From Oracle to MongoDB

Talk at Barcelona NoSQL Matters 2012 conference

The talk will cover the use case of the Personalisation Server, a master customers profile storage for the companies of the Telefonica Group (Telefonica, O2…). It provides real-time (ReST API) and batch interfaces to update, retrieve and share customers profile. Initially the PS used Oracle, but due to scalability and cost issues we implemented a new version with MongoDB.
In the talk we will see the problems that made us move to MongoDB and all the benefits that we obtained (with real performance figures, ofc).
Right now the Oracle version is being used at UK and Ireland (aprox.
30M user profiles stored) and the NoSQL version is being deployed at Mexico (18M customers) and other Latam countries.

Transcript

1. Pablo Enfedaque pev@tid.es 06.10.2012 A real use case at Telefónica PDI From Oracle to MongoDB
2. 01 02 03 04 Introduction • Telefónica PDI. Who? • Personalisation Server. Why? What? The SQL version • Data model and architecture • Integrations, problems and improvements The NoSQL version • Data model and architecture • Performance boost • The bad Conclusions • Conclusions • Personal thoughts Content
3. Título del capítulo Máximo 3 líneas 01 Introduction
4. 4 Telefónica PDI Telefónica PDI. Who? • Telefónica §  Fifth largest telecommunications company in the world §  Operations in Europe (7 countries), the United States and Latin America (15 countries) • Telefónica Digital §  Web and mobile digital contents and services division • Product Development and Innovation unit §  Formerly Telefónica R&D §  Product & service development, platforms development, research, technology strategy, user experience and deployment & operation §  Around 70 different on going projects at all time. 01
5. 5 Telefónica PDI Personalisation Server. What? • User profiling system • Machine learning • Recommendations • Customer’s profile storage 01
6. 6 Telefónica PDI Opt-in and profile module. Why? • Users data, profile and permissions, was scattered across different storages 01 • Gender • Film and music preferences IPTV service • Permission to contact by SMS? • Gender Mobile service • Address • Music preferences Music tickets service • Address • Permission to contact by SMS? Location based offers So you want to know my address… AGAIN?!
7. 7 Telefónica PDI Opt-in and profile module. Why? • Users data, profile and permissions, was scattered across different storages 01 • Gender • Film and music preferences IPTV service • Permission to contact by SMS? • Gender Mobile service • Address • Music preferences Music tickets service • Address • Permission to contact by SMS? Location based offers
8. 8 Telefónica PDI Opt-in and profile module. Why? • Provide a module to become master customer’s data storage 01 •  Gender •  Film and music preferences •  Permission to contact by SMS? •  Address IPTV service Mobile service Music tickets service Location based offers
9. 9 Telefónica PDI Opt-in and profile module. What? • Features: §  Flexible profile definition, classified in services §  Profile sharing options between different services §  Real time API §  Supplementary offline batch interface §  Authorization system §  High availability §  Inexpensive solution & hardware 01
10. Título del capítulo Máximo 3 líneas 02 The SQL solution
11. 11 Telefónica PDI Data model • Services defined a set of attributes (their profile), with default value and data type • Users were registered in services • Users defined values for some of the services attributes • Each attribute value had an update date to avoid overwriting newer changes through batch loads Services, users and their profile 02
12. 12 Telefónica PDI Data model • Services could access attributes declared inside other services • There were sharing rights for read or read and write • The user had to be registered in both services Services profile sharing matrix 02
13. 13 Telefónica PDI Data model • Everything that could be accessed in the PS was a resource • Roles defined access rights (read or read and write) of resources • Auth users had roles • Roles could include other roles Authorization system 02
14. 14 Telefónica PDI Data model • Multiple IDS: §  Users profile could be accessed with different equivalent IDs depending on the service §  Each user ID was defined by an ID type (phone number, email, portal ID, hash…) and the ID value Bonus features! 02
