Stupid Graphite Tips
My Ignite talk from DevOpsDays Portland on November 4, 2013.
Jason Dixon
November 04, 2013
Tweet
Share
More Decks by Jason Dixon
See All by Jason Dixon
Graphite 1.0-ish
obfuscurity
0
350
Monitorama PDX 2015 - Closing Plenary
obfuscurity
1
450
The State of Open-Source Monitoring
obfuscurity
145
49k
Trending with Purpose
obfuscurity
11
1.3k
Other Decks in Technology
See All in Technology
衛星画像超解像化によって実現する2D, 3D空間情報の即時生成と“AI as a Service”/ Real-time generation spatial data enabled_by satellite image super-resolution
lehupa
0
160
[Codex Meetup Japan #1] Codex-Powered Mobile Apps Development
korodroid
2
720
All About Sansan – for New Global Engineers
sansan33
PRO
1
1.2k
コンテキストエンジニアリング入門〜AI Coding Agent作りで学ぶ文脈設計〜
kworkdev
PRO
1
980
スタートアップにおけるこれからの「データ整備」
shomaekawa
2
470
研究開発部メンバーの働き⽅ / Sansan R&D Profile
sansan33
PRO
3
20k
GoでもGUIアプリを作りたい!
kworkdev
PRO
0
140
「れきちず」のこれまでとこれから - 誰にでもわかりやすい歴史地図を目指して / FOSS4G 2025 Japan
hjmkth
1
310
綺麗なデータマートをつくろう_データ整備を前向きに考える会 / Let's create clean data mart
brainpadpr
3
510
Bill One 開発エンジニア 紹介資料
sansan33
PRO
4
14k
Node.js 2025: What's new and what's next
ruyadorno
0
260
セキュアな認可付きリモートMCPサーバーをAWSマネージドサービスでつくろう! / Let's build an OAuth protected remote MCP server based on AWS managed services
kaminashi
3
320
Featured
See All Featured
Code Reviewing Like a Champion
maltzj
526
40k
Why You Should Never Use an ORM
jnunemaker
PRO
59
9.6k
4 Signs Your Business is Dying
shpigford
185
22k
[RailsConf 2023 Opening Keynote] The Magic of Rails
eileencodes
31
9.7k
Dealing with People You Can't Stand - Big Design 2015
cassininazir
367
27k
What’s in a name? Adding method to the madness
productmarketing
PRO
24
3.7k
How to Create Impact in a Changing Tech Landscape [PerfNow 2023]
tammyeverts
55
3k
A better future with KSS
kneath
239
18k
RailsConf 2023
tenderlove
30
1.2k
"I'm Feeling Lucky" - Building Great Search Experiences for Today's Users (#IAC19)
danielanewman
230
22k
Code Review Best Practice
trishagee
72
19k
Bash Introduction
62gerente
615
210k
Transcript
Stupid Graphite Tips DevOpsDays Portland 2013
What is Graphite? carbon whisper metrics
require 'socket' require ‘time’ conn = TCPSocket.new 'graphite.example.com', 2003 conn.puts
"foo #{value} #{Time.now.to_i}\n" conn.close metric key value timestamp $ echo "test.foo.bar 1 `date +%s`" | nc graphite.example.com 2003 metric key value timestamp Sending metrics to Carbon
Organizing metrics • Prefix with your collector/agent/app source • Keep
test/development stuff in check • Automatically purge test & release metrics • Avoid the urge to include your username
and Tracking deployments drawAsInfinite(color(custom.instances.*.killed,"white")) summarize(sumSeries(group(custom.instances.*.killed)), "1d")
mostDeviant(5, runtime.*.load.1m) Finding the Outliers p.s. Don’t forget about sortByMaxima,
sortByMinima and limit !
Adjusting Rate scale(nonNegativeDerivative(snmp.IF-MIB::ifInOctets.7),0.133333333) doesn’t scale! ... because as soon as
you hit a new resolution, your math is wrong. scaleToSeconds(nonNegativeDerivative(snmp.IF-MIB::ifInOctets.7),1)
Time Shifting sumSeries(mail.hosts.mta-*.messages.in) timeShift(sumSeries(mail.hosts.mta-*.messages.in),"6mon")
Counting metrics sumSeries(offset(scale(collectd.*.load.load.longterm,0),1))
Hybrid Graphs mail.hosts.mta-*.messages.in alpha(stacked(sumSeries(mail.hosts.mta-*.messages.in)),0.6)
Renaming Keys on-the-fly Ever wanted to redefine your metric key
in the middle of a query because the wildcard wasn’t quite in the right spot? aliasSub(hosts.web-01-pdx-prod-example- com.metric,”-(\w+)-prod”, ”.\1.prod”)
Graph Bookmarklet javascript:url=prompt("Enter Url");if (url) {content.Composer.loadMyGraph("temp", decodeURIComponent(url));};
Listing metrics $ curl -s http://graphite/metrics/index.json | json_pp | tail
"graphite-1.processes.ps_state-blocked.value", "graphite-1.processes.ps_state-paging.value", "graphite-1.processes.ps_state-running.value", "graphite-1.processes.ps_state-sleeping.value", "graphite-1.processes.ps_state-stopped.value", "graphite-1.processes.ps_state-zombies.value", "graphite-1.users.users.users", "test.bar", "test.foo" ]
Grokking Whisper $ whisper-info.py foo.wsp maxRetention: 31536000 xFilesFactor: 0.0 aggregationMethod:
average fileSize: 1262932 Archive 0 retention: 86400 secondsPerPoint: 1 points: 86400 size: 1036800 offset: 52 $ whisper-fetch.py foo.wsp | tail 1383585660! None 1383585720! 29.529000 1383585780! 87.016000 1383585840! 33.416000 1383585900! 29.012000 1383585960! 31.164000 1383586020! None 1383586080! 29.702000 1383586140! 29.299000 1383586200! None
Repairing Data $ whisper-fetch.py foo.wsp | grep -v None 1376066700
1.000000 1376066760 226.000000 1376066820 215.000000 1376066880 266.000000 1376066940 237.000000 1376072760 5.000000 1376074560 1.000000 1376075280 2.000000 $ for i in 1376066760 1376066820 1376066880 1376066940; \ do whisper-update.py foo.wsp ${i}:0"; done
Know your Carbon sumSeries(group(carbon.agents.*.updateOperations)) sumSeries(group(carbon.agents.*.metricsReceived)) sumSeries(group(carbon.agents.*.committedPoints)) secondYAxis(sumSeries(group(carbon.agents.*.pointsPerUpdate))) secondYAxis(averageSeries(group(carbon.agents.*.cpuUsage))) secondYAxis(sumSeries(group(carbon.agents.*.creates))) p.s.
Check out @scott_sanders’ collectd-tail examples https://gist.github.com/jssjr/35b592b4852625449c27
Tagged Events $ curl -X POST http://graphite/events/ \ -d '{"what":
"Something Interesting", "tags" : "wtf", "data" : "foo bar"}' events(“wtf”) events(“wtf”,”zomg”) events(“*”)
Dat Spark $ brew install spark $ curl -H 'Accept:
application/json' -s "http://graphite/ render/?target=foo&format=json&from=-30min" | json_pp | grep ',' | grep -v '\]' | grep -v target | spark ▂▂▁▂▂▂▂▂▁▃▁▂▂▂▄▃▂▂█▇▃█▂▃▂▃▁▂▄▂
Scaling dat Carbon Open Spaces, doge. omg multicore hip fanout
replication me much io vintage metrics
Thank You
