End-to-end encryption with BEAM and Elixir

End-to-end encryption with BEAM and Elixir

Mrinal Wadhwa

May 28, 2021
Tweet

More Decks by Mrinal Wadhwa

Other Decks in Programming

Transcript

  1. of messages-in-transit Security

  2. Mrinal Wadhwa CTO, Ockam mrinal github.com/ockam-network/ockam

  3. Actor Model The

  4. Start A C B Transition 1 Transition 2 Transition 3

    Sense Act Infer
  5. Edge Inference Start A C B Transition 1 Transition 2

    Transition 3 Cloud Inference
  6. Device Edge Cloud

  7. of messages-in-transit Security

  8. Messages, within modern applications, rarely flows over a single, direct,

    point-to-point transport connection. Client Server TCP
  9. Client Server TCP

  10. Client Load Balancer HTTP over TCP Server Server Server HTTP

    over TCP
  11. Client API Gateway Microservice Microservice Microservice Microservice

  12. Client Ingress Gateway Microservice Microservice Microservice Microservice Load Balancer

  13. Client Microservice Microservice Microservice Microservice Message Broker

  14. Client Microservice Microservice Microservice Microservice Externa l Message Broke r

    as a service
  15. Client Microservice Externa l Message Broke r as a service

    External Service Microservice Microservice Microservice
  16. Client Microservice Microservice Microservice Microservice Message Broker LPWAN Gateway Radio

    Protocol
  17. Client Microservice Microservice Microservice Microservice Message Broker Edge Message Broker

    Microservice Microservice Microservice Microservice Data Center
  18. of messages-in-transit Security

  19. Messages, within modern applications, rarely flows over a single, direct,

    point-to-point transport connection.
  20. THREAT DESIRED PROPERTY S Spoo fi ng identity Identi fi

    cation, Authentication T Tampering with data Integrity R Repudiation Non-repudiability (some applications desire the opposite) I Information disclosure Con fi dentiality D Denial of service Availability E Elevation of privilege Authorization Note that this model is very high level, there is massive amounts of nuance in dealing with each of the rows. The STRIDE threat model can help us evaluate every message.
  21. Trust in Network Boundaries

  22. Client Load Balancer HTTP over TCP Server Server Server HTTP

    over TCP
  23. Client Microservice Microservice Microservice Microservice Message Broker

  24. None
  25. • The network is always assumed to be hostile. •

    External and internal threats exist on the network at all times. • Network locality is not sufficient for deciding trust in a network. • Every device, user, and network flow is authenticated and authorized. • Policies must be dynamic & calculated from as many sources of data as possible. Zero Trust in network perimeters. A zero trust network is built upon five fundamental assertions:
  26. None
  27. Transport Layer Security

  28. Messages, within modern applications, rarely flows over a single, direct,

    point-to-point transport connection.
  29. TLS is tightly coupled with the length and duration of

    the underlying TCP connection.
  30. Data integrity and confidentiality guarantees are lost at every transport

    connection hop.
  31. Principle of Least Privilege Every program and every privileged user

    of the system should operate using the least amount of privilege necessary to complete the job.” — Jerome Saltzer, Communications of the ACM, 1974 “
  32. Trust is an application layer concern.

  33. Secure Channels

  34. Initiator Responder Shared Secret Shared Secret M1 M2 M3 The

    shared secret is then used as a key in Symmetric Key Cryptography to maintain con fi dentiality and integrity of application data. Application Data - Authenticated Encryption The entities involved use Public Key Cryptography to authenticate each other and agree on a shared secret. Authenticated Key Exchange D Secure Channel
  35. None
  36. TLS IP TCP Application

  37. TLS TCP Application TCP Application Ockam Routing Ockam Secure Channels

    IP IP
  38. TCP Application Ockam Routing Ockam Secure Channels IP

  39. TCP Application Ockam Routing Ockam Secure Channels IP UDP WebSocket

    HTTP
  40. TCP Application Ockam Routing Ockam Secure Channels IP UDP WebSocket

    HTTP Bluetooth LPWAN
  41. Create a Worker

  42. Create a Worker

  43. Create a routable message.

  44. Route the message.

  45. Create a TCP transport listener

  46. Create a TCP transport connection

  47. Create a routable message.

  48. Route the message.

  49. None
  50. None
  51. None
  52. None
  53. End-to-end Encryption

  54. THREAT DESIRED PROPERTY S Spoo fi ng identity Identi fi

    cation, Authentication T Tampering with data Integrity R Repudiation Non-repudiability (some applications desire the opposite) I Information disclosure Con fi dentiality D Denial of service Availability E Elevation of privilege Authorization Note that this model is very high level, there is massive amounts of nuance in dealing with each of the rows. The STRIDE threat model can help us evaluate every message.
  55. Heart Rate Monitor Heart Rate Application

