Graft: A Tool for Debugging and Testing Apache Giraph Programs

Presentation given at the 2nd Giraph & Graph Analytics Meetup at Facebook.

https://github.com/semihsalihoglu/graft
http://doi.acm.org/10.1145/2723372.2735353

Transcript

1. Graft* A Tool for Debugging and Testing
 Apache Giraph Programs
 Jaeho Shin <jaeho@cs.stanford.edu>
 Graph Analytics Meetup @ Facebook Aug 24, 2015 * https://github.com/semihsalihoglu/graft Joint work with Semih Salihoglu, Vikesh Khanna, Ba Quan Truong, and Jennifer Widom
2. Pregel Review Vertex Program 2 incoming message incoming message incoming message vertex state (value, isHalted) superstep = 0 superstep = n superstep = n-1 … outgoing message outgoing message
3. Problem “Debugging vertex program is hard!” — from interviews of Giraph and GPS users Most programmers rely on print() statements! Typical debuggers not useful for distributed programs. 3
4. Goal A replay-style debugger for Giraph • no need to change code for debugging • easy browsing of what’s going on • easy line-by-line replay of the vertex program • option to specify what to capture programmatically 4
5. Graft Streamlines user’s manual steps: 1. Capture 2. Visualize 3. Reproduce 5
6. Running Giraph Programs 6 Worker1 Worker2 Workern … Giraph Program Giraph HDFS Input Output $ hadoop jar \ target/giraph-examples.jar org.apache.giraph.GiraphRunner \ org.apache.giraph.examples.SimpleShortestPathsComputation \ # more command line arguments ...
7. Graft “Capture” 7 HDFS Worker1 Worker2 Workern … DebugConfig Giraph Program Graft Instrumenter Giraph Instrumented Giraph Program Captured Traces Input Output $ giraph-debug DebugConfig \ target/giraph-examples.jar org.apache.giraph.GiraphRunner \ org.apache.giraph.examples.SimpleShortestPathsComputation \ # more command line arguments ...
8. Graft “Capture” 8 public class DebugConfig { boolean shouldDebugSuperstep(long s) { return s < 10; } int numberOfRandomVerticesToCapture() { return 5; } boolean shouldCaptureNeighborsOfVertices() { return true; } boolean shouldCatchExceptions() { return false; } boolean shouldDebugVertex(Vertex v, long superstep) { ... } boolean isVertexValueCorrect(ID vertexId, Value val) { ... } boolean isMessageCorrect(Message msg, ID srcID, ID dstID, int superstep) { return msg.value >= 0; } ... } $ giraph-debug -S{0..9} -R5 -V{1,3,5,7,9} -N -E \ target/giraph-examples.jar org.apache.giraph.GiraphRunner \ org.apache.giraph.examples.SimpleShortestPathsComputation \ # ... DebugConfig example Command-line options
9. Graft “Visualize” 9 HDFS Worker1 Worker2 Workern … DebugConfig Giraph Program Giraph Instrumented Giraph Program Captured Traces Input Graft GUI Visualizations Output
10. Graft “Visualize” 10
11. Graft “Visualize” 11
12. Graft “Reproduce” 12 HDFS Worker1 Worker2 Workern … DebugConfig Giraph Program Giraph Instrumented Giraph Program Captured Traces Input Graft Context Reproducer JUnit Test Cases Output
13. Graft “Reproduce” 13
14. Graft “Reproduce” 14
15. Debugging with Graft 15 HDFS Worker1 Worker2 Workern … DebugConfig Giraph Program Graft Instrumenter Giraph Instrumented Giraph Program Captured Traces Input Graft GUI Graft Context Reproducer JUnit Test Cases Visualizations Output
16. Giraph Giraph API 16 User’s Vertex Program compute() AbstractComputation sendMessage() Worker extends calls calls runs
17. Graft Giraph Graft Instrumentation 17 User’s Vertex Program compute() AbstractComputation sendMessage() Worker Bottom Interceptor Top Interceptor compute() sendMessage() extends extends extends calls calls capture
 (inMsgs, valBefore, valAfter) capture
 (outMsgs) runs
18. Graft Instrumentation • Using Javassist • Caching instrumented jars on HDFS for faster reruns and reliable reproduction • Short-circuits to reduce instrumentation overhead • Asynchronous HDFS writes 18
19. Performance Overhead 0 0.5 1 1.5 2 GC-bipartite MWM-sk RW-tw Relative Runtime to 'no-debug' Algorithm & Graph Overhead of Graft no-debug DC-sp DC-sp+nbr DC-msg DC-vv DC-full 0 0 0 305 209 34 911 62747 2291 103 1 1 310375 1 13503 1246151 237467 24213 19
20. Performance Overhead 0 0.5 1 1.5 2 GC-bipartite MWM-sk RW-tw Relative Runtime to 'no-debug' Algorithm & Graph Overhead of Graft no-debug DC-sp DC-sp+nbr DC-msg DC-vv DC-full 0 0 0 305 209 34 911 62747 2291 103 1 1 310375 1 13503 1246151 237467 24213 20 Acceptable! Wall clock time Usually ~15% Less than 30% when fully capturing 1.2M (~18GB)
21. Limitations • Capturing states kept outside Giraph API • Capturing unread Aggregators • Instrumentation not perfect • DebugConfig expressivity limited to single vertex • Can’t filter outgoing messages by recipient’s state 21
22. Extra Features • MasterCompute debugging • End-to-end test input generation (GUI) 22
23. Summary Graft is a debugger for Apache Giraph programs • Streamlines Capture-Visualize-Reproduce process • Requires little effort to use (no change to code!) • Has acceptable performance overhead (20-30%) • Helps creating end-to-end test input graphs 23
24. Pointers • https://github.com/semihsalihoglu/graft • Our SIGMOD ’15 Paper:
 Semih Salihoglu, Jaeho Shin, Vikesh Khanna, Ba Quan Truong, and Jennifer Widom.
 Graft: A Debugging Tool For Apache Giraph. 24