15. 15 Telefónica PDI High level logical architecture §  Everything running on Red Hat EL 5.4 64 bits 02
16. 16 Telefónica PDI High level logical architecture §  Everything running on Red Hat EL 5.4 64 bits 02
17. 17 Telefónica PDI Integration • PS replaces all customers profile and permissions DBs • All systems access this data through PS real time API • In special cases, some PS-consumers could use the batch interface. • The same way new services could be added quite easily Planned integration 02
18. 18 Telefónica PDI Integration • Budget restrictions: adapt all services to use the API was too expensive • Keep independent systems DBs and synchronize PS through batch • Use DBs built-in massive extraction feature to generate daily batch files • However… in most cases those DBs were not able to generate Delta (only changes) extractions §  Provide full daily snapshots! Problems arise 02
19. 19 Telefónica PDI First version performance • 1.8M customers, 180 profile attributes, 6 services • Sizes §  Tables + indexes size: 65Gb §  30% of the size were indexes • Batch §  Full DWH customer’s profile import: > 24 hours §  Delta extractions: 4 - 6 hours §  Loads and extractions performance proportional to data size • API: §  Response time with average traffic: 110ms 02 Ireland
20. Título del capítulo Máximo 3 líneas 03 The SQL solution Second version
21. 21 Telefónica PDI Second version • New approach: batch processes access directly DB 03 High level logical architecture
22. 22 Telefónica PDI Second version • Batch processes had to §  Validate authentication and authorization §  Verify user, service and attribute existence §  Check equivalent IDs §  Validate sharing matrix rights §  Validate values data type §  Check the update date of the existing values 03 Batch processes
23. 23 Telefónica PDI Second version 03 DB Batch processing Our DBAs
24. 24 Telefónica PDI Second version • Preprocess incoming batch file in BE servers §  Validate format, services and attributes existence and values data types §  Generate intermediate file with structure like target DB table • Load intermediate file (Oracle’s SQL*Loader) to a temporal table • Switch DB to “deferred writing”, storing all incoming modifications • Merge temporal table and final table, checking values update date • Replace old users attributes values table with merge result • Apply deferred writing operations 03 New DB-based batch loading process
25. 25 Telefónica PDI Second version • Generate a temporal DB table with format similar to final batch file. Two loops over users attributes values table required: §  Select format of the table; number and order of columns / attributes §  Fill the new table • Loop the whole temporal table for final formatting (empty fields…) • From batch side loop across the whole table (SELECT * FROM …) • Write each retrieved row as a line in the resulting file 03 New batch extraction process
26. 26 Telefónica PDI Second version performance • Batch time window: 3:30 hours §  Full DWH load §  Two Delta loads §  Three Delta extractions • API: §  Ireland requirement: < 500ms 03 Ireland performance requirements
27. 27 Telefónica PDI Second version performance • 1.8M customers, 180 profile attributes, 6 services • Sizes §  Tables + indexes size: 65Gb §  30% of the size were indexes §  Temporal tables size increases almost exponentially: 15Gb and above §  Intermediate file size: from 700Mb to 7Gb • Batch §  Full DWH customer’s profile import: 2:30 hours §  Delta extractions: 1:00 hour §  Loads performance worsened quickly (almost exp): 6:00 hours §  Extractions performance proportional to data size §  Concurrent batch processes may halt the DB • API: §  Response time with average traffic: 80ms §  Response time while loading was unpredictable: >300ms 03 Ireland
28. Título del capítulo Máximo 3 líneas 04 The SQL solution Third version
29. 29 Telefónica PDI Third version 04 Speed up DB Batch processes Our DBAs (again)
30. 30 Telefónica PDI Third version • Minor preprocessing of incoming batch file in BE servers §  Just validate format §  No intermediate file needed! • Load validated file (Oracle’s SQL*Loader) to a temporal table • Loop the temporal table merging the values into final table, checking values update date and data types §  Use several concurrent writing jobs • Store results on real table, no need to replace! • No “deferred writing”! 04 New (second) DB-based batch loading process