  56. Heart Rate Monitor Heart Rate Application

  57. Heart Rate Monitor Heart Rate Service Heart Rate Application

  58. Heart Rate Monitor Heart Rate Service 80 bpm Heart Rate

    Application
  59. Heart Rate Monitor Heart Rate Service 80 bpm Heart Rate

    Application
  60. The phone may not be online all the time so

    the service also caches this data to deliver it later … Heart Rate Monitor Heart Rate Service 80 bpm Heart Rate Application
  61. Heart Rate Monitor Heart Rate Service Transport Layer Security Transport

    Layer Security Since these devices have direct access to the internet, with TLS … Heart Rate Application
  62. Heart Rate Monitor Heart Rate Service 80 bpm Transport Layer

    Security Transport Layer Security Heart Rate Application
  63. Heart Rate Monitor Heart Rate Service 80 bpm 0x217c5111… Transport

    Layer Security Transport Layer Security Heart Rate Application
  64. Heart Rate Monitor Heart Rate Service 80 bpm 0x217c5111… 80

    bpm Transport Layer Security Transport Layer Security Heart Rate Application
  65. Heart Rate Monitor Heart Rate Service 80 bpm 0x217c5111… 80

    bpm 0x8621f842… Transport Layer Security Transport Layer Security Heart Rate Application
  66. Heart Rate Monitor Heart Rate Service 80 bpm 0x217c5111… 80

    bpm 0x8621f842… 80 bpm This type of setup is industry best practice. Transport Layer Security Transport Layer Security Heart Rate Application
  67. Heart Rate Monitor Heart Rate Service 80 bpm 0x217c5111… 80

    bpm 0x8621f842… 80 bpm But even when we manage to setup the channels correctly the data is still exposed to the service.
 The service doesn’t need to know the contents of the message to route and cache messages (its primary job). Transport Layer Security Transport Layer Security Heart Rate Application
  68. Heart Rate Monitor Heart Rate Application Heart Rate

  69. Route on/off instructions. Connected Outlet Connected Outlet Application Connected Outlet

    Service
  70. Route open/close instructions. Connected Lock Connected Lock Application Connected Lock

    Service
  71. Route/Cache sensor data, alerts and videos. Camera Door Bell Camera

    Door Bell Application Camera Door Bell Service
  72. Gateway Flood Warning Sensor Multiple transport protocols in the path

    of one message. TCP TCP Flood Monitoring System Sensors Vendor’s Service LPWAN
  73. Gateway Flood Warning Sensor Flood Monitoring System Sensors Vendor’s Service

    Various protocols have various different secure channel designs. TLS TLS LPWAN
  74. Gateway Flood Warning Sensor A secure channel that is decoupled

    from the transport layer connections.
 The gateway and sensor vendor shouldn’t be exposed to application data. Flood Monitoring System Sensors Vendor’s Service
  75. D D D … Devices … … Gateways … Lighting

    HVAC Water Monitoring Elevators Access Control Fire Safety Waste Parking … Vendor IoT Backends … System Integrator 1 Building Management System … SI IoT Backends … System Integrator 2 G G D D D D D D D D D D D D D D D D D D D D D G G G G G G G G G G G G G G Complexity & attack surfaces grow to be unmanageable. Proprietary data is leaked. Security becomes untenable.
  76. D D D … Devices … … Gateways … Lighting

    HVAC Water Monitoring Elevators Access
  77. None
  78. Provable Change Events

  79. Privacy contexts & Identity Profiles

  80. Selective Disclosure

  81. Anonymous Credentials

  82. Trust Policies

  83. Fleet Enrollment

  84. Mrinal Wadhwa CTO, Ockam mrinal github.com/ockam-network/ockam
