(True)
    last_stored_time = time.time()
    while True:
    if not queue.empty() and (queue.qsize() > settings.batch_flush_size or
    time
    .time() - last_stored_time > settings.batch_max_time):
    to_store = []
    while not queue.empty():
    to_store
    .append(await queue.get())
    try:
    await store_bulk
    (logg_cur, to_store)
    except:
    break # DB down, breaking to reconnect
    last_stored_time = time.time()
    await asyncio
    .sleep(settings.batch_sleep)
    Consumer #3


    View Slide

13. Code is public on gitlab
    https://gitlab.skypicker.com/ondrej/faqstorer
    www.orwen.org ← this is me
    code.kiwi.com ← devs community around Kiwi.com
    Check graphs...