31. 31 Telefónica PDI Third version • Optimized loops to generate temporal output table. §  Use several concurrent writing jobs §  We achieved a speed-up of between 1.5 and 2 • Loop the whole temporal table for final formatting (empty fields…) • Download and write lines directly inside Oracle’s sqlplus • No SELECT * FROM … query from Batch side! 04 Enhancements to extraction process
32. 32 Telefónica PDI Our DBAs F**K YEAH Third version performance • 1.8M customers, 180 profile attributes, 6 services • Sizes §  Tables + indexes size: 65Gb §  30% of the size were indexes §  Temporal tables: 15Gb • Batch §  Full DWH customer’s profile import: 1:10 hours (vs. 2:30 hours) §  Three Delta extractions: 2:15 hours (vs. 3:00 hours) §  Loads and extractions performance proportional to data size §  Concurrent batch processes not so harmful • API: §  Response time with average traffic: 110ms §  Response time while loading: 400ms 04 Ireland
33. 33 Telefónica PDI Our DBAs F**K YEAH Third version performance • 25M customers, 150 profile attributes, 15 services • Sizes §  Tables + indexes size: 700Gb §  40% of the size were indexes • Batch §  Two Delta imports: < 2:00 hours §  Two Delta extractions: < 2:00 hours §  Loads and extractions performance proportional to data size • API: §  Response time with average traffic: 90ms 04 United Kingdom
34. 34 Telefónica PDI Our DBAs F**K YEAH Third version performance 04 Ireland 3rd version 2nd version DB size 65Gb + 15Gb (temp) 65Gb + > 15Gb Full DWH load 1:10 hours 2:30 hours Three Delta exports 2:15 hours 3:00 hours Batch stability Stable, linear Unstable, exponential API response time 110ms 110ms API while loading 400ms Unpredictable United Kingdom 3rd version DB size 700Gb Two Delta loads < 2:00 hours Three Delta exports < 2:00 hours API response time 90ms
35. 35 Telefónica PDI Third version performance • 20 database tables • API: several queries with up to 35 joins and even some unions • Authorization: 5 joins to validate auth users access • Batch: §  Load: 1700 lines of PL/SQL §  Extraction: 1200 of PL/SQL 04 DB stats
36. 36 Telefónica PDI Mission completed? 04
37. 37 Telefónica PDI Third version performance • 20M customers, 200 profile attributes, 10 services • Mexico time window: 4:00 hours §  Full DWH load! §  Additional Delta feeds loads §  At least two Delta extractions 04 Mexico Our DBAs
38. Título del capítulo Máximo 3 líneas 05 The NoSQL solution
39. 39 Telefónica PDI MongoDB Data Model Services and their profile + sharing matrix 05 { _id : 7, service_name : "root", id_type : 1, default_values: false, owned_attribs : [ { attrib_id : 70005, attrib_nane : “marketing.consent", attrib_data_type : 1, attrib_def_value : "no", attrib_status : 1 }, ... ], shared_attribs : [ {attrib_id : 20144, sharing_mode : 0}, ... ] } attrib_id = service_id * 10000 + num attribs + 1 attrib_id = service_id * 10000 + num attribs + 1
40. 40 Telefónica PDI MongoDB Data Model Users and their profile + multiple IDs 05 { _id : "011234" services_list : [ { service_id : 1, reg_date : {"$date" : 1318040693000} }, ... ], user_values : [ { attrib_id : 10140, attrib_value : "Open", update_date : {"$date" : 1317110161000} }, ... ] } Equivalent ID document: { _id : “05abcd" ue : "011234" } _id = “id type” + “user ID” attrib_id = service_id * 10000 + num attribs + 1 _id = “id type” + “user ID”
41. 41 Telefónica PDI MongoDB Data Model Authorization system 05 AUTH USERS COLLECTION: { _id: "admin" auth_pswd: ”XXX", auth_roles: ['PS_ADMIN_ROLE’, …], auth_uris: [ {uri_path: "/**", method: 'R'}, {uri_path: "/stats/**", method: 'RW'}, {uri_path: "/kpis/**", method: ’IMPORT'}, ... ] } RESOURCES COLLECTION: { _id: "admin.**", role_uri: "/**" } ROLES COLLECTION: { _id: 'PS_ADMIN_ROLE', roles_resources: [ { resource_id: "admin.**”, method: 'R' }, { resource_id: "stats.**”, method: 'IMPORT' }, ... ] } Replicate uris (from resources) and methods (from roles)
42. 42 Telefónica PDI MongoDB Data Model • Only 5 collections • API: typically 2 accesses (services and users collections) • Authorization: access only 1 collection to grant access • Batch: all processing done outside DB 05 DB stats
