Transcript
Introducing DisplayCutout Shibuya.apk #24
About Me • Matthew Vern / Panini • Twitter: @callipan
Github: panpanini • Mercari, Inc • Android Engineer (US) • Kotlin可愛い
Display Cutout support For devices like Essential Phone, or iPhone
X which have a cutout in the display (for camera, etc).
Display Cutout emulator Access from Developer options
Display Cutout emulator Mode: None - standard
Display Cutout emulator Mode: Narrow display cutout
Display Cutout emulator Mode: Tall display cutout
Display Cutout emulator Mode: Wide display cutout
Display Cutout emulator Cutout only covers status bar, so there
should be little affect to apps not using Fullscreen Activity
None
Important Point Status bar height has changed!
Important Point Clock has moved!
Important Point Clock has moved! Notifications only show on the
left
Important Point Clock has moved! Notifications only show on the
left Notifications will be hidden behind ..
LAYOUT_IN_DISPLAY_CUTOUT_MODE There are three layout modes for handling the cutout
in a fullscreen Activity: LAYOUT_IN_DISPLAY_CUTOUT_MODE_DEFAULT LAYOUT_IN_DISPLAY_CUTOUT_MODE_ALWAYS LAYOUT_IN_DISPLAY_CUTOUT_MODE_NEVER
LAYOUT_IN_DISPLAY_CUTOUT_MODE DEFAULT NEVER ALWAYS
WindowInsetListener // API Level 20+ view.setOnApplyWindowInsetsListener { view, windowInsets ->
val cutout: DisplayCutout? = windowInsets.displayCutout // Adjust view position based on cutout windowInsets.consumeDisplayCutout() }
WindowInsetListener // API Level 20+ view.setOnApplyWindowInsetsListener { view, windowInsets ->
val cutout: DisplayCutout? = windowInsets.displayCutout cutout?.bounds?.bounds?.let { view.translationX = it.right.toFloat() view.translationY = it.exactCenterY() - (view.measuredHeight() / 2) } windowInsets.consumeDisplayCutout() }
WindowInsetListener
Summary • Most apps don’t need to worry about DisplayCutout
• Status bar height can change • WindowInsetListener to get cutout position • LAYOUT_IN_DISPLAY_CUTOUT_MODE for fullscreen Activities • Clock & Notifications only shown on the left-hand side of status bar
Introducing DisplayCutout Shibuya.apk #24
