  1. 454
    RIP: 2005 - 2013

    View Slide

  2. The test of time
    454
    Illumina
    PacBio
    SOLiD
    Ion Torrent
    ONP
    100
    1,000
    10,000
    100,000
    1,000,000
    10,000,000
    1132
    46559
    23063
    30288
    3318279
    265436
    Number of SRA entries (Jan 2018)

    View Slide

  3. The first NGS
    ‣ Pyrosequencing
    ‣ 454 Process
    ‣ Multiplexing
    ‣ Paired end sequencing

    View Slide

  4. Nucleotide chemistry

    View Slide

  5. Polymerization

    View Slide

  6. Ligation

    View Slide

  7. Three ATP-like derivatives
    ATP
    dATPαS
    A 5' phosphosulfate
    (APS)

    View Slide

  8. Pål Nyrén

    View Slide

  9. The 4 enzymes of pyrosequencing

    View Slide

  10. Pyrosequencing process

    View Slide

  11. Output

    View Slide

  12. 454
    Library preparation
    Emulsion
    PCR
    Deposition
    sequencing reaction

    View Slide

  13. View Slide

  14. Jonathan Rothberg

    View Slide

  15. Library preparation
    dsDNA
    fragments
    P
    A B
    Ligatio
    n
    Fill
    in
    Capture on SA-Beads &
    Wash
    Alkaline Elution
    A B
    P Bio
    Bio
    Bio
    Bio
    Bio
    Primer A Key Library fragment Primer B
    #bases: 40 4
    Standard
    Library
    Seq. primer Read

    View Slide

  16. Emulsion PCR
    UCSC Sequencing Center
    Mix DNA Library
    & capture beads
    (limited dilution)
    “Break micro-reactors”
    Isolate DNA containing beads
    •  Generation of millions of clonally amplified sequencing templates on each bead
    •  No cloning and colony picking
    Create
    “Water-in-oil”
    emulsion
    + PCR Reagents
    + Emulsion Oil
    Perform emulsion PCR
    Adapter carrying
    library DNA
    A
    B
    Micro-reactors

    View Slide

  17. Deposition
    UCSC Sequencing Center
    Centrifuge Step
    Load Enzyme
    Beads
    44 µm
    Load beads into
    PicoTiter™Plate

    View Slide

  18. Sequencing
    UCSC Sequencing Center
    DNA Capture Bead
    Containing Millions of
    Copies of a Single
    Clonal Fragment
    A A T C G G C A T G C T A A A A G T C A
    Anneal Primer
      Simultaneous sequencing of the entire genome in hundreds of
    thousands of picoliter-size wells
      Pyrophosphate signal generation
    T
    PP
    i
    ATP
    Light + oxy luciferin
    Sulfurylase
    Luciferase
    APS
    luciferin

    View Slide

  19. The machine
    ‣ dNTP flow (dATPαS
    instead of dATP)
    ‣ Substrate flow (D-
    luciferin, APS etc)
    ‣ Apyrase flow (destroys
    triphosphates)
    Margulies et al. 2005

    View Slide

  20. Output
    Margulies et al. 2005

    View Slide

  21. Margulies et al. 2005

    View Slide

  22. Feb 2014

    View Slide

  23. Multiplexing
    UCSC Sequencing Center
    Primer A MID 1
    Key Library fragment Primer B
    Seq. primer Read
    #bases: 15 4 10
    Primer A Key Library fragment Primer B
    #bases: 40 4
    MID
    Library
    Standard
    Library
    Seq. primer Read
    Primer A MID 2
    Key Library fragment Primer B
    Primer A MID n
    Key Library fragment Primer B

    View Slide

  24. Mate-pair with 454
    UCSC Sequencing Center

    View Slide

  25. Flow value separation
    Balzer et al. 2010

    View Slide

  26. Flow value separation
    Balzer et al. 2010

    View Slide

  27. Errors in 454 data

    View Slide

  28. Errors in 454 data
    ‣ incomplete homopolymer extension
    ‣ carry forward incomplete extension
    (CAFIE)

    View Slide

  29. Base/Read qualities
    Huse et al. 2007

    View Slide

  30. Length versus Error rate
    Huse et al. 2007

    View Slide

  31. View Slide

  32. View Slide