43. 43 Telefónica PDI NoSQL version §  Everything running on Red Hat EL 6.2 64 bits 05 High level logical architecture
44. 44 Telefónica PDI NoSQL version performance • 1.8M customers, 180 profile attributes, 6 services • Sizes §  Collections + indexes size: 20Gb (vs. 65Gb) §  < 5% of the size are indexes (vs. 30%) • Batch §  Full DWH customer’s profile import: 0:12 hours (vs. 1:10 hours) §  Three Delta extractions: 0:40 hours (vs. 2:15 hours) §  Loads and extractions performance proportional to data size §  Concurrent batch processes without performance affection • API: §  Response time with average traffic: < 10ms (vs. 110ms) §  Response time while loading: the same §  High load (600 TPS) response time while loading: 300ms 05 Ireland (at PDI lab)
45. 45 Telefónica PDI NoSQL version performance • 25M customers, 150 profile attributes, 15 services • Sizes §  Collections + indexes size: 210Gb (vs. 700Gb) §  < 5% of the size were indexes • Batch §  Two Delta imports: < 0:40 hours (vs. 2:00 hours) §  Loads and extractions performance proportional to data size 05 United Kingdom (at PDI lab)
46. 46 Telefónica PDI NoSQL version performance • 20M customers, 200 profile attributes, 15 services • Sizes §  Collections + indexes size: 320Gb §  Indexes size: 1.2Gb • Batch §  Initial Full import (20M, 40 attributes): 2:00 hours §  Small Full import (20M, 6 attributes): 0:40 hours • API: §  Response time with average traffic: < 10ms (vs. 90ms) §  Response time while loading: the same §  High load (500 TPS) response time while loading: 270ms 05 Mexico
47. 47 Telefónica PDI Our DBAs NoSQL version performance 04 Ireland NoSQL version SQL version DB size 20Gb 80Gb Full DWH load 0:12 hours 1:10 hours Three Delta exports 0:40 hours 2:15 hours API while loading < 10ms 400ms API 600TPS + loading 300ms Timeout / failure United Kingdom NoSQL version SQL version DB size 210Gb 700Gb Two Delta loads < 0:40hours < 2:00 hours Mexico NoSQL version DB size 320Gb Initial Full load (40 attr) 2:00 hours Daily Full load (6 attr) 0:40 hours API while loading < 10ms API 500TPS + loading 270ms
48. 48 Telefónica PDI Mission completed? 05
49. 49 Telefónica PDI The bad • Batch load process was too fast §  To keep secondary nodes synched we needed oplog of 16 or 24Gb §  We had to disable journaling for the first migrations • Labels of documents fields take up disc space §  Reduced them to just 2 chars: “attribute_id” -> “ai” • Respect the unwritten law of at least 70% of size in RAM • Take care with compound indexes, order matters §  You can save one index… or you can have problems §  Put most important key (never nullable) the first one • DBAs whining and complaining about NoSQL §  “If we had enough RAM for all data, Oracle would outperform MongoDB” 05
50. 50 Telefónica PDI The ugly • Second migration once the PS is already running §  Full import adding 30 new attributes values: 10:00 hours §  Full import adding 150 new attributes values: 40:00 hours • Increase considerably documents size (i.e. adding lots of new values to the users) makes MongoDB rearrange the documents, performing around 5 times slower §  That’s a problem when you are updating 10k documents per second • Solutions? §  Avoid this situation at all cost. Run away! §  Normalize users values; move to a new individual collection §  Prealloc the size with a faux field •  You could waste space! §  Load in new collection, merge and swap, like we did in Oracle 05
51. Título del capítulo Máximo 3 líneas 06 Título del capítulo
 Máximo 3 líneas Conclusions
52. 52 Telefónica PDI Conclusions & personal thoughts • Awesome performance boost §  But not all use cases fit in a MongoDB / NoSQL solution! • New technology, different limitations • Fear of the unknown §  SSDs performance? §  Long term performance and stability? • Python + MongoDB + pymongo = fast development §  I mean, really fast • MongoDB Monitoring Service (MMS) • 10gen people were very helpful 06
53. 53 Telefónica PDI Questions? 06
55. 55 Telefónica PDI SQL Physical architecture §  Scale horizontally adding more BE or DB servers or disks in the SAN §  Virtualized or physical servers depending on the deployment 0X
56. 56 Telefónica PDI MongoDB Physical architecture §  MongoDB arbiters running on BE servers §  Scale horizontally adding more BE servers or disks in the SAN §  Sharding may already be configured to scale adding more replica sets 0X
