End-to-End Encryption in Elixir with Ockam

Machines, within distributed applications, operate by exchanging messages with cloud services and other remote machines. Secure, private, and trustworthy connected applications must protect these messages from eavesdropping, tampering, and forgery.

Ockam is a suite of open source programming libraries and infrastructure that make it simple for applications to dynamically create end-to-end encrypted, mutually authenticated, granularly authorized, lightweight secure channels that protect messages, end-to-end — from their source to their destination.

This enables secure communication between application layer entities that are not directly connected by simple point-to-point transport connections. En-route encrypted messages can travel over multiple transport layer connections and can be stored in message queues, databases or caches for asynchronous, end-to-end protected communication between entities that may not be online at the same time.

In this talk, we’ll dive into the design of Ockam’s Elixir libraries and the protocols they implement to provide end-to-end secure and private communication.

Transcript

1. End-to-End Encryption


   in Elixir with Ockam
   Mrinal Wadhwa
   CTO, Ockam
   mrinal


   View Slide

2. Verb
   Subject Object
   Allow / Deny


   View Slide

3. Action
   Subject Resource
   Allow / Deny


   View Slide

4. View Slide

5. The operating environment of a typical application looks like this.
   Internet
   Infra
   Network
   Machine
   Application


   View Slide

6. The operating environment of a typical application looks like this.
   Internet
   Application
   Cloud / Data Center / Home / Hospital / Factory …
   VPC / Kubernetes / NAT / Edge / No-IP wireless / Industrial
   VM / Container / K8s Pod / Rack Server / IoT


   Industrial / Embedded / Edge Device


   View Slide

7. Distributed applications work by sending each other messages across networks, over the Internet.
   Internet
   Infra
   Network
   Machine
   Application
   Internet
   Infra
   Network
   Machine
   Application
   Data, Commands,
   Acknowledgments, Configuration
   & Software Updates


   View Slide

8. To be secure both sides must check incoming messages for integrity and authenticity.
   Internet
   Infra
   Network
   Machine
   Application
   Internet
   Infra
   Network
   Machine
   Application
   Message Integrity & Authenticity
   Sender Identi
   fi
   cation & Authentication
   Authorization
   There is a complex set of cryptographic protocol guarantees that go into delivering those checkmarks.


   View Slide

9. To ensure user privacy and to protect business data both sides must have control of data con
   fi
   dentiality and access.
   Internet
   Infra
   Network
   Machine
   Application
   Internet
   Infra
   Network
   Machine
   Application
   Message Integrity & Authenticity
   Sender Identi
   fi
   cation & Authentication
   Authorization
   Con
   fi
   dentiality
   There is a complex set of cryptographic protocol guarantees that go into delivering those checkmarks.


   View Slide

10. Internet
    Infra
    Firewalls / VPN / TLS termination
    Machine
    Application
    Internet
    Infra
    Machine
    Application
    Traditional approach is to check our message guarantees at network boundaries.
    Firewalls / VPN / TLS termination


    View Slide

11. Internet
    Infra
    VPN
    Internet
    Infra
    VPN
    But network boundaries typically have hundreds of machines and thousands of applications within them.


    View Slide

12. Internet
    Infra
    VPN
    Internet
    Infra
    VPN
    All code in both networks must have no weaknesses for an application developer’s work to be secure.


    View Slide

13. Lab 1
    Lab 2
    Lab 500
    Cloud AZ 1
    Cloud AZ 2
    Data Center 1
    Data Center 2
    All code in all deployment networks must have no weaknesses for an application developer’s work to be secure.


    View Slide

14. Lab 1
    Lab 2
    Lab 500
    Cloud AZ 1
    Cloud AZ 2
    Data Center 1
    Data Center 2
    Gateways
    Event Streams
    Pub/Sub Queues
    All code in all deployment networks and all service provider networks must have no weaknesses for an application developer’s work to be secure.
    This also violates the principle of least privilege


    View Slide

15. Goal: Dependable, Trustworthy, Reliable applications
    To build a secure and private application that can be trusted by users and customers - we need to minimize the chances
    (vulnerability surface) of someone tricking our application into doing something undesirable.
    Big vulnerability surface is bad. Tiny vulnerability surface is good.


    View Slide

16. End-to-End Encrypted, Mutually Authenticated, Secure Channels


    enable granular authorization decisions at the application layer.


    View Slide

17. View Slide

18. View Slide

19. View Slide

20. Sender:


    • Needs to know the route to a destination, makes that route the onward_route of a new message


    • Makes its own address the the return_route of the new message
    Replier:


    • Makes return_route of incoming message, onward_route of outgoing message


    • Makes its own address the the return_route of the new message


    View Slide

21. View Slide

22. View Slide

23. View Slide

24. View Slide

25. View Slide

26. Sender:


    • Needs to know the route to a destination, makes that route the onward_route of a new message


    • Makes its own address the the return_route of the new message
    Hop:


    • Removes its own address from beginning of onward_route


    • Adds its own address to beginning of return_route
    Replier:


    • Makes return_route of incoming message, onward_route of outgoing message


    • Makes its own address the the return_route of the new message


    View Slide

27. View Slide

28. View Slide

29. View Slide

30. View Slide

31. View Slide

32. View Slide

33. View Slide

34. View Slide

35. Initiator
    Responder
    app echoer
    4000


    View Slide

36. View Slide

37. View Slide

38. View Slide

39. Initiator
    Responder
    app echoer
    4000


    View Slide

40. Middle
    Responder
    h1 echoer
    4000
    Initiator
    app
    3000


    View Slide

41. View Slide

42. View Slide

43. View Slide

44. View Slide

45. Middle
    Responder
    h1 echoer
    4000
    Initiator
    app
    3000


    View Slide

46. Initiator Responder
    Shared Secret Shared Secret
    M1
    M2
    M3
    M4
    M5
    The shared secret is then used as a key in Symmetric Key Cryptography to
    maintain con
    fi
    dentiality and integrity of application data.
    Application Data - Authenticated Encryption
    The entities involved use Public Key Cryptography to authenticate
    each other and agree on a shared secret.
    Authenticated Key Exchange


    View Slide

47. Middle
    Responder
    h1 echoer
    4000
    Initiator
    app
    3000


    View Slide

48. View Slide

49. View Slide

50. View Slide

51. View Slide

52. Middle
    Responder
    h1 echoer
    4000
    Initiator
    app
    3000


    View Slide

53. Middle
    Responder
    h1 echoer
    4000
    Initiator
    app
    3000


    View Slide

54. Middle
    Responder
    Forwarder
    echoer
    4000
    Initiator
    app
    3000


    View Slide

55. View Slide

56. View Slide

57. View Slide

58. View Slide

59. Middle
    Responder
    Forwarder
    echoer
    4000
    Initiator
    app
    3000


    View Slide

60. View Slide

61. View Slide

62. View Slide

63. View Slide

64. View Slide

65. Mrinal Wadhwa
    CTO, Ockam
    mrinal
    github.com/ockam-network/ockam
    github.com/ockam-network/ockam/tree/develop/examples/elixir/get_started
    All code examples from this talk:
